Automatic Transmission External Controls System: Other Ford Focus II

Selector lever cable

1. At the transaxle end the selector lever cable is attached to a ball on the shift shaft lever through the transmission range (TR) sensor.
2. The cable abutments are secured first to the transaxle housing and second to the bracket of the selector lever.
3. The adjuster for the selector lever cable is located on the end of the shift cable at the transaxle.
4. At the selector lever end the cable is clipped onto a ball.

Scheme 537

Adjuster in CLOSED position; lift in the direction of the arrow to open.

Scheme 538

Adjuster in OPEN position; press in the direction of the arrow to close.

Scheme 539

Scheme 540

Scheme 541

1. A quick-release fastener on the selector lever cable allows adjustment of the cable relative to the conduit.
2. Adjustment is required if the transaxle or the selector lever has been removed, if the engine does not start in PARK or NEUTRAL in case of shift quality concerns or if the switch catches are incorrect. To adjust the selector lever cable, the selector lever must be in DRIVE position.
3. To make sure the transaxle is in DRIVE position the cable should be removed from the shift shaft lever, the transaxle should be shifted in DRIVE and the selector lever cable should be clipped again onto the shift shaft lever.
4. The selector lever cable must not be stressed. The selector lever cable must be free from binding.

The selector lever cable is locked by pressing the cable adjuster after making sure the shift mechanism is in DRIVE.

Selector Lever

SELECTOR LEVER

Scheme 542

Function

The O/D indicator lights to tell the driver that the transaxle control has switched to the emergency operating program or that the transmission fluid temperature is too high.

Pinpoint Tests

Refer to TRANSMISSION for schematic and connector information.

Scheme 543

Scheme 544

Scheme 545

Scheme 546

Scheme 547

Scheme 548

Scheme 549

1. A1 CHECK THE KEY REMOVAL INHIBIT CIRCUIT Turn the ignition ON, gear selection in PARK position. Can the ignition switch be turned to the OFF position only when the selector lever is in PARK? Yes : GO to A2 . No : If the ignition switch cannot be turned to the OFF position when the selector lever is in park, GO to A11 . If the ignition switch can be turned to the OFF position when the selector lever is not in the PARK position, GO to A6
2. A2 CHECK IF STOPLAMPS LIGHT Switch ON the ignition. Depress the brake pedal. Are the stoplamps ON? Yes : GO to A3 . No : REFER to «EXTERIOR LIGHTING»(ref-255416) .
3. A3 CHECK THE VOLTAGE TO THE PARK INTERLOCK SOLENOID Disconnect: Selector Lever Unit (C3233). Measure the voltage between selector lever C3233, pin 3 (GN/WH) and ground. Is the voltage 0 V when the brake pedal is not depressed, and is battery voltage indicated when the brake pedal is depressed? Yes : GO to A4 . No : REPAIR circuit 15S-TA33 between C2314 (stoplamp switch), pin 1 and C3233, pin 3 for open.
4. A4 CHECK GROUND TO THE PARK INTERLOCK SOLENOID Measure the resistance between C3233, pin 1 (BK) and ground. Is resistance less than 5 ohms? Yes : GO to A5 . No : REPAIR circuit 31-TA34 between C3233, pin 1 and ground for open.
5. A5 CHECK THE RANGE SELECTOR LEVER CIRCUIT Measure the resistance at range selector lever C3233, between pins 3 and 1. Selector lever in PARK. Is resistance between 20 ohms and 35 ohms? Yes : Park interlock solenoid is electrically OK. CHECK for mechanical fault. No : INSTALL a new park interlock solenoid.
6. A6 CHECK FUSE F1.8 (30A) IN THE BATTERY JUNCTION BOX (BJB) Check fuse: F1.8 (30 A). Is the fuse F1.8 OK? Yes : GO to A8 . No : GO to A7 .
7. A7 CHECK CIRCUIT 30-BB9 (RD) FOR A SHORT TO GROUND Disconnect: Starter Relay. Disconnect: Ignition Switch C250. Measure the resistance between the output side of fuse F1.8 (30A) and ground. Is the resistance greater than 10,000 ohms? Yes : REPAIR starter motor circuit 50-BB12 (GY) for a short to ground. No : REPAIR circuit 30-BB9 (RD).
8. A8 CHECK CIRCUIT 30-BB9 (RD) FOR AN OPEN Disconnect: Ignition Switch C250. Measure the resistance between the output side of fuse F1.8 (30A) and ignition switch C250, pin 4. Is the resistance less than 5 ohms? Yes : GO to A9 . No : REPAIR circuit 30-BB9 (RD) for an open.
9. A9 CHECK CIRCUIT 31S-TA34 (BK/YE) FOR AN OPEN Measure the resistance between ignition switch C250, pin 3 and selector lever unit C3233, pin 2. Is the resistance less than 5 ohms? Yes : GO to A10 . No : REPAIR circuit 31S-TA34 (BK/YE).
10. A10 CHECK THE GEARSHIFT LEVER UNIT Measure the resistance between range selector lever unit C3233 component side, pins 2 and 1 with the range selector lever in positions R, N, D, 1 and 2. Is the resistance less than 5 ohms? Yes : INSTALL a new key removal inhibit solenoid. TEST the system for normal operation. No : INSTALL a new selector lever. TEST the system for normal operation.
11. A11 CHECK CIRCUIT 31S-TA34 (BK/YE) FOR A SHORT TO GROUND Disconnect: Generic Electronic Module (GEM) C201d. Disconnect: Selector Lever C3233. Disconnect: Ignition Switch C250. Measure the resistance between ignition switch C250, pin 3 and ground. Is the resistance greater than 10,000 ohms? Yes : GO to A12 . No : REPAIR circuit 31S-TA34 (BK/YE) for a short to ground.
12. A12 CHECK THE IGNITION SWITCH AND IGNITION LOCK CYLINDER FOR MECHANICAL DAMAGE Connect: GEM C201d. Connect: Selector Lever C3233. Connect: Ignition Switch C250. Remove BJB fuse F1.8 (30A) and attempt to turn the ignition key to the OFF position. Does the ignition cylinder turn to the OFF position? Yes : INSTALL a new selector lever. TEST the system for normal operation. No : INSPECT the ignition switch and ignition lock cylinder for damage. REPAIR or INSTALL new as required.

Scheme 550

Scheme 551

Scheme 552

Scheme 553

1. B1 CHECK CIRCUIT 15-TA21 (GN/BK) FOR VOLTAGE Key in ON position. Measure circuit 15-TA21 (GN/BK) for voltage at range selector lever C3233, pin 5. Is voltage greater than 10 volts? Yes : GO to B2 . No : REPAIR circuit 15-TA21 (GN/BK) for open. TEST the system for normal operation.
2. B2 TEST THE OVERDRIVE SWITCH Measure the resistance between range selector lever unit C3233, pin 5 and pin 6 with the overdrive (O/D) switch pressed and released. Is the resistance less than 5 ohms when pressed and greater than 10,000 ohms when released? Yes : GO to B3 . No : CHECK range selector lever harness for broken or damaged wires. If harness is OK, INSTALL a new gearshift lever knob.
3. B3 CHECK CIRCUIT 15S-TA21 (GN/BK) FOR A SHORT TO GROUND Disconnect: PCM C175. Inspect for damaged or pushed-out pins, corrosion or loose wires. Repair as necessary. Measure circuit 15S-TA21 (GN/BK) for resistance to ground at PCM C175, pin 29. Is the resistance greater than 10,000 ohms? Yes : GO to B4 . No : REPAIR circuit 15S-TA21 (GN/BK) for a short to ground. TEST the system for normal operation.
4. B4 CHECK CIRCUIT 15S-TA21 (GN/BK) FOR AN OPEN Disconnect: PCM C175. Inspect for damaged or pushed-out pins, corrosion or loose wires. Repair as necessary. Disconnect: Range Selector Lever C3233. Measure the resistance of circuit 15S-TA21 (GN/BK) between PCM C175, pin 29 and range selector lever C3233, pin 6. Is the resistance less than 5 ohms? Yes : INSTALL a new PCM. TEST the system for normal operation. No : REPAIR circuit 15S-TA21 (GN/BK) for open. TEST the system for normal operation.

Scheme 554

Scheme 555

Scheme 556

Scheme 557

1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING AND LIFTING»(ref-255374) .
2. Shift selector lever in DRIVE position.
3. Disconnect the shift cable end from the manual control lever.
4. Unlock the shift cable end. Make sure that the cable end moves freely.
5. Move the transaxle selector lever to DRIVE position (TR sensor removed shown).
6. Connect the shift cable end of the manual control lever.
7. Press the lock tab down to secure the cable end from moving.
8. Check to make sure that the vehicle starts in PARK and NEUTRAL and the reverse lamps illuminate in REVERSE.

Transmission Selector Lever

MATERIAL SPECIFICATION

Scheme 558

Scheme 559

Scheme 560

Scheme 561

1. Remove the floor console. For additional information, refer to «INSTRUMENT PANEL AND CONSOLE»(ref-255410) .
2. Remove the selector lever cable from the selector. Shift the selector lever to PARK. Unclip the selector lever cable. Unclip the selector lever cable outer sleeve.
3. Disconnect the selector lever assembly electrical connector.
4. Remove the selector lever assembly. Remove the 4 nuts.

Scheme 562

Scheme 563

Scheme 564

1. Install the selector lever assembly. Install the 4 nuts. Tighten to 9 Nm (80 lb-in).
2. Connect the selector lever assembly electrical connector.
3. Install the selector cable to the selector lever. Shift the selector lever to PARK. Clip in the selector lever cable outer sleeve. Clip in the selector lever cable.
4. Install the floor console. For additional information, refer to «INSTRUMENT PANEL AND CONSOLE»(ref-255410) .
5. Adjust the selector lever cable. For additional information, refer to «SELECTOR LEVER CABLE ADJUSTMENT»(ref-255432-S26761535452007053100000) in this article.

Scheme 565

Scheme 566

1. Remove the selector lever knob. For additional information, refer to «SELECTOR LEVER KNOB»(ref-255432-S23187698802007053100000) .
2. Remove the selector lever bezel. Unclip the bezel. Unclip the lamp.

Scheme 567

1. Install the selector lever bezel. Clip in the bezel. Clip in the lamp.
2. Install the selector lever knob. For additional information, refer to «SELECTOR LEVER KNOB»(ref-255432-S23187698802007053100000) .

Scheme 568

Scheme 569

1. Remove the floor console. For additional information, refer to «INSTRUMENT PANEL AND CONSOLE»(ref-255410) .
2. Disconnect the overdrive (O/D) switch electrical connector.
3. Remove the selector lever knob. Remove and discard the screw. Pull off the knob.

Scheme 570

1. Position the selector lever knob onto the lever and route the wiring harness through the transmission range indicator.
2. Slide the selector lever knob down the shaft and install a new screw.
3. Connect the O/D switch electrical connector.
4. Install the floor console. For additional information, refer to «INSTRUMENT PANEL AND CONSOLE»(ref-255410) .

MATERIAL SPECIFICATION

Scheme 571

Scheme 572

1. Disconnect the overdrive (O/D) switch electrical connector.
2. Remove the selector lever knob. Remove and discard the screw.
3. Disassemble the selector lever. Pull off the tappet. Unclip the bezel.
