Sunroof: Other Ford Focus I рестайлинг

Sun Roof/t-Top/convertible Top 23 illustrations ~1290 words

Roof Opening Panel

The roof opening panel is manually operated and is available as optional equipment. It requires a specific roof panel and headliner. A unique overhead console incorporates the interior lamp and houses the roof opening handle.

Refer to POWER TOP/SUNROOF for schematic and connector information.

Pinpoint Tests

Note. Use a digital multimeter for all electrical measurements.

Roof Opening Panel Control Switch

  1. Measure the resistance between the following: ROOF OPENING PANEL CONTROL SWITCH RESISTANCE CHART Roof Opening Panel Control Switch Position Terminals Measurements Neutral 1 - 5 Greater than 10,000 ohms Neutral 2 - 6 Greater than 10,000 ohms Neutral 5 - 6 Greater than 10,000 ohms Neutral 6 - 1 Greater than 10,000 ohms Fully Up/Close 5 - 6 Less than 100 ohms Fully Up/Close 5 - 1 Greater than 10,000 ohms Fully Up/Close 5 - 2 Less than 100 ohms Fully Up/Close 2 - 6 Less than 100 ohms Fully Down/Open 2 - 6 Less than 100 ohms Fully Down/Open 2 - 5 Less than 100 ohms Fully Down/Open 5 - 6 Less than 100 ohms Fully Down/Open 2 - 1 Greater than 10,000 ohms
  2. Apply +12v battery positive to the roof opening panel control switch C9014 pin 1, component side and 0v battery negative to the roof opening panel control switch C9014 pin 6, component side. The LED should illuminate.
  3. If all measurements of the roof opening panel control switch are as noted, return to the Pinpoint Test. Otherwise install a new roof opening panel control switch.

Updating Roof Opening Panel Motor Initialization

WARNINGThe roof opening panel anti-trap function will not operate during the updating roof opening panel motor initialization procedure. Make sure that the roof opening panel opening is free of all foreign material. Failure to follow this instruction may result in personal injury.

Note. This procedure should only be carried out when the roof opening panel motor has not been disconnected.

Note. The roof opening panel alignment must be carried out prior to carrying out roof opening panel motor initialization. For additional information, refer to ROOF OPENING PANEL ALIGNMENT .

  1. Operate the roof opening panel control switch to the up/close position until the roof opening panel is in the fully open/vent position.
  2. Release the roof opening panel control switch.
  3. Operate the roof opening panel control switch to the up/close position and hold for 30 seconds until there is a small movement (approximately 2 mm) and the roof opening panel motor stops.
  4. Release the roof opening panel control switch.
  5. Operate the roof opening panel control switch to the up/close position again within 0.5 seconds until the roof opening panel stops (one complete cycle).

Initial Roof Opening Panel Motor Initialization

WARNINGThe roof opening panel anti-trap function will not operate during the updating roof opening panel motor initialization procedure. Make sure that the roof opening panel opening is free of all foreign material. Failure to follow this instruction may result in personal injury.

Note. This procedure must be carried out when installing any roof opening panel motor or roof opening panel.

Note. The roof opening panel alignment must be carried out prior to carrying out roof opening panel motor initialization. For additional information, refer to ROOF OPENING PANEL ALIGNMENT .

  1. Operate the roof opening panel control switch to the up/close position.
  2. Release the roof opening panel control switch.
  3. Operate the roof opening panel control switch to the up/close position again within 0.5 seconds until the roof opening panel stops (one complete cycle).

Erasing Roof Opening Panel Motor Initialization

Note. The erasing procedure is to be carried out only when the roof opening panel motor has been detached from the roof opening panel.

Note. This procedure must be carried out before installing a previously used roof opening panel motor.

  1. Connect the roof opening panel motor electrical connector.
  2. Operate the roof opening panel control switch to the up/close position until the roof opening panel motor stops.
  3. Release the roof opening panel control switch.
  4. Operate the roof opening panel control switch again to the up/close position and hold for 30 seconds. With the roof opening panel control switch held, the roof opening panel motor will rotate in one direction.
  5. Release the roof opening panel control switch.
  6. Operate the roof opening panel control switch to the down/open position. If the roof opening panel motor does not rotate, the erasing procedure has been carried out successfully.
  7. If the roof opening panel motor rotates (with the roof opening panel control switch in the down/open position), repeat the procedure.

Scheme 31

Scheme 31: Removal
Scheme 31: Removal

Scheme 32

Scheme 32
Scheme 32

Scheme 33

Scheme 33
Scheme 33
  1. Remove the headliner. For additional information, refer to «HEADLINER»(ref-207807-S06061169332005120100000) .
  2. Detach the drain hoses from the roof opening panel.
  3. Detach the roof opening panel from the roof panel (12 bolts).
  4. Remove the roof opening panel. With the aid of another technician, compress the legs of the retaining clips and lower the roof opening panel.

Scheme 34

Scheme 34: Installation
Scheme 34: Installation

Scheme 35

Scheme 35
Scheme 35
  1. Install the roof opening panel.
  2. Tighten the retaining bolts in the sequence shown.
  3. Attach the drain hoses to the roof opening panel.
  4. Install the headliner. For additional information, refer to «INSTRUMENT PANEL AND CONSOLE»(ref-207811) .

Scheme 36

Scheme 36: Removal
Scheme 36: Removal

Scheme 37

Scheme 37
Scheme 37

Scheme 38

Scheme 38
Scheme 38
  1. Move the roof opening panel shield rearwards.
  2. Remove the roof opening panel guide arm covers.
  3. Remove the roof opening panel glass retaining screws on both sides.
  4. Remove the roof opening panel glass.

Scheme 39

Scheme 39: Installation
Scheme 39: Installation
  1. Position the roof opening panel glass in the roof opening panel.
  2. Install the roof opening panel glass.
  3. Align the roof opening panel glass. For additional information, refer to «ROOF OPENING PANEL ALIGNMENT»(ref-207814-S01739274842005120100000) .
  4. Install the roof opening panel guide arm covers.
  5. Move the roof opening panel shield forwards.

Scheme 40

Scheme 40: Removal
Scheme 40: Removal

Scheme 41

Scheme 41
Scheme 41

Scheme 42

Scheme 42
Scheme 42

Scheme 43

Scheme 43
Scheme 43

Scheme 44

Scheme 44
Scheme 44
  1. Remove the roof opening panel glass. For additional information, refer to «ROOF OPENING PANEL GLASS»(ref-207814-S09446764262005120100000) .
  2. Detach the water channel.
  3. Lift the front of the wind deflector clear of the roof panel.
  4. Remove the wind deflector. Using a small screwdriver disconnect the locating pegs from the hinges.
  5. Remove the roof opening panel glass guide arms.
  6. Wind the roof opening panel cable guides to the rear of the cover panel.
  7. Remove the cover panel. Remove the 16 screws.
  8. Detach the cable from the roof opening panel frame.
  9. Remove the cable and guide. Slide the guide forward. Disengage the guide from the guide rail.

Scheme 45

Scheme 45: Installation
Scheme 45: Installation

Scheme 46

Scheme 46
Scheme 46

Scheme 47

Scheme 47
Scheme 47

Scheme 48

Scheme 48
Scheme 48

Scheme 49

Scheme 49
Scheme 49
  1. Install the cable and guide. Engage the guide in the guide rail. Slide the guide to the rear of the guide rail.
  2. Align both cable guides with the guide stud securing screw hole.
  3. Install the cable in the roof opening panel frame.
  4. Locate the cover panel onto the roof opening panel frame. Install the 10 front screws.
  5. Wind the cable guide to the rear of the frame.
  6. Secure the cover panel. Install the six remaining screws.
  7. Install the roof opening panel glass guide arms.
  8. Attach the water channel.
  9. Install the wind deflector.
  10. Lower the wind deflector into the roof panel.
  11. Install the roof opening panel glass. For additional information, refer to «ROOF OPENING PANEL GLASS»(ref-207814-S09446764262005120100000) .
  12. Adjust the roof opening panel glass. For additional information, refer to «ROOF OPENING PANEL ALIGNMENT»(ref-207814-S01739274842005120100000) .
  13. Operate the roof opening panel from fully open to fully closed.

Scheme 50

Scheme 50: Removal
Scheme 50: Removal
  1. Remove the roof opening panel glass. For additional information, refer to «ROOF OPENING PANEL GLASS»(ref-207814-S09446764262005120100000) .
  2. Wind the roof opening panel mechanism to the rear.
  3. Remove the cover panel. Remove the 16 screws.
  4. Remove the roof opening panel shield. Slide the roof opening panel shield out of the guide rails.

General Equipment

Suitable draw cord with a minimum length of two meters

GENERAL EQUIPMENT

Scheme 51

Scheme 51: Removal
Scheme 51: Removal

Scheme 52

Scheme 52
Scheme 52

Scheme 53

Scheme 53
Scheme 53
  1. Remove the headliner. For additional information, refer to «HEADLINER»(ref-207807-S06061169332005120100000) .
  2. Detach the drain hose from the roof opening panel.
  3. Detach the A-pillar lower trim panel from the A-pillar.
  4. Disconnect the auxiliary junction box electrical connector. Remove the bolt.
  5. Detach the auxiliary junction box from the A-pillar. Depress the clip. Detach the junction box.
  6. Detach the auxiliary junction box from the A-pillar. Disconnect the electrical connector. Depress the clip. Detach the junction box.
  7. Attach a suitable length of draw cord to the roof opening panel end of the drain hose, and secure the free end of the cord to the vehicle.
  8. Remove the front drain hose. Pull the drain hose down through the A-pillar.
