Power Steering System Ford Taurus X I

Material

Material

a Capacities listed are average system capacities and may vary.

TORQUE SPECIFICATIONS

TORQUE SPECIFICATIONS

The power steering system consists of the following components

1. Inner tie-rod ends
2. Power steering pump (includes Fuel Efficient Power Steering (FEPS) solenoid/actuator)
3. Power steering fluid reservoir
4. Power steering fluid cooler
5. Pressure and return lines/hoses
6. Steering Effort Control Module (SECM)
7. Rack-and-pinion steering gear
8. Steering wheel rotation sensor

The FEPS system reduces vehicle fuel consumption by reducing the amount of power steering assist provided at higher engine speeds, when less assist is needed. The FEPS system is controlled by the SECM, FEPS solenoid/actuator and the steering wheel rotation sensor. As the steering wheel is turned, the steering wheel rotation sensor, which is mounted to the steering column, generates a steering wheel turning rate signal, which it sends to the SECM. The SECM also receives a vehicle speed signal from the ABS module. The SECM uses both of these signals to determine how much assist is needed. At slower speeds, full power steering assist is provided. As vehicle speed increases, the SECM sends a signal to the FEPS solenoid/actuator, which is mounted to the power steering pump. The FEPS solenoid/actuator is then activated to reduce the flow of power steering fluid through the power steering system. Power steering pump effort is reduced, which in turn, reduces the demands on the engine from the pump. With less load on the engine, the vehicle has greater fuel efficiency.

The power steering pump is a vane-type pump which is driven by the engine. A dedicated power steering pump belt connects the power steering pump and pulley to the engine. The power steering pump pulls power steering fluid from the power steering fluid reservoir, pressurizes it and pumps it through the power steering pressure line to the steering gear. From the steering gear, power steering fluid is returned to the reservoir through the power steering return line, power steering fluid cooler and power steering return hose.

For maximum power steering fluid cooling, the power steering cooler is mounted to the vehicle in front of the vehicle radiator and A/C condenser.

The outer tie-rod ends connect the steering gear to the wheel knuckles.

For information concerning the steering wheel rotation sensor, refer to STEERING SYSTEM - GENERAL INFORMATION article.

Refer to STEERING SYSTEM - GENERAL INFORMATION article.

Power Steering Fluid Reservoir

Material

Scheme 14

REMOVAL AND INSTALLATION

Note. When repairing the power steering system, care should be taken to prevent the entry of foreign material or failure of the power steering components may occur.

Note. Do not allow power steering fluid to contact the engine accessory drive belt or failure of the belt may occur.

1. Using a suitable suction device, drain the power steering fluid reservoir.
2. Carefully push the lock tab on the degas bottle away from the power steering fluid reservoir. To release the reservoir, grasp the top of the power steering fluid reservoir and carefully slide it upwards in the mounting guides to access the hoses. Release the clamp and disconnect the power steering fluid cooler-to-reservoir hose from the reservoir. Release the clamp and disconnect the power steering fluid reservoir-to-pump supply hose from the reservoir.
3. Remove the power steering fluid reservoir.
4. To install, reverse the removal procedure.
5. Fill the power steering system. For additional information, refer to «STEERING SYSTEM - GENERAL INFORMATION»(/ford/taurus-x/i-2007-2009/remont/manual-power-steering/#steering-system-general-information) article.

Power Steering Pump

Special Tools Illustration Tool Name Tool Number Installer Set, Teflon® Seal 211-D027 (D90P-3517-A) or equivalent Power Steering Belt Removal Tool 303-1252/1 Power Steering Belt Installation Tool 303-1252/2

Scheme 15

Scheme 16

Scheme 17

Material

Scheme 18

REMOVAL

Note. While repairing the power steering system, care should be taken to prevent the entry of foreign material or failure of the power steering components may result.

1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING AND LIFTING»(/ford/taurus-x/i-2007-2009/remont/hoistjack/#jacking-and-lifting) article.
2. Using a suitable suction device, siphon the power steering fluid from the power steering fluid reservoir.
3. Disconnect the power steering pressure (PSP) switch electrical connector.
4. Remove the pressure line bracket-to-valve cover stud nut and detach the bracket from the stud.
5. Remove the 7 pin-type retainers and the RH splash shield.
6. Using the special tool, remove the power steering pump belt from the power steering pump pulley and position it aside. Install the special tool between the power steering pump belt and pulley and turn the crankshaft bolt clockwise.
7. Release the clamp and disconnect the power steering fluid reservoir-to-pump supply hose from the power steering pump. Detach the supply hose retainer from the power steering pressure line bracket.
8. Disconnect the fuel efficient power steering (FEPS) solenoid electrical connector.
9. Remove the power steering pressure line bracket-to-engine bolt.
10. Remove the 3 power steering pump bolts.
11. Holding the power steering pump with a punch inserted into a mounting bolt cavity, disconnect the power steering pressure line fitting-to-power steering pump.

INSTALLATION

1. Using the special tool, install a new Teflon® seal on the power steering pressure line fitting.
2. Holding the power steering pump with a suitable holding device, connect the power steering pressure line fitting-to-power steering pump. Tighten to 65 Nm (48 lb-ft).
3. Position the power steering pump and install the 3 bolts. Tighten to 25 Nm (18 lb-ft).
4. Position the bracket and install the power steering pressure line bracket-to-engine bolt. Tighten to 9 Nm (80 lb-in).
5. Connect the FEPS solenoid electrical connector.
6. Release the clamp and connect the power steering fluid cooler-to-pump supply hose. Attach the supply hose retainer to the power steering pressure line bracket.
7. Using the special tool, install the power steering pump belt onto the power steering pump pulley. Install the special tool between the power steering pump belt and pulley and turn the crankshaft bolt clockwise.
8. Position the RH splash shield and install the 7 pin-type retainers.
9. Attach the pressure line bracket to the valve cover stud and install the nut. Tighten to 9 Nm (80 lb-in).
10. Connect the PSP switch electrical connector.
11. Fill the power steering system. For additional information, refer to «STEERING SYSTEM - GENERAL INFORMATION»(/ford/taurus-x/i-2007-2009/remont/manual-power-steering/#steering-system-general-information) article.

Power Steering Pump Pulley

Special Tools Illustration Tool Name Tool Number Remover, Power Steering Pump Pulley 211-016 (T69L-10300-B) Installer, Power Steering Pump Pulley 211-185 (T91P-3A733-A)

Scheme 19

Material

Scheme 20

1. Remove the power steering pump. For additional information, refer to «Power Steering Pump»(/ford/taurus-x/i-2007-2009/remont/manual-power-steering/#power-steering-system__power-steering-pump) .
2. Using the special tool, remove the power steering pump pulley.

1. Using the special tool, install the power steering pump pulley.
2. Install the power steering pump. For additional information, refer to «Power Steering Pump»(/ford/taurus-x/i-2007-2009/remont/manual-power-steering/#power-steering-system__power-steering-pump) .

Power Steering Pump to Steering Gear Pressure Line

Material

Scheme 21

Note. While repairing the power steering system, care should be taken to prevent the entry of foreign material or failure of the power steering components may occur.

Note. Do not allow power steering fluid to contact the engine accessory drive belt or failure of the belt may occur.

1. Remove the power steering pump. For additional information, refer to «Power Steering Pump»(/ford/taurus-x/i-2007-2009/remont/manual-power-steering/#power-steering-system__power-steering-pump) .
2. Remove the pressure line bracket-to-rear engine bolt. To install, tighten to 9 Nm (80 lb-in).
3. Disconnect the Power Steering Pressure (PSP) switch electrical connector from the pressure line.
4. Remove the pressure line bracket-to-valve cover stud nut. To install, tighten to 9 Nm (80 lb-in).
5. Remove the pressure line bracket-to-steering gear bolt. To install, tighten to 23 Nm (17 lb-ft).
6. Remove the power steering line clamp plate bolt. Rotate the clamp plate and disconnect the pressure line from the steering gear. To install, tighten to 23 Nm (17 lb-ft).
7. To install, reverse the removal procedure.

Steering Gear to Fluid Cooler Return Hose

Material

Scheme 22

Note. While repairing the power steering system, care should be taken to prevent the entry of foreign material or failure of the power steering components may occur.

1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING AND LIFTING»(/ford/taurus-x/i-2007-2009/remont/hoistjack/#jacking-and-lifting) article.
2. Release the clamp and disconnect the steering gear-to-fluid cooler return hose from the cooler.
3. Remove the 3 power steering return line bracket-to-frame bolts. To install, tighten to 5 Nm (44 lb-in).
4. Remove the power steering line clamp plate bolt, rotate the clamp plate and remove steering gear-to-fluid cooler return hose. To install, tighten to 23 Nm (17 lb-ft).
5. To install, reverse the removal procedure.
6. Fill the power steering system. For additional information, refer to «STEERING SYSTEM - GENERAL INFORMATION»(/ford/taurus-x/i-2007-2009/remont/manual-power-steering/#steering-system-general-information) article.

Power Steering Fluid Cooler

Material

Scheme 23

Note. When repairing the power steering system, care should be taken to prevent the entry of foreign material or failure of the power steering components may occur.

1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING AND LIFTING»(/ford/taurus-x/i-2007-2009/remont/hoistjack/#jacking-and-lifting) article.
2. Remove the lower radiator air deflector screws, pin-type retainers and the deflector.
3. Release the clamps and disconnect the hoses from the power steering fluid cooler.
4. Remove the 2 bolts and the power steering fluid cooler. To install, tighten to 9 Nm (80 lb-in).
5. To install, reverse the removal procedure.
6. Fill the power steering system. For additional information, refer to «STEERING SYSTEM - GENERAL INFORMATION»(/ford/taurus-x/i-2007-2009/remont/manual-power-steering/#steering-system-general-information) article.

Steering Gear

Material

Scheme 24

Scheme 25

All vehicles

Note. When repairing the power steering system, care should be taken to prevent the entry of foreign material or failure of the power steering components may occur.

1. Turn the steering wheel to the straight-ahead position and remove the ignition key.
2. Remove the wheels and tires. For additional information, refer to «WHEELS AND TIRES»(/ford/taurus-x/i-2007-2009/remont/wheel-tire-system/#wheels-tires) article.
3. Remove the 2 tie-rod end nuts and disconnect the tie-rod ends from the wheel knuckles. To install, tighten to 115 Nm (85 lb-ft).
4. Remove the pressure line bracket-to-steering gear bolt. To install, tighten to 23 Nm (17 lb-ft).
5. Remove the power steering line clamp plate bolt. Rotate the clamp plate and disconnect the pressure and return lines from the steering gear. Discard the 2 O-ring seals. To install, tighten to 23 Nm (17 lb-ft).
6. Remove the steering column shaft-to-steering gear bolt and disconnect the shaft from the steering gear. Discard the bolt. To install, tighten the new bolt to 25 Nm (18 lb-ft).
7. Remove and discard the 2 stabilizer bar link upper nuts. To install, tighten the 2 new nuts to 55 Nm (41 lb-ft). Position the stabilizer bar and links upwards.
8. Remove the roll resistor bracket-to-transaxle nut and bolt. To install, tighten to 48 Nm (35 lb-ft).
9. Place a suitable jack under the roll resistor-to-transaxle bracket. Raise the engine/transaxle approximately 25.4 mm (1 in).
10. Remove and discard the 4 stabilizer bar bracket bolts. To install, tighten the 4 new bolts to 50 Nm (37 lb-ft).
11. Remove the 2 steering gear nuts and bolts. Remove the steering gear from the left side of the vehicle. Discard the nuts. To install, tighten the 2 new nuts to 117 Nm (86 lb-ft).
12. To install, reverse the removal procedure. Fill the power steering system. For additional information, refer to «STEERING SYSTEM - GENERAL INFORMATION»(/ford/taurus-x/i-2007-2009/remont/manual-power-steering/#steering-system-general-information) article. Check and, if necessary, adjust the front toe. For additional information, refer to «SUSPENSION SYSTEM - GENERAL INFORMATION»(/ford/taurus-x/i-2007-2009/remont/suspension-front/#suspension-system-general-information) article.

Inner Tie Rod

Special Tools Illustration Tool Name Tool Number Installer, Constant Velocity Joint Boot Clamp 205-343 (T95P-3514-A)

Material

Scheme 26

Note. The boots and clamps are designed to provide an airtight seal and protect the internal components of the steering gear. If the seal is not airtight, the vacuum generated during turning will draw water and contamination into the gear, causing failure of the steering gear components. Zip ties must not be used as they do not provide an airtight seal.

Note. The inner ball joint grease is not compatible with water contamination. Do not allow water to become trapped in the grease or degradation and failure of the joint may occur.

Note. If present, the orientation of the vent tube must be noted so the boots and vent tubes can be installed in the correct location. Incorrect orientation may lead to improper ventilation and steering gear failure.

1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING AND LIFTING»(/ford/taurus-x/i-2007-2009/remont/hoistjack/#jacking-and-lifting) article.
2. Loosen the tie-rod jam nut.
3. Remove the outer tie-rod end nut and disconnect the outer tie-rod end from the wheel knuckle.
4. Remove the outer tie-rod end.
5. Remove the tie-rod jam nut.
6. Remove the outer bellows boot clamp.
7. Remove and discard the inner bellows boot clamp.
8. Remove the tie-rod bellows boot.
9. While holding the steering gear rack, use a suitable crowfoot-style inner tie-rod tool (such as Snap On® Stock# YA3000B) or an appropriate-sized crowfoot wrench to remove the inner tie rod.

1. While holding the steering gear rack, use a suitable crowfoot-style inner tie-rod tool (such as Snap On® Stock# YA3000B) or an appropriate-sized crowfoot wrench to install the inner tie rod. Tighten to 110 Nm (81 lb-ft).
2. Position the inner tie-rod bellows clamp and install the bellows.
3. Using the Constant Velocity Joint Boot Clamp Installer, install the inner bellows boot clamp. Install the outer bellows boot clamp.
4. Thread the tie-rod jam nut onto the inner tie rod.
5. Install the outer tie rod to the inner tie rod.
6. Position the outer tie-rod end and install the nut. Tighten to 115 Nm (85 lb-ft).
7. Tighten the tie-rod jam nut to 55 Nm (41 lb-ft).
8. Check and, if necessary, adjust the front toe. For additional information, refer to «SUSPENSION SYSTEM - GENERAL INFORMATION»(/ford/taurus-x/i-2007-2009/remont/suspension-front/#suspension-system-general-information) article.

Note. The right side lower instrument panel cover has been removed for clarity. The Steering Effort Control Module (SECM) is located on a bracket behind the carpet between the firewall and right side kick panel.

Scheme 27

1. Position the carpet aside.
2. Disconnect the 2 Steering Effort Control Module (SECM) electrical connectors.
3. Remove the 2 nuts and the SECM. To install, tighten to 4 Nm (35 lb-in).
4. To install, reverse the removal procedure.

Power Steering Control Valve Actuator

Special Tools Illustration Tool Name Tool Number Power Steering Belt Removal Tool 303-1252/1 Power Steering Belt Installation Tool 303-1252/2

Material

Scheme 28

Note. While repairing the power steering system, care should be taken to prevent the entry of foreign material or failure of the power steering components may result.

1. Using a suitable suction device, siphon the power steering fluid from the power steering reservoir.
2. Remove the 7 pin-type retainers and the RH splash shield.
3. Using the Power Steering Belt Removal Tool, remove the power steering pump belt from the power steering pump pulley and position it aside. Install the Power Steering Belt Removal Tool between the power steering pump belt and pulley and turn the crankshaft bolt clockwise.
4. Disconnect the power steering control valve actuator electrical connector.
5. Remove the 3 power steering pump bolts.
6. Holding the power steering pump with a suitable holding device, loosen the bolt and remove the power steering control valve actuator.

1. Holding the power steering pump with a suitable holding device, install the power steering control valve actuator. Tighten to 16 Nm (142 lb-in).
2. Position the power steering pump and install the 3 power steering pump bolts. Tighten to 25 Nm (18 lb-ft).
3. Connect the power steering control valve actuator electrical connector.
4. Using the Power Steering Belt Installation Tool, install the power steering pump belt onto the power steering pump pulley. Install the Power Steering Belt Installation Tool between the power steering pump belt and pulley and turn the crankshaft bolt clockwise.
5. Install the RH splash shield and the 7 pin-type retainers.
6. Fill the power steering system. For additional information, refer to «STEERING SYSTEM - GENERAL INFORMATION»(/ford/taurus-x/i-2007-2009/remont/manual-power-steering/#steering-system-general-information) article.

See also:
• STEERING SYSTEM - GENERAL INFORMATION
• JACKING AND LIFTING
• WHEELS AND TIRES
• SUPPLEMENTAL RESTRAINT SYSTEM
• SUSPENSION SYSTEM - GENERAL INFORMATION
• Power Steering Pump
