Specifications
| Specifications | |
|---|---|
| Motorcraft® SAE 5W-20 Premium Synthetic Blend Motor Oil XO-5W20-QSP | WSS-M2C945-A |
| Penetrating and Lock Lubricant | XL-1 |
| High Temperature Nickel Anti-Seize Lubricant | XL-2 |
LUBRICANTS, FLUIDS, SEALERS AND ADHESIVES
Scheme 1
| Item | Description |
|---|---|
| 1 | 6C315 Comments: CKP sensor |
| 2 | 6M280 Comments: VCT oil control solenoid |
| 3 | 12A648 Comments: ECT sensor |
| 4 | 6B288 Comments: CMP sensor |
| 5 | 12A699 Comments: KS |
| 6 | 9F972 Comments: FRP sensor |
Scheme 2
| Item | Description |
|---|---|
| 1 | 12A650 Comments: PCM |
Overview
Refer to the ENGINE CONTROLS - DESCRIPTION & OPERATION (EXCEPT DIESEL & HYBRID) .
System Operation
Refer to the ENGINE CONTROLS - DESCRIPTION & OPERATION (EXCEPT DIESEL & HYBRID) .
DTC Chart: Powertrain Control Module (PCM)
| DTC | Description | Action |
|---|---|---|
| PCM DTCs | Powertrain Control Module (PCM) Diagnostic Trouble Codes (DTCs) not listed in this chart | ENGINE CONTROLS - SYMPTOM CHARTS (EXCEPT DIESEL & HYBRID) . |
| P0125 | Insufficient Coolant Temp For Closed Loop Fuel Control | REFER to: ENGINE COOLING . |
| P0128 | Coolant Thermostat (Coolant Temp Below Thermostat Regulating Temperature) | REFER to: ENGINE COOLING . |
| P0217 | Engine Coolant Overtemperature Condition | REFER to: ENGINE COOLING . |
| P0460 | Fuel Level Sensor "A" Circuit | First, INTRODUCTION - GASOLINE MODELS If sent here from PC/ED , REFER to: INSTRUMENTATION, MESSAGE CENTER AND WARNING CHIMES . |
| P0461 | Fuel Level Sensor "A" Circuit Range/Performance | First, INTRODUCTION - GASOLINE MODELS If sent here from PC/ED , REFER to: INSTRUMENTATION, MESSAGE CENTER AND WARNING CHIMES . |
| P0462 | Fuel Level Sensor "A" Circuit Low | First, INTRODUCTION - GASOLINE MODELS If sent here from PC/ED , REFER to: INSTRUMENTATION, MESSAGE CENTER AND WARNING CHIMES . |
| P0463 | Fuel Level Sensor "A" Circuit High | First, INTRODUCTION - GASOLINE MODELS If sent here from PC/ED , REFER to: INSTRUMENTATION, MESSAGE CENTER AND WARNING CHIMES . |
| P0504 | Brake Switch "A"/"B" Correlation | REFER to: CRUISE CONTROL . |
| P0532 | A/C Refrigerant Pressure Sensor "A" Circuit Low | For Electronic Manual Temperature Control (EMTC) vehicles, REFER to: CLIMATE CONTROL SYSTEM - VEHICLES WITH: ELECTRONIC MANUAL TEMPERATURE CONTROL (EMTC) . For Dual Automatic Temperature Control (DATC) vehicles, REFER to: CLIMATE CONTROL SYSTEM - VEHICLES WITH: DUAL AUTOMATIC TEMPERATURE CONTROL . |
| P0533 | A/C Refrigerant Pressure Sensor "A" Circuit High | For Electronic Manual Temperature Control (EMTC) vehicles, REFER to: CLIMATE CONTROL SYSTEM - VEHICLES WITH: ELECTRONIC MANUAL TEMPERATURE CONTROL (EMTC) . For Dual Automatic Temperature Control (DATC) vehicles, REFER to: CLIMATE CONTROL SYSTEM - VEHICLES WITH: DUAL AUTOMATIC TEMPERATURE CONTROL . |
| P0562 | System Voltage Low | REFER to: CHARGING SYSTEM - 2.0L Duratec-HE . |
| P0563 | System Voltage High | REFER to: CHARGING SYSTEM - 2.0L Duratec-HE . |
| P0572 | Brake Switch "A" Circuit Low | REFER to: REFER to: CRUISE CONTROL .. |
| P0573 | Brake Switch "A" Circuit High | REFER to: REFER to: CRUISE CONTROL .. |
| P059F | Active Grille Air Shutter "A" Performance/Stuck Off | REFER to: ACTIVE GRILLE SHUTTER . |
| P05A1 | Active Grille Air Shutter "A" Position Sensor Minimum/Maximum Stop Performance | REFER to: ACTIVE GRILLE SHUTTER . |
| P05A2 | Active Grille Air Shutter "A" Control Circuit/Open | REFER to: ACTIVE GRILLE SHUTTER . |
| P05A7 | Active Grille Air Shutter Control Module "A" Supply Voltage Circuit Low | REFER to: ACTIVE GRILLE SHUTTER . |
| P05C0 | Active Grille Air Shutter Module "A" Over Temperature | INSTALL a new grille shutter actuator. REFER to: ACTIVE GRILLE SHUTTER . |
| P0615 | Starter Relay Circuit | REFER to: STARTING SYSTEM . |
| P0645 | A/C Clutch Relay Control Circuit | For Electronic Manual Temperature Control (EMTC) vehicles, REFER to: CLIMATE CONTROL SYSTEM - VEHICLES WITH: ELECTRONIC MANUAL TEMPERATURE CONTROL (EMTC) . For Dual Automatic Temperature Control (DATC) vehicles, REFER to: CLIMATE CONTROL SYSTEM - VEHICLES WITH: DUAL AUTOMATIC TEMPERATURE CONTROL . |
| P065B | Generator Control Circuit Range/Performance | INSTALL a new generator. REFER to: GENERATOR - 2.0L DURATEC-HE . |
| P065C | Generator Mechanical Performance | REFER to: CHARGING SYSTEM - 2.0L Duratec-HE . |
| P0833 | Clutch Pedal Switch "B" Circuit | REFER to: REFER to: CRUISE CONTROL .. |
| P0850 | Park / Neutral Switch Input Circuit | REFER to: AUTOMATIC TRANSMISSION . |
| P0851 | Park / Neutral Switch Input Circuit Low | REFER to: AUTOMATIC TRANSMISSION . |
| P0A3B | Generator Over Temperature | CARRY OUT self-test of the Powertrain Control Module (PCM) and DIAGNOSE any grille shutter or cooling fan Diagnostic Trouble Codes (DTCs). If necessary, REFER to: ACTIVE GRILLE SHUTTER . If no grille shutter or cooling fan Diagnostic Trouble Codes (DTCs) are present, INSTALL a new generator. REFER to: GENERATOR - 2.0L DURATEC-HE . |
| P1464 | A/C Demand Out Of Self Test Range | For Electronic Manual Temperature Control (EMTC) vehicles, REFER to: CLIMATE CONTROL SYSTEM - VEHICLES WITH: ELECTRONIC MANUAL TEMPERATURE CONTROL (EMTC) . For Dual Automatic Temperature Control (DATC) vehicles, REFER to: CLIMATE CONTROL SYSTEM - VEHICLES WITH: DUAL AUTOMATIC TEMPERATURE CONTROL . |
| P161A | Incorrect Response from Immobilizer Control Module | The Body Control Module (BCM) ID received by the Powertrain Control Module (PCM) does not match the ID stored in the Powertrain Control Module (PCM) memory. CARRY OUT a parameter reset. For vehicles without Push button start, REFER to: PASSIVE ANTI-THEFT SYSTEM (PATS) . For vehicles with Push button start, REFER to: PASSIVE ANTI-THEFT SYSTEM (PATS) (Push Button Start) . |
| P1703 | Brake Switch Out Of Self Test Range | REFER to: REFER to: CRUISE CONTROL .. |
| P193E | A/C Clutch Request Signal | For Electronic Manual Temperature Control (EMTC) vehicles, REFER to: CLIMATE CONTROL SYSTEM - VEHICLES WITH: ELECTRONIC MANUAL TEMPERATURE CONTROL (EMTC) . For Dual Automatic Temperature Control (DATC) vehicles, REFER to: CLIMATE CONTROL SYSTEM - VEHICLES WITH: DUAL AUTOMATIC TEMPERATURE CONTROL . |
| P2531 | Ignition Switch Run Position Circuit Low | REFER to: STARTING SYSTEM . |
| P2532 | Ignition Switch Run Position Circuit High | REFER to: STARTING SYSTEM . |
| P2534 | Ignition Switch Run/Start Position Circuit Low | REFER to: STARTING SYSTEM . |
| P2535 | Ignition Switch Run/Start Position Circuit High | REFER to: STARTING SYSTEM . |
| U012D | Lost Communication With Generator Control Module | REFER to: CHARGING SYSTEM - 2.0L Duratec-HE . |
| U0284 | Lost Communication With Active Grille Air Shutter Control Module "A" | REFER to: ACTIVE GRILLE SHUTTER . |
| U042E | Invalid Data Received From Generator Control Module | REFER to: CHARGING SYSTEM - 2.0L Duratec-HE . |
POWERTRAIN CONTROL MODULE (PCM) DTC CHART
Camshaft Position (CMP) Sensor
| Name | Specification |
|---|---|
| Motorcraft® SAE 5W-20 Premium Synthetic Blend Motor Oil XO-5W20-QSP | WSS-M2C945-A |
MATERIALS SPECIFICATIONS
Removal
Note. Removal steps in this procedure may contain installation details.
Scheme 3
Scheme 4
- Refer to: Health and Safety Precautions ( «HEALTH AND SAFETY PRECAUTIONS»(/ford/focus-st/iii-2012-2015/remont/oem-general-information/#service-information-introduction-except-electric) ).
- LH CMP sensor Torque : 6 Nm
- RH CMP sensor Torque : 6 Nm
Scheme 5
- To install, reverse the removal procedure. Material : Motorcraft® SAE 5W-20 Premium Synthetic Blend Motor Oil / XO-5W20-QSP (WSS-M2C945-A)
Crankshaft Position (CKP) Sensor
SPECIAL TOOL(S) / GENERAL EQUIPMENT 303-1521 Alignment Tool, Crankshaft Position Sensor 303-507 Timing Peg, Crankshaft TDC TKIT-2001N-FLM
Scheme 6
Scheme 7
Scheme 8
Scheme 9
Scheme 10
Scheme 11
- Refer to: Health and Safety Precautions ( «HEALTH AND SAFETY PRECAUTIONS»(/ford/focus-st/iii-2012-2015/remont/oem-general-information/#service-information-introduction-except-electric) ).
- Refer to: Jacking and Lifting - Overview ( «JACKING AND LIFTING - OVERVIEW»(/ford/focus-st/iii-2012-2015/remont/hoistjack/#jacking-lifting-except-electric) ).
- Remove the RH wheel and tire. Refer to: «WHEEL AND TIRE»(/ford/focus-st/iii-2012-2015/remont/wheel-tire-system/#wheels-tires-except-electric__wheel-and-tire) .
- Remove the RH front fender splash shield. Refer to: «FENDER SPLASH SHIELD»(/ford/focus-st/iii-2012-2015/remont/exterior-body-panels/#body-panel-system-front-end-body-panels-except-electric) .
- Disconnect the CKP electrical connector.
- Turn the crankshaft until piston no. 1 is 45 degrees BTDC by using the guide holes on the engine front cover and the crankshaft pulley.
- Turn the crankshaft clockwise until the crankshaft contacts the special tool. Install the Special Tool(s) : 303-507 (Timing Peg, Crankshaft TDC)
- Install a 6 mm x 18 mm bolt through the crankshaft pulley TDC guide hole and into the engine front cover TDC guide hole.
Scheme 12
Scheme 13
- NOTE: Do not tighten the bolts at this time.
- Special Tool(s) : 303-1521 (Alignment Tool, Crankshaft Position Sensor) Torque : 7 Nm
- Connect the CKP electrical connector.
- Remove the 6 mm x 18 mm bolt.
- Remove the special tool and install the cylinder block plug. Remove the Special Tool(s) : 303-507 (Timing Peg, Crankshaft TDC) Torque : 20 Nm
- Install the RH front fender splash shield. Refer to: «FENDER SPLASH SHIELD»(/ford/focus-st/iii-2012-2015/remont/exterior-body-panels/#body-panel-system-front-end-body-panels-except-electric) .
- Install the RH wheel and tire. Refer to: «WHEEL AND TIRE»(/ford/focus-st/iii-2012-2015/remont/wheel-tire-system/#wheels-tires-except-electric__wheel-and-tire) .
Powertrain Control Module (PCM)
| Ford Diagnostic Equipment |
SPECIAL TOOL(S) / GENERAL EQUIPMENT
Note. Removal steps in this procedure may contain installation details.
Scheme 14
Scheme 15
- Refer to: Health and Safety Precautions ( «HEALTH AND SAFETY PRECAUTIONS»(/ford/focus-st/iii-2012-2015/remont/oem-general-information/#service-information-introduction-except-electric) ).
- Retrieve the module configuration. Carry out the module configuration retrieval steps of the Programmable Module Installation (PMI) procedure. Refer to: «MODULE CONFIGURATION - SYSTEM OPERATION AND COMPONENT DESCRIPTION»(/ford/focus-st/iii-2012-2015/remont/communication-devices/#module-configuration-system-except-electric) . General Equipment : Ford Diagnostic Equipment
- Remove the LH inner fender splash shield. Refer to: «FENDER SPLASH SHIELD»(/ford/focus-st/iii-2012-2015/remont/exterior-body-panels/#body-panel-system-front-end-body-panels-except-electric) .
- Torque : 3 Nm
Installation
- To install, reverse the removal procedure.
- Restore the module configuration. Carry out the module configuration restore steps of the Programmable Module Installation (PMI) procedure. Refer to: «MODULE CONFIGURATION - SYSTEM OPERATION AND COMPONENT DESCRIPTION»(/ford/focus-st/iii-2012-2015/remont/communication-devices/#module-configuration-system-except-electric) . General Equipment : Ford Diagnostic Equipment
- Reprogram the PATS Refer to: Passive Anti-Theft System (PATS) Parameter Reset ( «PASSIVE ANTI-THEFT SYSTEM (PATS) PARAMETER RESET»(/ford/focus-st/iii-2012-2015/remont/door-locks-anti-theft-systems/#passive-anti-theft-system-except-electric__passive-anti-theft-system-pats-parameter-reset) ). Refer to: Passive Anti-Theft System (PATS) Parameter Reset ( «PASSIVE ANTI-THEFT SYSTEM (PATS) PARAMETER RESET»(/ford/focus-st/iii-2012-2015/remont/door-locks-anti-theft-systems/#passive-anti-theft-system-push-button-start-except-electric__passive-anti-theft-system-pats-parameter-reset) (Push Button Start) ).
Note. Removal steps in this procedure may contain installation details.
Scheme 16
Scheme 17
- Refer to: Health and Safety Precautions ( «HEALTH AND SAFETY PRECAUTIONS»(/ford/focus-st/iii-2012-2015/remont/oem-general-information/#service-information-introduction-except-electric) ).
- Torque : 8 Nm
- Torque : 2 Nm
- To install, reverse the removal procedure.
Heated Oxygen Sensor (HO2S)
SPECIAL TOOL(S) / GENERAL EQUIPMENT 303-476 Socket, Exhaust Gas Oxygen Sensor TKIT-1994-F TKIT-1994-FLM/FM TKIT-1994-LM/M
Scheme 18
| Name | Specification |
|---|---|
| High Temperature Nickel Anti-Seize Lubricant XL-2 | |
| Penetrating and Lock Lubricant XL-1 |
MATERIALS SPECIFICATIONS
Scheme 19
Scheme 20
- Refer to: Health and Safety Precautions ( «HEALTH AND SAFETY PRECAUTIONS»(/ford/focus-st/iii-2012-2015/remont/oem-general-information/#service-information-introduction-except-electric) ).
- Special Tool(s) : 303-476 (Socket, Exhaust Gas Oxygen Sensor) Material : Penetrating and Lock Lubricant / XL-1
Scheme 21
Scheme 22
- Calculate the correct torque wrench setting for the following torque. Refer to Torque Wrench Adapter Formula in the illustration . Special Tool(s) : 303-476 (Socket, Exhaust Gas Oxygen Sensor) Material : High Temperature Nickel Anti-Seize Lubricant / XL-2 Torque : 48 Nm
Catalyst Monitor Sensor
SPECIAL TOOL(S) / GENERAL EQUIPMENT 303-476 Socket, Exhaust Gas Oxygen Sensor TKIT-1994-F TKIT-1994-FLM/FM TKIT-1994-LM/M
| Name | Specification |
|---|---|
| High Temperature Nickel Anti-Seize Lubricant XL-2 | |
| Penetrating and Lock Lubricant XL-1 |
MATERIALS SPECIFICATIONS
Scheme 23
Scheme 24
Scheme 25
- Refer to: Health and Safety Precautions ( «HEALTH AND SAFETY PRECAUTIONS»(/ford/focus-st/iii-2012-2015/remont/oem-general-information/#service-information-introduction-except-electric) ).
- Refer to: Jacking and Lifting - Overview ( «JACKING AND LIFTING - OVERVIEW»(/ford/focus-st/iii-2012-2015/remont/hoistjack/#jacking-lifting-except-electric) ).
- Special Tool(s) : 303-476 (Socket, Exhaust Gas Oxygen Sensor) Material : Penetrating and Lock Lubricant / XL-1
Scheme 26
- Calculate the correct torque wrench setting for the following torque. Refer to Torque Wrench Adapter formula in the illustration . Special Tool(s) : 303-476 (Socket, Exhaust Gas Oxygen Sensor) Material : High Temperature Nickel Anti-Seize Lubricant / XL-2 Torque : 48 Nm
Fuel Rail Pressure (FRP) Sensor
| Name | Specification |
|---|---|
| Motorcraft® SAE 5W-20 Premium Synthetic Blend Motor Oil XO-5W20-QSP | WSS-M2C945-A |
MATERIALS SPECIFICATIONS
Scheme 27
- Refer to: «GASOLINE AND GASOLINE-ETHANOL FUEL SYSTEMS HEALTH AND SAFETY PRECAUTIONS»(/ford/focus-st/iii-2012-2015/remont/oem-general-information/#service-information-introduction-except-electric__gasoline-and-gasoline-ethanol-fuel-systems-health) .
- Refer to: «FUEL SYSTEM PRESSURE RELEASE»(/ford/focus-st/iii-2012-2015/remont/fuel-system/#fuel-system-general-information-20l-duratec-engine__fuel-system-pressure-release) .
- Disconnect the battery ground cable. Refer to: «BATTERY DISCONNECT AND CONNECT»(/ford/focus-st/iii-2012-2015/remont/charging-system/#battery-mounting-and-cables-except-electric) .
- NOTE: During repair procedure, cleanliness is extremely important. Any foreign material, including any material created while cleaning or removing components that enters the fuel supply passages may cause engine failure. NOTE: Use compressed air to remove any foreign material from around the Fuel Rail Pressure (FRP) sensor area before removal.
Scheme 28
- Install the Fuel Rail Pressure (FRP) sensor and tighten in the following 5 stages: Material : Motorcraft® SAE 5W-20 Premium Synthetic Blend Motor Oil / XO-5W20-QSP (WSS-M2C945-A)
- Stage 1 Torque : 6 Nm
- Stage 2 Angle : 5
- Stage 3 Loosen : 90°
- Stage 4 Torque : 6 Nm
- Stage 5 Angle : 21
- Connect the battery ground cable. Refer to: «BATTERY DISCONNECT AND CONNECT»(/ford/focus-st/iii-2012-2015/remont/charging-system/#battery-mounting-and-cables-except-electric) .
Note. Removal steps in this procedure may contain installation details.
- Refer to: Health and Safety Precautions ( «HEALTH AND SAFETY PRECAUTIONS»(/ford/focus-st/iii-2012-2015/remont/oem-general-information/#service-information-introduction-except-electric) ).
- Refer to: «INTAKE MANIFOLD»(/ford/focus-st/iii-2012-2015/remont/mechanical/#engine-20l-duratec-he) .
- Torque : 20 Nm
- To install, reverse the removal procedure.
Note. Removal steps in this procedure may contain installation details.
Scheme 29
- Refer to: Health and Safety Precautions ( «HEALTH AND SAFETY PRECAUTIONS»(/ford/focus-st/iii-2012-2015/remont/oem-general-information/#service-information-introduction-except-electric) ).
- Refer to: «COOLING SYSTEM DRAINING, FILLING AND BLEEDING)»(/ford/focus-st/iii-2012-2015/remont/cooling-system-mechanical/#engine-cooling-20l-duratec-he__cooling-system-draining-filling-and-bleeding) . Refer to: «COOLING SYSTEM DRAINING AND VACUUM FILLING»(/ford/focus-st/iii-2012-2015/remont/cooling-system-mechanical/#engine-cooling-20l-duratec-he__cooling-system-draining-and-vacuum-filling) .
- To install, reverse the removal procedure.
Note. Removal steps in this procedure may contain installation details.
Scheme 30
- Refer to: Health and Safety Precautions ( «HEALTH AND SAFETY PRECAUTIONS»(/ford/focus-st/iii-2012-2015/remont/oem-general-information/#service-information-introduction-except-electric) ).
- To install, reverse the removal procedure.
Variable Camshaft Timing (VCT) Oil Control Solenoid
| Name | Specification |
|---|---|
| Motorcraft® SAE 5W-20 Premium Synthetic Blend Motor Oil XO-5W20-QSP | WSS-M2C945-A |
MATERIALS SPECIFICATIONS
Note. Removal steps in this procedure may contain installation details.
Scheme 31
- Refer to: Health and Safety Precautions ( «HEALTH AND SAFETY PRECAUTIONS»(/ford/focus-st/iii-2012-2015/remont/oem-general-information/#service-information-introduction-except-electric) ).
- Refer to: «VALVE COVER»(/ford/focus-st/iii-2012-2015/remont/mechanical/#engine-20l-duratec-he__valve-cover) .
- Torque : 10 Nm
Scheme 32
- To install, reverse the removal procedure. Material : Motorcraft® SAE 5W-20 Premium Synthetic Blend Motor Oil / XO-5W20-QSP (WSS-M2C945-A)
