FLUID CAPACITIES
Note. Refill capacities not available from manufacturer.
| Application | Capacity - Qts. (L) |
|---|---|
| 4F27E | 7.0 (6.7) |
TRANSAXLE FLUID CAPACITIES
Torque Converter Always Applied/Stalls Vehicle
Check for damage/fault at PCM, shift solenoids SSB and SSC and related wiring. Check valve body for contamination, improperly tightened bolts, damaged separator plate and stuck valves/springs. Check low one-way clutch for damage or incorrect assembly. Check torque converter for internal failure.
Torque Converter Clutch (TCC) Cycling/Shudder/Chatter
Check for damage/fault at PCM, shift solenoids SSB and SSC and related wiring. Check valve body for contamination, improperly tightened bolts, damaged separator plate and stuck valves/springs. Check torque converter for internal failure.
Torque Converter Clutch (TCC) Does Not Apply
Check for damage/fault at PCM, shift solenoids SSB and SSC, TFT sensor and related wiring. Check valve body for contamination, improperly tightened bolts, damaged separator plate and stuck valves/springs. Check oil pump assembly for improperly tightened bolts, damaged/leaking pump gasket, missing check ball and plugged passage. Check torque converter for internal failure.
Torque Converter End Play Test
Install torque converter gauge Special Tool (307-409) to torque converter as shown. (Scheme 1) Using special tool, measure torque converter end play by pulling up on the special tool. Dial indicator reading should not exceed.002-.020" (.05-.51 mm). If dial indicator reading exceeds specification, replace torque converter.
Scheme 1
Scheme 2
- Thoroughly clean outside surface of torque converter. Install torque converter leak check Special Tool and Gasket (307-421). Install special tool with torque converter into an arbor press as shown. (Scheme 2) Apply enough pressure from press to seal special tool to torque converter. Apply air pressure to special tool valve.
- Using a soap solution, inspect torque converter hub, seams and studs for leaks. If any leaks are present, replace torque converter. Remove air pressure. Release pressure in torque converter through release valve. Slowly release press and remove special tool.
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|---|
| Converter Housing To Case Bolts | 22 (30) |
| Engine/Transaxle Flange Bolts | 35 (47) |
| Final Drive Input Gear Bearing Retainer Nut | 332 (450) |
| Intermediate/Overdrive Band Anchor Bolt | 33 (45) |
| Intermediate/Overdrive Band Servo Cover Bolts | 10 (14) |
| Lower Suspension Arm Bolt | 37 (50) |
| Oil Cooler Tubes | 18 (24) |
| Oil Pump Bolts | 16 (22) |
| Oil Pump Case Bolts | 10 (14) |
| Parking Pawl Bolts | 10 (14) |
| Parking Pawl Cover Bolts | 10 (14) |
| Ring Gear Bolt | 89 (121) |
| Right Side Drive Axle Center Bearing Cap Nuts | 18 (24) |
| Shift Lever Bolt | 10 (14) |
| Strut Nuts | 35 (47) |
| Tie Rod Nut | 35 (47) |
| Torque Converter To Engine Drive Plate Bolts | 27 (37) |
| Transaxle End Cover Bolts | 16 (22) |
| Wheel Nuts | 63 (85) |
| INCH Lbs. (N.m) | |
| Oil Filler Tube Bolt | 80 (9) |
| Oil Pan Bolt | 62 (7) |
| OSS Sensor Bolt | 89 (10) |
| Solenoid Body Bolts | 80 (9) |
| TR Sensor Bolt | 89 (10) |
| Transaxle Pan Bolt | 62 (7) |
| TSS Sensor Bolt | 89 (10) |
| Valve Body Bolts | 80 (9) |
| Valve Body Ground Wire Bolt | 89 (10) |
TORQUE SPECIFICATIONS
TRANSAXLE SPECIFICATIONS
| Application | In. (mm) |
|---|---|
| Forward Clutch | .059-.071 (1.50-1.80) |
| Direct & Reverse Clutch | .039-.051 (1.00-1.30) |
| Low/Reverse Clutch | .087-.098 (2.20-2.50) |
| Transaxle End Play | .010-.020 (.25-.50) |
CLEARANCE SPECIFICATIONS
