GENERAL SPECIFICATIONS
| Item | Specification |
|---|---|
| Lubricants and Sealants | |
| SAE 5W-20 Premium Synthetic Blend Motor Oil XO-5W20-QSP | WSS-M2C153-H |
| Silicone Gasket and Sealant F7AZ-19554-EA | WSE-M4G323-A4 |
| Pipe Sealant with Teflon® D8AZ-19954-A | WSK-M2G350-A2 |
| Gasket Maker F8AZ-19B508-AB | WSK-M2G348-A5 |
| Weatherstrip Adhesive E8AZ-19552-A | ESB-M2G14-A |
| Engine | |
| Displacement | 3.0L |
| Number of cylinders | 6 |
| Bore | 89.0 mm (3.50 in) |
| Stroke | 80.00 mm (3.14 in) |
| Firing order | 1--4-2--5-3--6 |
| Oil pressure (Hot 2,500 rpm) | 276--414 kPa (40--60 psi) |
| Oil capacity | 4.25 L (4.5 qts) with filter change |
| Cylinder Head and Valve Train | |
| Combustion chamber volume | 47.1--50.1 cm (2.874 in) |
| Valve guide bore diameter | 7.042--7.017 mm (0.2772--0.2763 in) |
| Valve stem diameter -- intake (standard) | 6.971--6.991 mm (0.2744--0.2752 in) |
| Valve stem diameter - exhaust (standard) | 6.959--6.979 mm (0.2740--0.2748 in) |
| Valve stem diameter - oversize (intake) | 7.351--7.371 mm (0.289--0.290 in) |
| Valve stem diameter - oversize (exhaust) | 7.339--7.359 mm (0.289--0.290 in) |
| Valve stem diameter - oversize (intake) | 7.731--7.751 mm (0.304--0.305 in) |
| Valve stem diameter - oversize (exhaust) | 7.719--7.739 mm (0.304--0.305 in) |
| Valve stem-to-guide clearance - intake | 0.026--0.071 mm (0.001--0.0028 in) |
| Valve stem-to-guide clearance - exhaust | 0.038--0.083 mm (0.0015--0.0033 in) |
| Valve head diameter - intake | 40.0 mm (1.57 in) |
| Valve head diameter - exhaust | 33.0 mm (1.30 in) |
| Valve face runout | 0.05 mm (0.002 in) |
| Valve face angle | 45 degrees |
| Valve seat width - intake | 1.5--2.0 mm (0.06--0.08 in) |
| Valve seat width - exhaust | 2.0--2.5 mm (0.08--0.10 in) |
| Valve seat runout (TIR) | 0.078--0.098 mm (0.003--0.004 in) |
| Valve seat angle | 45 degrees |
| Valve spring free length (approx.) | 46.4 mm (1.85 in) |
| Valve spring compression pressure - valve open to maximum lift | 857.0 - 967.0 N (193 - 217 lb) 29.74 mm (1.17 in) |
| Valve spring compression pressure - valve closed | 285 - 323 N (64 - 72 lb) 40.52 mm (1.60 in) |
| Valve spring installed height | 41.98--44.17 mm (1.650--1.736 in) |
| Valve spring installed height - service limit | 10% force loss @ specified height |
| Rocker arm ratio | 1:61 |
| Hydraulic Lash Adjuster | |
| Diameter | 22.206 mm (0.874 in) |
| Clearance-to-bore | 0.018--0.069 mm (0.0007--0.0027 in) |
| Service limit | 0.127 mm (0.005 in) |
| Hydraulic leakdown rate | 20--200 seconds to leakdown 3.18 mm (0.125 in) with 225 N (50 lbs) load and tappet filled with leak-down fluid |
| Collapsed lash adjuster gap | 2.23--4.77 mm (0.088--0.189 in) |
| Camshaft | |
| Theoretical valve lift @ 0 lash - intake | 10.26 mm (0.404 in) |
| Theoretical valve lift @ 0 lash - exhaust | 10.77 mm (0.424 in) |
| Lobe lift - intake | 6.38 mm (0.25 in) |
| Lobe lift - exhaust | 6.72 mm (0.26 in) |
| Allowable lobe lift loss | 0.127 mm (0.005 in) |
| Journal diameter | 50.987--51.013 mm (2.0074 - 2.0084 in) |
| Camshaft journal bore inside diameter - No. 1 and No. 4 | 54.668--54.713 mm (2.1531--2.1541 in) |
| Camshaft journal bore inside diameter - No. 2 and No. 3 | 54.188--54.213 mm (2.1334--2.1344 in) |
| Camshaft journal-to-bearing clearance | 0.025--0.076 mm (0.001--0.003 in) |
| Runout | 0.05 mm (0.002 in) Runout of No. 2 or No. 3 relative to No. 1 and No. 4 |
| End play | 0.003 mm (0.007 in) |
| Cylinder Block | |
| Cylinder bore diameter | 89.00 mm (3.504 in) |
| Cylinder bore maximum taper | 0.050 mm (0.002 in) |
| Cylinder bore maximum out-of-round | 0.025 mm (0.001 in) |
| Cylinder bore maximum out-of-round - service limit | 0.050 mm (0.002 in) |
| Main bearing bore inside diameter | 68.905 mm (2.713 in) 68.885 mm (2.712 in) |
| Head gasket surface flatness | 0.08 mm (0.003 in) 152.0 mm (6.00 in) |
| Crankshaft | |
| Main bearing journal diameter | 63.983--64.003 mm (2.5190--2.5198 in) |
| Main bearing journal maximum taper | 0.06 mm (0.0006 in) total 0.013 mm (0.0003 in) per 25 mm (1 in) |
| Main bearing journal maximum out-of-round | 0.0003 in |
| Connecting rod journal diameter | 53.983--54.003 mm (2.1253--2.1261 in) |
| Connecting rod journal maximum taper | 0.008 mm per 25 mm (0.0003 in per in) |
| Connecting rod journal maximum out-of-round | 0.006 mm (0.0003 in) max. 0.015 mm (0.0006 in) total |
| Crankshaft maximum end play | 0.10--0.20 mm (0.004--0.008 in) |
| Thrust bearing journal length | 25.775--25.825 mm (1.0148--1.067 in) |
| Piston and Connecting Rod | |
| Piston diameter - coded red | 88.962--88.978 mm (3.5024--3.5031 in) |
| Piston diameter - coded blue | 88.988--89.004 mm (3.5035--3.5041 in) |
| Piston diameter - coded yellow | 89.014--89.030 mm (3.5045--3.5051 in) |
| Piston-to-cylinder bore clearance | 0.030--0.056 mm (0.0012--0.0022 in) |
| Piston-to-cylinder bore clearance - service limit | 0.081 mm (0.031 in) max. |
| Piston ring end gap - compression (top and bottom, in gauge) | 0.25--0.50 mm (0.01--0.02 in) |
| Piston ring end gap - oil ring (steel rail, in gauge) | 0.25--1.25 mm (0.010--0.049 in) |
| Piston ring groove width - compression (top and bottom) | 1.530--1.555 mm (0.0602--0.0612 in) |
| Piston ring groove width - oil | 4.030--4.055 mm (0.1587--0.1596 in) |
| Piston ring width - compression (top and bottom) | 1.460--1.490 mm (0.0575--0.0587 in) |
| Piston ring width - oil ring | Side seal-snug fit |
| Piston ring width - service limit | Side clearance 0.015 mm (0.0006 in) max. |
| Piston pin bore diameter | Service piston grade required |
| Piston pin bore diameter - red | 89.009--89.035 mm (3.5043--3.5053 in) |
| Piston pin bore diameter - blue | 89.035--89.060 mm (3.5053--3.5063 in) |
| Piston pin bore diameter - yellow | 89.060--89.086 mm (3.5063--3.5073 in) |
| Piston pin diameter | 23.162--23.175 mm (0.9119--0.9124 in) |
| Piston pin length | 57.12--57.88 mm (2.248--2.278 in) |
| Connecting rod pin bore diameter | 23.105--23.145 mm (0.9096--0.9112 in) |
| Connecting rod length (center-to-center) | 140.46--140.54 mm (5.530--5.533 in) |
| Connecting rod maximum allowed bend | 0.04 per 25 mm (0.0016 per in) |
| Connecting rod maximum allowed twist | 0.075 per 25 mm (0.003 per in) |
| Connecting rod bearing bore diameter | 57.15--57.17 mm (2.250--2.251 in) |
| Connecting rod bearing-to-crankshaft clearance - desired | 0.025--0.035 mm (0.001--0.0014 in) |
| Connecting rod bearing-to-crankshaft clearance - allowable | 0.020--0.066 mm (0.00086--0.0027 in) |
| Connecting rod side clearance (assembled to crank) - standard | 0.15--0.35 mm (0.006--0.014 in) |
| Connecting rod side clearance (assembled to crank) - service limit | 0.36 mm (0.014 in) max. |
GENERAL SPECIFICATIONS
TORQUE SPECIFICATIONS
| Description | Nm | Lb-ft | Lb-in |
|---|---|---|---|
| A/C compressor-to-A/C compressor bracket bolts | 25 | 18 | |
| A/C compressor bracket-to-cylinder block bolts | 47 | 35 | |
| A/C compressor bracket stabilizer bracket bolt | 25 | 18 | |
| A/C compressor bracket stabilizer bracket nut | 25 | 18 | |
| A/C manifold and tube nut | 10 | 89 | |
| Accelerator cable bracket-to-throttle body bolts | 17 | 13 | |
| Accessory drive belt tensioner/idler assembly cover bolts | 48 | 35 | |
| Camshaft position (CMP) sensor-to-camshaft synchronizer bolts | 2 | 18 | |
| Camshaft sprocket-to-camshaft bolt | 63 | 46 | |
| Camshaft synchronizer clamp bolt | 24 | 18 | |
| Camshaft thrust plate-to-cylinder block bolt | 10 | 89 | |
| Coolant pump bolts (1) | |||
| Coolant pump pulley-to-coolant pump bolts | 25 | 18 | |
| Crankshaft damper-to-crankshaft bolt | 145 | 107 | |
| Crankshaft main bearing cap stud bolt (1) | |||
| Crankshaft pulley-to-crankshaft damper bolts | 48 | 35 | |
| Cylinder head-to-cylinder block bolts (1) | |||
| Exhaust gas recirculation (EGR) tube-to-RH exhaust manifold nut | 40 | 30 | |
| EGR tube-to-EGR valve nut | 55 | 41 | |
| EGR valve-to-upper intake manifold bolts | 25 | 18 | |
| EGR vacuum regulator solenoid-to-upper intake manifold nuts | 6 | 53 | |
| Engine control sensor wire harness 42-pin connector bolt | 10 | 89 | |
| Engine coolant temperature (ECT) sensor | 20 | 15 | |
| Engine coolant temperature sender | 20 | 15 | |
| Engine front cover-to-cylinder block bolts | 25 | 18 | |
| Engine ground strap nut | 25 | 18 | |
| Engine oil cooler adapter mounting bolt | 54 | 40 | |
| Engine rear insulator-to-front subframe bolts | 88 | 65 | |
| Engine rear insulator-to-transaxle bracket nut | 98 | 72 | |
| Engine rear plate-to-transaxle bolt. | 12 | 9 | |
| Engine roll restrictor bolts | 48 | 35 | |
| Engine roll restrictor brace nuts | 48 | 35 | |
| Engine roll restrictor bracket-to-engine front cover nut | 25 | 18 | |
| Engine roll restrictor-to-generator bolt | 25 | 18 | |
| Exhaust manifold heat shield-to-RH exhaust manifold bolts | 10 | 89 | |
| Flywheel-to-crankshaft bolts | 80 | 59 | |
| Front subframe-to-body insulator bolts | 103 | 76 | |
| Fuel injection supply manifold-to-lower intake manifold bolts | 10 | 89 | |
| Generator output nut | 8 | 71 | |
| Half shaft-to- steering knuckle nuts | 257 | 190 | |
| Ignition coil-to-valve cover | 6 | 53 | |
| LH engine insulator-to-A/C compressor bracket bolts | 62 | 46 | |
| LH engine insulator-to-front subframe nut | 90 | 66 | |
| LH exhaust manifold-to-LH cylinder head bolts (1) | |||
| LH exhaust manifold-to-Y-pipe flange nuts | 40 | 30 | |
| Lower control arm-to-steering knuckle nuts | 80 | 59 | |
| Lower intake manifold-to-cylinder head bolts (1) | |||
| Oil filter (1) | |||
| Oil filter mounting boss | 34 | 25 | |
| Oil level indicator tube-to-exhaust manifold stud bolt nut | 18 | 13 | |
| Oil pan-to-cylinder block bolts (1) | |||
| Oil pan drain plug | 13 | 10 | |
| Oil pressure switch | 19 | 14 | |
| Oil pump-to-crankshaft main bearing cap bolt | 48 | 35 | |
| Piston rod cap-to-piston connecting rod nuts | 35 | 26 | |
| Power steering pressure (PSP) line-to-exhaust manifold stud bolt nut | 27 | 20 | |
| PSP line-to-power steering pump nut | 48 | 35 | |
| PSP line-to-transaxle nut | 27 | 20 | |
| Power steering pump bracket-to-cylinder head bolt | 48 | 35 | |
| Power steering pump bracket-to cylinder head nuts | 48 | 35 | |
| Power steering pump bracket-to-generator stud bolt | 48 | 35 | |
| Powertrain control module (PCM) connector bolt | 4 | 35 | |
| RH catalytic converter heat shield-to-cylinder head bolt | 20 | 15 | |
| RH catalytic converter heat shield nuts | 20 | 15 | |
| RH cylinder head-to-cylinder block bolts (1) | |||
| RH engine insulator-to-front subframe nut | 90 | 66 | |
| RH engine insulator bracket-to-transaxle bolts | 60 | 44 | |
| RH engine insulator through bolt | 120 | 89 | |
| RH exhaust manifold-to-RH cylinder head bolts (1) | |||
| RH exhaust manifold-to-RH catalytic converter flange bolts | 40 | 30 | |
| Spark plugs | 15 | 11 | |
| Stabilizer bar link-to-stabilizer bar nuts | 55 | 41 | |
| Starter motor-to-transaxle bolts | 25 | 18 | |
| Starter motor electrical connector nuts | 12 | 9 | |
| Steering column-to- steering gear input shaft pinch bolt | 25 | 18 | |
| Steering column boot nuts | 6 | 53 | |
| Thermostat housing-to-lower intake manifold bolts | 12 | 9 | |
| Tie rod end-to-steering knuckle nuts | 55 | 41 | |
| Transaxle-to-engine bolts | 50 | 37 | |
| Transaxle manual control cable nut | 17 | 13 | |
| Upper intake manifold-to-lower intake manifold bolts | 10 | 89 | |
| Upper intake manifold support bracket bolt | 50 | 35 | |
| Upper intake manifold support bracket nut | 6 | 53 | |
| Valve cover-to-cylinder head bolts and stud bolts | 12 | 9 | |
| Valve rocker arm bolts (1) | |||
| Valve tappet guide plate retainer bolts | 12 | 9 | |
| Wire harness ground-to-cowl screw | 10 | 89 | |
| (1) Refer to the procedure in this article. | |||
| (1) | Refer to the procedure in this article. |
TORQUE SPECIFICATIONS
The 3.0L engine has
- a V-block with six cylinders and splayed crankpins
- a distributorless ignition system
- a multiport, sequential fuel injection (SFI) system
- overhead valves
- hydraulic valve tappets for automatic lash adjustment
- connecting rod parting faces that are unique with an interference fit
Scheme 1
Scheme 2
Scheme 3
Scheme 4
Refer to ENGINE SYSTEM-GENERAL INFORMATION .
Scheme 5
Scheme 6
Scheme 7
Scheme 8
Scheme 9
Scheme 10
Scheme 11
Scheme 12
Scheme 13
Scheme 14
Scheme 15
Scheme 16
Scheme 17
Scheme 18
- Disconnect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(ref-233724) .
- Disconnect the tubes, loosen the clamps and remove the air cleaner outlet pipe.
- Remove the pin-type retainers and the snow shield.
- Disconnect the accelerator cable, speed control cable and throttle return spring from the throttle body.
- Remove the bolts and position the accelerator cables and bracket aside.
- Disconnect the throttle position (TP) sensor and the intake air control (IAC) electrical connectors. Detach the harness retainer from the throttle body stud bolt.
- Disconnect the vacuum hose and the evaporative emissions (EVAP) return tube.
- Remove the upper intake manifold support bracket bolt and nut. Position the bracket and harness aside.
- Loosen the nut and disconnect the exhaust gas recirculation (EGR) tube from the EGR valve.
- Disconnect the positive crankcase ventilation (PCV) tube from the upper intake manifold.
- Disconnect the fuel supply manifold pressure sensor vacuum tube.
- Disconnect the PCV tube from the PCV valve and remove the tube.
- Disconnect the EGR vacuum regulator solenoid and intake manifold tuning valve (IMTV) electrical connectors. Detach the pin-type harness retainer from the upper intake manifold.
- Detach the spark plug wire holder from the valve cover stud and disconnect the radio interference capacitor electrical connector.
- Remove the 2 nuts and position the EGR vacuum regulator solenoid and bracket aside.
- Remove the bolts and the upper intake manifold.
Scheme 19
Scheme 20
Scheme 21
Scheme 22
Scheme 23
- Install the upper intake manifold. Tighten bolts in 2 stages in the sequence shown. Stage 1: Tighten the bolts hand tight. Stage 2: Tighten the bolts to 10 Nm (89 lb-in).
- Position the EGR vacuum regulator solenoid and bracket and install the nuts.
- Attach the spark plug wire holder to the valve cover stud and connect the radio interference capacitor electrical connector.
- Connect the EGR vacuum regulator solenoid and IMRC electrical connectors. Attach the pin-type harness retainer to the upper intake manifold.
- Connect the PCV tube from the PCV valve.
- Connect the fuel supply manifold pressure sensor vacuum tube.
- Connect the PCV tube to the upper intake manifold.
- Connect the EGR tube to the EGR valve and tighten the fitting.
- Position the upper intake manifold support bracket and install bolt and nut.
- Connect the vacuum hose and the EVAP return tube.
- Connect the TP sensor and the IAC electrical connectors. Attach the harness retainer from the throttle body stud bolt.
- Position the accelerator cable bracket and install the bolts.
- Connect the accelerator cable, speed control cable and throttle return spring to the throttle body.
- Install the pin-type retainers and the snow shield.
- Position the air cleaner outlet pipe, connect the tubes and tighten the clamps.
- Connect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(ref-233724) .
See also:
• AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N
