Body Panel System - Body Closures Ford Taurus X I

Material

Material

TORQUE SPECIFICATIONS TABLE

TORQUE SPECIFICATIONS TABLE

The power liftgate feature allows the customer to automatically open or close the liftgate by activating the instrument panel control button, activating the Remote Keyless Entry (RKE) transmitter, lifting the exterior handle (open only) or activating the rear quarter trim-mounted switch (close only). The power liftgate uses a power cinching system to latch the liftgate.

Power liftgate operation requires the vehicle to be in PARK and the vehicle speed to be less than 5 km/h (3 mph).

To manually open the power liftgate, due to power latch loss of function, remove the latch access cover located on the lower center of the liftgate trim panel. Reach in on the right side of opening, and push down on the manual latch release lever.

The power liftgate feature suspends a power open or power close when the ignition key is moved to the START position. The clutch will remain active to hold the liftgate in place during a start operation. Once the ignition key is no longer in the START position, the liftgate power open or power close will resume. If the ignition key is cycled during a power close and the liftgate is 15 cm to 24 cm (6 in to 10 in) from being latched, the liftgate may reverse to the full open position.

The power liftgate feature can be enabled/disabled from the message center. When the power liftgate feature is disabled (OFF), operation from the liftgate handle and liftgate rear control switch are disabled.

The power liftgate system consists of the following components

1. Power liftgate control switch (located in the instrument panel)
2. Power liftgate rear control switch (located in the LH rear quarter trim panel)
3. Exterior handle switch
4. Power liftgate motor (located behind the LH rear quarter trim panel)
5. Power liftgate clutch (part of the liftgate motor)
6. Power liftgate rod (attached to the power liftgate motor assembly and liftgate mounting stud)
7. Position sensor (located in the power liftgate motor assembly)
8. Pinch strip switches (located on the liftgate sides)
9. Power liftgate latch (located in the middle lower portion of the liftgate)
10. Forkbolt switches (located in the power liftgate latch)
11. Sector gear switches (located in the power liftgate latch)
12. Detent switch (located in the power liftgate latch)
13. Unlatch/cinching motor (located in the power liftgate latch)
14. Liftgate/Trunk Module (LTM) (located behind the left rear quarter trim panel)

The power liftgate is controlled by the LTM.

Note. The Smart Junction Box (SJB) may also be identified as the Generic Electronic Module (GEM).

The LTM receives inputs from the following components

1. Forkbolt switch - primary (determines the position of the latch)
2. Forkbolt switch - secondary (determines the position of the latch)
3. Sector gear open switch - open (determines the sector gear position)
4. Sector gear close switch - close (determines the sector gear position)
5. SJB (exterior handle)
6. Detent switch (determines the position of the latch)
7. Power liftgate control switch (located in the instrument panel)
8. Power liftgate rear control switch (located in the LH rear quarter trim panel)
9. Pinch strip switches (determines if an obstacle is between the pinch strip and the liftgate body opening)
10. Position sensor (determines the direction, travel speed and obstacle detection of the liftgate)
11. Controller Area Network (CAN) serial communication link

The LTM sends outputs to the following components

1. Liftgate motor
2. Liftgate clutch
3. Unlatch/cinching motor
4. Liftgate chime
5. SJB (ajar status)

The liftgate chime sounds an audible chime (located on the power liftgate motor assembly) for 3 seconds whenever a powered closing operation is initiated or if conditions are not correct for closing. The chime sound serves as a warning to alert the vehicle occupants and any bystanders that the liftgate is being moved in a closing direction by a powered operation. The gate will not be moved for the first second, as a pre-warning of impending gate movement.

The power liftgate may not operate under the following conditions

1. Low voltage or dead battery
2. Disconnected battery
3. Power liftgate that has been manually closed and left ajar

If any of these conditions have occurred, the power liftgate must be re-initialized before carrying out any pinpoint tests. Refer to Power Liftgate Initialization .

Power Liftgate

Special Tools Illustration Tool Name Tool Number 73III Automotive Meter 105-R0057 or equivalent Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool

Scheme 36

Power and Ground Requirements

Note. The Smart Junction Box (SJB) may also be identified as the Generic Electronic Module (GEM).

The SJB fuse 14 (10A) supplies battery logic power required for the software, clutch and internal switching operations. Power is supplied to the motor by Battery Junction Box (BJB) fuse 29 (30A).

Ground for the Liftgate/Trunk Module (LTM) is a separate single connection. Some of the continuous inputs which are at a ground state when on are also used for logic switching.

Power Liftgate Detent Switch, Forkbolt Primary Switch and Forkbolt Secondary Switch

The power liftgate detent switch, forkbolt primary switch and forkbolt secondary switch provide inputs to the LTM in order to determine liftgate latch position. The LTM receives inputs from the power liftgate detent switch, forkbolt primary switch and forkbolt secondary switch in the following manner

Note. The liftgate is in the primary position when the liftgate is in the full closed position. The liftgate is in the unlatch position when the liftgate is open and completely out of the striker. The liftgate can be placed in the unlatched position by lifting up on the liftgate handle.

LATCH SWITCH STATES

a The detent switch may be in open or grounded state depending on forkbolt position. The detent switch state changes as the forkbolt rotates.

Manual Latch Release for Power Liftgate

To manually open the power liftgate, due to power latch failure, remove the latch access cover located on the lower center of the liftgate trim panel. Reach in on the right side of opening, and push down on the manual latch release lever.

Unlatch/Cinching Motor

The latch uses a bi-directional motor to accomplish both release and cinch operations. The motor is driven in one direction to cinch and in the opposite direction to release.

During a cinch operation, power is supplied to the unlatch/cinching motor by the Liftgate/Trunk Module (LTM) when the secondary latch position is reached during a power close operation. When the motor activates, it pulls the liftgate into the primary latch position. The LTM removes power from the unlatch/cinching motor when the primary latch position is reached.

During an unlatch operation, power is supplied to the unlatch/cinching motor by the LTM when a valid open command is received.

Sector Gear Switches

The sector gear open switch and sector gear close switch provide input to the LTM in order to determine the position of the sector gear. The sector gear is part of the latch assembly. It is driven by the latch motor and in turn drives the latch mechanism. During a release operation, the LTM deactivates the unlatch/cinching motor once the end of travel is reached. After a release operation, the LTM keeps the latch released until the gate moves away from the vehicle. The LTM then reverses the direction of the unlatch/cinching motor until the sector gear switches indicate the sector gear has returned to the neutral position. Refer to the following table for sector gear switch states

SECTOR GEAR SWITCH STATES

The drive assembly consists of the following

Position Sensor

When awake, the LTM supplies a 5-volt reference voltage to the position sensor on a valid open command or anytime the liftgate is in the open position (up to 6 hours). The LTM constantly supplies the ground. The position sensor has 2 data lines that the LTM monitors to determine the liftgate movement and position. The LTM uses the liftgate position information to determine which direction to power the liftgate (open or close) when a valid operation command is received. The movement is monitored to identify obstructions.

Actuator Clutch

The drive assembly actuator clutch separates the drive assembly actuator motor from the liftgate drive gear. This allows manual opening and closing of the liftgate without driving the motor. The LTM supplies power to the drive assembly actuator clutch for any valid open/close operation. The clutch connects the drive assembly actuator motor to the drive actuator, allowing the motor to turn the actuator and open or close the liftgate.

Actuator Motor

The drive assembly actuator motor is a reversible motor. Upon a valid activation, the LTM supplies power and ground to the motor circuits depending on the liftgate position and the direction the liftgate needs to be moved.

Power Liftgate Control Switch - Instrument Panel

Pressing the instrument panel power liftgate control switch supplies a momentary ground signal to the LTM which will open or close the liftgate depending on the conditions.

Power Liftgate Rear Control Switch - Quarter Trim Panel

Pressing the power liftgate rear control switch (located on the LH quarter trim panel) supplies a momentary ground signal to the LTM which will close the liftgate depending on the conditions.

Exterior Handle Switch

When the exterior handle switch is activated, the Smart Junction Box (SJB) sends a signal to the LTM which will open the liftgate depending on the conditions.

Remote Keyless Entry (RKE) Operation

The SJB receives a power liftgate activation command (double press) from the Remote Keyless Entry (RKE) transmitter. The SJB will send a signal on the Controller Area Network (CAN) to the power liftgate. The signal transmitted between the SJB and the LTM is not specific to the open or close operation. The LTM will determine which operation to carry out depending on the liftgate position when the signal is received.

Power Liftgate Interface

Power liftgate open operation requires the vehicle to be in PARK and the vehicle speed to be less than 5 km/h (3 mph). The power liftgate receives information over the CAN from the PCM for the PRNDL position and from the Instrument Cluster (IC) (gateway) for vehicle speed. These inputs have network DTCs. If any vehicle speed or transmission rangeTransmission Range (TR) switch DTCs are retrieved and the power liftgate is not operating, repair these DTCs first.

Power Liftgate Operation

The following is a brief explanation of a normal power open cycle of the power liftgate.

1. The power open operation will begin with one of the following methods: The LTM receives a momentary ground signal from the power liftgate control switch. The SJB receives a signal from the remote transmitter key fob (double button press). The LTM receives a signal from the SJB indicating the exterior liftgate handle has been activated.
2. The LTM checks the PRNDL position and vehicle speed status from the CAN communication link.
3. The LTM supplies power to the unlatch/cinching motor until the sector gear switches indicate end of travel which releases the power liftgate latch.
4. The power liftgate detent switch, primary forkbolt switch and secondary forkbolt switch circuits are monitored for correct latch release signals.
5. Power is supplied to the drive assembly actuator clutch and motor, opening the power liftgate.
6. The power liftgate supplies power to the unlatch/cinching motor while monitoring the sector gear switches to return the sector gear to the neutral position.
7. When the power liftgate is opening, the position sensor is monitored for liftgate position and velocity. If an obstruction is detected, the liftgate will stop.
8. The power liftgate full open position is learned by the LTM during the power liftgate initialization. When the power liftgate reaches the full open position, the LTM removes the power from the drive assembly actuator motor and clutch.
9. After the power is removed from the clutch and drive motor, the position sensor briefly continues to monitor the position of the liftgate. If excessive movement in the closed direction is detected, power is reapplied to the clutch and a continuous chime is initiated and remains on as the liftgate is automatically power closed.
10. If the excessive closing movement is detected on 11 successive power open requests, DTC B201A is set and power liftgate operation is disabled until the DTC is cleared.

The following is a brief explanation of a normal power close cycle of the power liftgate.

1. The power close operation will begin with one of the following methods: The LTM receives a momentary ground signal from the power liftgate control switch. The LTM receives a momentary ground signal from the power liftgate rear control switch (LH rear quarter panel). The SJB receives a signal from the remote transmitter key fob (double press).
2. The LTM checks the PRNDL position and vehicle speed status from the CAN communication link.
3. The LTM will start an audible chime.
4. After one second of audible chime, power is supplied to the drive assembly actuator clutch and motor as the audible chime continues 3 seconds total.
5. As the power liftgate is powered closed, the position sensor is monitored for liftgate position and velocity. The power liftgate will reverse if an obstruction is detected.
6. Also, as the power liftgate is powered closed, the pinch strips are monitored for a pinch condition. The power liftgate will reverse if an obstruction is detected by either pinch strip.
7. The power liftgate detent switch, forkbolt primary switch and forkbolt secondary switch circuits are monitored for correct latch signals.
8. When the LTM receives switch signals indicating the secondary latch position is reached, power is supplied to the unlatch/cinching motor to pull the liftgate into the primary latch position. When primary latch position is reached, power is removed from the drive motor and clutch.
9. When the LTM receives switch signals indicating the primary latch position has been reached (liftgate is fully closed), the LTM reverses the direction of the unlatch/cinching motor until the sector gear switches indicate the neutral position.

Power Liftgate Chime

The LTM requests a chime to sound for 3 seconds when

1. the LTM receives a request to power close.
2. the liftgate reverses when closing due to an obstacle.
3. the liftgate stops opening due to an obstacle.

The LTM requests a chime to sound for one second when an open or close input is received when

1. the vehicle speed is greater than or equal to 5 km/h (3 mph).
2. the ignition key is in the RUN position and the transmission is not in the PARK position.
3. the battery voltage is between 8 and 9.5 volts.

The LTM requests a continuous chime during a power close immediately after a power open under the following conditions

1. there is excessive weight on the liftgate (snow, ice, bicycle rack, etc.).
2. worn/damaged liftgate assist cylinders.
3. the LTM incorrectly learned the full open position during the power liftgate initialization procedure.

The chime will sound continuously for up to 5 minutes when the transmission is shifted out of the PARK position or the vehicle speed exceeds 5 km/h (3 mph) while the liftgate is open/ajar. The chime will stop sounding when the liftgate reaches the latch, 5 minutes has elapsed or the transmission is shifted into the PARK position and the vehicle speed is less than 5 km/h (3 mph).

The chime will sound continuously for up to 5 minutes when the liftgate fails to close to the primary latch position after 20 seconds of powering in the close direction. The chime will stop if the liftgate reaches the primary latch position or 5 minutes has elapsed.

Power Liftgate Initialization Procedure

If the LTM loses the logic battery supply for any reason, such as battery disconnect, module disconnect or if left open for more than 6 hours, the LTM will lose the power liftgate position stored in memory and will attempt to open when the liftgate switch is pressed the first time.

The power liftgate can also lose position if the following components are removed, adjusted or disconnected

1. Power liftgate motor
2. Liftgate hinges
3. Power liftgate rod
4. Liftgate striker

The power liftgate normal operation will not be restored until the power liftgate position is once again stored into memory. The initialization procedure is the learning process the LTM uses to restore the power liftgate position in memory. The LTM monitors the position sensor data received during the initial power open-and-close operation to learn the position.

Refer to Power Liftgate Initialization .

Power Liftgate Awake/Sleep Status

1. The LTM is in the awake state whenever the ignition is in the RUN position.
2. The LTM is in the awake state while carrying out a close or an open operation, including cinch.
3. The LTM is in the sleep state when all of the following conditions exist: The latch is not in the fully unlatched position. The ignition is in the OFF position. No power operation is active. No wakeup inputs have changed state for more than 20 seconds.
4. The LTM is also in the sleep state when all of the following conditions exist: The latch is in the unlatched position. The ignition is in the OFF position. No power operation is active. No wakeup inputs have changed state for more than 6 hours.

The wakeup inputs for the power liftgate are

1. Power liftgate open/close switch request signal
2. Forkbolt primary signal
3. Forkbolt secondary signal
4. Detent switch signal
5. Rear control switch
6. Exterior handle switch
7. Glass ajar switch
8. CAN

Inspection and Verification

1. Verify the customer concern.
2. The battery voltage must be at normal operating levels in order for the power liftgate to open and close correctly. Make sure the battery and charging systems are operating correctly before proceeding with the power liftgate diagnosis.
3. Visually inspect for obvious signs of mechanical and electrical damage. Refer to the following chart. VISUAL INSPECTION CHART Mechanical Electrical Power liftgate drive assembly Power liftgate rod assembly Power liftgate cinching latch Power liftgate pinch strip switches Liftgate and liftgate hinges Liftgate assist cylinders Liftgate strikers Exterior release handle Liftgate weatherstrip Liftgate alignment to body and striker Wedges Excessive weight on the liftgate (for example: bike rack or snow and ice) Battery Junction Box (BJB) fuse 29 (30A) Smart Junction Box (SJB) fuse(s): 14 (10A) 17 (20A) Circuitry Power liftgate control switch - instrument panel Power liftgate rear control switch - quarter trim panel Power liftgate position sensor Power liftgate latch detent switch primary forkbolt switch secondary forkbolt switch sector gear open switch sector gear close switch unlatch/cinching motor Liftgate/Trunk Module (LTM) SJB
4. If an obvious cause for an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step.
5. If the cause is not visually evident, connect the scan tool to the Data Link Connector (DLC).
6. If the scan tool does not communicate with the VCM: check the VCM connection to the vehicle. check the scan tool connection to the VCM. refer to «MODULE COMMUNICATIONS NETWORK»(/ford/taurus-x/i-2007-2009/remont/communication-devices/#module-communications-network-system) article, No Power To The Scan Tool, to diagnose no power to the scan tool.
7. If the scan tool does not communicate with the vehicle: verify the ignition key is in the ON position. verify the scan tool operation with a known good vehicle. refer to «MODULE COMMUNICATIONS NETWORK»(/ford/taurus-x/i-2007-2009/remont/communication-devices/#module-communications-network-system) article to diagnose no response from the Liftgate/Trunk Module (LTM) or Smart Junction Box (SJB).
8. Carry out the network test. If the scan tool responds with no communication for one or more modules, refer to «MODULE COMMUNICATIONS NETWORK»(/ford/taurus-x/i-2007-2009/remont/communication-devices/#module-communications-network-system) article. If the network test passes, retrieve and record Continuous Memory Diagnostic Trouble Codes (CMDTCs).
9. Clear the CMDTCs and carry out the self-test diagnostics for the power liftgate or SJB.
10. If the DTCs retrieved are related to the concern, go to the «LIFTGATE/TRUNK MODULE (LTM) DTC TABLE»(/ford/taurus-x/i-2007-2009/remont/exterior-body-panels/#body-panel-system-body-closures) or the «SMART JUNCTION BOX (SJB) DTC TABLE»(/ford/taurus-x/i-2007-2009/remont/exterior-body-panels/#body-panel-system-body-closures) . For all other DTCs, refer to «MULTIFUNCTION ELECTRONIC MODULES»(/ford/taurus-x/i-2007-2009/remont/communication-devices/#multifunction-electronic-modules-system) article.
11. If no DTCs related to the concern are retrieved, go to «Symptom Chart»(/ford/taurus-x/i-2007-2009/remont/exterior-body-panels/#body-panel-system-body-closures) .

DTC Tables

SMART JUNCTION BOX (SJB) DTC TABLE

LIFTGATE/TRUNK MODULE (LTM) DTC TABLE

Symptom Chart

Symptom Chart

Pinpoint Test A: The Power Liftgate is Inoperative - Does Not Open or Close

Refer to appropriate SYSTEM WIRING DIAGRAMS article, Power Liftgate for schematic and connector information.

Normal Operation

The Liftgate/Trunk Module (LTM) receives battery voltage at all times through circuit SBP14 (BN/RD) and SBB29 (GY/RD). Ground is provided to the LTM through circuit GD147 (BK/VT).

During power opening and/or power closing operation, the LTM receives inputs from the following system components

1. Power liftgate control switch (instrument panel), power liftgate close switch (quarter trim panel) through circuit CPR63 (GY/YE) or Remote Keyless Entry (RKE).
2. Pinch strip through circuit CPR51 (YE/OG)(RH) and circuit CPR52 (YE/VT)(LH). The pinch strip switches are grounded through the LTM through circuit RPR52 (VT/GY).
3. Position sensor through circuit VPR53 (BU/WH) and VPR54 (BU/BN). The position sensor receives 5 volts from the LTM through circuit CPR55 (GN/BU) and ground from the LTM through circuit RPR55 (WH/BU).
4. Detent switch through circuit CPR66 (GY/YE).
5. Forkbolt primary switch through circuit CPR64 (VT/OG).
6. Forkbolt secondary switch through circuit CPR65 (BU/GN).
7. Sector gear close switch through circuit CPR67 (VT).
8. Sector gear open switch through circuit CPR68 (YE).

During power opening and/or power closing operation, the LTM provides output to the following system components

1. Power liftgate clutch through circuit CPR69 (BN/BU). Ground is provided to the clutch through circuit GD147 (BK/VT).
2. Power liftgate motor through circuit CPR57 (GN/WH) and circuit CPR58 (GN/OG).
3. Power liftgate cinch motor through circuit CPR61 (BN) and circuit CPR62 (WH/BU).
4. Power liftgate chime through circuit CPR56 (VT/BN) and circuit RPR56 (GY/VT).

For detailed description of normal operation, refer to Principles Of Operation .

This pinpoint test is intended to diagnose the following

1. Fuse(s)
2. Wiring, terminals or connectors
3. Power liftgate latch
4. Motor/clutch assembly
5. LTM
6. Power liftgate rod

Scheme 37

Scheme 38

Scheme 39

Scheme 40

Scheme 41

Scheme 42

Scheme 43

Scheme 44

Scheme 45

Scheme 46

Scheme 47

Scheme 48

Scheme 49

Scheme 50

Scheme 51

Scheme 52

Scheme 53

Scheme 54

Scheme 55

Scheme 56

Scheme 57

Scheme 58

Scheme 59

1. A1 RETRIEVE THE DTCs FROM THE LTM Use the recorded LTM DTCs from the continuous and LTM self-tests. Are any LTM DTCs recorded? YES : For DTC B106F, REFER to the «LIFTGATE/TRUNK MODULE (LTM) DTC TABLE»(/ford/taurus-x/i-2007-2009/remont/exterior-body-panels/#body-panel-system-body-closures) . For DTC B2908, go to A5 . For DTC B2418, go to A19 . For DTC B2419 or B2420, go to A18 . For DTC B2935, go to A10 . For DTC B2552, go to A13 . For DTC B2936, B2819, B2937 or B2939, go to A14 . For DTC B106E, go to A16 . For DTC B1179, B117A or B117B, go to A27 . NO : Go to A2 .
2. A2 CHECK THE OPERATION OF THE POWER LIFTGATE SWITCHES Vehicle in PARK. NOTE: Make sure the power liftgate is enabled (ON) in the vehicle message center. Close the liftgate to the full closed position (manually if necessary). Activate the power liftgate from the power liftgate control switch (instrument panel). Activate the power liftgate from the remote transmitter. Activate the power liftgate from the liftgate exterior handle. Does the power liftgate power open from any switch? YES : Go to «Pinpoint Test B»(/ford/taurus-x/i-2007-2009/remont/exterior-body-panels/#body-panel-system-body-closures__pinpoint-test-b-the-power-liftgate) . NO : Go to A3 .
3. A3 CHECK CIRCUIT SBP14 (BN/RD) FOR AN OPEN Disconnect LTM C4174B. Measure the voltage between LTM C4174B-9, circuit SBP14 (BN/RD), harness side and ground. Is the voltage greater than 10 volts? YES : Go to A4 . NO : VERIFY Smart Junction Box (SJB) fuse 14 (10A) is OK. If OK, REPAIR the circuit. CLEAR the DTCs. REPEAT the LTM self-test. If not OK, REFER to the Wiring Diagrams Manual to identify the possible causes of the circuit short. CLEAR the DTCs. REPEAT the LTM self-test.
4. A4 CHECK CIRCUIT GD147 (BK/VT) FOR AN OPEN Key in OFF position. Measure the resistance between LTM C4174B-1, circuit GD147 (BK/VT), harness side and ground. Is the resistance less than 5 ohms? YES : RECONNECT power liftgate system electrical connectors and Go to A5 . NO : REPAIR the circuit. CLEAR the DTCs. REPEAT the LTM self-test.
5. A5 CHECK THE DETENT AND FORKBOLT SWITCH PID Enter the following diagnostic mode on the diagnostic tool: DataLogger - LTM Operate the liftgate manually while monitoring the following LTM PIDs: Detent Switch Status (DETENTSW) Forkbolt Switch Status (FORKBLT_S) Forkbolt Secondary Switch (FKSWSEC) NOTE: The liftgate is in the primary position when the liftgate is in the full closed position. The liftgate is in the unlatch position when the liftgate is open and completely out of the striker. The liftgate can be placed in the unlatched position by lifting up on the liftgate handle. Begin with the liftgate in the open position, then slowly close the liftgate into each of the latch positions specified by the table below. Liftgate Latch Position DETENTSW FORKBLT_S FKSWSEC Fully Unlatched Inactive a Active Active Primary Active Inactive Inactive a If detent switch is active in the fully unlatched position, manually attempt to rotate the forkbolt towards the latched position. Do the switch states agree with the table? YES : Go to A10 . NO : Go to A6 .
6. A6 CHECK THE OPERATION OF THE DETENT AND FORKBOLT SWITCHES Key in OFF position. Disconnect: LTM C4174A Measure the resistance between LTM C4174A, harness side and ground at each of the connector pins and each latch position specified by the chart below. Liftgate Latch Position C4174A Circuit Resistance Fully Unlatched Pin 3, circuit CPR66 (GY/YE) Greater than 10,000 ohms a Fully Unlatched Pin 5, circuit CPR65 (BU/GN) Less than 5 ohms Fully Unlatched Pin 4, circuit CPR64 (VT/OG) Less than 5 ohms Primary Pin 3, circuit CPR66 (GY/YE) Less than 5 ohms Primary Pin 5, circuit CPR65 (BU/GN) Greater than 10,000 ohms Primary Pin 4, circuit CPR64 (VT/OG) Greater than 10,000 ohms a If resistance measured is less than 5 ohms, manually rotate the forkbolt to the latched position and retest. Do the resistance values agree with the chart? YES : Go to A31 . NO : Go to A7 .
7. A7 CHECK THE DETENT AND FORKBOLT SWITCH GROUND CIRCUIT Disconnect: Liftgate Latch/Unlatch Assembly C4339 Measure the resistance between power liftgate latch/unlatch assembly C4339-8, circuit GD147 (BK/VT), harness side and ground. Is the resistance less than 5 ohms? YES : Go to A8 . NO : REPAIR the circuit. CLEAR the DTCs. REPEAT the LTM self-test.
8. A8 CHECK THE DETENT AND FORKBOLT SWITCH CIRCUITS FOR AN OPEN Measure the resistance between power liftgate latch/unlatch assembly C4339, harness side and LTM C4174A, harness side using the following chart: Power Liftgate Latch/Unlatch Assembly Circuit LTM C4339-1 CPR65 (BU/GN) C4174A-5 C4339-3 CPR64 (VT/OG) C4174A-4 C4339-2 CPR66 (GY/YE) C4174A-3 Is the resistance less than 5 ohms on all circuits? YES : Go to A9 . NO : REPAIR the circuit. CLEAR the DTCs. REPEAT the LTM self-test.
9. A9 CHECK THE DETENT AND FORKBOLT SWITCH CIRCUITS FOR A SHORT TO GROUND Measure the resistance between LTM C4174A-5, circuit CPR65 (BU/GN), harness side and ground; between LTM C4174A-4, circuit CPR64 (VT/OG), harness side and ground; then between LTM C4174A-3, circuit CPR66 (GY/YE), harness side and ground. Are the resistances greater than 10,000 ohms on all circuits? YES : CHECK the power liftgate latch connector for bent or corroded connections on the component side and harness side. REPAIR as necessary. INSTALL a new power liftgate latch. REFER to «HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS»(/ford/taurus-x/i-2007-2009/remont/door-locks-anti-theft-systems/#handles-locks-latches-and-entry-systems) article. CLEAR the DTCs. REPEAT the LTM self-test. NO : REPAIR the circuit. CLEAR the DTCs. REPEAT the LTM self-test.
10. A10 CHECK POWER LIFTGATE ROD OPERATION Check for correct function of power liftgate rod and cable. Correctly attached to motor and liftgate. Cable turns with actuator. Is the power liftgate rod operating correctly? YES : Go to A11 . NO : REPAIR as necessary. If installing a new power liftgate rod, REFER to «Power Liftgate Rod»(/ford/taurus-x/i-2007-2009/remont/exterior-body-panels/#body-panel-system-body-closures__power-liftgate-rod) . CLEAR the DTCs. REPEAT the LTM self-test.
11. A11 CHECK FOR VOLTAGE AT THE POWER LIFTGATE MOTOR AND CLUTCH Key in ON position. Liftgate in the fully closed position. With the motor/clutch connected and while activating the power liftgate control switch, measure the voltage between power liftgate motor/clutch C4332-1, circuit CPR57 (GN/WH) backprobe and ground; then between power liftgate motor/clutch C4332-2, circuit CPR69 (BN/BU), backprobe and power liftgate motor/clutch C4332-7, circuit GD147 (BK/VT), backprobe. Are both of the voltages greater than 10 volts while activating the power liftgate switch? YES : If no DTCs were present, go to A18 . If DTCs were present, INSTALL a new power liftgate motor. REFER to «Power Liftgate Motor»(/ford/taurus-x/i-2007-2009/remont/exterior-body-panels/#body-panel-system-body-closures) . CLEAR the DTCs. REPEAT the LTM self-test. NO : Go to A12 .
12. A12 CHECK THE MOTOR AND CLUTCH VOLTAGE OUTPUTS AT THE LTM With the LTM connected, measure the voltage between LTM C4174B-6, circuit CPR58 (GN/OG), backprobe and ground; then between LTM C4174B-8, circuit CPR69 (BN/BU), backprobe and ground. Are the voltages greater than 10 volts while activating the power liftgate switch? YES : Go to A14 . NO : Go to A13 .
13. A13 CHECK FOR VOLTAGE AT THE LTM Key in OFF position. Disconnect: LTM C4174B Measure the voltage between LTM C4174B-4, circuit SBB29 (GY/RD), harness side and ground. Is the voltage greater than 10 volts? YES : If you are here because of DTC B2552, go to A31 . Otherwise, go to A18 . NO : VERIFY Battery Junction Box (BJB) fuse 29 (30A) is OK. If OK, REPAIR the circuit. CLEAR the DTCs. REPEAT the LTM self-test. If not OK, REFER to the Wiring Diagrams Manual to identify the possible causes of the circuit short. CLEAR the DTCs. REPEAT the LTM self-test.
14. A14 CHECK CIRCUIT CLUTCH GROUND CIRCUIT GD147 (BK/VT) FOR AN OPEN Key in OFF position. Disconnect: LTM C4174A Disconnect: Power Liftgate Motor C4332 Measure the resistance between power liftgate motor C4332-7, circuit GD147 (BK/VT), harness side and ground. Is the resistance less than 5 ohms? YES : Go to A15 . NO : REPAIR the circuit. CLEAR the DTCs. REPEAT the LTM self-test.
15. A15 CHECK THE MOTOR/CLUTCH CIRCUITS FOR AN OPEN Measure the resistance between LTM C4174B, harness side and the power liftgate motor/clutch C4332, harness side, using the following chart: LTM Circuit Power Liftgate Motor/Clutch C4174B-5 CPR57 (GN/WH) C4332-1 C4174B-6 CPR58 (GN/OG) C4332-5 C4174B-8 CPR69 (BN/BU) C4332-2 Are the resistances less than 5 ohms? YES : Go to A16 . NO : REPAIR the circuit. CLEAR the DTCs. REPEAT the LTM self-test.
16. A16 CHECK THE MOTOR/CLUTCH CIRCUITS FOR A SHORT TO GROUND Key in OFF position. Disconnect: LTM C4174A Disconnect: Power Liftgate Motor C4332 Measure the resistance between LTM C4174B-5, circuit CPR57 (GN/WH), harness side and ground; between LTM C4174B-6, circuit CPR58 (GN/OG), harness side and ground; then between LTM C4174B-8, circuit CPR69 (BN/BU), harness side and ground. Are the resistances greater than 10,000 ohms? YES : Go to A17 . NO : REPAIR the circuit. If DTC B106E was present, CLEAR the DTCs. REPEAT the LTM self-test.
17. A17 CHECK THE MOTOR/CLUTCH CIRCUITS FOR A SHORT TO VOLTAGE Key in ON position. Measure the voltage between LTM C4174B-5, circuit CPR57 (GN/WH), harness side and ground; between LTM C4174B-6, circuit CPR58 (GN/OG), harness side and ground; then between LTM C4174B-8, circuit CPR69 (BN/BU), harness side and ground. Is any voltage present? YES : REPAIR the circuit. CLEAR the DTCs. REPEAT the LTM self-test. NO : CHECK the power liftgate motor and clutch connectors for corrosion or pushed-out pins. REPAIR as necessary. CLEAR the DTCs. REPEAT the LTM self-test.
18. A18 CHECK THE POSITION SENSOR PID Key in OFF position. Connect: All LTM Connectors Connect: Power Liftgate Motor C4332 Key in ON position. Open the liftgate to the full open position. Enter the following diagnostic mode on the diagnostic tool: DataLogger - LTM Monitor the LTM PIDs OPT_SEN_1 and OPT_SEN_2 while slowly closing the liftgate. Do both of the PID values alternate from ACTIVE to INACTIVE while the liftgate is moving? YES : Go to A27 . NO : Go to A19 .
19. A19 CHECK THE POSITION SENSOR POWER CIRCUIT Disconnect: Power Liftgate Motor C4332 Key in ON position. Measure the voltage between power liftgate motor C4332-4, circuit CPR55 (GN/BU), harness side and ground. Is the voltage approximately 4 to 5 volts? YES : Go to A21 . NO : Go to A20 .
20. A20 CHECK THE POSITION SENSOR POWER CIRCUIT FOR AN OPEN OR SHORT TO GROUND Key in OFF position. Disconnect: LTM C4174A Measure the resistance between LTM C4174A-6, circuit CPR55 (GN/BU), harness side and power liftgate motor C4332-4, circuit CPR55 (GN/BU), harness side; and between LTM C4174A-6, circuit CPR55 (GN/BU), harness side and ground. Is the resistance less than 5 ohms between LTM and power liftgate motor; and greater than 10,000 ohms between LTM and ground? YES : Go to A31 . NO : REPAIR the circuit. CLEAR the DTCs. REPEAT the LTM self-test.
21. A21 CHECK THE POSITION SENSOR RETURN CIRCUIT Key in OFF position. Disconnect: Power Liftgate Motor C4332 Key in ON position. Measure the resistance between power liftgate motor C4332-9, circuit RPR55 (WH/BU), harness side and ground. Is the resistance less than 50 ohms? YES : Go to A23 . NO : Go to A22 .
22. A22 CHECK THE POSITION SENSOR RETURN CIRCUIT FOR AN OPEN Key in OFF position. Disconnect: LTM C4174A Measure the resistance between LTM C4174A-7, circuit RPR55 (WH/BU), harness side and power liftgate motor C4332-9, circuit RPR55 (WH/BU), harness side. Is the resistance less than 5 ohms? YES : Go to A31 . NO : REPAIR the circuit. CLEAR the DTCs. REPEAT the LTM self-test.
23. A23 CHECK THE POSITION SENSOR CIRCUITS FOR AN OPEN Key in ON position. Measure the voltage between power liftgate motor C4332-3, circuit VPR53 (BU/WH), harness side and ground; and between power liftgate motor C4332-8, circuit VPR54 (BU/BN), harness side and ground. Is the voltage approximately 5 volts for both measurements? YES : INSTALL a new power liftgate motor. REFER to «Power Liftgate Motor»(/ford/taurus-x/i-2007-2009/remont/exterior-body-panels/#body-panel-system-body-closures) . CLEAR the DTCs. REPEAT the LTM self-test. NO : Go to A24 .
24. A24 CHECK THE POSITION SENSOR CIRCUITS FOR AN OPEN Key in OFF position. Disconnect: LTM C4174A Measure the resistance between power liftgate motor C4332, harness side and LTM C4174A, harness side using the following chart: Power Liftgate Motor Circuit LTM C4332-3 VPR53 (BU/WH) C4174A-20 C4332-8 VPR54 (BU/BN) C4174A-21 Are the resistances less than 5 ohms? YES : Go to A25 . NO : REPAIR the circuit. CLEAR the DTCs. REPEAT the LTM self-test.
25. A25 CHECK THE POSITION SENSOR CIRCUITS FOR A SHORT TO GROUND Measure the resistance between power liftgate motor C4332-8, circuit VPR54 (BU/BN), harness side and ground; and between power liftgate motor C4332-3, circuit VPR53 (BU/WH), harness side and ground. Are the resistances greater than 10,000 ohms? YES : Go to A26 . NO : REPAIR the circuit. CLEAR the DTCs. REPEAT the LTM self-test.
26. A26 CHECK THE POSITION SENSOR CIRCUITS FOR A SHORT TO VOLTAGE Key in ON position. Measure the voltage between power liftgate motor C4332-8, circuit VPR54 (BU/BN), harness side and ground; and between power liftgate motor C4332-3, circuit VPR53 (BU/WH), harness side and ground. Is any voltage present? YES : REPAIR the circuit. CLEAR the DTCs. REPEAT the LTM self-test. NO : Go to A31 .
27. A27 CHECK THE UNLATCH/CINCHING MOTOR CIRCUITS Key in OFF position. Disconnect: LTM C4174B Close the power liftgate. NOTE: Do not apply power and ground to the unlatch actuator circuits for more than a few seconds or damage to the motor may occur. Connect a fused jumper wire between LTM C4174B-3, circuit CPR62 (WH/BU), harness side and the positive side of the battery; and connect a jumper between LTM C4174B-2, circuit CPR61 (BN), harness side and ground. Does the unlatch/cinching motor activate when power and ground are applied? YES : Go to A31 . NO : Go to A28 .
28. A28 CHECK THE UNLATCH/CINCHING MOTOR CIRCUITS FOR AN OPEN Disconnect: Liftgate Latch/Unlatch Assembly C4339 Measure the resistance between power liftgate latch C4339, harness side and LTM C4174B, harness side, using the following chart: Liftgate Latch/Unlatch Assembly Circuit LTM C4339-5 CPR61 (BN) C4174B-2 C4339-7 CPR62 (WH/BU) C4174B-3 Are the resistances less than 5 ohms? YES : Go to A29 . NO : REPAIR the circuit. CLEAR the DTCs. REPEAT the LTM self-test.
29. A29 CHECK THE UNLATCH/CINCHING MOTOR CIRCUITS FOR A SHORT TO GROUND Measure the resistance between power liftgate latch C4339-5, circuit CPR61 (BN), harness side and ground; then between power liftgate latch C4339-7, circuit CPR62 (WH/BU), harness side and ground. Are the resistances greater than 10,000 ohms? YES : Go to A30 . NO : REPAIR the circuit. CLEAR the DTCs. REPEAT the LTM self-test.
30. A30 CHECK THE UNLATCH ACTUATOR CIRCUITS FOR A SHORT TO VOLTAGE Key in ON position. Measure the voltage between power liftgate latch C4339-5, circuit CPR61 (BN), harness side and ground; then between power liftgate latch C4339-7, circuit CPR62 (WH/BU), harness side and ground. Is voltage present on either circuit? YES : REPAIR the circuit. CLEAR the DTCs. REPEAT the LTM self-test. NO : CHECK the power liftgate latch connectors for bent or corroded connections on the component side and harness side. REPAIR as necessary. INSTALL a new power liftgate latch. REFER to «HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS»(/ford/taurus-x/i-2007-2009/remont/door-locks-anti-theft-systems/#handles-locks-latches-and-entry-systems) article. CLEAR the DTCs. REPEAT the LTM self-test.
31. A31 CHECK FOR CORRECT LTM OPERATION Disconnect all the LTM connectors. Check for: corrosion. pushed-out pins. Connect all the LTM connectors and make sure they are seated correctly. Make sure the liftgate is fully CLOSED. Operate the system and verify the concern is still present. Is the concern still present? YES : INSTALL a new LTM. REFER to «Liftgate/Trunk Module (LTM)»(/ford/taurus-x/i-2007-2009/remont/exterior-body-panels/#body-panel-system-body-closures) . REPEAT the LTM self-test. NO : The system is operating correctly at this time. Concern may have been caused by a loose or corroded connector. CLEAR the DTCs. REPEAT the LTM self-test.

Pinpoint Test B: The Power Liftgate is Inoperative From an Individual Switch

Refer to appropriate SYSTEM WIRING DIAGRAMS article, Power Liftgate/Retractable Running Board for schematic and connector information.

If the power liftgate is operated from the power liftgate control switch (instrument panel), circuit CPR63 (GY/YE) is grounded by the open/close switch, which signals the Liftgate/Trunk Module (LTM) of the open/close request. If the power liftgate is operated from the rear switch (quarter trim panel), circuit CPR63 (GY/YE) is grounded by the rear switch through circuit GD148 (BK/YE). If the power liftgate is operated from the liftgate handle, the Smart Junction Box (SJB) sends a voltage signal to the LTM through circuit CPL10 (GN/WH).

This pinpoint test is intended to diagnose the following

1. Wiring, terminals or connectors
2. Power liftgate control switch (instrument panel)
3. Power liftgate rear control switch (quarter trim panel)
4. LTM
5. SJB

Scheme 60

Scheme 61

Scheme 62

Scheme 63

Scheme 64

Scheme 65

Scheme 66

Scheme 67

1. B1 RETRIEVE THE DTCs FROM THE LTM AND THE SJB Use the recorded LTM DTCs and SJB DTCs from the continuous and self-tests. Are any power liftgate DTCs present? YES : For SJB DTC B2666, REFER to «HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS»(/ford/taurus-x/i-2007-2009/remont/door-locks-anti-theft-systems/#handles-locks-latches-and-entry-systems) article to diagnose the liftgate handle release switch. For SJB module DTC B273A or B273B, go to B4 . For LTM DTC B1105, go to B8 . For LTM DTC B2703, go to B12 . NO : Go to B2 .
2. B2 CHECK THE OPERATION OF THE POWER LIFTGATE SWITCHES NOTE: Make sure the power liftgate is ON (enabled) in the message center. Close the liftgate to the full closed position (manually if necessary). Electronically unlock the vehicle. Activate the power liftgate from the power liftgate control switch (instrument panel). Activate the power liftgate from the remote transmitter. Activate the power liftgate from the liftgate exterior handle. With the liftgate in the open position, activate the power liftgate from the power liftgate rear control switch (quarter trim panel). Does the power liftgate open/close from at least one switch? YES : If the power liftgate control switch is inoperative, go to B12 . If the exterior handle is inoperative, go to B3 . If the remote transmitter is inoperative, go to «Symptom Chart»(/ford/taurus-x/i-2007-2009/remont/exterior-body-panels/#body-panel-system-body-closures) . If the power liftgate rear control switch is inoperative, go to B8 . NO : Go to «Pinpoint Test A»(/ford/taurus-x/i-2007-2009/remont/exterior-body-panels/#body-panel-system-body-closures__pinpoint-test-a-the-power-liftgate) to diagnose an inoperative power liftgate.
3. B3 CHECK THE LIFTGATE HANDLE PID Key in ON position. Enter the following diagnostic mode on the diagnostic tool: DataLogger - SJB Monitor the SJB PID GATE_SW while activating the liftgate release handle. Does the switch change states from INACTIVE to ACTIVE when the liftgate release handle is activated? YES : Go to B4 . NO : REFER to «HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS»(/ford/taurus-x/i-2007-2009/remont/door-locks-anti-theft-systems/#handles-locks-latches-and-entry-systems) article to diagnose the liftgate handle release switch.
4. B4 CHECK THE SJB RELEASE CIRCUIT OUTPUT Disconnect: LTM C4174A Measure the voltage between LTM C4174A-12, circuit CPL10 (GN/WH), harness side and ground while commanding the liftgate open from the power liftgate control switch (instrument panel). Is the voltage greater than 10 volts when the power liftgate control switch is activated, and approximately 5 volts when the power liftgate control switch is inactive? YES : Go to B16 . NO : Go to B5 .
5. B5 CHECK CIRCUIT CPL10 (GN/WH) FOR A SHORT TO VOLTAGE Key in OFF position. Disconnect: SJB Module C2280D Key in ON position. Measure the voltage between LTM C4174A-12, circuit CPL10 (GN/WH), harness side and ground. Is the voltage greater than 10 volts? YES : REPAIR the circuit. CLEAR the DTCs. REPEAT the SJB self-test. NO : Go to B6 .
6. B6 CHECK CIRCUIT CPL10 (GN/WH) FOR AN OPEN OR SHORT TO GROUND Measure the resistance between LTM C4174A-12, circuit CPL10 (GN/WH), harness side and SJB C2280D-15, circuit CPL10 (GN/WH), harness side; and between LTM C4174A-12, circuit CPL10 (GN/WH), harness side and ground. Is the resistance less than 5 ohms between LTM and the SJB; and greater than 10,000 ohms between LTM and ground? YES : Go to B7 . NO : REPAIR the circuit. CLEAR the DTCs. REPEAT the SJB self-test.
7. B7 CHECK FOR CORRECT SJB MODULE OPERATION Disconnect all the SJB and LTM connectors. Check for: corrosion. pushed-out pins. Connect all the SJB and LTM connectors and make sure they are seated correctly. Make sure the liftgate is fully CLOSED. Operate the system and verify the concern is still present. Is the concern still present? YES : INSTALL a new SJB module. REPEAT the SJB module self-test. NO : The system is operating correctly at this time. Concern may have been caused by a loose or corroded connector. CLEAR the DTCs. REPEAT the SJB module self-test.
8. B8 CHECK THE REAR/OPEN SWITCH (REAR_OC) PID Enter the following diagnostic mode on the diagnostic tool: DataLogger - LTM Monitor the LTM PID REAR_OC while operating the power liftgate rear control switch. Does the PID state change or agree with the rear control switch status? YES : Go to B16 . NO : Go to B9 .
9. B9 CHECK POWER LIFTGATE REAR SWITCH CIRCUIT OPERATION Disconnect: LTM C4174A Measure the resistance between LTM C4174A-24, circuit CPR63 (GY/YE), harness side and ground while depressing and releasing the power liftgate rear switch. Is the resistance less than 10 ohms with the power liftgate rear switch depressed, and greater than 10,000 ohms when the power liftgate rear switch is released? YES : Go to B16 . NO : Go to B10 .
10. B10 CHECK CIRCUIT GD148 (BK/YE) FOR AN OPEN Key in OFF position. Disconnect: Power Liftgate Rear Open/Close Switch C4216 Measure the resistance between power liftgate rear switch C4216-4, circuit GD148 (BK/YE), harness side and ground. Is the resistance less than 5 ohms? YES : Go to B11 . NO : REPAIR the circuit. CLEAR the DTCs. REPEAT the LTM self-test.
11. B11 CHECK CIRCUIT CPR70 (GN) FOR AN OPEN OR SHORT TO GROUND Measure the resistance between LTM C4174A-24, circuit CPR63 (GY/YE), harness side and power liftgate rear switch C4216-3, circuit CPR63 (GY/YE), harness side; and between LTM C4174A-24, circuit CPR63 (GY/YE), harness side and ground. Is the resistance less than 5 ohms between LTM and power liftgate rear switch; and greater than 10,000 ohms between LTM and ground? YES : INSTALL a new power liftgate rear switch. CLEAR the DTCs. REPEAT the LTM self-test. NO : REPAIR the circuit. CLEAR the DTCs. REPEAT the LTM self-test.
12. B12 CHECK POWER LIFTGATE SWITCH OPERATION Enter the following diagnostic mode on the diagnostic tool: DataLogger - LTM Monitor the LTM PID PLGM_SW while operating the power liftgate control switch (instrument panel). Does the PID state change/agree with the switch status? YES : Go to B16 . NO : Go to B13 .
13. B13 CHECK POWER LIFTGATE CONTROL SWITCH CIRCUIT OPERATION Disconnect: LTM C4174A Measure the resistance between LTM C4174A-16, circuit CPR63 (GY/YE), harness side and ground while depressing and releasing the power liftgate control switch (instrument panel). Is the resistance less than 13 ohms with the power liftgate control switch depressed, and greater than 10,000 ohms when the power liftgate control switch is released? YES : Go to B16 . NO : Go to B14 .
14. B14 CHECK CIRCUIT GD111 (BK/BU) FOR AN OPEN Key in OFF position. Disconnect: Liftgate/Traction Control/Hazard Switch C2114 Measure the resistance between power liftgate control switch C2114-4, circuit GD111 (BK/BU), harness side and ground. Is the resistance less than 5 ohms? YES : Go to B15 . NO : REPAIR the circuit. CLEAR the DTCs. REPEAT the LTM self-test.
15. B15 CHECK CIRCUIT GD111 (BK/BU) FOR AN OPEN OR SHORT TO GROUND Measure the resistance between LTM C4174A-16, circuit CPR63 (GY/YE), harness side and power liftgate control switch C2114-10, circuit CPR63 (GY/YE), harness side; and between LTM C2114-10, circuit CPR63 (GY/YE), harness side and ground. Is the resistance less than 5 ohms between LTM and power liftgate control switch; and greater than 10,000 ohms between LTM and ground? YES : INSTALL a new liftgate/traction control/hazard switch. CLEAR the DTCs. REPEAT the LTM self-test. NO : REPAIR the circuit. CLEAR the DTCs. REPEAT the LTM self-test. TEST the system for normal operation.
16. B16 CHECK FOR CORRECT LTM OPERATION Disconnect all the LTM connectors. Check for: corrosion. pushed-out pins. Connect all the LTM connectors and make sure they are seated correctly. Make sure the liftgate is fully CLOSED. Operate the system and verify the concern is still present. Is the concern still present? YES : INSTALL a new LTM. REFER to «Liftgate/Trunk Module (LTM)»(/ford/taurus-x/i-2007-2009/remont/exterior-body-panels/#body-panel-system-body-closures) . REPEAT the LTM self-test. NO : The system is operating correctly at this time. Concern may have been caused by a loose or corroded connector. CLEAR the DTCs. REPEAT the LTM self-test.

Pinpoint Test C: The Power Liftgate Does Not Operate Correctly - Stops in Secondary Latch Position (Does Not Pull into Primary Latch Position)

Refer to appropriate SYSTEM WIRING DIAGRAMS article, Power Liftgate/Retractable Running Board for schematic and connector information.

When the power liftgate moves in the close direction, the Liftgate/Trunk Module (LTM) monitors the detent switch, secondary forkbolt switch and the primary forkbolt switch. When the combination of signals is received that indicates the liftgate has reached the secondary latch position, the LTM supplies 12 volts to the unlatch/cinching motor on circuit CPR61 (BN) and ground on circuit CPR62 (WH/BU). The unlatch/cinching motor rotates the latch mechanism which pulls the liftgate into primary latch position.

1. DTC B2019 Liftgate Exceeded Time Allowed to Cinch Door - If the cinching sequence has been active for more than 5 seconds, the LTM will set this DTC.
2. DTC B2908 Latch Switch Invalid - If switch signals are invalid at start of self-test or no signal transitions during releasing/cinching, the LTM will set this DTC.

This pinpoint test is intended to diagnose the following

1. Liftgate alignment
2. Latch striker alignment
3. Wiring, terminals or connectors
4. Power liftgate latch
5. LTM

Scheme 68

Scheme 69

1. C1 RETRIEVE THE DTCs FROM THE LTM Use the recorded LTM DTCs from the continuous and self-tests. Is power liftgate DTC B2019 present? YES : CHECK the liftgate alignment. REFER to «Liftgate Alignment»(/ford/taurus-x/i-2007-2009/remont/exterior-body-panels/#body-panel-system-body-closures__liftgate-alignment) . If OK, go to C2 . NO : Go to C2 .
2. C2 CHECK THE DETENT AND FORKBOLT SWITCH PID Enter the following diagnostic mode on the diagnostic tool: DataLogger - LTM Operate the liftgate manually while monitoring the following LTM PIDs: Detent Switch Status (DETENTSW) Forkbolt Switch Status (FORKBLT_S) Forkbolt Secondary Switch (FKSWSEC) NOTE: The liftgate is in the primary position when the liftgate is in the full closed position. The liftgate is in the unlatch position when the liftgate is open and completely out of the striker. The liftgate can be placed in the unlatched position by lifting up on the liftgate handle. Begin with the liftgate in the open position, then slowly close the liftgate into each of the latch positions specified by the table below. Liftgate Latch Position DETENTSW FORKBLT_S FKSWSEC Fully Unlatched Inactive a Active Active Primary Active Inactive Inactive a If detent switch is active in the fully unlatched position, manually attempt to rotate the forkbolt towards the latched position. Do the switch states agree with the table? YES : Go to C7 . NO : Go to C3 .
3. C3 CHECK THE OPERATION OF THE DETENT AND FORKBOLT SWITCHES Key in OFF position. Disconnect: LTM C4174A Measure the resistance between LTM C4174A, harness side and ground at each of the connector pins and each latch position specified by the chart below. Liftgate Latch Position C4174A Circuit Resistance Fully Unlatched Pin 3, circuit CPR66 (GY/YE) Greater than 10,000 ohms a Fully Unlatched Pin 4, circuit CPR64 (VT/OG) Less than 5 ohms Fully Unlatched Pin 5, circuit CPR65 (BU/GN) Less than 5 ohms Primary Pin 3, circuit CPR66 (GY/YE) Less than 5 ohms Primary Pin 4, circuit CPR64 (VT/OG) Greater than 10,000 ohms Primary Pin 5, circuit CPR65 (BU/GN) Greater than 10,000 ohms a If resistance measured is less than 5 ohms, manually rotate the forkbolt to the latched position and retest. Do the resistance values agree with the chart? YES : Go to C7 . NO : Go to C4 .
4. C4 CHECK THE DETENT AND FORKBOLT SWITCH GROUND CIRCUIT Disconnect: Power Liftgate Latch/Unlatch Assembly C4339 Measure the resistance between power liftgate latch C4339-8, circuit GD147 (BK/VT), harness side and ground. Is the resistance less than 5 ohms? YES : Go to C5 . NO : REPAIR the circuit. CLEAR the DTCs. REPEAT the LTM self-test.
5. C5 CHECK THE DETENT AND FORKBOLT SWITCH CIRCUITS FOR AN OPEN Measure the resistance between power liftgate latch/unlatch assembly C4339, harness side and LTM C4174A, harness side using the following chart: Power Liftgate Latch/Unlatch Assembly Circuit LTM C4339-1 CPR65 (BU/GN) C4174A-5 C4339-3 CPR64 (VT/OG) C4174A-4 C4339-2 CPR66 (GY/YE) C4174A-3 Is the resistance less than 5 ohms on all circuits? YES : Go to C6 . NO : REPAIR the circuit. CLEAR the DTCs. REPEAT the LTM self-test.
6. C6 CHECK THE DETENT AND FORKBOLT SWITCH CIRCUITS FOR A SHORT TO GROUND Measure the resistance between LTM C4174A-4, circuit CPR64 (VT/OG), harness side and ground; then between LTM C4174A-5, circuit CPR65 (BU/GN), harness side and ground; then between LTM C4174A-3, circuit CPR66 (GY/YE), harness side and ground. Is the resistance greater than 10,000 ohms on all circuits? YES : CHECK the power liftgate latch connectors for bent or corroded connections on the component side and harness side. REPAIR as necessary. INSTALL a new power liftgate latch. REFER to «HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS»(/ford/taurus-x/i-2007-2009/remont/door-locks-anti-theft-systems/#handles-locks-latches-and-entry-systems) article. CLEAR the DTCs. REPEAT the LTM self-test. NO : REPAIR the circuit. CLEAR the DTCs. REPEAT the LTM self-test.
7. C7 CHECK FOR CORRECT LTM OPERATION Disconnect all the LTM connectors. Check for: corrosion. pushed-out pins. Connect all the LTM connectors and make sure they are seated correctly. Make sure the liftgate is fully CLOSED. Operate the system and verify the concern is still present. Is the concern still present? YES : INSTALL a new LTM. REFER to «Liftgate/Trunk Module (LTM)»(/ford/taurus-x/i-2007-2009/remont/exterior-body-panels/#body-panel-system-body-closures) . REPEAT the LTM self-test. NO : The system is operating correctly at this time. Concern may have been caused by a loose or corroded connector. CLEAR the DTCs. REPEAT the LTM self-test.

Pinpoint Test D: The Power Liftgate Does Not Operate Correctly - Reverses During the Power Close Operation

Refer to appropriate SYSTEM WIRING DIAGRAMS article, Power Liftgate/Retractable Running Board for schematic and connector information.

When the power liftgate moves in the close direction, the Liftgate/Trunk Module (LTM) monitors the pinch strips and position sensor for obstacle detection. The LTM uses a 5-volt reference signal on circuit CPR52 (YE/VT) and a return signal on circuit RPR52 (VT/GY) for the left pinch strip. The LTM uses a 5-volt reference signal on circuit CPR51 (YE/OG) and a return signal on circuit RPR52 (VT/GY) for the right pinch strip. The right and left pinch strip return signal circuits are spliced together.

The position sensor receives 5 volts from the LTM through circuit CPR55 (GN/BU) and ground from the LTM through circuit RPR55 (WH/BU). The position sensor output signal is supplied to the LTM through circuit VPR53 (BU/WH) and VPR54 (BU/BN).

1. DTC B107D Obstacle Detected While Closing - The LTM will set this DTC if an obstacle is detected during powered open/close during self-test only.
2. DTC B2419 Sensor 1 Invalid - This DTC sets when the LTM detects the position sensor feedback signals are not correct.
3. DTC B2420 Sensor 2 Invalid - This DTC sets when the LTM detects the position sensor feedback signals are not correct.

This pinpoint test is intended to diagnose the following

1. Mechanical binding
2. Power liftgate latch striker alignment
3. Power liftgate latch
4. Power liftgate motor
5. LTM
6. Wedges
7. Wiring, terminals or connectors

1. D1 CHECK THE MANUAL OPERATION OF THE LIFTGATE Turn the power liftgate OFF (disable) from the message center. While manually opening and closing the liftgate, check the liftgate for: liftgate/wedge alignment. strut operation (struts should push open liftgate when beyond half open). power liftgate rod (should move freely while manually opening and closing liftgate and should be securely mounted to the liftgate and bracket). power liftgate latch (should latch completely). Does the liftgate open and close correctly? YES : If the liftgate reverses near the midpoint of travel, go to D2 . If the liftgate reverses near or at the latch, go to D10 . NO : REPAIR as necessary. ALIGN as necessary. REFER to «Liftgate Alignment»(/ford/taurus-x/i-2007-2009/remont/exterior-body-panels/#body-panel-system-body-closures__liftgate-alignment) . CLEAR the DTCs. REPEAT the LTM self-test.
2. D2 CHECK THE POSITION SENSOR PID Key in OFF position. Connect: All LTM Connectors Connect: Power Liftgate Motor C4332 Key in ON position. Open the liftgate to the full open position. Enter the following diagnostic mode on the diagnostic tool: DataLogger - LTM Monitor the LTM PIDs OPT_SEN_1 and OPT_SEN_2 while slowly closing the liftgate. Do both of the PID values alternate from ACTIVE to INACTIVE while the liftgate is moving? YES : Go to D11 . NO : Go to D3 .
3. D3 CHECK THE POSITION SENSOR POWER CIRCUIT Disconnect: Power Liftgate Motor C4332 Key in ON position. Measure the voltage between power liftgate motor C4332-4, circuit CPR55 (GN/BU), harness side and ground. Is the voltage approximately 5 volts? YES : Go to D5 . NO : Go to D4 .
4. D4 CHECK THE POSITION SENSOR POWER CIRCUIT FOR AN OPEN OR SHORT TO GROUND Key in OFF position. Disconnect: LTM C4174A Measure the resistance between LTM C4174A-6, circuit CPR55 (GN/BU), harness side and power liftgate motor C4332-4, circuit CPR55 (GN/BU), harness side; and between LTM C4174A-6, circuit CPR55 (GN/BU), harness side and ground. Is the resistance less than 5 ohms between LTM and power liftgate motor; and greater than 10,000 ohms between LTM and ground? YES : Go to D16 . NO : REPAIR the circuit. CLEAR the DTCs. REPEAT the LTM self-test.
5. D5 CHECK THE POSITION SENSOR RETURN CIRCUIT Key in OFF position. Disconnect: Power Liftgate Motor C4332 Key in ON position. Measure the resistance between power liftgate motor C4332-9, circuit RPR55 (WH/BU), harness side and ground. Is the resistance less than 50 ohms? YES : Go to D7 . NO : Go to D6 .
6. D6 CHECK THE POSITION SENSOR RETURN CIRCUIT FOR AN OPEN Key in OFF position. Disconnect: LTM C4174A Measure the resistance between LTM C4174A-7, circuit RPR55 (WH/BU), harness side and power liftgate motor C4332-9, circuit RPR55 (WH/BU), harness side. Is the resistance less than 5 ohms? YES : Go to D16 . NO : REPAIR the circuit. CLEAR the DTCs. REPEAT the LTM self-test.
7. D7 CHECK THE POSITION SENSOR CIRCUITS FOR AN OPEN Key in ON position. Measure the voltage between power liftgate motor C4332-8, circuit VPR54 (BU/BN), harness side and ground; and between power liftgate motor C4332-3, circuit VPR53 (BU/WH), harness side and ground. Is the voltage approximately 5 volts for both measurements? YES : INSTALL a new power liftgate motor. REFER to «Power Liftgate Motor»(/ford/taurus-x/i-2007-2009/remont/exterior-body-panels/#body-panel-system-body-closures) . CLEAR the DTCs. REPEAT the LTM self-test. NO : Go to D8 .
8. D8 CHECK THE POSITION SENSOR CIRCUITS FOR AN OPEN Key in OFF position. Disconnect: LTM C4174A Measure the resistance between power liftgate motor C4332, harness side and LTM C4174A, harness side using the following chart: Power Liftgate Motor Circuit LTM C4332-3 VPR53 (BU/WH) C4174A-20 C4332-8 VPR54 (BU/BN) C4174A-21 Are the resistances less than 5 ohms? YES : Go to D9 . NO : REPAIR the circuit. CLEAR the DTCs. REPEAT the LTM self-test.
9. D9 CHECK THE POSITION SENSOR CIRCUITS FOR A SHORT TO GROUND Measure the resistance between power liftgate motor C4332-3, circuit VPR53 (BU/WH), harness side and ground; and between power liftgate motor C4332-8, circuit VPR54 (BU/BN), harness side and ground. Are the resistances greater than 10,000 ohms? YES : Go to D10 . NO : REPAIR the circuit. CLEAR the DTCs. REPEAT the LTM self-test.
10. D10 CHECK THE POSITION SENSOR CIRCUITS FOR A SHORT TO VOLTAGE Key in ON position. Measure the voltage between power liftgate motor C4332-3, circuit VPR53 (BU/WH), harness side and ground; and between power liftgate motor C4332-8, circuit VPR54 (BU/BN), harness side and ground. Is any voltage present? YES : REPAIR the circuit. CLEAR the DTCs. REPEAT the LTM self-test. NO : Go to D16 .
11. D11 CHECK THE DETENT AND FORKBOLT SWITCH PID Enter the following diagnostic mode on the diagnostic tool: DataLogger - LTM Operate the liftgate manually while monitoring the following LTM PIDs: Detent Switch Status (DETENTSW) Forkbolt Switch Status (FORKBLT_S) Forkbolt Secondary Switch (FKSWSEC) NOTE: The liftgate is in the primary position when the liftgate is in the full closed position. The liftgate is in the unlatch position when the liftgate is open and completely out of the striker. The liftgate can be placed in the unlatched position by lifting up on the liftgate handle. Begin with the liftgate in the open position, then slowly close the liftgate into each of the latch positions specified by the table below. Liftgate Latch Position DETENTSW FORKBLT_S FKSWSEC Fully Unlatched Inactive a Active Active In primary Active Inactive Inactive a If detent switch is active in the fully unlatched position, manually attempt to rotate the forkbolt towards the latched position. Do the switch states agree with the table? YES : Go to D16 . NO : Go to D12 .
12. D12 CHECK THE OPERATION OF THE DETENT AND FORKBOLT SWITCHES Key in OFF position. Disconnect: LTM C4174A Measure the resistance between LTM C4174A, harness side and ground at each of the connector pins and each latch position specified by the chart below. Liftgate Latch Position C4174A Circuit Resistance Fully Unlatched Pin 3, circuit CPR66 (GY/YE) Greater than 10,000 ohms a Fully Unlatched Pin 5, circuit CPR65 (BU/GN) Less than 5 ohms Fully Unlatched Pin 4, circuit CPR64 (VT/OG) Less than 5 ohms Primary Pin 3, circuit CPR66 (GY/YE) Less than 5 ohms Primary Pin 5, circuit CPR65 (BU/GN) Greater than 10,000 ohms Primary Pin 4, circuit CPR64 (VT/OG) Greater than 10,000 ohms a If resistance measured is less than 5 ohms, manually rotate the forkbolt to the latched position and retest. Do the resistance values agree with the chart? YES : Go to D16 . NO : Go to D13 .
13. D13 CHECK THE DETENT AND FORKBOLT SWITCH GROUND CIRCUIT Disconnect: Liftgate Latch/Unlatch Assembly C4339 Measure the resistance between power liftgate latch/unlatch assembly C4339-8, circuit GD147 (BK/VT), harness side and ground. Is the resistance less than 5 ohms? YES : Go to D14 . NO : REPAIR the circuit. CLEAR the DTCs. REPEAT the LTM self-test.
14. D14 CHECK THE DETENT AND FORKBOLT SWITCH CIRCUITS FOR AN OPEN Measure the resistance between power liftgate latch/unlatch assembly C4339, harness side and LTM C4174A, harness side using the following chart: Power Liftgate Latch/Unlatch Assembly Circuit LTM C4339-1 CPR65 (BU/GN) C4174A-5 C4339-3 CPR64 (VT/OG) C4174A-4 C4339-2 CPR66 (GY/YE) C4174A-3 Is the resistance less than 5 ohms on all circuits? YES : Go to D15 . NO : REPAIR the circuit. CLEAR the DTCs. REPEAT the LTM self-test.
15. D15 CHECK THE DETENT AND FORKBOLT SWITCH CIRCUITS FOR A SHORT TO GROUND Measure the resistance between LTM C4174A-4, circuit CPR64 (VT/OG), harness side and ground; between LTM C4174A-5, circuit CPR65 (BU/GN), harness side and ground; then between LTM C4174A-3, circuit CPR66 (GY/YE), harness side and ground. Are the resistances greater than 10,000 ohms on all circuits? YES : CHECK the power liftgate latch connector for bent or corroded connections on the component side and harness side. REPAIR as necessary. INSTALL a new power liftgate latch. REFER to «HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS»(/ford/taurus-x/i-2007-2009/remont/door-locks-anti-theft-systems/#handles-locks-latches-and-entry-systems) article. CLEAR the DTCs. REPEAT the LTM self-test. NO : REPAIR the circuit. CLEAR the DTCs. REPEAT the LTM self-test.
16. D16 CHECK FOR CORRECT LTM OPERATION Disconnect all the LTM connectors. Check for: corrosion. pushed-out pins. Connect all the LTM connectors and make sure they are seated correctly. Make sure the liftgate is fully CLOSED. Operate the system and verify the concern is still present. Is the concern still present? YES : INSTALL a new LTM. REFER to «Liftgate/Trunk Module (LTM)»(/ford/taurus-x/i-2007-2009/remont/exterior-body-panels/#body-panel-system-body-closures) . REPEAT the LTM self-test. NO : The system is operating correctly at this time. Concern may have been caused by a loose or corroded connector. CLEAR the DTCs. REPEAT the LTM self-test.

Pinpoint Test E: The Power Liftgate Chime is Inoperative

Refer to appropriate SYSTEM WIRING DIAGRAMS article, Power Liftgate/Retractable Running Board for schematic and connector information.

The power liftgate chime is controlled by the Liftgate/Trunk Module (LTM). To activate the chime, the LTM supplies a high frequency voltage output on circuit CPR56 (VT/BN) and ground on circuit RPR56 (GY/VT).

1. DTC B236A Chime Output Circuit Open - This DTC will set when the LTM detects an open in the chime output circuit.
2. DTC B2903 Chime Output Circuit Short to Battery - This DTC will set when the LTM detects a short to voltage in the chime output circuit.
3. DTC B2940 Chime Output Circuit Short to Ground - This DTC will set when the LTM detects a short to ground in the chime output circuit.

This pinpoint test is intended to diagnose the following

1. Wiring, terminals or connectors
2. Power liftgate motor

Scheme 70

Scheme 71

Scheme 72

Scheme 73

1. E1 CHECK FOR VOLTAGE TO THE POWER LIFTGATE CHIME Key in ON position. Set the parking brake to the ON position. Open the liftgate. NOTE: The LTM applies voltage to the power liftgate chime for one second after the rear power liftgate switch is pressed, when the transmission is not in the PARK position and the liftgate is in the open position. With the power liftgate chime still connected, press the rear power liftgate switch and measure the voltage between power liftgate chime C4186-1, circuit CPR56 (VT/BN), back probe and power liftgate chime C4186-2, circuit RPR56 (GY/VT), back probe. Is AC voltage present? YES : INSTALL a new power liftgate motor. REFER to «Power Liftgate Motor»(/ford/taurus-x/i-2007-2009/remont/exterior-body-panels/#body-panel-system-body-closures) . CLEAR the DTCs. REPEAT the LTM self-test. NO : Go to E2 .
2. E2 CHECK THE POWER LIFTGATE CHIME CIRCUITS FOR AN OPEN Key in OFF position. Disconnect: Power Liftgate Chime C4186 Disconnect: LTM C4174A Measure the resistance between LTM C4174A, harness side and power liftgate chime C4186, harness side using the following chart: LTM Circuit Power Liftgate Chime C4174A-9 CPR56 (VT/BN) C4186-1 C4174A-22 RPR56 (GY/VT) C4186-2 Are the resistances less than 5 ohms? YES : Go to E3 . NO : REPAIR the circuit. CLEAR the DTCs. REPEAT the LTM self-test.
3. E3 CHECK THE POWER LIFTGATE CHIME CIRCUITS FOR A SHORT TO GROUND Measure the resistance between power liftgate chime C4186-1, circuit CPR56 (VT/BN), harness side and ground; then between power liftgate chime C4186-2, circuit RPR56 (GY/VT), harness side and ground. Are the resistances greater than 10,000 ohms? YES : Go to E4 . NO : REPAIR the circuit. CLEAR the DTCs. REPEAT the LTM self-test.
4. E4 CHECK THE POWER LIFTGATE CHIME CIRCUITS FOR A SHORT TO VOLTAGE Measure the voltage between power liftgate chime C4186-1, circuit CPR56 (VT/BN), harness side and ground; then between power liftgate chime C4186-2, circuit RPR56 (GY/VT), harness side and ground. Is any voltage present? YES : REPAIR the circuit. CLEAR the DTCs. REPEAT the LTM self-test. NO : Go to E5 .
5. E5 CHECK FOR CORRECT LTM OPERATION Disconnect all the LTM connectors. Check for: corrosion. pushed-out pins. Connect all the LTM connectors and make sure they are seated correctly. Make sure the liftgate is fully CLOSED. Operate the system and verify the concern is still present. Is the concern still present? YES : INSTALL a new LTM. REFER to «Liftgate/Trunk Module (LTM)»(/ford/taurus-x/i-2007-2009/remont/exterior-body-panels/#body-panel-system-body-closures) . REPEAT the LTM self-test. NO : The system is operating correctly at this time. Concern may have been caused by a loose or corroded connector. CLEAR the DTCs. REPEAT the LTM self-test.

Pinpoint Test F: The Power Liftgate Does Not Operate Correctly - Pinch Strip Does Not Stop/Reverse the Liftgate

Refer to appropriate SYSTEM WIRING DIAGRAMS article, Power Liftgate/Retractable Running Board for schematic and connector information.

When the power liftgate moves in the close direction, the Liftgate/Trunk Module (LTM) monitors the pinch strips and position sensor for obstacle detection. The LTM uses a 5-volt reference signal on circuit CPR52 (YE/VT) and a return signal on circuit RPR52 (VT/GY) for the left pinch strip. The LTM uses a 5-volt reference signal on circuit CPR51 (YE/OG) and a return signal on circuit RPR52 (VT/GY) for the right pinch strip. The right and left pinch strip return signal circuits are spliced together.

This pinpoint test is intended to diagnose the following

1. Wiring, terminals or connectors
2. Pinch strip(s)
3. LTM

1. F1 RETRIEVE THE DTCs FROM THE LTM Use the recorded LTM DTCs from the continuous and LTM self-tests. Is DTC B2699, B2700, B2701 or B2702 present? YES : Go to «Pinpoint Test G»(/ford/taurus-x/i-2007-2009/remont/exterior-body-panels/#body-panel-system-body-closures__pinpoint-test-g-the-power-liftgate) . NO : Go to F2 .
2. F2 CHECK THE LIFTGATE LEFT/RIGHT PINCH STRIP STATUS (LFT_PINCH / RT_PINCH) OPERATION Enter the following diagnostic mode on the diagnostic tool: DataLogger - LTM Monitor the LTM PIDs LFT_PINCH and RT_PINCH while activating the left and right pinch strips. Does the PID state change/agree with the pinch strip status? YES : Go to F3 . NO : INSTALL a new left or right pinch strip switch. REFER to «Pinch Strip Switch»(/ford/taurus-x/i-2007-2009/remont/exterior-body-panels/#body-panel-system-body-closures__pinch-strip-switch) . TEST the system for normal operation.
3. F3 CHECK FOR CORRECT LTM OPERATION Disconnect all the LTM connectors. Check for: corrosion. pushed-out pins. Connect all the LTM connectors and make sure they are seated correctly. Make sure the liftgate is fully CLOSED. Operate the system and verify the concern is still present. Is the concern still present? YES : INSTALL a new LTM. REFER to «Liftgate/Trunk Module (LTM)»(/ford/taurus-x/i-2007-2009/remont/exterior-body-panels/#body-panel-system-body-closures) . REPEAT the LTM self-test. NO : The system is operating correctly at this time. Concern may have been caused by a loose or corroded connector. CLEAR the DTCs. REPEAT the LTM self-test.

Pinpoint Test G: The Power Liftgate Does Not Power Close (Power Open OK)

Refer to appropriate SYSTEM WIRING DIAGRAMS article, Power Liftgate/Retractable Running Board for schematic and connector information.

When the power liftgate moves in the close direction, the Liftgate/Trunk Module (LTM) monitors the pinch strips and position sensor for obstacle detection. The LTM uses a 5-volt reference signal on circuit CPR52 (YE/VT) and a return signal on circuit RPR52 (VT/GY) for the left pinch strip. The LTM uses a 5-volt reference signal on circuit CPR51 (YE/OG) and a return signal on circuit RPR52 (VT/GY) for the right pinch strip. The right and left pinch strip return signal circuits are spliced together.

Note. Initialize the power liftgate before proceeding with this pinpoint test. Refer to Power Liftgate Initialization .

This pinpoint test is intended to diagnose the following

1. Wiring, terminals or connectors
2. Pinch strip
3. Power liftgate latch
4. LTM

Scheme 74

Scheme 75

Scheme 76

Scheme 77

Scheme 78

Scheme 79

1. G1 RETRIEVE THE DTCs FROM THE LTM Use the recorded LTM DTCs from the continuous and LTM self-tests. Is DTC B2699, B2700, B2701 or B2702 present? YES : Go to G2 . NO : Go to G9 .
2. G2 CHECK THE LIFTGATE LEFT/RIGHT PINCH STRIP STATUS (LFT_PINCH / RT_PINCH) OPERATION Enter the following diagnostic mode on the diagnostic tool: DataLogger - LTM Monitor the LTM PIDs LFT_PINCH and RT_PINCH while activating the left and right pinch strips. Does the PID state change/agree with the pinch strip status? YES : Go to G14 . NO : Go to G3 .
3. G3 CHECK THE PINCH STRIP SIGNAL CIRCUIT Key in OFF position. Disconnect: Pinch Strip (Left C4172, Right C4173) Key in ON position. Measure the voltage between left pinch strip C4172-1, circuit CPR52 (YE/VT), harness side and ground; and between right pinch strip C4173-1, circuit CPR51 (YE/OG), harness side and ground. Are the voltages approximately 5 volts? YES : Go to G7 . NO : If the voltage measured was greater than 5 volts, go to G4 . If the voltage measured was less than 5 volts, go to G5 .
4. G4 CHECK THE PINCH STRIP SIGNAL CIRCUIT FOR SHORT TO VOLTAGE Key in OFF position. Disconnect: LTM C4174A Key in ON position. Measure the voltage between left pinch strip C4172-1, circuit CPR52 (YE/VT), harness side and ground; and between right pinch strip C4173-1, circuit CPR51 (YE/OG), harness side and ground. Is any voltage present? YES : REPAIR the circuit(s). CLEAR the DTCs. REPEAT the LTM self-test. NO : Go to G14 .
5. G5 CHECK THE PINCH STRIP SIGNAL CIRCUIT FOR A SHORT TO GROUND Key in OFF position. Disconnect: LTM C4174A Measure the resistance between left pinch strip C4172-1, circuit CPR52 (YE/VT), harness side and ground; or between right pinch strip C4173-1, circuit CPR51 (YE/OG), harness side and ground. Is the resistance greater than 10,000 ohms? YES : Go to G6 . NO : REPAIR the circuit. CLEAR the DTCs. REPEAT the LTM self-test.
6. G6 CHECK THE PINCH STRIP SIGNAL CIRCUITS FOR AN OPEN Key in OFF position. Disconnect: LTM C4174A Measure the resistance between left pinch strip C4172-1, circuit CPR52 (YE/VT), harness side and LTM C4174A-25, circuit CPR52 (YE/VT), harness side. Then measure the resistance between right pinch strip C4173-1, circuit CPR51 (YE/OG), harness side and LTM C4174A-1, circuit CPR51 (YE/OG), harness side. Are the resistances less than 5 ohms? YES : Go to G14 . NO : REPAIR the circuit. CLEAR the DTCs. REPEAT the LTM self-test.
7. G7 CHECK THE PINCH STRIP RETURN CIRCUIT Key in ON position. Measure the resistance between left pinch strip C4172-2, circuit RPR52 (VT/GY), harness side and ground; and between right pinch strip C4173-2, circuit RPR52 (VT/GY), harness side and ground. Are the resistances less than 5 ohms? YES : INSTALL a new pinch strip. REFER to «Pinch Strip Switch»(/ford/taurus-x/i-2007-2009/remont/exterior-body-panels/#body-panel-system-body-closures__pinch-strip-switch) . CLEAR the DTCs. REPEAT the LTM self-test. NO : Go to G8 .
8. G8 CHECK THE PINCH STRIP RETURN CIRCUIT FOR AN OPEN Key in OFF position. Disconnect: LTM C4174A Measure the resistance between left pinch strip C4172-2, circuit RPR52 (VT/GY), harness side and LTM C4174A-8, circuit RPR52 (VT/GY), harness side; and between right pinch strip C4173-2, circuit RPR52 (VT/GY), harness side and LTM C4174A-8, circuit RPR52 (VT/GY), harness side. Are the resistances less than 5 ohms? YES : Go to G14 . NO : REPAIR the circuit. CLEAR the DTCs. REPEAT the LTM self-test.
9. G9 CHECK THE DETENT AND FORKBOLT SWITCH PIDs Enter the following diagnostic mode on the diagnostic tool: DataLogger - LTM Operate the liftgate manually while monitoring the following LTM PIDs: Detent Switch Status (DETENTSW) Forkbolt Switch Status (FORKBLT_S) Forkbolt Secondary Switch (FKSWSEC) NOTE: The liftgate is in the primary position when the liftgate is in the full closed position. The liftgate is in the unlatch position when the liftgate is open and completely out of the striker. The liftgate can be placed in the unlatched position by lifting up on the liftgate handle. Begin with the liftgate in the open position, then slowly close the liftgate into each of the latch positions specified by the table below. Liftgate Latch Position DETENTSW FORKBLT_S FKSWSEC Fully Unlatched Inactive a Active Active Primary Active Inactive Inactive a If detent switch is active in the fully unlatched position, manually attempt to rotate the forkbolt towards the latched position. Do the switch states agree with the table? YES : Go to G14 . NO : Go to G10 .
10. G10 CHECK THE OPERATION OF THE DETENT AND FORKBOLT SWITCHES Key in OFF position. Disconnect: LTM C4174A Measure the resistance between LTM C4174A, harness side and ground at each of the connector pins and each latch position specified by the chart below. Liftgate Latch Position C4174A Circuit Resistance Fully Unlatched Pin 3, circuit CPR66 (GY/YE) Greater than 10,000 ohms a Fully Unlatched Pin 5, circuit CPR65 (BU/GN) Less than 5 ohms Fully Unlatched Pin 4, circuit CPR64 (VT/OG) Less than 5 ohms Primary Pin 3, circuit CPR66 (GY/YE) Less than 5 ohms Primary Pin 5, circuit CPR65 (BU/GN) Greater than 10,000 ohms Primary Pin 4, circuit CPR64 (VT/OG) Greater than 10,000 ohms a If resistance measured is less than 5 ohms, manually rotate the forkbolt to the latched position and retest. Do the resistance values agree with the chart? YES : Go to G14 . NO : Go to G11 .
11. G11 CHECK THE DETENT AND FORKBOLT SWITCH GROUND CIRCUIT Disconnect: Liftgate Latch/Unlatch Assembly C4339 Measure the resistance between power liftgate latch/unlatch assembly C4339-8, circuit GD147 (BK/VT), harness side and ground. Is the resistance less than 5 ohms? YES : Go to G12 . NO : REPAIR the circuit. CLEAR the DTCs. REPEAT the LTM self-test.
12. G12 CHECK THE DETENT AND FORKBOLT SWITCH CIRCUITS FOR AN OPEN Measure the resistance between power liftgate latch/unlatch assembly C4339, harness side and LTM C4174A, harness side using the following chart: Power Liftgate Latch/Unlatch Assembly Circuit LTM C4339-1 CPR65 (BU/GN) C4174A-5 C4339-3 CPR64 (VT/OG) C4174A-4 C4339-2 CPR66 (GY/YE) C4174A-3 Are the resistances less than 5 ohms on all circuits? YES : Go to G13 . NO : REPAIR the circuit. CLEAR the DTCs. REPEAT the LTM self-test.
13. G13 CHECK THE DETENT AND FORKBOLT SWITCH CIRCUITS FOR A SHORT TO GROUND Measure the resistance between LTM C4174A-5, circuit CPR65 (BU/GN), harness side and ground; between LTM C4174A-4, circuit CPR64 (VT/OG), harness side and ground; then between LTM C4174A-3, circuit CPR66 (GY/YE), harness side and ground. Are the resistances greater than 10,000 ohms on all circuits? YES : CHECK the power liftgate latch connector for bent or corroded connections on the component side and harness side. REPAIR as necessary. INSTALL a new power liftgate latch. REFER to «HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS»(/ford/taurus-x/i-2007-2009/remont/door-locks-anti-theft-systems/#handles-locks-latches-and-entry-systems) article. CLEAR the DTCs. REPEAT the LTM self-test. NO : REPAIR the circuit. CLEAR the DTCs. REPEAT the LTM self-test.
14. G14 CHECK FOR CORRECT LTM OPERATION Disconnect all the LTM connectors. Check for: corrosion. pushed-out pins. Connect all the LTM connectors and make sure they are seated correctly. Make sure the liftgate is fully CLOSED. Operate the system and verify the concern is still present. Is the concern still present? YES : INSTALL a new LTM. REFER to «Liftgate/Trunk Module (LTM)»(/ford/taurus-x/i-2007-2009/remont/exterior-body-panels/#body-panel-system-body-closures) . REPEAT the LTM self-test. NO : The system is operating correctly at this time. Concern may have been caused by a loose or corroded connector. CLEAR the DTCs. REPEAT the LTM self-test.

Pinpoint Test H: The Power Liftgate Does Not Power Open (Power Close OK)

Refer to appropriate SYSTEM WIRING DIAGRAMS article, Power Liftgate/Retractable Running Board for schematic and connector information.

If the power liftgate is in the closed position and the conditions are correct, the Liftgate/Trunk Module (LTM) supplies 12 volts to the unlatch/cinching motor on circuit CPR62 (WH/BU), 12 volts to the clutch on circuit CPR69 (BN/BU) and 12 volts to the motor on circuit CPR57 (GN/WH). As the liftgate is moving in the open direction, the LTM monitors the position sensor for door speed to detect obstacles. Once the liftgate is unlatched, the motor and clutch are activated to power open the liftgate.

This pinpoint test is intended to diagnose the following

1. Mechanical binding
2. Power liftgate latch
3. LTM
4. Wiring, terminals or connectors

1. H1 CHECK THE MANUAL OPERATION OF THE LIFTGATE NOTE: If any other power liftgate related DTCs are present, diagnose those first before proceeding with this pinpoint test. Refer to the «LIFTGATE/TRUNK MODULE (LTM) DTC TABLE»(/ford/taurus-x/i-2007-2009/remont/exterior-body-panels/#body-panel-system-body-closures) . Key in ON position. Unlock all doors. Turn the power liftgate OFF (disable) from the message center. NOTE: A small amount of interference during a manual operation will be amplified during a power operation and may cause the liftgate to not power open. Manually open and close the liftgate. Does the liftgate unlatch, open, close and latch correctly? YES : Go to H2 . NO : If liftgate does not unlatch correctly, REFER to «HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS»(/ford/taurus-x/i-2007-2009/remont/door-locks-anti-theft-systems/#handles-locks-latches-and-entry-systems) article. If liftgate does not open and close correctly, REFER to «Liftgate»(/ford/taurus-x/i-2007-2009/remont/exterior-body-panels/#body-panel-system-body-closures__liftgate) .
2. H2 CHECK THE LIFTGATE LATCH AND STRIKER ALIGNMENT NOTE: Make sure to inspect the underside of the striker bridge for witness marks. Inspect the striker and latch for correct alignment. Is the latch and striker aligned correctly? YES : Go to «Pinpoint Test A»(/ford/taurus-x/i-2007-2009/remont/exterior-body-panels/#body-panel-system-body-closures__pinpoint-test-a-the-power-liftgate) . NO : ALIGN the liftgate and striker. REFER to «Liftgate Alignment»(/ford/taurus-x/i-2007-2009/remont/exterior-body-panels/#body-panel-system-body-closures__liftgate-alignment) . TEST the system for normal operation.

Pinpoint Test I: Power Liftgate DTC B117C - Latch Centering Switch Invalid

Refer to appropriate SYSTEM WIRING DIAGRAMS article, Power Liftgate/Retractable Running Board for schematic and connector information.

The Liftgate/Trunk Module (LTM) monitors the sector gear open switch, circuit CPR67 (VT) and sector gear close switch, CPR68 (YE) to determine the sector gear position.

1. DTC B117C Latch Centering Switch Invalid - This DTC will set when the LTM detects the sector gear open/close switch(es) are not in the correct state at the beginning of self-test.

This pinpoint test is intended to diagnose the following

1. Power liftgate latch
2. LTM
3. Wiring, terminals or connectors

Scheme 80

Scheme 81

Scheme 82

1. I1 CHECK THE SECTOR GEAR SWITCH CIRCUITS NOTE: If any other power liftgate related DTCs are present, diagnose those first before proceeding with this pinpoint test. Refer to the «LIFTGATE/TRUNK MODULE (LTM) DTC TABLE»(/ford/taurus-x/i-2007-2009/remont/exterior-body-panels/#body-panel-system-body-closures) . Disconnect: Latch/Unlatch Assembly C4339 Key in ON position. Measure the voltage between power liftgate latch/unlatch assembly C4339-6, circuit CPR67 (VT), harness side and ground; and between C4339-4, circuit CPR68 (YE), harness side and ground. Is the voltage greater than 10 volts for both measurements? YES : Go to I4 . NO : Go to I2 .
2. I2 CHECK CIRCUITS CPR67 (VT) AND CPR68 (YE) FOR A SHORT TO GROUND Key in OFF position. Disconnect: LTM C4174A Measure the resistance between LTM C4174A-26, circuit CPR67 (VT), harness side and ground; and between LTM C4174A-15, circuit CPR68 (YE), harness side and ground. Is the resistance greater than 10,000 ohms? YES : Go to I3 . NO : REPAIR the circuit. CLEAR the DTCs. REPEAT the LTM self-test.
3. I3 CHECK CIRCUITS CPR67 (VT) AND CPR68 (YE) FOR AN OPEN Measure the resistance between LTM C4174A, harness side and power liftgate latch/unlatch assembly C4339, harness side using the following chart: LTM Circuit Power Liftgate Latch/Unlatch Assembly C4174A-26 CPR67 (VT) C4339-6 C4174A-15 CPR68 (YE) C4339-4 Is the resistance less than 5 ohms for both measurements? YES : CHECK the LTM connector for bent or corroded connections on the component side and harness side. REPAIR as necessary. CLEAR the DTCs. REPEAT the LTM self-test. IF DTC B117C returns, INSTALL a new LTM. REFER to «Liftgate/Trunk Module (LTM)»(/ford/taurus-x/i-2007-2009/remont/exterior-body-panels/#body-panel-system-body-closures) . CLEAR the DTCs. REPEAT the LTM self-test. NO : REPAIR the circuit. CLEAR the DTCs. REPEAT the LTM self-test.
4. I4 CHECK CIRCUITS CPR67 (VT) AND CPR68 (YE) FOR A SHORT TO VOLTAGE Key in OFF position. Disconnect: LTM C4174A Key in ON position. Measure the voltage between power liftgate latch/unlatch assembly C4339-6, circuit CPR67 (VT), harness side and ground; and between C4339-4, circuit CPR68 (YE), harness side and ground. Is any voltage present for both measurements? YES : REPAIR the circuit. CLEAR the DTCs. REPEAT the LTM self-test. NO : CHECK the power liftgate latch connector for bent or corroded connections on the component side and harness side. REPAIR as necessary. INSTALL a new power liftgate latch. REFER to «HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS»(/ford/taurus-x/i-2007-2009/remont/door-locks-anti-theft-systems/#handles-locks-latches-and-entry-systems) article. CLEAR the DTCs. REPEAT the LTM self-test.

Pinpoint Test J: DTC B1317/B1318 - Battery Voltage High/Battery Voltage Low

Refer to appropriate SYSTEM WIRING DIAGRAMS article, Power Liftgate for schematic and connector information.

Note. DTCs B1317 or B1318 can be set if the vehicle has been recently jump started, the battery has been recently charged or the battery has been discharged. The battery may become discharged due to excessive load(s) on the charging system from aftermarket accessories or if the battery has been left unattended with the accessories on.

Normal Operation - Liftgate/Trunk Module (LTM)

The Liftgate/Trunk Module (LTM) continuously monitors the input voltage for correct operation. If the LTM detects input voltage below 8 volts, it will store DTC B1318 in memory. If the LTM detects input voltage greater than 16 volts, it will store DTC B1317 in memory. If the LTM sets DTC B1317 or B1318, it will inhibit the power liftgate system operation.

1. DTC B1317 Battery Voltage High - If the LTM detects voltage above 16 volts for greater than 3 seconds, it will set this DTC.
2. DTC B1318 Battery Voltage Low - If the LTM detects voltage below 8 volts for greater than 3 seconds, it will set this DTC.

This pinpoint test is intended to diagnose the following

1. Wiring, terminals or connectors
2. LTM

Note. Most faults are due to connector and/or wiring concerns. Carry out a thorough inspection and verification before proceeding with the pinpoint test.

Scheme 83

Scheme 84

1. J1 RETRIEVE ALL Continuous Memory Diagnostic Trouble Codes (CMDTCs) IN ALL MODULES Key in ON position. Enter the following diagnostic mode on the diagnostic tool: Self Test - ALL CMDTCs Is DTC B1317 or B1318 retrieved from one or more modules and P0563, P0620, P0626 or P065B retrieved from the PCM? YES : REFER to «CHARGING SYSTEM - GENERAL INFORMATION»(/ford/taurus-x/i-2007-2009/remont/charging-system/#charging-system-general-information) article to diagnose the charging system. CLEAR all CMDTCs. REPEAT the LTM self-test. NO : Go to J2 .
2. J2 TEST BATTERY CONDITION Key in OFF position. Carry out the battery condition test. Refer to «BATTERY, MOUNTING AND CABLES»(/ford/taurus-x/i-2007-2009/remont/body-electrical/#battery-mounting-and-cables) article. Did the battery pass the condition test? YES : If the battery passed the condition test but required a recharge, REFER to «CHARGING SYSTEM - GENERAL INFORMATION»(/ford/taurus-x/i-2007-2009/remont/charging-system/#charging-system-general-information) article to diagnose the charging system. CLEAR all CMDTCs. REPEAT the LTM self-test. If the battery passed the condition test and did not require a recharge, go to J3 . NO : INSTALL a new battery. CLEAR all CMDTCs. REPEAT the LTM self-test.
3. J3 CHECK CHARGING SYSTEM VOLTAGE NOTE: Do not allow the engine speed to increase above 2,000 RPM while performing this step or the generator may self excite and result in default charging system output voltage. If engine speed goes above 2,000 RPM, shut the vehicle OFF and restart the engine before performing this step. Measure the voltage of the battery: For DTC B1317, turn off all accessories and run the engine at 1,500 RPM for a minimum of 2 minutes while measuring battery voltage. For DTC B1318, turn on headlights and HVAC fan on high and run engine at 1,500 RPM for a minimum of 2 minutes while measuring battery voltage. Is the voltage between 13 and 15.2 volts? YES : For DTC B1318, go to J4 . For DTC B1317, go to J6 . NO : REFER to «CHARGING SYSTEM - GENERAL INFORMATION»(/ford/taurus-x/i-2007-2009/remont/charging-system/#charging-system-general-information) article to diagnose the charging system. CLEAR all CMDTCs. REPEAT the LTM self-test.
4. J4 CHECK CIRCUITS SBB29 (GY/RD) AND SBP14 (BN/RD) FOR VOLTAGE Key in OFF position. Disconnect: LTM C4174B Measure the voltage between LTM C4174B-4, circuit SBB29 (GY/RD), harness side and ground; and between LTM C4174B-9, circuit SBP14 (BN/RD), harness side and ground. Is the voltage greater than 10 volts for both measurements? YES : Go to J5 . NO : VERIFY Battery Junction Box (BJB) fuse 29 (30A) and Smart Junction Box (SJB) fuse 14 (10A) are OK. If OK, REPAIR the circuit. CLEAR the DTCs. REPEAT the LTM self-test. If not OK, REFER to the Wiring Diagrams Manual to identify the possible causes of the circuit short. CLEAR the DTCs. REPEAT the LTM self-test.
5. J5 CHECK CIRCUIT GD147 (BK/VT) FOR AN OPEN Measure the resistance between LTM C4174B-1, circuit GD147 (BK/VT), harness side and ground. Is the resistance less than 5 ohms? YES : Go to J6 . NO : REPAIR the circuit. CLEAR the DTCs. REPEAT the LTM self-test.
6. J6 CHECK FOR MODULE OPERATION Check LTM C4174B for the following: corrosion. damaged pins. pushed-out pins. Connect LTM C4174B and make sure the connector seats correctly. CLEAR all CMDTCs. Operate the system to verify the concern is still present. Is the concern still present? YES : INSTALL a new LTM module. REFER to «Liftgate/Trunk Module (LTM)»(/ford/taurus-x/i-2007-2009/remont/exterior-body-panels/#body-panel-system-body-closures) . REPEAT the LTM self-test. NO : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector. CLEAR the DTCs. REPEAT the LTM self-test.

Pinpoint Test K: The Power Liftgate Does Not Operate Correctly - Closes (With a Continuous Chime) Immediately After a Power Open

Refer to appropriate SYSTEM WIRING DIAGRAMS article, Power Liftgate for schematic and connector information.

After the Liftgate/Trunk Module (LTM) has performed a power open operation, power is removed from the clutch and drive motor. The LTM briefly continues to monitor the position of the liftgate. If excessive movement in the closed direction is detected, power is reapplied to the clutch and a continuous chime is initiated and remains on as the liftgate is automatically power closed.

If the excessive closing movement is detected on 11 successive power open requests, DTC B201A is set and power liftgate operation is disabled until the DTC is cleared.

1. DTC 201A Power System Disabled Due to High Manual Closing Speed - This DTC is set when the LTM detects excessive closing movement on 11 successive power open requests. When DTC 201A is set, power liftgate operation is disabled until the DTC is cleared.

This pinpoint test is intended to diagnose the following

1. Excessive weight on the liftgate (for example: bike rack or snow and ice)
2. Power liftgate full open position not learned correctly during power liftgate initialization procedure
3. Liftgate assist cylinders
4. LTM

1. K1 RETRIEVE ALL Continuous Memory Diagnostic Trouble Codes (CMDTCs) IN ALL MODULES Key in ON position. Enter the following diagnostic mode on the diagnostic tool: Self Test - ALL CMDTCs Is DTC B201A retrieved from the Liftgate/Trunk Module (LTM)? YES : CLEAR all CMDTCs. Go to K2 . NO : Go to K2 .
2. K2 CHECK THE LIFTGATE ASSIST CYLINDERS Verify there is no excessive weight on the liftgate (for example: bike rack or snow and ice). Turn the power liftgate OFF (disable) from the message center. Operate the liftgate manually to verify the liftgate assist cylinders hold the liftgate open. Did the liftgate assist cylinders hold the liftgate open correctly? YES : RE-INITIALIZE the power liftgate. REFER to «Power Liftgate Initialization»(/ford/taurus-x/i-2007-2009/remont/exterior-body-panels/#body-panel-system-body-closures__power-liftgate-initialization) . TEST the system for normal operation. If DTC B201A returns or power liftgate still closes (with a continuous chime) immediately after a power open, INSTALL a new LTM. REFER to «Liftgate/Trunk Module (LTM)»(/ford/taurus-x/i-2007-2009/remont/exterior-body-panels/#body-panel-system-body-closures) . INITIALIZE the power liftgate. REFER to «Power Liftgate Initialization»(/ford/taurus-x/i-2007-2009/remont/exterior-body-panels/#body-panel-system-body-closures__power-liftgate-initialization) . TEST the system for normal operation. NO : INSTALL a new liftgate assist cylinders. RE-INITIALIZE the power liftgate. REFER to «Power Liftgate Initialization»(/ford/taurus-x/i-2007-2009/remont/exterior-body-panels/#body-panel-system-body-closures__power-liftgate-initialization) . TEST the system for normal operation.

Liftgate Alignment

1. Loosen the 4 liftgate hinge-to-liftgate bolts until the liftgate is able to move slightly.
2. Align the liftgate to the body. Align the liftgate gaps evenly. Be sure that the liftgate is flush to the body.
3. Tighten the 4 liftgate hinge-to-liftgate bolts. Tighten to 25 Nm (18 lb-ft).
4. Loosen the 2 liftgate striker bolts until the striker is able to move slightly.
5. Align the liftgate striker to the liftgate.
6. Tighten the 2 liftgate striker bolts. Tighten to 25 Nm (18 lb-ft).
7. For vehicles equipped with power liftgate, initialize the power liftgate. For additional information, refer to «Power Liftgate Initialization»(/ford/taurus-x/i-2007-2009/remont/exterior-body-panels/#body-panel-system-body-closures__power-liftgate-initialization) .

Door Adjustment - Front

1. Loosen the front door hinge-to-front door bolts until the front door is able to move slightly.
2. Align the front door. Align the front door body angles to the rear door. Be sure that the front door is flush to the body.
3. Tighten the front door hinge-to-front door bolts. Tighten to 30 Nm (22 lb-ft).
4. Loosen the front door striker bolts until the striker is able to move slightly.
5. Align the front door striker to the front door.
6. Tighten the striker bolts. Tighten to 22 Nm (16 lb-ft).

Door Adjustment - Rear

1. Loosen the rear door hinge-to-rear door bolts until the rear door is able to move slightly.
2. Align the rear door. Align the rear door body angles to the rear quarter panel. Be sure that the rear door is flush to the body.
3. Tighten the rear door hinge-to-rear door bolts. Tighten to 30 Nm (22 lb-ft).
4. Loosen the rear door striker bolts until the striker is able to move slightly.
5. Align the rear door striker to the rear door.
6. Tighten the striker bolts. Tighten to 22 Nm (16 lb-ft).
7. Adjust the front door. For additional information, refer to «Door Adjustment - Front»(/ford/taurus-x/i-2007-2009/remont/exterior-body-panels/#body-panel-system-body-closures__door-adjustment-front) .

Power Liftgate Initialization

Note. The power liftgate may not operate correctly under the following conditions: A low voltage or dead battery A disconnected battery Repairs/adjustments have been made to the power liftgate rod, power liftgate motor, liftgate hinges or liftgate striker If any of these conditions has occurred, the power liftgate must be reinitialized.

1. Disconnect the battery or remove the LTM fuse(s).
2. Wait 20 seconds and reconnect the battery or reinstall the LTM fuse(s).
3. Manually close and fully latch the power liftgate.
4. Power open the power liftgate by using the key fob or control switch.
5. Once the power liftgate is fully open, close the power liftgate by using the key fob or control switch.

Door

Note. Front door shown, rear door similar.

Scheme 85

REMOVAL AND INSTALLATION

1. Disconnect the front door electrical connector at the A-pillar.
2. Remove the door check bolts. To install, tighten to 25 N.m (18 lb-ft).
3. With a wax pencil, mark the position of each hinge and remove the hinge-to-door bolts. To install, tighten to 30 N.m (22 lb-ft).
4. Remove the front door.
5. To install, reverse the removal procedure. Verify door adjustment. For additional information, refer «Door Adjustment - Front»(/ford/taurus-x/i-2007-2009/remont/exterior-body-panels/#body-panel-system-body-closures__door-adjustment-front) or «Door Adjustment - Rear»(/ford/taurus-x/i-2007-2009/remont/exterior-body-panels/#body-panel-system-body-closures__door-adjustment-rear) .

Liftgate

Material

Scheme 86

All vehicles

1. Remove the D-pillar trim panels. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(/ford/taurus-x/i-2007-2009/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) article.
2. Remove the pin-type retainers from the rear of the headliner.
3. Remove the handle assemblies from the headliner. Disconnect the handle assembly screw covers. Remove the handle assembly screws.
4. Lower the rear of the headliner to gain access to the electrical connectors.
5. Disconnect the electrical connectors and the routing clips.
6. Disconnect the rear washer hose routing.
7. Disconnect the grommets from the vehicle body. Position the wiring harness through the vehicle body. Position the rear washer hose routing through the vehicle body.
8. Remove the power liftgate rod-to-liftgate cover and nut. To install, tighten to 11 N.m (97 lb-in).
9. Remove the power liftgate rod from the liftgate.
10. Support the liftgate in the open position.
11. Remove the liftgate struts.
12. With help from an assistant, remove the liftgate hinge-to-liftgate bolts. To install, tighten to 25 N.m (18 lb-ft).
13. With help from an assistant, remove the liftgate.
14. To install, reverse the removal procedure. Check liftgate alignment. For additional information, refer to «Liftgate Alignment»(/ford/taurus-x/i-2007-2009/remont/exterior-body-panels/#body-panel-system-body-closures__liftgate-alignment) . If equipped with power liftgate, initialize the power liftgate system. For additional information, refer to «Power Liftgate Initialization»(/ford/taurus-x/i-2007-2009/remont/exterior-body-panels/#body-panel-system-body-closures__power-liftgate-initialization) .

Scheme 87

1. Open the luggage compartment lid.
2. Disconnect the electrical connectors.
3. With the help of an assistant, remove the hinge-to-luggage compartment lid nuts. To install, tighten to 25 Nm (18 lb-ft).
4. With the help of an assistant, remove the luggage compartment lid.
5. To install, reverse the removal procedure.

Scheme 88

1. Remove the LH rear quarter trim panel. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(/ford/taurus-x/i-2007-2009/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) article.
2. Disconnect the electrical connectors and remove the Liftgate/Trunk Module (LTM) retaining bolt. To install, tighten to 9 N.m (80 lb-in).
3. Carefully rotate the LTM bracket approximately 45 degrees to release the mount and then pull up to remove the module.
4. To install, reverse the removal procedure. Initialize the power liftgate. For additional information, refer to «Power Liftgate Initialization»(/ford/taurus-x/i-2007-2009/remont/exterior-body-panels/#body-panel-system-body-closures__power-liftgate-initialization) .

Scheme 89

1. Remove the LH rear quarter trim panel. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(/ford/taurus-x/i-2007-2009/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) article.
2. Disconnect the power liftgate motor electrical connectors.
3. Remove the power liftgate motor retaining bolts and nut. To install, tighten to 11 N.m (97 lb-in).
4. Remove the power liftgate motor.
5. To install, reverse the removal procedure. Initialize the power liftgate. For additional information, refer to «Power Liftgate Initialization»(/ford/taurus-x/i-2007-2009/remont/exterior-body-panels/#body-panel-system-body-closures__power-liftgate-initialization) .

Power Liftgate Rod

Material

Scheme 90

1. Remove the LH quarter trim panel access cover.
2. Unclip the power liftgate rod from the motor assembly. Squeeze the clip as shown to release and position the rod assembly upward.
3. Remove the cover and the power liftgate rod-to-liftgate retaining nut. To install, apply threadlock to the threads of the fastener and tighten to 11 N.m (97 lb-in).
4. Remove the 3 power liftgate rod mounting bracket nuts. To install, tighten to 30 N.m (22 lb-ft).
5. To install, reverse the removal procedure. Initialize the power liftgate. For additional information, refer to «Power Liftgate Initialization»(/ford/taurus-x/i-2007-2009/remont/exterior-body-panels/#body-panel-system-body-closures__power-liftgate-initialization) .

Pinch Strip Switch

Note. Left side shown, right side similar.

Scheme 91

1. Remove the liftgate trim panel. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(/ford/taurus-x/i-2007-2009/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) article.
2. Disconnect the pinch strip electrical connector.
3. Remove the pinch strip. Remove the pin-type retainers. Remove the grommet and route the harness out of the vehicle.
4. To install, reverse the removal procedure.

See also:
• MODULE COMMUNICATIONS NETWORK
• MULTIFUNCTION ELECTRONIC MODULES
• HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS
• INTERIOR LIGHTING
• INSTRUMENT CLUSTER (IC), MESSAGE CENTER, AND WARNING CHIMES
• AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50
• STEERING COLUMN SWITCHES
• CHARGING SYSTEM - GENERAL INFORMATION
• BATTERY, MOUNTING AND CABLES
• INTERIOR TRIM AND ORNAMENTATION
• Power Liftgate Initialization
• LIFTGATE/TRUNK MODULE (LTM) DTC TABLE
• Pinpoint Test B
• Pinpoint Test A
• Pinpoint Test D
• Pinpoint Test I
• Pinpoint Test J
• Pinpoint Test C
• Pinpoint Test K
• Pinpoint Test E
• Pinpoint Test G
• Liftgate
• Pinpoint Test F
• Pinpoint Test H
• Power Liftgate Rod
• Liftgate Alignment
• Pinch Strip Switch
• Door Adjustment - Front
• Door Adjustment - Rear
