Automatic Transmission External Controls System: Removal & Installation Ford Focus II

Removal & Installation

1. The brake shift interlock is not serviced. If a problem is detected with the brake shift interlock, install a new shifter assembly. For additional information, refer to «TRANSMISSION SELECTOR LEVER»(ref-255432-S24447570152007053100000) in this article.

Scheme 509

Scheme 510

Scheme 511

Scheme 512

Scheme 513

Scheme 514

Scheme 515

Scheme 516

Scheme 517

Scheme 518

Scheme 519

1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING AND LIFTING»(ref-255374) .
2. Remove the battery tray. For additional information, refer to «BATTERY MOUNTING AND CABLES»(ref-255404) .
3. Disconnect the battery ground cable. For additional information, refer to «BATTERY MOUNTING AND CABLES»(ref-255404) .
4. Remove the air cleaner. For additional information, refer to «INTAKE AIR DISTRIBUTION AND FILTERING»(ref-255385) .
5. Support the flexible exhaust pipe, using a suitable wrap.
6. Disconnect the front exhaust pipe and detach the support isolators. Discard the gasket.
7. Disconnect the center exhaust hanger and support the exhaust with wire.
8. Remove the exhaust heat shield. Unclip the selector lever cable.
9. Disconnect the selector lever cable from the selector lever bracket and manual control lever. Disconnect the shift cable end from the manual control lever. Depress the tabs on the shift cable and remove the cable from the bracket.
10. Remove the floor console. For additional information, refer to «INSTRUMENT PANEL AND CONSOLE»(ref-255410) .
11. Remove the selector lever cable from the selector lever. Shift the selector lever to PARK. Unclip the selector lever cable. Unclip the selector lever cable outer sleeve.
12. Remove the center armrest brace.
13. Remove the center console lower trim panels. Remove the screws. Release the clip.
14. Remove the footwell heater channel.
15. Remove the heater housing cover. Unclip the 4 clips. Remove the 2 screws.
16. Detach the floor covering and the insulator material and position it aside.
17. Attach a suitable length of draw cord to the transaxle end of the selector lever cable and secure it to the transaxle.
18. Remove the selector lever cable grommet nuts and the grommet.
19. Remove the selector lever cable. Pull the cable and draw cord through the floor panel.

Scheme 520

Scheme 521

Scheme 522

Scheme 523

Scheme 524

Scheme 525

Scheme 526

Scheme 527

Scheme 528

Scheme 529

Scheme 530

Scheme 531

Scheme 532

1. Attach the draw cord to the transaxle end of the selector lever cable.
2. Pull the selector lever cable through the floor panel.
3. Install the selector lever cable grommet and nuts. Tighten to 9 Nm (80 lb-in).
4. Secure the insulator material and the floor covering with adhesive tape.
5. Install the heater housing cover. Locate the 4 clips. Install the 2 screws.
6. Install the footwell heater channel.
7. Install the center console lower trim panels. Install the clip. Install the screws.
8. Install the armrest brace. Tighten to 10 Nm (89 lb-in).
9. Install the selector cable to the selector lever. Shift the selector lever to PARK. Clip in the selector lever cable outer sleeve. Clip in the selector lever cable.
10. Install the floor console. For additional information, refer to «INSTRUMENT PANEL AND CONSOLE»(ref-255410) .
11. Remove the draw cord.
12. Unlock the shift cable end. Make sure that the cable end moves freely.
13. Connect the shift cable end to the manual control lever. Connect the shift cable to the cable bracket. Connect the shift cable end to the manual control lever.
14. Press the lock tab down to secure the cable end from moving.
15. Install the exhaust heat shield.
16. Connect the center exhaust hanger and remove the support wire.
17. Attach the exhaust pipe support insulators and connect the front exhaust pipe. Tighten to 47 Nm (35 lb-ft).
18. Remove the support wrap.
19. Adjust the selector lever cable. For additional information, refer to «SELECTOR LEVER CABLE ADJUSTMENT»(ref-255432-S26761535452007053100000) in this article.
20. Connect the battery ground cable. For additional information, refer to «BATTERY MOUNTING AND CABLES»(ref-255404) .
21. Install the air cleaner. For additional information, refer to «INTAKE AIR DISTRIBUTION AND FILTERING»(ref-255385) .
22. Install the battery tray. For additional information, refer to «BATTERY MOUNTING AND CABLES»(ref-255404) .
23. Check that the vehicle starts in PARK and NEUTRAL and the reverse lamps illuminate in REVERSE.
