TORQUE SPECIFICATIONS
| Description | Nm | Lb-ft | Lb-in |
|---|---|---|---|
| Front wheel spindle tie-rod-to-steering gear | 100 | 74 | |
| Intermediate steering shaft pinch bolt | 47 | 35 | |
| Power steering pressure (PSP) switch | 11 | 8 | |
| Power steering pump bracket bolts and nut (CII) | 47 | 35 | |
| Power steering pump mounting bolts (CII) | 47 | 35 | |
| Power steering pump mounting bolts (CIII) | 25 | 18 | |
| Power steering pump reservoir mounting bolt (CIII) | 11 | 8 | |
| Power steering pump reservoir mounting nuts (CIII) | 4 | 35 | |
| Wiring harness retainer-to-reservoir mounting nut (3.0L 4V) | 5 | 44 | |
| Pressure line fitting at pump (CII) | 37 | 27 | |
| Pressure line fitting at pump (CIII) | 47 | 35 | |
| Pressure line at steering gear | 37 | 27 | |
| Return line at steering gear | 37 | 27 | |
| Steering gear-to-subframe mounting nut | 115 | 85 | |
| Subframe to body bolts | 103 | 76 | |
| Tie-rod end jam nut | 55 | 41 | |
| Tie-rod end-to-knuckle nut | 55 (1) | 41 (1) | |
| Power steering pressure and return hose retainer bolts and nuts | 10 | 89 | |
| Power steering pressure hose bracket-to-gear bolts | 10 | 89 | |
| Accessory drive belt tensioner bolt | 47 | 35 | |
| Accessory drive belt idler pulley bolt | 47 | 35 | |
| Coolant expansion tank nut and bolt | 10 | 89 | |
| Power steering fluid cooler nut and bolt | 6 | 53 | |
| Inner tie rod | 100 | 74 | |
| (1) Once torque is reached, continue turning to align slot in nut with cotter pin hole in tie-rod end. | |||
| (1) | Once torque is reached, continue turning to align slot in nut with cotter pin hole in tie-rod end. |
TORQUE SPECIFICATIONS
System View-3.0L 2V Engine (CII Pump)
Scheme 1
System View-3.0L 4V Engine (CIII Pump)
Scheme 2
Steering Gear (Typical)
Scheme 3
Power Steering Pump (CII)
Scheme 4
Power Steering Pump (CIII)
