TORQUE SPECIFICATIONS
| Description | Nm | Lb-ft | Lb-in |
|---|---|---|---|
| Lower arm to wheel knuckle pinch bolt nut | 50 | 37 | |
| Wheel knuckle to strut and spring assembly pinch bolt | 90 | 66 | |
| Wheel hub nut | 316 | 233 | |
| Wheel speed sensor bolt | 9 | 80 | |
| Tie-rod end to wheel knuckle nut | 47 | 35 | |
| Stabilizer bar to connecting link nuts | 50 | 37 | |
| Strut top mount nuts | 25 | 18 | |
| Strut and spring assembly thrust bearing nut | 48 | 35 | |
| Disc brake caliper to wheel knuckle bolts | 28 | 21 | |
| Lower arm bolts (1) | |||
| Stabilizer bar clamp bolts | 70 | 52 | |
| Connecting link to strut and spring assembly nut | 50 | 37 | |
| Steering column shaft coupling. | 28 | 21 | |
| Crossmember retaining bolts (M12) | 115 | 85 | |
| Crossmember retaining bolts (M14) | 175 | 129 | |
| (1) Refer to the procedure | |||
| (1) | Refer to the procedure |
TORQUE SPECIFICATIONS
Scheme 1
Note. The final tightening of the suspension must be carried out at curb ride height.
Carry out the final tightening of the suspension components with the vehicle on a drive-on hoist or on an alignment rack.
For additional information, refer to SUSPENSION SYSTEM -- GENERAL INFORMATION .
Scheme 2
Scheme 3
Scheme 4
Scheme 5
- Remove the wheel knuckle. For additional information, refer to «WHEEL KNUCKLE»(ref-207737-S10598478992005120100000) .
- Using the special tools, remove the wheel hub and outer bearing race.
- Using the special tools, remove the bearing inner ring from the wheel hub.
- Remove the circlip from the wheel knuckle.
- Install the old bearing inner ring. Install the bearing cage onto the bearing inner ring. Install the bearing cage and inner ring assembly to the wheel knuckle.
- Using the special tools, remove the bearing outer ring from the wheel knuckle.
