Water Drainage System Check And Water Leak Corrections - 3-Door

1. If a drain hose blockage or obstruction is suspected, check the drain hoses by pouring 500 ml of water into the drain trough and checking the flow from under the vehicle rocker panels. Attempt to clear any blockage or obstruction using a drain clearing wire (nylon). If the blockage or obstruction cannot be cleared the drain hose must be removed. For additional information, refer to «ROOF OPENING PANEL FRONT DRAIN HOSE»(ref-207814-S10913189202005120100000) or «ROOF OPENING PANEL REAR DRAIN HOSE - 3-DOOR»(ref-207814-S31908116532005120100000) .
2. If a drain hose leak is suspected the drain hose must be removed and inspected for cracks or splits. For additional information, refer to «ROOF OPENING PANEL FRONT DRAIN HOSE»(ref-207814-S10913189202005120100000) or «ROOF OPENING PANEL REAR DRAIN HOSE - 3-DOOR»(ref-207814-S31908116532005120100000) .

Water Drainage System Check And Water Leak Corrections - 4-Door/5-Door/Wagon

1. If a drain hose blockage or obstruction is suspected, check the drain hoses by pouring 500 ml of water into the drain trough and checking the flow from under the vehicle rocker panels. Attempt to clear any blockage or obstruction using a drain clearing wire (nylon). If the blockage or obstruction cannot be cleared the drain hose must be removed. For additional information, refer to «ROOF OPENING PANEL FRONT DRAIN HOSE»(ref-207814-S10913189202005120100000) or «ROOF OPENING PANEL REAR DRAIN HOSE - 4-DOOR/5-DOOR/WAGON»(ref-207814-S39862955262005120100000) .
2. If a drain hose leak is suspected the drain hose must be removed and inspected for cracks or splits. For additional information, refer to «ROOF OPENING PANEL FRONT DRAIN HOSE»(ref-207814-S10913189202005120100000) or «ROOF OPENING PANEL REAR DRAIN HOSE - 4-DOOR/5-DOOR/WAGON»(ref-207814-S39862955262005120100000) .

Scheme 27

Scheme 28

Scheme 29

Scheme 30

1. Remove the roof opening panel guide arm covers (if equipped).
2. Place a suitable 1.0 -1.2 mm thick, 150 mm long plastic spacer between the rear edge of the roof opening panel glass and the roof panel opening.
3. Adjust the rear edge of the roof opening panel glass. Loosen the retaining screws. Push the rear edge up or down to give the correct alignment (flush to + 1 mm).
4. Make sure that the roof opening panel glass is located centrally in the roof panel opening.
5. Tighten the rear retaining screws.
6. Adjust the front edge of the roof opening panel glass. Push the front edge up or down to give the correct alignment (flush to -1 mm). Tighten the front retaining screws.
7. Install the roof opening panel guide arm covers (if equipped).
8. Operate the roof opening panel and check the alignment.
9. Check the roof opening panel seal for wind noise and water leaks.
