Sunroof: Removal & Installation Ford Focus I рестайлинг

Installation

1. To install, reverse the removal procedure.
2. Adjust the roof opening panel glass For additional information, refer to «ROOF OPENING PANEL ALIGNMENT»(ref-207814-S01739274842005120100000) .

Scheme 7

Scheme 8

Scheme 9

1. Detach the overhead console trim panel from the overhead console. Using a suitable screwdriver, detach the front retaining clips. Pull the overhead console trim panel downwards to detach the side retaining clips. Push the overhead console trim panel forwards to detach the rear retaining clips.
2. Remove the overhead console trim panel. Disconnect the power roof opening panel control switch electrical connector.
3. Disconnect the roof opening panel motor electrical connector (headliner shown removed for clarity).
4. Remove the roof opening panel motor.

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Scheme 14

Scheme 15

Scheme 16

Scheme 17

1. Remove the roof opening panel guide arm covers.
2. Check the alignment of the left-hand and right-hand cable guide pins (left-hand side shown). Depress the bar.
3. Adjust the left-hand cable guide pin. Using a suitable screwdriver, move the cable in the direction required
4. Adjust the right-hand cable guide pin. Using a suitable screwdriver, move the cable in the direction required.
5. Install the roof opening panel guide arm covers
6. Connect the roof opening panel motor electrical connector (headliner shown removed for clarity).
7. Connect the roof opening panel motor control switch electrical connector.
8. Carry out the Erasing Roof Opening Panel Motor Initialization procedure. For additional information, refer to «ROOF OPENING PANEL MOTOR INITIALIZATION»(ref-207814-S22485557862005120100000) .
9. Install the roof opening panel motor.
10. Carry out the appropriate Roof Opening Panel Motor Initialization procedure. For additional information, refer to «ROOF OPENING PANEL MOTOR INITIALIZATION»(ref-207814-S22485557862005120100000) .
11. Install the overhead console trim panel.

1. To install, reverse the removal procedure.

Scheme 18

Scheme 19

Scheme 20

Scheme 21

Scheme 22

Scheme 23

Scheme 24

Scheme 25

1. Remove the headliner. For additional information, refer to «HEADLINER»(ref-207807-S06061169332005120100000) .
2. Remove the load space floor covering.
3. Detach the scuff plate from the liftgate opening panel.
4. Remove the C-pillar lower trim panel.
5. Detach the load space trim panel from the rear quarter trim panel.
6. Remove the rear parcel shelf support.
7. Remove the load space trim panel.
8. Detach the drain hose from the roof opening panel.
9. Remove the rear drain hose.

1. To install, reverse the removal procedure.

Scheme 26

1. Remove the headliner. For additional information, refer to «HEADLINER»(ref-207807-S06061169332005120100000) .
2. Detach the C-pillar lower trim panel from the load space trim panel.
3. Remove the rear drain hose. Detach the drain hose from the roof opening panel. Detach the drain hose from the clips.

1. To install, reverse the removal procedure.
