Electric Powertrain Control Ford Focus ST III

Removal & Installation 6 illustrations ~19165 words

Specifications

ItemNm
BARO sensor bolt9

TORQUE SPECIFICATIONS

Scheme 153

Scheme 153: Electric Powertrain Control - Component Location
Scheme 153: Electric Powertrain Control - Component Location

Overview

The center of the electric motor control system is a microprocessor called the PCM . The PCM receives inputs from sensors and other electronic components. Based on information received and programmed into its memory, the PCM generates output signals to control various relays, solenoids, and actuators. This vehicle uses two PCM connectors.

The PCM stores information in keep alive RAM (a memory integrated circuit chip) about vehicle operating conditions, and then uses this information to compensate for component variability. Keep Alive Memory (KAM) remains powered when the ignition is off so this information is not lost.

The Vehicle Battery Power (VBPWR) is a PCM -supplied power source that supplies regulated voltage (5 to 12 volts) to vehicle sensors that run off 12 volts but cannot withstand VPWR voltage variations. It is regulated to VPWR minus 1.5 volts and is voltage limited to protect the sensors. VPWR is the primary source of PCM power. VPWR is switched through the PCM power relay and is controlled by the PCM . The VREF is a positive voltage (about 5 volts) that is output by the PCM. This is a consistent voltage that is used by the three-wire sensors. The Signal Return (SIG RTN) is a dedicated ground circuit used by the sensors and some of the other PCM inputs.

DTC Chart Powertrain Control Module (PCM)

Diagnostics in this service information assume a certain skill level and knowledge of Ford-specific diagnostic practices.

REFER to: DIAGNOSTIC METHODS .

Note. Before performing a self-test, turn the vehicle off and wait 20 seconds.

DTCDescriptionAction
P0071:00Ambient Air Temperature Sensor Circuit "A" Range/PerformanceCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST A
P0072:00Ambient Air Temperature Sensor Circuit "A" LowCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST A
P0073:00Ambient Air Temperature Sensor Circuit "A" HighCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST A
P0120:12Throttle/Pedal Position Sensor "A" Circuit Short To BatteryCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST J
P0120:14Throttle/Pedal Position Sensor "A" Circuit Short To Ground or OpenCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST J
P0220:12Throttle/Pedal Position Sensor/Switch "B" Circuit Short To BatteryCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST J
P0220:14Throttle/Pedal Position Sensor/Switch "B" Circuit Short To Ground or OpenCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST J
P0480:00Fan 1 Control CircuitCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST K
P0483:00Fan PerformanceCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST K
P0504:00Brake Switch A/B CorrelationCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST B
P0532:00A/C Refrigerant Pressure Sensor "A" Circuit LowCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST C
P0533:00A/C Refrigerant Pressure Sensor "A" Circuit HighCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST C
P0560:16System Voltage LowOverall system voltage low. INSPECT the PCM connector for damaged or pushed-out terminals, corrosion or loose wires. REFER to: DIRECT CURRENT/DIRECT CURRENT (DC/DC) CONVERTER CONTROL MODULE .
P0560:17System Voltage HighOverall system voltage high. REFER to: DIRECT CURRENT/DIRECT CURRENT (DC/DC) CONVERTER CONTROL MODULE .
P0572:23Brake Switch A Circuit LowCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST B
P0579:00Cruise Control Multi-Function Input "A" Circuit Range/PerformanceCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, REFER to: CRUISE CONTROL .
P057F:02Battery State of Charge PerformanceCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, test the 12V battery REFER to: BATTERY .
P0600:00Serial Communication LinkCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, INSTALL a new PCM . REFER to: POWERTRAIN CONTROL MODULE (PCM)
P0602:00Powertrain Control Module Programming ErrorCLEAR the DTC . PROGRAM the PCM with the latest calibration level. RERUN the KOEO self-test. If the DTC returns, INSTALL a new PCM . REFER to: POWERTRAIN CONTROL MODULE (PCM) .
P060C:00Internal Control Module Main Processor PerformanceCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, INSTALL a new PCM . REFER to: POWERTRAIN CONTROL MODULE (PCM) .
P061A:00Internal Control Module Torque PerformanceCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, INSTALL a new PCM . REFER to: POWERTRAIN CONTROL MODULE (PCM) .
P061B:00Internal Control Module Torque Calculation PerformanceCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST AP
P061B:01Internal Control Module Torque Calculation Performance General Electrical FaultCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST AP
P061B:02Internal Control Module Torque Calculation Performance General Signal FaultCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST AP
P061E:00Internal Control Module Brake Signal PerformanceCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, INSTALL a new PCM . REFER to: POWERTRAIN CONTROL MODULE (PCM) .
P062F:42Internal Control Module Electrically Erasable Programmable Read Only Memory ErrorCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, INSTALL a new PCM . REFER to: POWERTRAIN CONTROL MODULE (PCM) .
P0642:00Sensor Reference Voltage "A" Circuit LowOverall system voltage low, REFER to: BATTERY .
P0643:00Sensor Reference Voltage "A" Circuit HighOverall system voltage high, REFER to: BATTERY .
P0652:00Sensor Reference Voltage "B" Circuit LowOverall system voltage high, REFER to: BATTERY .
P0653:00Sensor Reference Voltage "B" Circuit HighOverall system voltage high, REFER to: BATTERY .
P0685:00Engine Control Module/Powertrain Control Module Power Relay Control Circuit/OpenCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST E
P0688:00Engine Control Module/Powertrain Control Module Power Relay Sense CircuitCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST E
P0689:00Engine Control Module/Powertrain Control Module Power Relay Sense Circuit LowCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST E
P06A6:1CSensor Reference Voltage "A" Circuit Range/PerformanceOverall system voltage out of range. REFER to: BATTERY .
P06A7:1CSensor Reference Voltage "B" Circuit Range/PerformanceOverall system voltage out of range. REFER to: BATTERY .
P06AF:02Torque Management System - Forced Engine ShutdownGeneral signal failure. Disabled propulsion system. Red lamp turned on.
P06E4:12Control Module Wake-up Circuit PerformanceCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST S
P0706:12Transmission Range Sensor "A" Circuit Range/Performance Circuit Short To BatteryCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST F
P0706:14Transmission Range Sensor "A" Circuit Range/Performance Circuit Short To Ground or OpenCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST F
P0706:1CTransmission Range Sensor "A" Circuit Range/Performance Circuit Voltage Out of RangeCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST F
P0706:28Transmission Range Sensor "A" Circuit Range/Performance Out of RangeCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST F
P0707:14Transmission Range Sensor "A" Circuit LowCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST F
P0708:12Transmission Range Sensor "A" Circuit HighCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST F
P0882:00Transmission Control Module Power Input Signal LowINSPECT the TCM power and ground circuits for an open or short to power. INSPECT the TCM connector for damaged or pushed-out terminals, corrosion or loose wires. CLEAR the DTC . If the DTC returns, REFER to: BATTERY .
P0883:00Transmission Control Module Power Input Signal HighINSPECT the TCM power and ground circuits for short to ground. INSPECT the TCM connector for damaged or pushed-out terminals, corrosion or loose wires. CLEAR the DTC. If the DTC returns, REFER to: BATTERY .
P0A02:00Motor Electronics Coolant Temperature Sensor Circuit LowCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST G
P0A03:00Motor Electronics Coolant Temperature Sensor Circuit HighCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST G
P0A0A:01High Voltage System Interlock Circuit General Electrical FailureCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST H
P0A12:00DC/DC Converter Enable Circuit LowREFER to: DIRECT CURRENT/DIRECT CURRENT (DC/DC) CONVERTER CONTROL MODULE .
P0A13:00DC/DC Converter Enable Circuit HighREFER to: DIRECT CURRENT/DIRECT CURRENT (DC/DC) CONVERTER CONTROL MODULE .
P0AA0:01Hybrid/EV Battery Positive Contactor CircuitCLEAR the DTC . RERUN the KOEO self-test. If DTC P0AA0:01 returns, REFER to: HIGH VOLTAGE BATTERY, MOUNTING AND CABLES .
P0C44:00Hybrid/EV Battery Pack Coolant Temperature Sensor "A" Circuit LowCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST L
P0C45:00Hybrid/EV Battery Pack Coolant Temperature Sensor "A" Circuit HighCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST L
P0C47:00Hybrid/EV Battery Pack Coolant Pump Control Circuit/OpenCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST M
P0C4A:00Hybrid/EV Battery Pack Coolant Pump Control PerformanceCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST M
P0C4A:12Hybrid/EV Battery Pack Coolant Pump Control Performance Short To BatteryCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST M
P0C4A:14Hybrid/EV Battery Pack Coolant Pump Control Performance Short To Ground or OpenCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST M
P0CC1:00Drive Motor "A" Coolant Pump Control Circuit/OpenCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST O
P0CC2:00Drive Motor "A" Coolant Pump Control Circuit Range/PerformanceCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST O
P0CC2:12Drive Motor "A" Coolant Pump Control Circuit Range/Performance Short To BatteryCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST O
P0CC2:14Drive Motor "A" Coolant Pump Control Circuit Range/Performance Short To Ground or OpenCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST O
P0CE0:00Hybrid/EV Battery Pack Coolant Control Valve "A" Performance/Stuck OffCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST D
P0CE0:12Hybrid/EV Battery Pack Coolant Control Valve "A" Performance/Stuck Off Short To BatteryCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST D
P0CE0:14Hybrid/EV Battery Pack Coolant Control Valve "A" Performance/Stuck Off Short To Ground or OpenCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST D
P0CE2:00Hybrid/EV Battery Pack Coolant Control Valve "A" Control Circuit LowCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST D
P0CE3:00Hybrid/EV Battery Pack Coolant Control Valve "A" Control Circuit HighCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST D
P0CE9:00Hybrid/EV Electronics Coolant Pump Control Circuit/OpenCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST W
P0CEA:00Hybrid/EV Electronics Coolant Pump PerformanceCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST W
P0CEA:12Hybrid/EV Electronics Coolant Pump Performance Short To BatteryCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST W
P0CEA:14Hybrid/EV Electronics Coolant Pump Performance Short To Ground or OpenCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST W
P0D71:09Electric A/C Compressor Control Module Internal Temperature Sensor PerformanceCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, REFER to: CLIMATE CONTROL SYSTEM .
P0D82:00Battery Charger Input Circuit LowCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST N
P0D83:00Battery Charger Input Circuit HighCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST N
P0E12:00Hybrid/EV Battery Pack Coolant Heater "A" Control Circuit/OpenCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST P
P0E12:09Hybrid/EV Battery Pack Coolant Heater "A" Control Circuit/Open Component FailureCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST P
P0E16:00Hybrid/EV Battery Pack Coolant Heater "B" Control Circuit/OpenCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST P
P0E16:09Hybrid/EV Battery Pack Coolant Heater "B" Control Circuit/Open Component FailureCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST P
P1449:09Evaporative Check Solenoid Circuit IntermittentCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, REFER to: CLIMATE CONTROL SYSTEM .
P1543:11Engine Coolant Heater "A" Control CircuitCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST X
P1543:15Engine Coolant Heater "A" Control Circuit PerformanceCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST X
P1543:25Engine Coolant Heater "A" Control CircuitCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST X
P1543:92Engine Coolant Heater "A" Control Circuit PerformanceCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST X
P1594:00Forced Engine Shutdown - Remote Start System Fault, No Unattended Vehicle Time-outREMOVE vehicle from remote start mode. CLEAR the DTC
P1595:00Forced Engine Shutdown - Remote Start System Fault, Transmission Range Not In Park PositionMAKE SURE the selector lever is in the PARK or NEUTRAL position. CLEAR the DTC
P1601:01Engine Control Module/Transmission Control Module Serial Communication ErrorIf DTC U0101:00 is set, diagnose that DTC first. CLEAR the DTC . RUN the network test. If the DTC returns, GO to PINPOINT TEST Z
P1608:00Watchdog MalfunctionCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, INSTALL a new PCM . REFER to: POWERTRAIN CONTROL MODULE (PCM) .
P1712:01Transmission Torque Reduction Request SignalCLEAR the DTC . RERUN the KOEO self-test. If APP and/or TR DTCs are set, diagnose those DTCs first. If DTC P1712:01 returns, INSTALL a new PCM . REFER to: POWERTRAIN CONTROL MODULE (PCM) .
P2122:14Throttle/Pedal Position Sensor/Switch "D" Circuit LowCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST J
P2123:12Throttle/Pedal Position Sensor/Switch "D" Circuit HighCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST J
P2127:14Throttle/Pedal Position Sensor/Switch "E" Circuit LowCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST J
P2128:12Throttle/Pedal Position Sensor/Switch "E" Circuit HighCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST J
P2135:1FThrottle/Pedal Position Sensor/Switch "A"/"B" Voltage CorrelationCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST J
P2138:1FThrottle/Pedal Position Sensor/Switch "D"/"E" Voltage CorrelationCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST J
P2226:12Barometric Pressure Sensor "A" Circuit Short To BatteryCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST Q
P2226:14Barometric Pressure Sensor "A" Circuit Short To Ground or OpenCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST Q
P2515:12A/C Refrigerant Pressure Sensor "B" Circuit Short To BatteryCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST C
P2515:14A/C Refrigerant Pressure Sensor "B" Circuit Short To Ground or OpenCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST C
P2531:00Ignition Switch Run Position Circuit LowCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST R
P2532:01Ignition Switch Run Position Circuit HighCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST R
P2535:10Ignition Switch Run/Start Position Circuit HighCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST R
P2545:00Torque Management Request Input Signal "A" Range/PerformanceCLEAR the DTC . RERUN the KOEO self-test. If APP and/or TR DTCs are set, diagnose those DTCs first. If the DTC returns, GO to PINPOINT TEST F .
P2549:00Torque Management Request Input Signal "B" Range/PerformanceCLEAR the DTC . RERUN the KOEO self-test. If APP and/or TR DTCs are set, diagnose those DTCs first. If the DTC returns, GO to PINPOINT TEST F .
P258A:00Vacuum Pump Control Circuit/OpenIf any ABS DTCs are set, REFER to: ANTI-LOCK BRAKE SYSTEM (ABS) AND STABILITY CONTROL . and diagnose those DTCs first. CLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST I
P2611:00A/C Refrigerant Distribution Valve Control Circuit/OpenCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST AL
P2611:09A/C Refrigerant Distribution Valve Control Circuit/OpenCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST AL
P2613:00A/C Refrigerant Distribution Valve Control Circuit HighCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST AL
P2682:00Engine Coolant Bypass Valve "A" Control Circuit LowCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST T
P2683:00Engine Coolant Bypass Valve "A" Control Circuit HighCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST T
P26A3:10Engine Coolant Bypass Valve "A" Range/PerformanceCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST T
P26A3:12Engine Coolant Bypass Valve "A" Range/Performance Short To BatteryCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST T
P26A3:14Engine Coolant Bypass Valve "A" Range/Performance Short To Ground or OpenCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST T
P26AD:00Engine Coolant Bypass Valve "B" Control Circuit LowCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST AM
P26AE:00Engine Coolant Bypass Valve "B" Control Circuit HighCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST AM
P26B0:00Engine Coolant Bypass Valve "B" Range/PerformanceCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST AM
P26B0:12Engine Coolant Bypass Valve "B" Range/Performance Short To BatteryCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST AM
P26B0:14Engine Coolant Bypass Valve "B" Range/Performance Short To Ground or OpenCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST AM
P2801:12Transmission Range Sensor "B" Circuit Range/Performance Short To BatteryCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST F
P2801:14Transmission Range Sensor "B" Circuit Range/Performance Short To Ground or OpenCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST F
P2801:1CTransmission Range Sensor "B" Circuit Range/Performance Voltage Out of RangeCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST F
P2801:28Transmission Range Sensor "B" Circuit Range/Performance Signal Bias Level Out of Range/Zero Adjustment FailureCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST F
P2802:14Transmission Range Sensor "B" Circuit LowCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST F
P2803:12Transmission Range Sensor "B" Circuit HighCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST F
P2805:1FTransmission Range Sensor "A"/"B" Correlation IntermittentCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST F
P2805:29Transmission Range Sensor "A"/"B" Correlation InvalidCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST F
C113A:-12Wakeup ControlCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST U
B10E8:00Secondary Battery Relay "A"CLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST V
B139F:12Main Battery Relay Short To BatteryCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST V
B139F:14Main Battery Relay Short To Ground or OpenCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST V
B1D17:11Battery Backed SounderCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST AN
B1D22:11Coolant Temperature Sensor Circuit Short To GroundCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST Y
B1D22:15Coolant Temperature Sensor Circuit Short To Battery or OpenCLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST Y
B1D63:00External Control RelayIf any ABS DTCs are set, REFER to: ANTI-LOCK BRAKE SYSTEM (ABS) AND STABILITY CONTROL . and diagnosie those DTCs first. CLEAR the DTC . RERUN the KOEO self-test. If the DTC returns, GO to PINPOINT TEST I
U0101:00Lost Communication With Transmission Control ModuleCLEAR the DTC . RUN the network test. If the DTC returns, GO to PINPOINT TEST Z
U0111:00Lost Communication With Battery Energy Control Module "A"CLEAR the DTC . RUN the network test. If the DTC returns, GO to PINPOINT TEST AA
U0129:00Lost Communication With Brake System Control ModuleCLEAR the DTC . RUN the network test. If the DTC returns, GO to PINPOINT TEST AB
U0140:00Lost Communication With Body Control ModuleCLEAR the DTC . RUN the network test. If the DTC returns, GO to PINPOINT TEST AC
U0151:00Lost Communication With Restraints Control ModuleCLEAR the DTC . RUN the network test. If the DTC returns, GO to PINPOINT TEST AD
U0155:00Lost Communication With Instrument Panel Cluster (IPC) Control ModuleCLEAR the DTC . RUN the network test. If the DTC returns, GO to PINPOINT TEST AE
U0164:00Lost Communication With HVAC Control ModuleCLEAR the DTC . RUN the network test. If the DTC returns, GO to PINPOINT TEST AF
U016A:00Lost Communication With Global Positioning System ModuleCLEAR the DTC . RUN the network test. If the DTC returns, GO to PINPOINT TEST AG
U016B:00Lost Communication With Electric A/C Compressor Control ModuleCLEAR the DTC . RUN the network test. If the DTC returns, GO to PINPOINT TEST AH
U0198:00Lost Communication With Telematic Control ModuleCLEAR the DTC . RUN the network test. If the DTC returns, GO to PINPOINT TEST AI
U019B:00Lost Communication With Battery Charger Control ModuleCLEAR the DTC . RUN the network test. If the DTC returns, GO to PINPOINT TEST AJ
U0298:00Lost Communication With DC to DC Converter Control Module "A"CLEAR the DTC . RUN the network test. If the DTC returns, GO to PINPOINT TEST AK
U0300:00Internal Control Module Software IncompatibilityCLEAR the DTC . RUN the network test. If the DTC returns, CARRY OUT Programmable Module Installation (PMI). REFER to: MODULE CONFIGURATION - SYSTEM OPERATION AND COMPONENT DESCRIPTION .
U0402:00Invalid Data Received From Transmission Control ModuleCLEAR the DTC . RUN the network test. If the DTC returns, CARRY OUT Programmable Module Installation (PMI). REFER to: MODULE CONFIGURATION - SYSTEM OPERATION AND COMPONENT DESCRIPTION .
U0412:00Invalid Data Received From Battery Energy Control Module ACLEAR the DTC . RUN the network test. If the DTC returns, CARRY OUT Programmable Module Installation (PMI). REFER to: MODULE CONFIGURATION - SYSTEM OPERATION AND COMPONENT DESCRIPTION .
U0422:00Invalid Data Received From Body Control ModuleCLEAR the DTC . RUN the network test. If the DTC returns, CARRY OUT Programmable Module Installation (PMI). REFER to: MODULE CONFIGURATION - SYSTEM OPERATION AND COMPONENT DESCRIPTION .
U1012:00Invalid Internal Control Module Monitoring Data Received from ABS ModuleCLEAR the DTC . RUN the network test. If the DTC returns, CARRY OUT Programmable Module Installation (PMI). REFER to: MODULE CONFIGURATION - SYSTEM OPERATION AND COMPONENT DESCRIPTION .
U1A14:00CAN Initialization FailureCLEAR the DTC . RUN the network test. If the DTC returns, CARRY OUT Programmable Module Installation (PMI). REFER to: MODULE CONFIGURATION - SYSTEM OPERATION AND COMPONENT DESCRIPTION .

Symptom Chart

Diagnostics in this service information assume a certain skill level and knowledge of Ford-specific diagnostic practices.

REFER to: DIAGNOSTIC METHODS .

In most circumstances, the PCM sets Diagnostic Trouble Codes (DTCs) to help guide with diagnostics. Refer to the DTC Chart in DTC Chart Powertrain Control Module (PCM) before using the symptom chart. The Condition column lists the vehicle condition. The Source column list a detailed vehicle condition. The Action to column lists the action be performed to determine the cause of the condition. Each action lists the components that can cause the system and the individual components in that system. The components are listed in order of disassembly. Use the list of components and the required action to focus on disassembly inspections for the root cause of the concern.

ConditionSourceActions
The scan tool does not communicate with the PCMConnectors damaged or pushed-out terminals or loose wiresREFER to: NO COMMUNICATION BETWEEN THE INTEGRATED DIAGNOSTIC SYSTEM (IDS) AND THE VEHICLE .
PCMGO to PINPOINT TEST AO
Vehicle will not startLow batteryCHECK for Diagnostic Trouble Codes (DTCs).
Charging systemREFER to: DIRECT CURRENT/DIRECT CURRENT (DC/DC) CONVERTER CONTROL MODULE .
Interconnect openCHECK for Diagnostic Trouble Codes (DTCs). REFER to: HIGH VOLTAGE BATTERY, MOUNTING AND CABLES .

P0071:00, P0072:00, P0073:00

Diagnostics in this service information assume a certain skill level and knowledge of Ford-specific diagnostic practices.

REFER to: DIAGNOSTIC METHODS

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

Normal Operation and Fault Conditions

The Ambient Air Temperature (AAT) sensor is a negative temperature coefficient thermistor which senses the outside air temperature. The PCM sends a 5-volt signal to the Ambient Air Temperature (AAT) sensor. Based on the voltage level, the PCM determines the outside temperature. The PCM sends this information to the BECM to the climate control system. When the PCM senses a signal voltage high or voltage signal low, the PCM sets a DTC .

Possible Sources

  1. Connectors damaged or pushed-out terminals, corrosion, loose wires and missing or damaged seals
  2. Ambient Air Temperature Sensor (AAT)
  3. PCM
DTCDescriptionFault Trigger Conditions
P0071:00Ambient Air Temperature Sensor Circuit "A" Range/PerformanceThe PCM detects voltage mismatch at the signal input.
P0072:00Ambient Air Temperature Sensor Circuit "A" LowThe PCM detects less than 0.1 volt at the signal input. Short to ground in the Ambient Air Temperature (AAT) sensor or wire harness.
P0073:00Ambient Air Temperature Sensor Circuit "A" HighThe PCM detects greater than 4.9 volts at the signal input. Open circuit or short to power in the Ambient Air Temperature (AAT) sensor or wire harness.

DTC FAULT TRIGGER CONDITIONS

PINPOINT TEST A: P0071:00, P0072:00, P0073:00

  1. A1 RETRIEVE AND RECORD ALL DTCS Connect the diagnostic tool. Using the scan tool, retrieve all Diagnostic Trouble Codes (DTCs). Is DTC P0071:00, P0072:00 and/or P0073:00 set? Yes : For Diagnostic Trouble Codes (DTCs) P0071:00 and/or P0072:00, GO to A5 For DTC P0073:00, GO to A2 No : GO to «SYMPTOM CHART»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control__symptom-chart) .
  2. A2 CHECK THE AMBIENT AIR TEMPERATURE (AAT) SENSOR SIGNAL CIRCUIT FOR AN OPEN Ignition OFF. Disconnect Powertrain Control Module (PCM) C175B . Disconnect Ambient Air Temperature (AAT) Sensor C650 . Measure the resistance between. Positive Lead Measurement/Action Negative Lead C175B-52 C650-2 Is the resistance less than 5.0 ohms? Yes : GO to A3 No : REPAIR the circuit.
  3. A3 CHECK THE AMBIENT AIR TEMPERATURE (AAT) SENSOR SIGNAL RETURN CIRCUIT FOR AN OPEN Measure the resistance between. Positive Lead Measurement/Action Negative Lead C175B-37 C650-1 Is the resistance less than 5.0 ohms? Yes : GO to A4 No : REPAIR the circuit.
  4. A4 CHECK THE AMBIENT AIR TEMPERATURE (AAT) SENSOR SIGNAL CIRCUIT FOR A SHORT TO VOLTAGE Ignition ON. Measure the voltage between. Positive Lead Measurement/Action Negative Lead C175B-52 Ground Is any voltage present? Yes : REPAIR the circuit. No : INSTALL a new PCM . REFER to: «POWERTRAIN CONTROL MODULE (PCM)»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control) .
  5. A5 CHECK THE AMBIENT AIR TEMPERATURE (AAT) SENSOR SIGNAL CIRCUIT FOR A SHORT TO GROUND Ignition OFF. Disconnect Powertrain Control Module (PCM) C175B . Disconnect Ambient Air Temperature (AAT) Sensor C650 . Measure the resistance between. Positive Lead Measurement/Action Negative Lead C175B-37 Ground Is the resistance greater that 10, 000 ohms? Yes : INSTALL a new Ambient Air Temperature (AAT) sensor. REFER to: «AMBIENT AIR TEMPERATURE SENSOR»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric) . No : REPAIR the circuit.

P0504:00, P0572:23

Diagnostics in this service information assume a certain skill level and knowledge of Ford-specific diagnostic practices.

REFER to: DIAGNOSTIC METHODS .

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

The BPP switch is a dual position switch and receives battery voltage from the BJB fuse 21 (5A). When the brake pedal is applied, a voltage signal is sent to the PCM BPP input. The PCM applies a voltage signal to the BPP switch to determine the brake pedal status. The PCM sets a DTC if one or both of these inputs do not match.

  1. Connectors damaged or pushed-out terminals, corrosion, loose wires and missing or damaged seals
  2. BJB fuse 21 (5A)
  3. PCM
DTCDescriptionFault Trigger Conditions
P0504:00Brake Switch "A"/"B" CorrelationA voltage mismatch on the BPP switch input and the brake pedal status input.
P0572:23Brake Switch "A" Circuit LowWhen the BPP switch input detects a voltage input when the brake pedal status input detects voltage low for an extended period of time.

DTC FAULT TRIGGER CONDITIONS

PINPOINT TEST B: P0504:00, P0572:23

  1. B1 RETRIEVE AND RECORD ALL DTCS Connect the diagnostic tool. Using the scan tool, retrieve all Diagnostic Trouble Codes (DTCs) Is DTC P0504:00 and/or P0572:23 set? Yes : GO to B2 No : INSPECT the connector for damaged or pushed-out terminals and the BPP switch is adjusted correctly.
  2. B2 CHECK THE BATTERY JUNCTION BOX (BJB) FUSE 21 Ignition OFF. Remove the BJB fuse 21 (5A). CHECK Battery Junction Box (BJB) fuse 21 (5A). Is the resistance less than 5.0 ohms? Yes : GO to B5 No : GO to B3
  3. B3 CHECK THE BRAKE PEDAL POSITION (BPP) SWITCH POWER CIRCUIT FOR A SHORT TO GROUND Disconnect Brake Pedal Position (BPP) Switch C278 . Measure the resistance between. Positive Lead Measurement/Action Negative Lead C278-1 Ground Is the resistance greater than 10, 000 ohms? Yes : GO to B7 No : REPAIR the circuit.
  4. B4 CHECK THE BRAKE PEDAL POSITION (BPP) SWITCH POWER CIRCUIT FOR VOLTAGE Install a new fuse. Ignition ON. Measure the voltage between. Positive Lead Measurement/Action Negative Lead C278-1 Ground Is voltage greater than 10.0 volts? Yes : GO to B5 No : INSPECT and REPAIR the circuit. If an open circuit is not found, INSTALL a new BJB.
  5. B5 CHECK THE BRAKE PEDAL STATUS INPUT CIRCUIT FOR AN OPEN Disconnect Brake Pedal Position (BPP) Switch C278 . Measure the voltage between. Positive Lead Measurement/Action Negative Lead C278-3 Ground Is voltage greater than 10.0 volts? Yes : GO to B6 No : REPAIR the circuit.
  6. B6 CHECK THE BRAKE PEDAL POSITION (BPP) SWITCH INPUT CIRCUIT FOR AN OPEN Disconnect Powertrain Control Module (PCM) C175A . Measure the resistance between. Positive Lead Measurement/Action Negative Lead C278-4 C175A-29 Is the resistance less than 5.0 ohms? Yes : GO to B7 No : REPAIR the circuit.
  7. B7 CHECK THE BRAKE PEDAL POSITION (BPP) SWITCH INPUT CIRCUIT FOR A SHORT TO GROUND Measure the resistance between. Positive Lead Measurement/Action Negative Lead C278-4 Ground Is the resistance greater than 10, 000 ohms? Yes : GO to B8 No : REPAIR the circuit.
  8. B8 CHECK THE BRAKE PEDAL POSITION (BPP) SWITCH Connect Brake Pedal Position (BPP) Switch C278 . Apply the brake pedal and measure the voltage between. Positive Lead Measurement/Action Negative Lead C175B-29 Ground Is the voltage greater than 10.0 volts? Yes : INSTALL a new PCM . REFER to: «POWERTRAIN CONTROL MODULE (PCM)»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control) . No : INSTALL a new BPP switch.

P0532:00, P0533:00, P2515:12, P2515:14

Diagnostics in this service information assume a certain skill level and knowledge of Ford-specific diagnostic practices.

REFER to: DIAGNOSTIC METHODS .

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

The PCM provides a 5-volt reference voltage to the A/C high and low pressure sensors. The A/C pressure sensors sends a voltage signal to the PCM which indicate the high and low side pressure. The PCM sets a DTC if voltage on these inputs are above or below a calibrated threshold.

  1. Connectors damaged or pushed-out terminals, corrosion, loose wires and missing or damaged seals
  2. A/C high pressure sensor
  3. A/C low pressure sensor
  4. PCM
DTCDescriptionFault Trigger Conditions
P0532:00Air Conditioning Refrigerant Pressure Sensor "A" Circuit LowThe PCM detects less than 0.3 volts A/C high pressure sensor input.
P0533:00Air Conditioning Refrigerant Pressure Sensor "A" Circuit HighThe PCM detects greater than 4.9 volts A/C high pressure sensor input.
P2515:12Air Conditioning Refrigerant Pressure Sensor "B" Circuit Short to BatteryThe PCM detects greater than 4.9 volts A/C high pressure sensor input.
P2515:14Air Conditioning Refrigerant Pressure Sensor "B" Circuit Short to Ground or OpenThe PCM detects less than 0.3 volts A/C high pressure sensor input.

DTC FAULT TRIGGER CONDITIONS

PINPOINT TEST C: P0532:00, P0533:00, P2515:12, P2515:14

  1. C1 RETRIEVE AND RECORD ALL DTCS Connect the diagnostic tool. Using the scan tool, retrieve all Diagnostic Trouble Codes (DTCs). Is DTC P0532:00, P0533:00, P2515:12 and/or P2515:14 set? Yes : For DTC P0533:00, GO to C2 For DTC P0532:00, GO to C4 For DTC P2515:12, GO to C7 For DTC P2515:14, GO to C9 No : GO to «SYMPTOM CHART»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control__symptom-chart) .
  2. C2 CHECK THE AIR CONDITIONING (A/C) HIGH PRESSURE SENSOR SIGNAL INPUT CIRCUIT FOR A SHORT TO POWER Disconnect Air Conditioning (A/C) High Pressure Sensor C1800 . Ignition ON. Measure the voltage between. Positive Lead Measurement/Action Negative Lead C1800-2 Ground Is any voltage present? Yes : REPAIR the circuit. No : GO to C3
  3. C3 CHECK THE AIR CONDITIONING (A/C) HIGH PRESSURE SENSOR SIGNAL RETURN CIRCUIT FOR AN OPEN Disconnect Powertrain Control Module (PCM) C175A . Measure the resistance between. Positive Lead Measurement/Action Negative Lead C1800-1 C175A-52 Is the resistance less than 5.0 ohms? Yes : INSTALL a new A/C high pressure sensor. REFER to: «AIR CONDITIONING (A/C) HIGH PRESSURE SENSOR»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric) . No : REPAIR the circuit.
  4. C4 CHECK THE AIR CONDITIONING (A/C) HIGH PRESSURE SENSOR VOLTAGE REFERENCE CIRCUIT FOR VOLTAGE Disconnect Air Conditioning (A/C) High Pressure Sensor C1800 . Ignition ON. Measure the voltage between. Positive Lead Measurement/Action Negative Lead C1800-3 Ground Is the voltage greater than 4.8 volts? Yes : GO to C5 No : INSPECT and REPAIR the circuit. If an open circuit is not found, INSTALL a new PCM . REFER to: «POWERTRAIN CONTROL MODULE (PCM)»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control) .
  5. C5 CHECK THE AIR CONDITIONING (A/C) HIGH PRESSURE SENSOR INPUT CIRCUIT FOR AN OPEN Disconnect Powertrain Control Module (PCM) C175A . Measure the resistance between. Positive Lead Measurement/Action Negative Lead C1800-2 C175A-69 Is the resistance less than 5.0 ohms? Yes : GO to C6 No : REPAIR the circuit.
  6. C6 CHECK THE AIR CONDITIONING (A/C) HIGH PRESSURE SENSOR INPUT CIRCUIT FOR A SHORT TO GROUND Measure the resistance between. Positive Lead Measurement/Action Negative Lead C1800-2 Ground Is the resistance greater than 10, 000 ohms? Yes : INSTALL a new PCM . REFER to: «POWERTRAIN CONTROL MODULE (PCM)»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control) . No : REPAIR the circuit.
  7. C7 CHECK THE AIR CONDITIONING (A/C) LOW PRESSURE SENSOR SIGNAL INPUT CIRCUIT FOR A SHORT TO POWER Disconnect Air Conditioning (A/C) Low Pressure Sensor C1801 . Ignition ON. Measure the voltage between. Positive Lead Measurement/Action Negative Lead C1801-2 Ground Is any voltage present? Yes : REPAIR the circuit. No : GO to C8
  8. C8 CHECK THE AIR CONDITIONING (A/C) LOW PRESSURE SENSOR SIGNAL RETURN CIRCUIT FOR AN OPEN Disconnect Powertrain Control Module (PCM) C175B . Measure the resistance between. Positive Lead Measurement/Action Negative Lead C1801-1 C175B-39 Is the resistance less than 5.0 ohms? Yes : INSTALL a new A/C low pressure sensor. REFER to: «AIR CONDITIONING (A/C) LOW PRESSURE SENSOR»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric) . No : REPAIR the circuit.
  9. C9 CHECK THE AIR CONDITIONING (A/C) LOW PRESSURE SENSOR VOLTAGE REFERENCE CIRCUIT FOR VOLTAGE Disconnect Air Conditioning (A/C) Low Pressure Sensor C1801 . Ignition ON. Measure the voltage between. Positive Lead Measurement/Action Negative Lead C1801-3 Ground Is the voltage greater than 4.8 volts? Yes : GO to C10 No : INSPECT and REPAIR the circuit. If an open circuit is not found, INSTALL a new PCM . REFER to: «POWERTRAIN CONTROL MODULE (PCM)»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control) .
  10. C10 CHECK THE AIR CONDITIONING (A/C) LOW PRESSURE SENSOR INPUT CIRCUIT FOR AN OPEN Disconnect Powertrain Control Module (PCM) C175B . Measure the resistance between. Positive Lead Measurement/Action Negative Lead C1801-2 C175B-5 Is the resistance less than 5.0 ohms? Yes : GO to C11 No : REPAIR the circuit.
  11. C11 CHECK THE AIR CONDITIONING (A/C) LOW PRESSURE SENSOR INPUT CIRCUIT FOR A SHORT TO GROUND Measure the resistance between. Positive Lead Measurement/Action Negative Lead C1801-2 Ground Is the resistance greater than 10, 000 ohms? Yes : INSTALL a new PCM . REFER to: «POWERTRAIN CONTROL MODULE (PCM)»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control) . No : REPAIR the circuit.

P0CE0:00, P0CE0:12, P0CE0:14, P0CE2:00, P0CE3:00

Diagnostics in this service information assume a certain skill level and knowledge of Ford-specific diagnostic practices.

REFER to: DIAGNOSTIC METHODS .

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

The battery pack coolant control valve is a 12-volt operated valve which regulates coolant to the battery pack. The PCM provides a PWM signal to the pump and monitors this signal by monitoring a diagnostic circuit input. The PCM sets a DTC if voltage on these inputs are above or below a calibrated threshold.

  1. Connectors damaged or pushed-out terminals, corrosion, loose wires and missing or damaged seals
  2. Battery pack coolant control valve
  3. BJB fuse 32 (10A)
  4. PCM
DTCDescriptionFault Trigger Conditions
P0CE0:00Hybrid/EV Battery Pack Coolant Control Valve "A" Performance/Stuck OffThe PCM detects an overall fault with the control valve system. Diagnostic Trouble Codes (DTCs) P0CE0:12, P0CE0:14, P0CE2:00 and/or P0CE3:00 may set.
P0CE0:12Hybrid/EV Battery Pack Coolant Control Valve "A" Performance/Stuck Off Short To BatteryThe PCM PWM output is at 0% but the feedback input detects voltage.
P0CE0:14Hybrid/EV Battery Pack Coolant Control Valve "A" Performance/Stuck Off Short To Ground/OpenThe PCM PWM output is less than 70% but the feedback input detects 0 volts.
P0CE2:00Hybrid/EV Battery Pack Coolant Control Valve "A" Control Circuit LowThe PCM commanded PWM output greater than 0% but the feedback input detects 0 volts.
P0CE3:00Hybrid/EV Battery Pack Coolant Control Valve "A" Control Circuit HighThe PCM commanded PWM output less than 90% but the feedback input detects 12 volts.

DTC FAULT TRIGGER CONDITIONS

PINPOINT TEST D: P0CE0:00, P0CE0:12, P0CE0:14, P0CE2:00, P0CE3:00

  1. D1 RETRIEVE AND RECORD ALL DTCS Connect the diagnostic tool. Using the scan tool, retrieve all Diagnostic Trouble Codes (DTCs). Is DTC P0CE0:00, P0CE0:12, P0CE:14, P0CE2:00, and/or P0CE3:00 set? Yes : For DTC P0CE0:00, GO to D2 For DTC P0CE2:00, GO to D4 For DTC P0CE3:00, GO to D5 For DTC P0CE0:12, GO to D6 For DTC P0CE0:14, GO to D7 No : GO to «SYMPTOM CHART»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control__symptom-chart) .
  2. D2 CHECK THE BATTERY PACK COOLANT CONTROL VALVE POWER CIRCUIT FOR AN OPEN Disconnect Battery Pack Coolant Control Valve C1811 . Ignition ON. Measure the voltage between. Positive Lead Measurement/Action Negative Lead C1811-A Ground Is voltage greater than 10.5 volts? Yes : GO to D3 No : REPAIR the circuit.
  3. D3 CHECK THE BATTERY PACK COOLANT CONTROL VALVE GROUND CIRCUIT FOR AN OPEN Measure the voltage between. Positive Lead Measurement/Action Negative Lead C1811-A C1811-C Is voltage greater than 10.5 volts? Yes : GO to D4 No : REPAIR the circuit.
  4. D4 CHECK THE BATTERY PACK COOLANT CONTROL VALVE PULSE WIDTH MODULATION (PWM) CIRCUIT FOR A SHORT TO GROUND Ignition OFF. Disconnect Powertrain Control Module (PCM) C175B . Measure the resistance between. Positive Lead Measurement/Action Negative Lead C175B-24 Ground Is the resistance greater than 10, 000 ohms? Yes : INSTALL a new high voltage battery coolant diverter valve. REFER to: «HIGH VOLTAGE BATTERY COOLANT DIVERTER VALVE»(/ford/focus-st/iii-2012-2015/remont/cooling-system-mechanical/#electric-powertrain-cooling__high-voltage-battery-coolant-diverter-valve) . If the DTC returns, INSTALL a new PCM . REFER to: «POWERTRAIN CONTROL MODULE (PCM)»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control) . No : REPAIR the circuit.
  5. D5 CHECK THE BATTERY PACK COOLANT CONTROL VALVE PULSE WIDTH MODULATION (PWM) CIRCUIT FOR A SHORT TO POWER Disconnect Powertrain Control Module (PCM) C175B . Disconnect Battery Pack Coolant Control Valve C1811 . Ignition ON. Measure the voltage between. Positive Lead Measurement/Action Negative Lead C175B-24 Ground Is any voltage present? Yes : REPAIR the circuit. No : INSTALL a new high voltage battery coolant diverter valve. REFER to: «HIGH VOLTAGE BATTERY COOLANT DIVERTER VALVE»(/ford/focus-st/iii-2012-2015/remont/cooling-system-mechanical/#electric-powertrain-cooling__high-voltage-battery-coolant-diverter-valve) . If the DTC returns, INSTALL a new PCM . REFER to: «POWERTRAIN CONTROL MODULE (PCM)»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control) .
  6. D6 CHECK THE BATTERY PACK COOLANT CONTROL VALVE FEEDBACK CIRCUIT FOR A SHORT TO POWER Disconnect Powertrain Control Module (PCM) C175A . Disconnect Battery Pack Coolant Control Valve C1811 . Ignition ON. Measure the voltage between. Positive Lead Measurement/Action Negative Lead C175A-63 Ground Is any voltage present? Yes : REPAIR the circuit. No : INSTALL a new high voltage battery coolant diverter valve. REFER to: «HIGH VOLTAGE BATTERY COOLANT DIVERTER VALVE»(/ford/focus-st/iii-2012-2015/remont/cooling-system-mechanical/#electric-powertrain-cooling__high-voltage-battery-coolant-diverter-valve) ). If the DTC returns, INSTALL a new PCM . REFER to: «POWERTRAIN CONTROL MODULE (PCM)»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control) .
  7. D7 CHECK THE BATTERY PACK COOLANT CONTROL VALVE FEEDBACK CIRCUIT FOR A SHORT TO GROUND Ignition OFF. Disconnect Powertrain Control Module (PCM) C175A . Measure the resistance between. Positive Lead Measurement/Action Negative Lead C175A-63 Ground Is the resistance greater than 10, 000 ohms? Yes : INSTALL a new high voltage battery coolant diverter valve. REFER to: «HIGH VOLTAGE BATTERY COOLANT DIVERTER VALVE»(/ford/focus-st/iii-2012-2015/remont/cooling-system-mechanical/#electric-powertrain-cooling__high-voltage-battery-coolant-diverter-valve) . If the DTC returns, INSTALL a new PCM . REFER to: «POWERTRAIN CONTROL MODULE (PCM)»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control) . No : REPAIR the circuit.

P0685:00, P0688:00, P0689:00

Diagnostics in this service information assume a certain skill level and knowledge of Ford-specific diagnostic practices.

REFER to: DIAGNOSTIC METHODS .

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

The PCM controls the low side of the PCM power relay. When the PCM power relay is energized, battery voltage is applied to the various components including the PCM sense input. The PCM sets a DTC if voltage on these inputs are above or below a calibrated threshold.

  1. Connectors damaged or pushed-out terminals, corrosion, loose wires and missing or damaged seals
  2. Battery and charging system
  3. BJB fuse 23 (5A)
  4. BJB fuse 12 (40A)
  5. BJB fuse 33 (10A)
  6. PCM
DTCDescriptionFault Trigger Conditions
P0685:00ECM/PCM Power Relay Control Circuit/OpenThe power relay was commanded on, but the PCM did not detect 12-volts on the control input or the power relay is off, but did detected voltage on the control input.
P0688:00ECM/PCM Power Relay Sense CircuitThe power relay is off, but the PCM sense input detected a voltage greater than 3.55 volts.
P0689:-00ECM/PCM Power Relay Sense Circuit LowThe PCM commanded the power relay on, but did not detect voltage on the sense input.

DTC FAULT TRIGGER CONDITIONS

PINPOINT TEST E: P0685:00, P0688:00, P0689:00

  1. E1 RETRIEVE AND RECORD ALL DTCS Connect the diagnostic tool. Using the scan tool, retrieve all Diagnostic Trouble Codes (DTCs) Is DTC P0685:00, P0688:00 and/or P0689:00 set? Yes : For DTC For P0685:00, GO to E2 For DTC P0688:00, GO to E6 For P0689:00, GO to E5 No : GO to «SYMPTOM CHART»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control__symptom-chart) .
  2. E2 CHECK POWERTRAIN CONTROL MODULE (PCM) POWER RELAY HOT AT ALL TIMES POWER CIRCUITS Disconnect Powertrain Control Module (PCM) Power Relay. Measure the voltage between. Positive Lead Measurement/Action Negative Lead Relay Pin 1 Ground Relay Pin 3 Ground Is the voltage greater than 10.0 volts on both circuits? Yes : GO to E3 No : REPAIR the circuit.
  3. E3 CHECK THE POWERTRAIN CONTROL MODULE (PCM) POWER RELAY CONTROL CIRCUIT FOR A SHORT TO POWER Disconnect Powertrain Control Module (PCM) C175A . Ignition ON. Measure the voltage between. Positive Lead Measurement/Action Negative Lead C175A-62 Ground Is any voltage present? Yes : REPAIR the circuit. No : GO to E4
  4. E4 CHECK THE POWERTRAIN CONTROL MODULE (PCM) POWER RELAY CONTROL CIRCUIT FOR AN OPEN Ignition OFF. Measure the resistance between. Positive Lead Measurement/Action Negative Lead C175A-62 Relay Pin 2 Is the resistance less than 5.0 ohms? Yes : INSTALL a new PCM . REFER to: «POWERTRAIN CONTROL MODULE (PCM)»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control) . No : REPAIR the circuit.
  5. E5 CHECK THE POWERTRAIN CONTROL MODULE (PCM) POWER RELAY SENSE CIRCUIT FOR A SHORT TO GROUND Disconnect Powertrain Control Module (PCM) C175B . CHECK Battery Junction Box (BJB) fuse 33 (10A). Is the resistance less than 5.0 ohms? Yes : INSTALL a new BJB. No : REPAIR the circuit.
  6. E6 CHECK THE POWERTRAIN CONTROL MODULE (PCM) POWER RELAY SENSE CIRCUIT FOR A SHORT TO POWER Disconnect Powertrain Control Module (PCM) C175B . Remove BJB fuse 33 (10A). Ignition ON. Measure the voltage between. Positive Lead Measurement/Action Negative Lead C175B-6 Ground Is any voltage present? Yes : REPAIR the circuit. No : GO to E7
  7. E7 CHECK THE POWERTRAIN CONTROL MODULE (PCM) POWER RELAY SENSE CIRCUIT FOR AN OPEN Ignition OFF. Measure the resistance between. Positive Lead Measurement/Action Negative Lead C175B-6 Fuse 33 Is the resistance less than 5.0 ohms? Yes : INSTALL a new PCM . REFER to REFER to: «POWERTRAIN CONTROL MODULE (PCM)»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control) . No : REPAIR the circuit.

P0706:12, P0706:14, P0706:1C, P0706:28, P0707:14, P0708:12 P2801:1C

Diagnostics in this service information assume a certain skill level and knowledge of Ford-specific diagnostic practices.

REFER to: DIAGNOSTIC METHODS .

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

The TR sensor has a 6-pin connector. The TR sensor is located on the transmission at the manual lever. The TR sensor sends a signal to the PCM to start the vehicle in PARK and NEUTRAL. The TR sensor uses 2 hall-effect switches that are monitored by the PCM to determine the position of the manual lever. The PCM sets a DTC if voltage on these inputs are above or below a calibrated threshold.

  1. Connectors damaged or pushed-out terminals, corrosion, loose wires and missing or damaged seals
  2. TR sensor
  3. Selector lever cable
  4. PCM
DTCDescriptionFault Trigger Conditions
P0706:12Transmission Range Sensor "A" Circuit Range/Performance Short to BatteryThe PCM detects a short to power.
P0706:14Transmission Range Sensor "A" Circuit Range/Performance Short to Ground or OpenThe PCM detects a short to ground or open.
P0706:1CTransmission Range Sensor "A" Circuit Range/Performance Voltage Out of RangeThe TR sensor indicates a voltage between park and neutral.
P0706:28Transmission Range Sensor "A" Circuit Range/Performance Signal Bias Level Out of Range/Zero Adjustment FailureThe PCM detects a voltage out of range.
P0707:14Transmission Range Sensor "A" Circuit LowThe PCM detects a short to ground on the voltage reference circuit
P0708:12Transmission Range Sensor "A" Circuit HighThe PCM detects a short to power on the voltage reference circuit
P2801:1CTransmission Range Sensor "B" Circuit Range/Performance Voltage Out of RangeThe TR sensor indicates a voltage between park and neutral.

DTC FAULT TRIGGER CONDITIONS

PINPOINT TEST F: P0706:12, P0706:14, P0706:1C, P0706:28, P0707:14, P0708:12, P2801:1C

  1. F1 RETRIEVE AND RECORD ALL DTCS Connect the diagnostic tool. Using a diagnostic scan tool, perform KOEO self-test. Is DTC P0706:1C or P2801:1C set? Yes : GO to F12 No : GO to F2
  2. F2 CHECK FOR POWER TO THE TRANSMISSION RANGE (TR) SENSOR Ignition OFF. Disconnect TR Sensor C1816 . Ignition ON. Measure : Positive Lead Measurement/Action Negative Lead C1816-3 Ground C1816-6 Ground Are the voltages between 4.7 and 5.1 volts? Yes : GO to F3 No : GO to F5
  3. F3 CHECK THE GROUND TO THE TRANSMISSION RANGE (TR) SENSOR Measure: Positive Lead Measurement/Action Negative Lead C1816-3 C1816-2 C1816-6 C1816-5 Are the voltages between 4.7 and 5.1 volts? Yes : GO to F9 No : GO to F4
  4. F4 CHECK THE GROUND CIRCUITS TO THE TRANSMISSION RANGE (TR) SENSOR FOR AN OPEN Ignition OFF. Disconnect PCM C175A . Measure: Positive Lead Measurement/Action Negative Lead C1816-2 C175A-71 C1816-5 C175A-70 Are the resistances less than 3 ohms? Yes : GO to F13 No : REPAIR the circuit(s).
  5. F5 CHECK THE TRANSMISSION RANGE (TR) REFERENCE CIRCUITS FOR A SHORT TO POWER Ignition OFF. Disconnect PCM C175A . Ignition ON. Measure: Positive Lead Measurement/Action Negative Lead C1816-3 Ground C1816-6 Ground Is any voltage present? Yes : REPAIR the affected circuit(s). No : GO to F6
  6. F6 CHECK THE TRANSMISSION RANGE (TR) REFERENCE CIRCUITS FOR AN OPEN Ignition OFF. Measure: Positive Lead Measurement/Action Negative Lead C1816-3 C175A-55 C1816-6 C1816-54 Are the resistances less than 3 ohms? Yes : GO to F7 No : REPAIR the circuit.
  7. F7 CHECK THE TRANSMISSION RANGE (TR) REFERENCE CIRCUITS FOR A SHORT TO GROUND Measure: Positive Lead Measurement/Action Negative Lead C1816-3 Ground C1816-6 Ground Are the resistances greater than 10, 000 ohms? Yes : GO to F8 No : REPAIR the circuit.
  8. F8 CHECK THE TRANSMISSION RANGE (TR) CIRCUITS SHORTED TOGETHER Measure: Positive Lead Measurement/Action Negative Lead C1816-1 C1816-2 C1816-1 C1816-3 C1816-1 C1816-4 C1816-1 C1816-5 C1816-1 C1816-6 C1816-2 C1816-3 C1816-2 C1816-4 C1816-2 C1816-5 C1816-2 C1816-6 C1816-3 C1816-4 C1816-3 C1816-5 C1816-3 C1816-6 C1816-4 C1816-5 C1816-4 C1816-6 C1816-5 C1816-6 Are the resistances greater than 10, 000 ohms? Yes : GO to F13 No : REPAIR the affected circuit(s).
  9. F9 CHECK THE TRANSMISSION RANGE (TR) SIGNAL CIRCUITS FOR A SHORT TO POWER Ignition OFF. Disconnect PCM C175A . Ignition ON. Measure: Positive Lead Measurement/Action Negative Lead C1816-1 Ground C1816-4 Ground Is any voltage present? Yes : REPAIR the circuit(s). No : GO to F10
  10. F10 CHECK THE TRANSMISSION RANGE (TR) SIGNAL CIRCUITS FOR A SHORT TO GROUND Ignition OFF. Measure: Positive Lead Measurement/Action Negative Lead C1816-1 Ground C1816-4 Ground Are the resistances greater than 10, 000 ohms? Yes : GO to F11 No : REPAIR the circuit(s).
  11. F11 CHECK THE TRANSMISSION RANGE (TR) SIGNAL CIRCUITS FOR AN OPEN Measure: Positive Lead Measurement/Action Negative Lead C1816-1 C175A-72 C1816-4 C175A-53 Are the resistances less than 3 ohms? Yes : INSTALL a new TR sensor. REFER to: «TRANSMISSION RANGE (TR) SENSOR»(/ford/focus-st/iii-2012-2015/remont/automatic-trans/#automatic-transaxle-electric) . RETEST the system, if the DTCs return, GO to F13 No : REPAIR the circuit(s).
  12. F12 RETRIEVE AND RECORD DTCS NOTE: After KOEO self-test, DTCs P0706:1C and P2801:1C will take five minutes to set. Ignition ON. CLEAR all Diagnostic Trouble Codes (DTCs). Carry out the KOEO self-test. WAIT 5 minutes. RERUN the KOEO self-test. Is Diagnostic Trouble Codes (DTCs), P0706:1C or P2801:1C present? Yes : VERIFY selector lever cable is adjusted correctly. REFER to: «SELECTOR LEVER CABLE ADJUSTMENT»(/ford/focus-st/iii-2012-2015/remont/automatic-trans/#automatic-transaxle-external-controls-electric) . If the selector lever cable is adjusted correctly, INSTALL a new TR sensor. REFER to: «TRANSMISSION RANGE (TR) SENSOR»(/ford/focus-st/iii-2012-2015/remont/automatic-trans/#automatic-transaxle-electric) . RETEST the system, if DTCs return, GO to F13 No : The system is operating correctly at this time. The DTCs may have been caused by the selector lever momentarily stuck between Park and Neutral.
  13. F13 CHECK THE PCM FOR CORRECT OPERATION NOTE: After KOEO self-test. DTCs P0706:1C and P2801:1C will take five minutes to set. Ignition OFF. Disconnect all the PCM connectors. Inspect the module connectors for: corrosion pushed-out terminals damaged terminals Repair as necessary, refer to Refer to «SYSTEM WIRING DIAGRAMS»(ref-541405) for schematic and connector information. Connect and correctly seat all the PCM connectors. Connect all previously disconnected connectors. Make sure they connect and seat correctly. Clear the DTCs. CARRY OUT the KOEO self-test. Wait 5 minutes. RERUN the KOEO self-test. Operate the system and verify the concern is still present. Is the concern still present? Yes : INSTALL a new PCM . REFER to: «POWERTRAIN CONTROL MODULE (PCM)»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control) . No : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector.

P0A02:00, P0A03:00

Diagnostics in this service information assume a certain skill level and knowledge of Ford-specific diagnostic practices.

REFER to: DIAGNOSTIC METHODS .

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

The motor electronics coolant temperature sensor is a temperature-sensitive device called a thermistor. The resistance value of the motor electronics coolant temperature sensor varies with temperature change. The PCM provides a signal voltage to the motor electronics coolant temperature sensor. The PCM monitors the voltage across the motor electronics coolant temperature sensor to determine the temperature of the electric motor coolant. The PCM sets a DTC if voltage on these inputs are above or below a calibrated threshold.

  1. Connectors damaged or pushed-out terminals, corrosion, loose wires and missing or damaged seals
  2. Motor electronics coolant temperature sensor
  3. PCM
DTCDescriptionFault Trigger Conditions
P0A02:00Motor Electronics Coolant Temperature Sensor Circuit Short to GroundThe PCM detects less than 0.1 volts at the electric motor electronics coolant temperature sensor input.
P0A03:00Motor Electronics Coolant Temperature Sensor Circuit Short to Battery or OpenThe PCM detects greater than 4.9 volts at the electric motor electronics coolant temperature sensor input.

DTC FAULT TRIGGER CONDITIONS

Scheme 154

Scheme 154: PINPOINT TEST G: P0A02:00, P0A03:00
Scheme 154: PINPOINT TEST G: P0A02:00, P0A03:00
  1. G1 RETRIEVE AND RECORD ALL DTCS Ignition ON. Connect the diagnostic tool. Using the scan tool, retrieve all Diagnostic Trouble Codes (DTCs). Is DTC P0A02:00 and/or P0A03:00 set? Yes : GO to G2 No : GO to «SYMPTOM CHART»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control__symptom-chart) .
  2. G2 CHECK THE MOTOR ELECTRONICS COOLANT TEMPERATURE SENSOR SIGNAL INPUT Ignition OFF. Disconnect Motor Electronics Coolant Temperature Sensor C1817 . Ignition ON. Enter the following diagnostic mode: MTR_TEMP_V PID. Does the MTR_TEMP_V PID display 4.9 volts? Yes : GO to G3 No : REPAIR the circuit.
  3. G3 CHECK THE MOTOR ELECTRONICS COOLANT TEMPERATURE SENSOR SIGNAL CIRCUIT Connect a fuse jumper wire between. Positive Lead Measurement/Action Negative Lead C1817-1 C1817-2 Does the PID display 0.0 volts? Yes : GO to G5 No : GO to G4
  4. G4 CHECK THE MOTOR ELECTRONICS COOLANT TEMPERATURE SENSOR SIGNAL VOLTAGE Measure the voltage between. Positive Lead Measurement/Action Negative Lead C1817-1 Ground Is the voltage between 4.8 and 5.1 volts? Yes : GO to G5 No : INSPECT and REPAIR the circuit. If an open circuit is not found, INSTALL a new PCM . REFER to: «POWERTRAIN CONTROL MODULE (PCM)»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control) .
  5. G5 CHECK THE MOTOR ELECTRONICS COOLANT TEMPERATURE SENSOR RESISTANCE Measure the component side resistance between. Positive Lead Measurement/Action Negative Lead C1817-1 C1817-2 TEMPERATURE °F (°C) Ohms -39.9-4.0°F (-40-20°C) 1, 076K-269K -2.2-30.2°F (-19-1°C) 309K-91K 32.0-68.0°F (-20°C) 104K-35K 69.8-103.9°F (21-40°C) 40K-15K 105.7-157.9°F (41-70°C) 17K-4.9K 159.7-193.9°F (71-90°C) 5.6K-2.5K 195.7-229.8°F (91-110°C) 3.0K-1.4K 231.6-265.8°F (111-130°C) 1.7K-0.8K 267.6-301.8°F (131-150°C) 0.97K-0.56K Does the temperature to resistance specifications match? Yes : INSTALL a new PCM . REFER to: «POWERTRAIN CONTROL MODULE (PCM)»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control) . No : INSTALL a new electric motor coolant temperature sensor. REFER to: «ELECTRIC MOTOR COOLANT TEMPERATURE SENSOR»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control) .

P0A0A:01

Diagnostics in this service information assume a certain skill level and knowledge of Ford-specific diagnostic practices.

REFER to: DIAGNOSTIC METHODS .

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

WARNINGTo prevent the risk of high-voltage shock, always follow precisely all warnings and service instructions, including instructions to depower the system. The high-voltage hybrid system utilizes approximately 300 volts DC, provided through high-voltage cables to its components and modules. The high-voltage cables and wiring are identified by orange harness tape or orange wire covering. All high-voltage components are marked with high-voltage warning labels with a high-voltage symbol. Failure to follow these instructions may result in serious personal injury or death.

The PCM monitors the DC to DC Converter Control Module (DC/DC), PTC heater, the A/C compressor module and the TCM high voltage circuits. The high voltage interlock system verifies these connectors are properly connected. The PCM sends a 5-volt reference signal to each connector, in series and monitors the voltage return. The PCM high voltage interlock sense input checks for continuity of the high-voltage system interlock circuit. The interlock circuit must have continuity before high-voltage is supplied to the vehicle. The interlock circuit voltage travels through each of the high-voltage components and high-voltage cables and back to the PCM. The PCM sets a DTC if voltage on these inputs are above or below a calibrated threshold.

  1. Connectors damaged or pushed-out terminals, corrosion, loose wires and missing or damaged seals
  2. High voltage components
  3. High voltage connector C1822B shorting bars installed properly
  4. PCM
DTCDescriptionFault Trigger Conditions
P0A0A:01High Voltage System Interlock Circuit General Electrical FailureThe PCM detects greater than 4.9 volts or less than 0.1 volt at the high voltage interlock sense input.

DTC FAULT TRIGGER CONDITIONS

PINPOINT TEST H: P0A0A:01

  1. H1 RETRIEVE AND RECORD ALL DTCS Connect the diagnostic tool. Using the scan tool, retrieve all Diagnostic Trouble Codes (DTCs). Is DTC P0A0A:01 set? Yes : GO to H2 No : GO to «SYMPTOM CHART»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control__symptom-chart) .
  2. H2 CHECK THE HIGH VOLTAGE INTERLOCK SYSTEM POWERTRAIN CONTROL MODULE (PCM) INTERLOCK CIRCUITS FOR AN OPEN Depower the high voltage battery. Disconnect Powertrain Control Module (PCM) C175B . Disconnect Transmission Control Module (TCM) C1822A . Measure the resistance between. Positive Lead Measurement/Action Negative Lead C175B-55 C1822A-14 C175B-59 C1822A-13 Is the resistance less than 5.0 ohms? Yes : GO to H3 No : REPAIR the circuit.
  3. H3 CHECK THE HIGH VOLTAGE INTERLOCK SYSTEM POSITIVE TEMPERATURE COEFFICIENT (PTC) CABIN HEATER INTERLOCK CIRCUITS FOR AN OPEN Disconnect Positive Temperature Coefficient (PTC) Cabin Heater C1822E . Measure the resistance between. Positive Lead Measurement/Action Negative Lead C1822E-1 C1822E-2 Is the resistance less than 5.0 ohms? Yes : GO to H4 No : REPAIR the circuit.
  4. H4 CHECK THE HIGH VOLTAGE INTERLOCK SYSTEM AIR CONDITIONING (A/C) INTERLOCK CIRCUITS FOR AN OPEN Disconnect Air Conditioning (A/C) C1822C . Measure the resistance between. Positive Lead Measurement/Action Negative Lead C1822C-1 C1822C-2 Is the resistance less than 5.0 ohms? Yes : GO to H5 No : REPAIR the circuit.
  5. H5 CHECK THE HIGH VOLTAGE INTERLOCK SYSTEM DC TO DC CONVERTER CONTROL MODULE (DC/DC) INTERLOCK CIRCUITS FOR AN OPEN Disconnect Transmission Control Module (TCM) C1822G . Disconnect DC to DC Converter Control Module (DC/DC) C1457A . Measure the resistance between. Positive Lead Measurement/Action Negative Lead C1822G-1 C1457A-3 C1822G-2 C1457A-4 Is the resistance less than 5.0 ohms? Yes : GO to H6 No : REPAIR the circuit.
  6. H6 CHECK THE HIGH VOLTAGE INTERLOCK SYSTEM POWERTRAIN CONTROL MODULE (PCM) INTERLOCK CIRCUITS FOR A SHORT TO GROUND Measure the resistance between. Positive Lead Measurement/Action Negative Lead C175B-55 Ground C175B-59 Ground Is the resistance greater than 10, 000 ohms? Yes : GO to H7 No : REPAIR the circuit.
  7. H7 CHECK THE HIGH VOLTAGE INTERLOCK SYSTEM POSITIVE TEMPERATURE COEFFICIENT (PTC) CABIN HEATER INTERLOCK CIRCUITS FOR A SHORT TO GROUND Measure the resistance between. Positive Lead Measurement/Action Negative Lead C1822E-1 Ground Is the resistance greater than 10, 000 ohms? Yes : GO to H8 No : REPAIR the circuit.
  8. H8 CHECK THE HIGH VOLTAGE INTERLOCK SYSTEM AIR CONDITIONING (A/C) INTERLOCK CIRCUITS FOR A SHORT TO GROUND Measure the resistance between. Positive Lead Measurement/Action Negative Lead C1822C-1 Ground Is the resistance greater than 10, 000 ohms? Yes : GO to H9 No : REPAIR the circuit.
  9. H9 CHECK THE HIGH VOLTAGE INTERLOCK SYSTEM DC TO DC CONVERTER CONTROL MODULE (DC/DC) INTERLOCK CIRCUITS FOR A SHORT TO GROUND Measure the resistance between. Positive Lead Measurement/Action Negative Lead C1822G-1 Ground C1822G-2 Ground Is the resistance greater than 10, 000 ohms? Yes : GO to H10 No : REPAIR the circuit.
  10. H10 CHECK THE HIGH VOLTAGE INTERLOCK SYSTEM POWERTRAIN CONTROL MODULE (PCM) INTERLOCK CIRCUIT FOR A SHORT TO POWER Ignition ON. Measure the voltage between. Positive Lead Measurement/Action Negative Lead C175B-55 Ground C175B-59 Ground Is the voltage greater than 0.1 volt? Yes : REPAIR the circuit. No : GO to H11
  11. H11 CHECK THE HIGH VOLTAGE INTERLOCK SYSTEM POSITIVE TEMPERATURE COEFFICIENT (PTC) CABIN HEATER INTERLOCK CIRCUIT FOR A SHORT TO POWER Measure the voltage between. Positive Lead Measurement/Action Negative Lead C1822E-1 Ground Is the voltage greater than 0.1 volt? Yes : REPAIR the circuit. No : GO to H12
  12. H12 CHECK THE HIGH VOLTAGE INTERLOCK SYSTEM AIR CONDITIONING (A/C) INTERLOCK CIRCUIT FOR A SHORT TO POWER Measure the voltage between. Positive Lead Measurement/Action Negative Lead C1822C-1 Ground Is the voltage greater than 0.1 volt? Yes : REPAIR the circuit. No : GO to H13
  13. H13 CHECK THE HIGH VOLTAGE INTERLOCK SYSTEM DC TO DC CONVERTER CONTROL MODULE (DC/DC) INTERLOCK CIRCUIT FOR A SHORT TO POWER Measure the voltage between. Positive Lead Measurement/Action Negative Lead C1822G-1 Ground C1822G-2 Ground Is the voltage greater than 0.1 volt? Yes : REPAIR the circuit. No : INSTALL a new motor. REFER to: «ELECTRIC MOTOR»(/ford/focus-st/iii-2012-2015/remont/mechanical/#electric-motor) .

P258A:00, B1D63:00

Diagnostics in this service information assume a certain skill level and knowledge of Ford-specific diagnostic practices.

REFER to: DIAGNOSTIC METHODS .

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

The PCM monitors the vacuum pump relay input. When the ABS module or the PCM commands the vacuum pump relay on and the PCM did not detect a voltage input, a DTC sets.

  1. Connectors damaged or pushed-out terminals, corrosion, loose wires and missing or damaged seals
  2. BJB fuse 11 (40A)
  3. BJB fuse 35 (5A)
  4. Vacuum pump relay
  5. Vacuum pump cut-out relay
  6. PCM
DTCDescriptionFault Trigger Conditions
P258A:00Vacuum Pump Control Circuit/OpenThe vacuum pump relay was commanded ON but the PCM did not detect a voltage input.
B1D63:00External Control RelayThe vacuum pump cut-off relay was commanded ON but the PCM did not detect a voltage input.

DTC FAULT TRIGGER CONDITIONS

PINPOINT TEST I: P258A:00, B1D63:00

  1. I1 RETRIEVE AND RECORD ALL DTCS Connect the diagnostic tool. Using the scan tool, retrieve all Diagnostic Trouble Codes (DTCs). Is DTC P258A:00 or B1D63:00 set? Yes : For DTC P2528A:00, GO to I2 For DTC B1D63:00, GO to I5 No : If ABS Diagnostic Trouble Codes (DTCs) are set, REFER to: «ANTI-LOCK BRAKE SYSTEM (ABS) AND STABILITY CONTROL»(/ford/focus-st/iii-2012-2015/remont/anti-locktraction-control/#anti-lock-brake-system-stability-control-system-electric) .
  2. I2 CHECK THE VACUUM PUMP RELAY CONTROL CIRCUIT FOR AN OPEN Disconnect Powertrain Control Module (PCM) C175A . Disconnect Battery Junction Box (BJB) C1035C . Measure the resistance between. Positive Lead Measurement/Action Negative Lead C175A-8 C1035C-30 Is the resistance less than 5.0 ohms? Yes : GO to I3 No : REPAIR the circuit.
  3. I3 CHECK THE VACUUM PUMP RELAY CONTROL CIRCUIT FOR A SHORT TO GROUND Measure the resistance between. Positive Lead Measurement/Action Negative Lead C175A-8 Ground Is the resistance greater than 10, 000 ohms? Yes : GO to I4 No : REPAIR the circuit.
  4. I4 CHECK THE VACUUM PUMP RELAY CONTROL CIRCUIT FOR A SHORT TO POWER Ignition ON. Measure the voltage between. Positive Lead Measurement/Action Negative Lead C175A-8 Ground Is any voltage present? Yes : REPAIR the circuit. No : INSTALL a new PCM . REFER to: «POWERTRAIN CONTROL MODULE (PCM)»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control) .
  5. I5 CHECK THE VACUUM PUMP CUT-OFF RELAY CONTROL CIRCUIT FOR AN OPEN Disconnect Powertrain Control Module (PCM) C175A . Disconnect Battery Junction Box (BJB) C1035C . Measure the resistance between. Positive Lead Measurement/Action Negative Lead C175A-22 C1035C-33 Is the resistance less than 5.0 ohms? Yes : GO to I6 No : REPAIR the circuit.
  6. I6 CHECK THE VACUUM PUMP CUT-OFF RELAY CONTROL CIRCUIT FOR A SHORT TO GROUND Measure the resistance between. Positive Lead Measurement/Action Negative Lead C175A-22 Ground Is the resistance greater than 10, 000 ohms? Yes : GO to I7 No : REPAIR the circuit.
  7. I7 CHECK THE VACUUM PUMP CUT-OFF RELAY CONTROL CIRCUIT FOR A SHORT TO POWER Ignition ON. Measure the voltage between. Positive Lead Measurement/Action Negative Lead C175A-22 Ground Is any voltage present? Yes : REPAIR the circuit. No : INSTALL a new PCM . REFER to: «POWERTRAIN CONTROL MODULE (PCM)»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control) .

P0120:12, P0120:14, P0220:12, P0220:14, P2122:14, P2123:12, P2127:14, P2128:12, P2135:1F, P2138:1F

Diagnostics in this service information assume a certain skill level and knowledge of Ford-specific diagnostic practices.

REFER to: DIAGNOSTIC METHODS .

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

There are 2 APP signals in the sensor. Both signals, APP 1 and APP 2, have a positive slope (increasing angle, increasing voltage), but are offset and increase at different rates. The 2 APP signals make sure the PCM receives a correct input even if 1 signal has a concern. The PCM determines if a signal is incorrect by calculating where it should be, inferred from the other signals. If a concern is present with one of the circuits the other input is used. There are 2 reference voltage circuits, 2 signal return circuits, and two signal circuits (a total of 6 circuits and terminals) between the PCM and the APP sensor assembly. The APP signal is converted to pedal travel degrees (rotary angle) by the PCM . The software then converts these degrees to counts, which is the input to the torque based strategy. The PCM sets a DTC if voltage on these inputs are above or below a calibrated threshold.

  1. Connectors damaged or pushed-out terminals, corrosion, loose wires and missing or damaged seals
  2. APP sensor
  3. PCM
DTCDescriptionFault Trigger Conditions
P0120:12Throttle/Pedal Position Sensor "A" Circuit Short to BatteryThe PCM detects the APP sensor 1 signal is to high.
P0120:14Throttle/Pedal Position Sensor "A" Circuit Short to Ground or OpenThe PCM detects the APP sensor 1 signal is to low or open.
P0220:12Throttle/Pedal Position Sensor "B" Circuit Short to BatteryThe PCM detects the APP sensor 2 signal is to high.
P0220:14Throttle/Pedal Position Sensor "B" Circuit Short to Ground or OpenThe PCM detects the APP sensor 2 signal is to low or open.
P2122:14Throttle/Pedal Position Sensor/Switch "D" Circuit LowThe PCM detects the APP sensor 1 is out of self-test range low.
P2123:12Throttle/Pedal Position Sensor/Switch "D" Circuit HighThe PCM detects the APP sensor 1 is out of self-test range high.
P2127:14Throttle/Pedal Position Sensor/Switch "E" Circuit LowThe PCM detects the APP sensor 2 is out of self-test range low.
P2128:12Throttle/Pedal Position Sensor/Switch "E" Circuit HighThe PCM detects the APP sensor 2 is out of self-test range high.
P2135:1FThrottle/Pedal Position Sensor/Switch "A"/"B" Voltage CorrelationThe PCM detects a concern indicating that APP voltage PIDs APP 1 and APP 2 disagree by more than a calibrated limit.
P2138:1FThrottle/Pedal Position Sensor/Switch "D"/"E" Voltage CorrelationThe PCM compares the APP 1 and APP 2 sensor inputs. This DTC sets when the APP sensor 1 and APP 2 inputs disagree on the position of the accelerator pedal by more than an expected value.

DTC FAULT TRIGGER CONDITIONS

PINPOINT TEST J: P0120:12, P0120:14, P0220:12, P0220:14, P2122:14, P2123:12, P2127:14, P2128:12, P2135:1F, P2138:1F

  1. J1 RETRIEVE AND RECORD ALL DTCS Connect the diagnostic tool. Using the scan tool, retrieve all Diagnostic Trouble Codes (DTCs). Is DTC P0120:12, P0120:14, P0220:12, P0220:14, P2122:14, P2123:12, P2127:14, P2128:12, P2135:1F and/or P2138:1F set? Yes : For Diagnostic Trouble Codes (DTCs) P0120:12, P2123:12 and/or P2135:1F, GO to J2 For Diagnostic Trouble Codes (DTCs) P0120:14, P2122:14 and/or P2135:1F, GO to J5 For Diagnostic Trouble Codes (DTCs) P0220:12, P2128:12 and/or P2135:1F, GO to J8 For Diagnostic Trouble Codes (DTCs) P0220:14, P2127:14 and/or P2135:1F, GO to J11 For DTC P2138:1F, GO to J14 No : GO to «SYMPTOM CHART»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control__symptom-chart) .
  2. J2 CHECK ACCELERATOR PEDAL POSITION (APP) VOLTAGE REFERENCE 1 CIRCUIT FOR VOLTAGE Disconnect Accelerator Pedal Position (APP) C2040 . Ignition ON. Measure the voltage between. Positive Lead Measurement/Action Negative Lead C2040-1 Ground Is the voltage greater than 4.8 volts? Yes : GO to J3 No : INSPECT and REPAIR the circuit. If an open circuit is not found, INSTALL a new PCM . REFER to: «POWERTRAIN CONTROL MODULE (PCM)»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control) .
  3. J3 CHECK ACCELERATOR PEDAL POSITION (APP) RETURN 1 CIRCUIT FOR AN OPEN Measure the voltage between. Positive Lead Measurement/Action Negative Lead C2040-1 C2040-3 Is the voltage greater than 4.8 volts? Yes : GO to J4 No : REPAIR the circuit.
  4. J4 CHECK ACCELERATOR PEDAL POSITION (APP)1 SIGNAL CIRCUIT FOR A SHORT TO POWER Ignition OFF. Disconnect Powertrain Control Module (PCM) C175A . Ignition ON. Measure the voltage between. Positive Lead Measurement/Action Negative Lead C2040-2 Ground Is any voltage present? Yes : REPAIR the circuit. No : INSTALL a new PCM . REFER to: «POWERTRAIN CONTROL MODULE (PCM)»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control) .
  5. J5 CHECK ACCELERATOR PEDAL POSITION (APP) VOLTAGE REFERENCE 1 CIRCUIT FOR VOLTAGE Disconnect Accelerator Pedal Position (APP) C2040 . Ignition ON. Measure the voltage between. Positive Lead Measurement/Action Negative Lead C2040-1 Ground Is voltage greater than 4.8 volts? Yes : GO to J6 No : INSPECT and REPAIR the circuit. If a short to ground is not found, INSTALL a new PCM . REFER to: «POWERTRAIN CONTROL MODULE (PCM)»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control) .
  6. J6 CHECK ACCELERATOR PEDAL POSITION (APP)1 CIRCUIT FOR A SHORT TO GROUND Ignition OFF. Disconnect Powertrain Control Module (PCM) C175A . Measure the resistance between. Positive Lead Measurement/Action Negative Lead C2040-2 Ground Is the resistance greater than 10, 000 ohms? Yes : GO to J7 No : REPAIR the circuit.
  7. J7 CHECK ACCELERATOR PEDAL POSITION (APP) CIRCUITS FOR SHORT TOGETHER Measure the resistance between. Positive Lead Measurement/Action Negative Lead C2040-1 C2040-3 C2040-1 C2040-2 Is the resistance greater than 10, 000 ohms? Yes : INSTALL a new PCM . REFER to: «POWERTRAIN CONTROL MODULE (PCM)»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control) . No : REPAIR the circuit.
  8. J8 CHECK ACCELERATOR PEDAL POSITION (APP) VOLTAGE REFERENCE 2 CIRCUIT FOR VOLTAGE Disconnect Accelerator Pedal Position (APP) C2040 . Ignition ON. Measure the voltage between. Positive Lead Measurement/Action Negative Lead C2040-6 Ground Is the voltage greater than 4.8 volts? Yes : GO to J9 No : INSPECT and REPAIR the circuit. If an open circuit is not found, INSTALL a new PCM . REFER to: «POWERTRAIN CONTROL MODULE (PCM)»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control) .
  9. J9 CHECK ACCELERATOR PEDAL POSITION (APP) RETURN 2 CIRCUIT FOR AN OPEN Measure the voltage between. Positive Lead Measurement/Action Negative Lead C2040-6 C2040-4 Is the voltage greater than 4.8 volts? Yes : GO to J10 No : REPAIR the circuit.
  10. J10 CHECK ACCELERATOR PEDAL POSITION (APP)2 SIGNAL CIRCUIT FOR A SHORT TO POWER Disconnect Accelerator Pedal Position (APP) C2040 . Ignition ON. Measure the voltage between. Positive Lead Measurement/Action Negative Lead C2040-5 Ground Is any voltage present? Yes : REPAIR the circuit. No : INSTALL a new PCM . REFER to: «POWERTRAIN CONTROL MODULE (PCM)»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control) .
  11. J11 CHECK ACCELERATOR PEDAL POSITION (APP) VOLTAGE REFERENCE 2 CIRCUIT FOR VOLTAGE Disconnect Accelerator Pedal Position (APP) C2040 . Ignition ON. Measure the voltage between. Positive Lead Measurement/Action Negative Lead C2040-6 Ground Is the voltage greater than 4.8 volts? Yes : GO to J12 No : INSPECT and REPAIR the circuit. If a short to ground is not found, INSTALL a new PCM . REFER to: «POWERTRAIN CONTROL MODULE (PCM)»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control) .
  12. J12 CHECK ACCELERATOR PEDAL POSITION (APP)2 SIGNAL CIRCUIT FOR A SHORT TO GROUND Ignition OFF. Disconnect Powertrain Control Module (PCM) C175A . Measure the resistance between. Positive Lead Measurement/Action Negative Lead C2040-5 Ground Is the resistance greater than 10, 000 ohms? Yes : GO to J13 No : REPAIR the circuit.
  13. J13 CHECK ACCELERATOR PEDAL POSITION (APP) CIRCUITS FOR SHORT TOGETHER Measure the resistance between. Positive Lead Measurement/Action Negative Lead C2040-6 C2040-4 C2040-6 C2040-5 Is the resistance greater than 10, 000 ohms? Yes : INSTALL a new PCM . REFER to: «POWERTRAIN CONTROL MODULE (PCM)»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control) . No : REPAIR the circuit.
  14. J14 CHECK THE ACCELERATOR PEDAL POSITION (APP) VOLTAGE VALUES NOTE: Diagnose and repair all other Diagnostic Trouble Codes (DTCs) before entering this pinpoint test. Access and monitor the APP1 (volt) and APP2 (volt) PIDS. Apply the accelerator pedal fully to the floor and release. Pedal Position APP1 APP2 Applied 3.59 - 4.60 volts 1.72 - 2.40 volts Released 0.64 - 0.96 volts 0.27 - 0.53 volts Are both APP voltage signals in range for the accelerator pedal applied and released positions? Yes : The system is operating correctly at this time. No : INSTALL a new APP sensor.

P0480:00, P0483:00

Diagnostics in this service information assume a certain skill level and knowledge of Ford-specific diagnostic practices.

REFER to: DIAGNOSTIC METHODS .

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

The PCM checks the fan control variable output circuit. If the PCM detects the voltage on the fan control variable circuit is not within the expected range then the PCM sets a DTC .

  1. Connectors damaged or pushed-out terminals, corrosion, loose wires and missing or damaged seals
  2. Engine cooling fan relay
  3. High current BJB mega fuse 8 (50A)
  4. BJB fuse 32 (10A)
  5. Engine cooling fan motor
  6. PCM
DTCDescriptionFault Trigger Conditions
P0480:00Fan 1 Control CircuitThe PCM detects a voltage outside of an acceptable range.
P0483:00Fan PerformanceDTC P0480:00 is not set but an intermittent condition occurred.

DTC FAULT TRIGGER CONDITIONS

PINPOINT TEST K: P0480:00, P0483:00

  1. K1 RETRIEVE AND RECORD ALL DTCS Connect the diagnostic tool. Using the scan tool, retrieve all Diagnostic Trouble Codes (DTCs). Is DTC P0480:00 and/or P0483:00 set? Yes : GO to K4 No : GO to K2
  2. K2 CHECK THE ENGINE COOLING FAN MOTOR POWER CIRCUIT Ignition OFF. Disconnect Engine Cooling Fan Motor C1048 . Rotate the fan by hand. The fan should rotate freely with no abnormal binding. Ignition ON. Measure the voltage between. Positive Lead Measurement/Action Negative Lead C1048-1 Ground Is voltage greater than 10.5 volts? Yes : GO to K3 No : INSPECT and REPAIR the circuit. If an open circuit is not found, INSTALL a new engine cooling fan relay.
  3. K3 CHECK THE ENGINE COOLING FAN MOTOR GROUND CIRCUIT FOR AN OPEN Measure the voltage between. Positive Lead Measurement/Action Negative Lead C1048-1 C1048-2 Is the voltage greater than 10.5 volts? Yes : INSTALL an new engine cooling fan motor. REFER to: «COOLING FAN MOTOR AND SHROUD»(/ford/focus-st/iii-2012-2015/remont/cooling-system-mechanical/#electric-powertrain-cooling) . No : REPAIR the circuit.
  4. K4 CHECK THE FAN CONTROL VARIABLE CIRCUIT FOR AN OPEN Ignition OFF. Disconnect Powertrain Control Module (PCM) C175B . Measure the resistance between. Positive Lead Measurement/Action Negative Lead C1048-4 C175B-12 Is the resistance less than 5.0 ohms? Yes : GO to K5 No : REPAIR the circuit.
  5. K5 CHECK THE FAN CONTROL VARIABLE CIRCUIT FOR A SHORT TO GROUND Measure the resistance between. Positive Lead Measurement/Action Negative Lead C1048-4 Ground Is the resistance greater than 10, 000 ohms? Yes : INSTALL a new PCM . REFER to: «POWERTRAIN CONTROL MODULE (PCM)»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control) . No : REPAIR the circuit.

P0C44:00, P0C45:00

Diagnostics in this service information assume a certain skill level and knowledge of Ford-specific diagnostic practices.

REFER to: DIAGNOSTIC METHODS .

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

The battery pack coolant temperature sensor is a temperature-sensitive device called a thermistor. The resistance value of the battery pack coolant temperature sensor varies with temperature change. The PCM provides a signal voltage to the battery pack coolant temperature sensor. The PCM monitors the voltage across the battery pack coolant temperature sensor to determine the temperature of the electric motor coolant. The PCM sets a DTC if voltage on these inputs are above or below a calibrated threshold.

  1. Connectors damaged or pushed-out terminals, corrosion, loose wires and missing or damaged seals
  2. Battery pack coolant temperature sensor
  3. PCM
DTCDescriptionFault Trigger Conditions
P0C44:00Hybrid/EV Battery Pack Coolant Temperature Sensor "A" Circuit LowThe PCM detects less than 0.1 volt at the battery pack coolant temperature sensor input.
P0C45:00Hybrid/EV Battery Pack Coolant Temperature Sensor "A" Circuit HighThe PCM detects greater than 4.9 volts at the battery pack coolant temperature sensor input.

DTC FAULT TRIGGER CONDITIONS

PINPOINT TEST L: P0C44:00, P0C45:00

  1. L1 RETRIEVE AND RECORD ALL DTCS Connect the diagnostic tool. Using the scan tool, retrieve all Diagnostic Trouble Codes (DTCs) Is DTCs P0C44:00 and/or P0C45:00 set? Yes : GO to L2 No : GO to «SYMPTOM CHART»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control__symptom-chart) .
  2. L2 CHECK THE BATTERY PACK COOLANT TEMPERATURE SENSOR SIGNAL INPUT Ignition OFF. Disconnect Battery Pack Coolant Temperature Sensor C1819 . Ignition ON. Locate the battery pack coolant temperature sensor PID. Does the PID display 5.1 volts? Yes : GO to L3 No : REPAIR the circuit.
  3. L3 CHECK THE BATTERY PACK COOLANT TEMPERATURE SENSOR SIGNAL CIRCUIT Connect a fuse jumper wire between. Positive Lead Measurement/Action Negative Lead C1819-1 C1819-2 Does the PID display 0.0 volts? Yes : GO to L5 No : GO to L4
  4. L4 CHECK THE BATTERY PACK COOLANT TEMPERATURE SIGNAL VOLTAGE Measure the voltage between. Positive Lead Measurement/Action Negative Lead C1819-1 Ground Is the voltage between 4.8 and 5.1 volts? Yes : GO to L5 No : INSPECT and REPAIR the circuit. If an open circuit is not found, INSTALL a new PCM . REFER to: «POWERTRAIN CONTROL MODULE (PCM)»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control) .
  5. L5 CHECK THE BATTERY PACK COOLANT TEMPERATURE SENSOR RESISTANCE Measure the component side resistance between. Positive Lead Measurement/Action Negative Lead C1819-1 C1819-2 TEMPERATURE °F (°C) Ohms -39.9-4.0°F (-40-20°C) 1, 076K-269K -2.2-30.2°F (-19-1°C) 309K-91K 32.0-68.0°F (-20°C) 104K-35K 69.8-103.9°F (21-40°C) 40K-15K 105.7-157.9°F (41-70°C) 17K-4.9K 159.7-193.9°F (71-90°C) 5.6K-2.5K 195.7-229.8°F (91-110°C) 3.0K-1.4K 231.6-265.8°F (111-130°C) 1.7K-0.8K 267.6-301.8°F (131-150°C) 0.97K-0.56K Does the temperature to resistance specifications match? Yes : INSTALL a new PCM . REFER to: «POWERTRAIN CONTROL MODULE (PCM)»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control) . No : INSTALL a new battery pack coolant temperature sensor.

P0C47:00, P0C4A:00, P0C4A:12, P0C4A:14

Diagnostics in this service information assume a certain skill level and knowledge of Ford-specific diagnostic practices.

REFER to: DIAGNOSTIC METHODS .

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

The battery pack coolant pump is a 12-volt pump which can operate at variable speeds. The PCM provides a PWM signal to the pump and monitors this signal by monitoring a diagnostic circuit input. The battery pack coolant pump provides coolant to the battery pack to keep the battery warm by providing warm coolant and to keep the battery cool as it begins to generate heat.

  1. Connectors damaged or pushed-out terminals, corrosion, loose wires and missing or damaged seals
  2. Battery pack coolant pump
  3. BJB fuse 36
  4. PCM

Note. If electric motor coolant pump and cabin heater coolant pump Diagnostic Trouble Codes (DTCs) are set, inspect the BJB fuse 36 (20A) for an open.

DTCDescriptionFault Trigger Conditions
P0C47:00Hybrid/EV Battery Coolant Pump "A" Control Circuit/OpenThe PCM detects a short to power, ground or an open on the PWM output.
P0C4A:00Hybrid/EV Battery Coolant Pump "A" Control PerformanceThe PCM detects a short to power, ground or an open on the PWM output.
P0C4A:12Hybrid/EV Battery Coolant Pump "A" Control Performance Short to BatteryThe PCM detects a 100% duty cycle on the diagnostic input.
P0C4A:14Hybrid/EV Battery Coolant Pump "A" Control Performance Short to Ground or OpenThe PCM detects a 0% duty cycle on the diagnostic input.

DTC FAULT TRIGGER CONDITIONS

PINPOINT TEST M: P0C47:00, P0C4A:00, P0C4A:12, P0C4A:14

  1. M1 RETRIEVE AND RECORD ALL DTCS Connect the diagnostic tool. Using the scan tool, retrieve all Diagnostic Trouble Codes (DTCs). Is DTC P0C47:00, P0C4A:00, P0C4A:12 and/or P0C4A:14 set? Yes : For Diagnostic Trouble Codes (DTCs) P0C47:00 and P0C4A:00, GO to M2 For DTC P0C4A:12, GO to M7 For DTC P0C4A:14, GO to M8 No : GO to «SYMPTOM CHART»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control__symptom-chart) .
  2. M2 CHECK THE BATTERY PACK COOLANT PUMP POWER CIRCUIT Ignition OFF. Disconnect Battery Pack Coolant Pump C1814 . Ignition ON. Measure the voltage between. Positive Lead Measurement/Action Negative Lead C1814-1 Ground C1814-5 Ground Is the voltage greater than 10.5 volts? Yes : GO to M3 No : REPAIR the circuit.
  3. M3 CHECK THE BATTERY PACK COOLANT PUMP GROUND CIRCUIT FOR AN OPEN Measure the voltage between. Positive Lead Measurement/Action Negative Lead C1814-1 C1814-4 Is the voltage greater than 10.5 volts? Yes : GO to M4 No : REPAIR the circuit.
  4. M4 CHECK THE BATTERY PACK COOLANT PUMP PULSE WIDTH MODULATION (PWM) CIRCUIT FOR AN OPEN Ignition OFF. Disconnect Powertrain Control Module (PCM) C175A . Measure the resistance between. Positive Lead Measurement/Action Negative Lead C175A-13 C1814-3 Is the resistance less than 5.0 ohms? Yes : GO to M5 No : REPAIR the circuit.
  5. M5 CHECK THE BATTERY PACK COOLANT PUMP PULSE WIDTH MODULATION (PWM) CIRCUIT FOR A SHORT TO GROUND Measure the resistance between. Positive Lead Measurement/Action Negative Lead C175A-13 Ground Is the resistance greater than 10, 000 ohms? Yes : GO to M6 No : REPAIR the circuit.
  6. M6 CHECK THE BATTERY PACK COOLANT PUMP PULSE WIDTH MODULATION (PWM) CIRCUIT FOR A SHORT TO POWER Ignition ON. Measure the voltage between. Positive Lead Measurement/Action Negative Lead C175A-13 Ground Is the voltage greater than 0.1 volt? Yes : REPAIR the circuit. No : INSTALL a new high voltage battery coolant pump. REFER to: «HIGH VOLTAGE BATTERY COOLANT PUMP»(/ford/focus-st/iii-2012-2015/remont/cooling-system-mechanical/#electric-powertrain-cooling__high-voltage-battery-coolant-pump) .
  7. M7 CHECK THE BATTERY PACK COOLANT PUMP DIAGNOSTIC CIRCUIT FOR A SHORT TO POWER Ignition OFF. Disconnect Powertrain Control Module (PCM) C175A . Disconnect Battery Pack Coolant Pump C1814 . Ignition ON. Measure the voltage between. Positive Lead Measurement/Action Negative Lead C175A-73 Ground Is the voltage greater than 0.1 volt? Yes : REPAIR the circuit. No : INSTALL a new PCM . REFER to: «POWERTRAIN CONTROL MODULE (PCM)»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control) .
  8. M8 CHECK THE BATTERY PACK COOLANT PUMP DIAGNOSTIC CIRCUIT FOR AN OPEN Ignition OFF. Disconnect Powertrain Control Module (PCM) C175A . Disconnect Battery Pack Coolant Pump C1814 . Measure the resistance between. Positive Lead Measurement/Action Negative Lead C175A-73 C1814-2 Is the resistance less than 5.0 ohms? Yes : GO to M9 No : REPAIR the circuit.
  9. M9 CHECK THE BATTERY PACK COOLANT PUMP DIAGNOSTIC CIRCUIT FOR A SHORT TO GROUND Measure the resistance between. Positive Lead Measurement/Action Negative Lead C175A-73 Ground Is the resistance greater than 10, 000 ohms? Yes : INSTALL a new PCM . REFER to: «POWERTRAIN CONTROL MODULE (PCM)»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control) . No : REPAIR the circuit.

P0D82:00, P0D83:00

Diagnostics in this service information assume a certain skill level and knowledge of Ford-specific diagnostic practices.

REFER to: DIAGNOSTIC METHODS .

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

When the PCM is powered up the PCM sends a 12-volt signal to the secondary on-board diagnostic module A as a wake up input. The secondary on-board diagnostic module A begins communicating on the high speed CAN . The PCM sets a DTC if voltage on this input is above or below a calibrated threshold.

  1. Connectors damaged or pushed-out terminals, corrosion, loose wires and missing or damaged seals
  2. Secondary on-board diagnostic module A
  3. PCM
DTCDescriptionFault Trigger Conditions
P0D82:00Battery Charger Input Circuit LowThe PCM detects a short to ground on the secondary on-board diagnostic module A high side driver enable circuit.
P0D83:00Battery Charger Input Circuit HighThe PCM detects an open on the secondary on-board diagnostic module A high side driver enable circuit.

DTC FAULT TRIGGER CONDITIONS

PINPOINT TEST N: P0D82:00, P0D83:00

  1. N1 RETRIEVE AND RECORD ALL DTCS Connect the diagnostic tool. Using the scan tool, retrieve all Diagnostic Trouble Codes (DTCs). Is DTCs P0D82:00 or P0D83:00 set? Yes : For DTC P0D82:00, GO to N2 For DTC P0D83:00, GO to N3 No : REFER to: «HIGH VOLTAGE BATTERY CHARGING SYSTEM»(/ford/focus-st/iii-2012-2015/remont/body-electrical/#high-voltage-battery-charging-system-electric) .
  2. N2 CHECK THE SECONDARY ON-BOARD DIAGNOSTIC MODULE A HIGH SIDE DRIVER ENABLE WAKE UP CIRCUIT FOR A SHORT TO GROUND Ignition OFF. Disconnect Powertrain Control Module (PCM) C175B . Disconnect Secondary On-Board Diagnostic Module A C1821C . Measure the resistance between. Positive Lead Measurement/Action Negative Lead C175B-86 Ground Is the resistance greater than 10, 000 ohms? Yes : INSTALL a new PCM . REFER to: «POWERTRAIN CONTROL MODULE (PCM)»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control) . No : REPAIR the circuit.
  3. N3 CHECK THE SECONDARY ON-BOARD DIAGNOSTIC MODULE A HIGH SIDE DRIVER ENABLE WAKE UP CIRCUIT FOR AN OPEN Ignition OFF. Disconnect Powertrain Control Module (PCM) C175B . Disconnect Secondary On-Board Diagnostic Module A C1821C . Measure the resistance between. Positive Lead Measurement/Action Negative Lead C175B-86 C1821C-4 Is the resistance less than 5.0 ohms? Yes : GO to N4 No : REPAIR the circuit.
  4. N4 CHECK THE SECONDARY ON-BOARD DIAGNOSTIC MODULE A HIGH SIDE DRIVER ENABLE WAKE UP CIRCUIT FOR A SHORT TO POWER Ignition ON. Measure the voltage between. Positive Lead Measurement/Action Negative Lead C175B-86 Ground Is any voltage present? Yes : REPAIR the circuit. No : INSTALL a new PCM . REFER to: «POWERTRAIN CONTROL MODULE (PCM)»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control) .

P0CC1:00, P0CC2:00, P0CC2:12, P0CC2:14

Diagnostics in this service information assume a certain skill level and knowledge of Ford-specific diagnostic practices.

REFER to: DIAGNOSTIC METHODS .

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

The drive motor coolant pump is a 12-volt pump which operates at variable speeds. The PCM provides a PWM signal to the pump and monitors this signal by monitoring a feedback circuit. The drive motor coolant pump provides coolant to the drive motor to keep the motor warm by providing warm coolant and to keep the motor cool as it begins to generate heat.

  1. Connectors damaged or pushed-out terminals, corrosion, loose wires and missing or damaged seals
  2. Drive motor coolant pump
  3. BJB fuse 36 (20A)
  4. PCM

Note. If battery pack coolant pump and cabin heater coolant pump Diagnostic Trouble Codes (DTCs) are set, inspect the BJB fuse 36 (20A) for an open.

DTCDescriptionFault Trigger Conditions
P0CC1:00Drive Motor "A" Coolant Pump Control Circuit/OpenThe PCM detects a short to power, ground or an open on the PWM output.
P0CC2:00Drive Motor "A" Coolant Pump Control Circuit Range/PerformanceThe PCM detects a short to power, ground or an open on the PWM output.
P0CC2:12Drive Motor "A" Coolant Pump Control Circuit Range/Performance Short to BatteryThe PCM detects a 100% duty cycle on the diagnostic circuit.
P0CC2:14Drive Motor "A" Coolant Pump Control Circuit Range/Performance Short to Ground or OpenThe PCM detects a 0% duty cycle on the diagnostic circuit.

DTC FAULT TRIGGER CONDITIONS

PINPOINT TEST O: P0CC1:00, P0CC2:00, P0CC2:12, P0CC2:14

  1. O1 RETRIEVE AND RECORD ALL DTCS Connect the diagnostic tool. Using the scan tool, retrieve all Diagnostic Trouble Codes (DTCs). Is DTC P0CC1:00, P0CC2:00, P0CC2:12 and/or P0CC2:14 set? Yes : For Diagnostic Trouble Codes (DTCs) P0CC1:00 and P0CC2:00, GO to O2 For DTC P0CC2:12, GO to O7 For DTC P0CC2:14, GO to O8 No : GO to «SYMPTOM CHART»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control__symptom-chart) .
  2. O2 CHECK THE DRIVE MOTOR COOLANT PUMP POWER CIRCUIT Ignition OFF. Disconnect Drive Motor Coolant Pump C1812 . Ignition ON. Measure the voltage between. Positive Lead Measurement/Action Negative Lead C1812-1 Ground C1812-5 Ground Are the voltages greater than 10.5 volts? Yes : GO to O3 No : REPAIR the affected circuit(s).
  3. O3 CHECK THE DRIVE MOTOR COOLANT PUMP GROUND CIRCUIT FOR AN OPEN Measure the voltage between. Positive Lead Measurement/Action Negative Lead C1812-1 C1812-4 Is voltage greater than 10.5 volts? Yes : GO to O4 No : REPAIR the circuit.
  4. O4 CHECK THE DRIVE MOTOR COOLANT PUMP PULSE WIDTH MODULATION (PWM) CIRCUIT FOR AN OPEN Ignition OFF. Disconnect Powertrain Control Module (PCM) C175B . Measure the resistance between. Positive Lead Measurement/Action Negative Lead C175B-13 C1812-3 Is the resistance less than 5.0 ohms? Yes : GO to O5 No : REPAIR the circuit.
  5. O5 CHECK THE DRIVE MOTOR COOLANT PUMP PULSE WIDTH MODULATION (PWM) CIRCUIT FOR A SHORT TO GROUND Measure the resistance between. Positive Lead Measurement/Action Negative Lead C175B-13 Ground Is the resistance greater than 10, 000 ohms? Yes : GO to O6 No : REPAIR the circuit.
  6. O6 CHECK THE DRIVE MOTOR COOLANT PUMP PULSE WIDTH MODULATION (PWM) CIRCUIT FOR A SHORT TO POWER Ignition ON. Measure the voltage between. Positive Lead Measurement/Action Negative Lead C175B-13 Ground Is voltage greater than 0.1 volt? Yes : REPAIR the circuit. No : INSTALL a new electric motor coolant pump. REFER to: «ELECTRIC MOTOR COOLANT PUMP»(/ford/focus-st/iii-2012-2015/remont/cooling-system-mechanical/#electric-powertrain-cooling__electric-motor-coolant-pump) .
  7. O7 CHECK THE DRIVE MOTOR COOLANT PUMP DIAGNOSTIC CIRCUIT FOR A SHORT TO POWER Ignition OFF. Disconnect Powertrain Control Module (PCM) C175B . Disconnect Drive Motor Coolant Pump C1812 . Ignition ON. Measure the voltage between. Positive Lead Measurement/Action Negative Lead C175B-51 Ground Is voltage greater than 0.1 volt? Yes : REPAIR the circuit. No : INSTALL a new PCM . REFER to: «POWERTRAIN CONTROL MODULE (PCM)»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control) .
  8. O8 CHECK THE DRIVE MOTOR COOLANT PUMP DIAGNOSTIC CIRCUIT FOR AN OPEN Ignition OFF. Disconnect Powertrain Control Module (PCM) C175B . Disconnect Drive Motor Coolant Pump C1812 . Measure the resistance between. Positive Lead Measurement/Action Negative Lead C175B-51 C1812-2 Is the resistance less than 5.0 ohms? Yes : GO to O9 No : REPAIR the circuit.
  9. O9 CHECK THE DRIVE MOTOR COOLANT PUMP DIAGNOSTIC CIRCUIT FOR A SHORT TO GROUND Measure the resistance between. Positive Lead Measurement/Action Negative Lead C175B-51 Ground Is the resistance greater than 10, 000 ohms? Yes : INSTALL a new PCM . REFER to: «POWERTRAIN CONTROL MODULE (PCM)»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control) . No : REPAIR the circuit.

P0E12:00, P0E12:09, P0E16:00, P0E16:09

Diagnostics in this service information assume a certain skill level and knowledge of Ford-specific diagnostic practices.

REFER to: DIAGNOSTIC METHODS .

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

The battery pack coolant heater elements are used to warm the coolant when temperatures drop below a calibrated limit. When the vehicle is started, the PCM commands one or all of the battery pack coolant heater elements to come on. The PCM sets a DTC if voltage on these battery pack coolant heater element inputs are above or below a calibrated threshold.

  1. Connectors damaged or pushed-out terminals, corrosion, loose wires and missing or damaged seals
  2. BJB fuse 23 (5A)
  3. High current BJB mega fuse 5 (70A)
  4. High current BJB mega fuse 10 (40A)
  5. Heater element 1 and 2 relay
  6. Heater element 3 relay
  7. PCM
DTCDescriptionFault Trigger Conditions
P0E12:00Hybrid/EV Battery Pack Coolant Heater "A" Control Circuit/OpenThe PCM detects a short to power, ground or an open on the high voltage battery heater element 1 and 2 relay control circuit.
P0E12:09Hybrid/EV Battery Pack Coolant Heater "A" Control Circuit/Open Component FailureThe PCM detects a short to power, ground or an open on the high voltage battery heater element 1 and 2 relay control circuit.
P0E16:00Hybrid/EV Battery Pack Coolant Heater "B" Control Circuit/OpenThe PCM detects a short to power, ground or an open on the high voltage battery heater element 3 relay control circuit.
P0E16:09Hybrid/EV Battery Pack Coolant Heater "B" Control Circuit/Open Component FailureThe PCM detects a short to power, ground or an open on the high voltage battery heater element 3 relay control circuit.

DTC FAULT TRIGGER CONDITIONS

PINPOINT TEST P: P0E12:00, P0E12:09, P0E16:00, P0E16:09

  1. P1 RETRIEVE AND RECORD ALL DTCS Connect the diagnostic tool. Using the scan tool, retrieve all Diagnostic Trouble Codes (DTCs). Is DTC P0E12:00, P0E12:09, P0E16:00 and/or P0E16:09 set? Yes : For Diagnostic Trouble Codes (DTCs) P0E12:00, P0E12:09, P0E16:00, P0E16:09, GO to P2 For DTC P0E12:00 and P0E12:09, GO to P3 For DTC P0E16:00 and P0E16:09, GO to P6 No : GO to «SYMPTOM CHART»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control__symptom-chart) .
  2. P2 CHECK THE HEATER ELEMENT RELAYS POWER CIRCUIT FOR AN OPEN Disconnect Heater Element 1 and 2 Relay. Disconnect Heater Element 3 Relay. Measure the voltage between. Positive Lead Measurement/Action Negative Lead Relay 1-2 Pin 1 Ground Relay 3 Pin 1 Ground Is voltage greater than 10.5 volts? Yes : GO to P3 No : REPAIR the circuit.
  3. P3 CHECK THE HEATER ELEMENT RELAY 1 AND 2 CONTROL CIRCUIT FOR AN OPEN Disconnect Powertrain Control Module (PCM) C175B . Measure the resistance between. Positive Lead Measurement/Action Negative Lead Relay Pin 2 C175B-15 Is the resistance less than 5.0 ohms? Yes : GO to P4 No : REPAIR the circuit.
  4. P4 CHECK THE HEATER ELEMENT RELAY 1 AND 2 CONTROL CIRCUIT FOR A SHORT TO GROUND Measure the resistance between. Positive Lead Measurement/Action Negative Lead Relay Pin 2 ohms Ground Is the resistance greater than 10, 000 ohms? Yes : GO to P5 No : REPAIR the circuit.
  5. P5 CHECK THE HEATER ELEMENT RELAY 1 AND 2 CONTROL CIRCUIT FOR A SHORT TO POWER Ignition ON. Measure the voltage between. Positive Lead Measurement/Action Negative Lead Relay 1-2 Pin 2 Ground Is any voltage present? Yes : REPAIR the circuit. No : INSTALL a new heater element 1 and 2 relay. If the DTC returns, INSTALL a new PCM . REFER to: «POWERTRAIN CONTROL MODULE (PCM)»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control) .
  6. P6 CHECK THE HEATER ELEMENT RELAY 3 CONTROL CIRCUIT FOR AN OPEN Disconnect Powertrain Control Module (PCM) C175A . Measure the resistance between. Positive Lead Measurement/Action Negative Lead Relay 3 Pin 2 C175A-10 Is the resistance less than 5.0 ohms? Yes : GO to P7 No : REPAIR the circuit.
  7. P7 CHECK THE HEATER ELEMENT RELAY 3 CONTROL CIRCUIT FOR A SHORT TO GROUND Measure the resistance between. Positive Lead Measurement/Action Negative Lead Relay 3 Pin 2 Ground Is the resistance greater than 10, 000 ohms? Yes : GO to P8 No : REPAIR the circuit.
  8. P8 CHECK THE HEATER ELEMENT RELAY 3 CONTROL CIRCUIT FOR A SHORT TO POWER Ignition ON. Measure the voltage between. Positive Lead Measurement/Action Negative Lead Relay 3 Pin 2 Ground Is any voltage present? Yes : REPAIR the circuit. No : INSTALL a new heater element 3 relay. If the DTC returns, INSTALL a new PCM . REFER to: «POWERTRAIN CONTROL MODULE (PCM)»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control) .

P2226:12, P2226:14

Diagnostics in this service information assume a certain skill level and knowledge of Ford-specific diagnostic practices.

REFER to: DIAGNOSTIC METHODS .

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

The PCM provides a 5-volt reference voltage to the BARO sensor. The BARO sensor sends a voltage signal to the PCM which indicate atmospheric pressure. The barometric sensor is used in conjunction with the TPMS. The PCM sets a DTC if voltage on this input is above or below a calibrated threshold.

  1. Connectors damaged or pushed-out terminals, corrosion, loose wires and missing or damaged seals
  2. BARO sensor
  3. PCM
DTCDescriptionFault Trigger Conditions
P2226:12Barometric Pressure Sensor "A" CircuitThe PCM detects greater than 4.9 volts on the BARO sensor input.
P2226:14Barometric Pressure Sensor "A" CircuitThe PCM detects less than 0.3 volts on the BARO sensor input.

DTC FAULT TRIGGER CONDITIONS

PINPOINT TEST Q: P2226:12, P2226:14

  1. Q1 RETRIEVE AND RECORD DTCS Connect the diagnostic tool. Using the scan tool, retrieve all Diagnostic Trouble Codes (DTCs). Is DTC P2226:12 or P2226:14 set? Yes : For DTC P2226:12, GO to Q2 For DTC P2226:14, GO to Q4 No : If TPMS Diagnostic Trouble Codes (DTCs) are set, REFER to: «TIRE PRESSURE MONITORING SYSTEM (TPMS)»(/ford/focus-st/iii-2012-2015/remont/wheel-tire-system/#tire-pressure-monitoring-system-electric) .
  2. Q2 CHECK THE BAROMETRIC PRESSURE SENSOR SIGNAL INPUT CIRCUIT FOR A SHORT TO POWER Disconnect Barometric Pressure (BARO) Sensor C1299 . Ignition ON. Measure the voltage between. Positive Lead Measurement/Action Negative Lead C1299-3 Ground Is the voltage greater than 4.9 volts? Yes : REPAIR the circuit. No : GO to Q3
  3. Q3 CHECK THE BAROMETRIC PRESSURE SENSOR SIGNAL RETURN CIRCUIT FOR AN OPEN Ignition OFF. Disconnect Powertrain Control Module (PCM) C175B . Measure the resistance between. Positive Lead Measurement/Action Negative Lead C175B-21 C1299-2 Is the resistance less than 5.0 ohms? Yes : INSTALL a new BARO sensor. No : REPAIR the circuit.
  4. Q4 CHECK THE BAROMETRIC PRESSURE SENSOR SIGNAL INPUT CIRCUIT FOR A SHORT TO GROUND Disconnect Powertrain Control Module (PCM) C175B . Disconnect Barometric Pressure Sensor C1299 . Measure the resistance between. Positive Lead Measurement/Action Negative Lead C175B-4 Ground Is the resistance greater than 10, 000 ohms? Yes : GO to Q5 No : REPAIR the circuit.
  5. Q5 CHECK THE BAROMETRIC PRESSURE SENSOR SIGNAL INPUT CIRCUIT FOR AN OPEN Measure the resistance between. Positive Lead Measurement/Action Negative Lead C175B-4 C1299-3 Is the resistance less than 5.0 ohms? Yes : INSTALL a new BARO sensor. No : INSPECT and REPAIR the circuit. If an open circuit is not found, INSTALL a new PCM . REFER to: «POWERTRAIN CONTROL MODULE (PCM)»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control) .

P2531:00, P2532:01, P2535:00

Diagnostics in this service information assume a certain skill level and knowledge of Ford-specific diagnostic practices.

REFER to: DIAGNOSTIC METHODS .

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

The PCM sends a signal to the BCM which commands the ignition relay on. The PCM monitors the ignition relay and crank detect inputs for voltage. The PCM sets a DTC if voltage on these inputs are above or below a calibrated threshold.

  1. Connectors damaged or pushed-out terminals, corrosion, loose wires and missing or damaged seals
  2. Start/Stop switch
  3. Ignition relay
  4. PCM power relay
  5. BJB fuse 38 (15A)
  6. BCM
  7. BCM fuse 78 (5A)
  8. PCM
DTCDescriptionFault Trigger Conditions
P2531:00Ignition Switch Run Position Circuit LowThe PCM commanded the PCM power relay on but did not detect voltage on the ignition relay input.
P2532:01Ignition Switch Run Position Circuit HighThe PCM commanded the PCM power relay off but voltage is detected on the ignition relay input.
P2535:00Ignition Switch Run/Start Position Circuit HighThe Start/Stop button was pressed On then released and the PCM did not detect voltage at the crank detect input.

DTC FAULT TRIGGER CONDITIONS

PINPOINT TEST R: P2531:00, P2532:01, P2535:00

  1. R1 RETRIEVE AND RECORD ALL DTCS Connect the diagnostic tool. Using the scan tool, retrieve all Diagnostic Trouble Codes (DTCs). Is DTC P2531:00, P2532:01 and/or P2535:00 set? Yes : For DTC P2531:00 and/or P2532:01, GO to R2 For DTC P2535:00, GO to R5 No : GO to «SYMPTOM CHART»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control__symptom-chart) .
  2. R2 CHECK THE IGNITION RELAY RUN POSITION INPUT CIRCUIT FOR AN OPEN Disconnect Powertrain Control Module (PCM) C175A . Disconnect Battery Junction Box (BJB) C1035C . Measure the resistance between. Positive Lead Measurement/Action Negative Lead C175A-56 C1035C-20 Is the resistance less than 5.0 ohms? Yes : GO to R3 No : REPAIR the circuit.
  3. R3 CHECK THE IGNITION RELAY RUN POSITION INPUT CIRCUIT FOR A SHORT TO GROUND Measure the resistance between. Positive Lead Measurement/Action Negative Lead C175A-56 Ground Is the resistance greater than 10, 000 ohms? Yes : GO to R4 No : REPAIR the circuit.
  4. R4 CHECK THE IGNITION RELAY RUN POSITION INPUT CIRCUIT FOR A SHORT TO POWER Ignition ON. Measure the voltage between. Positive Lead Measurement/Action Negative Lead C175A-56 Ground Is any voltage present? Yes : REPAIR the circuit. No : INSTALL a new PCM . REFER to: «POWERTRAIN CONTROL MODULE (PCM)»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control) .
  5. R5 CHECK THE CRANK DETECT CIRCUIT FOR AN OPEN Disconnect Powertrain Control Module (PCM) C175A . Disconnect Start/Stop Switch C2195 . Measure the resistance between. Positive Lead Measurement/Action Negative Lead C175A-27 C2195-3 Is the resistance less than 5.0 ohms? Yes : GO to R6 No : REPAIR the circuit.
  6. R6 CHECK THE CRANK DETECT CIRCUIT FOR A SHORT TO GROUND Measure the resistance between. Positive Lead Measurement/Action Negative Lead C175A-27 Ground Is the resistance greater than 10, 000 ohms? Yes : INSTALL a new PCM . REFER to: «POWERTRAIN CONTROL MODULE (PCM)»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control) . No : REPAIR the circuit.

P06E4:12

Diagnostics in this service information assume a certain skill level and knowledge of Ford-specific diagnostic practices.

REFER to: DIAGNOSTIC METHODS .

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

The PCM receives a voltage signal from the BCM which alerts the PCM to wake up or shut down. The PCM sets a DTC if voltage on these inputs are above or below a calibrated threshold.

  1. Connectors damaged or pushed-out terminals, corrosion, loose wires and missing or damaged seals
  2. BCM
  3. PCM
DTCDescriptionFault Trigger Conditions
P06E4:12Control Module Wake-up Circuit PerformanceAll vehicle wake-up systems are low for a calibrated amount of time but the PCM wake-up system remains high.

DTC FAULT TRIGGER CONDITIONS

PINPOINT TEST S: P06E4:12

  1. S1 RETRIEVE AND RECORD ALL DTCS Connect the diagnostic tool. Using the scan tool, retrieve all Diagnostic Trouble Codes (DTCs). Is DTC P06E4:12 set? Yes : No : GO to «SYMPTOM CHART»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control__symptom-chart) .
  2. S2 CHECK POWERTRAIN CONTROL MODULE (PCM) WAKE-UP CIRCUIT FOR A SHORT TO POWER Disconnect Body Control Module (BCM) C2280A . Disconnect Powertrain Control Module (PCM) C175A . Ignition ON. Measure the voltage between. Positive Lead Measurement/Action Negative Lead C175A-6 Ground Is voltage greater than 3.55 volts? Yes : REPAIR the circuit. No : INSTALL a new PCM . REFER to: «POWERTRAIN CONTROL MODULE (PCM)»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control) .

P2682:00, P2683:00, P26A3:00, P26A3:12, P26A3:14

Diagnostics in this service information assume a certain skill level and knowledge of Ford-specific diagnostic practices.

REFER to: DIAGNOSTIC METHODS .

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

The engine coolant bypass valve is a 12-volt operated valve which regulates coolant to the electric motor. The PCM provides a PWM signal to the pump and monitors this signal by monitoring a diagnostic circuit input. The PCM sets a DTC if voltage on these inputs are above or below a calibrated threshold.

  1. Connectors damaged or pushed-out terminals, corrosion, loose wires and missing or damaged seals
  2. BJB fuse 32 (10A)
  3. Engine coolant bypass valve
  4. PCM
DTCDescriptionFault Trigger Conditions
P2682:00Engine Coolant Bypass Valve "A" Control Circuit LowThe PCM commanded PWM output greater than 11% but the feedback input detects 0 volts.
P2683:00Engine Coolant Bypass Valve "A" Control Circuit HighThe PCM commanded PWM output less than 70% but the feedback input detects 12-volts. Or
P26A3:00Engine Coolant Bypass Valve "A" Range/PerformanceThe PCM commanded PWM output less than 70% but the feedback input detects 12-volts. Or the PCM commanded PWM output greater than 11% but the feedback input detects 0-volts.
P26A3:12Engine Coolant Bypass Valve "A" Range/Performance Short To BatteryThe PCM PWM output is greater than 11% but the feedback input detects at or near 100%.
P26A3:14Engine Coolant Bypass Valve "A" Range/Performance Short To ground or OpenThe PCM commanded PWM output less than 70% but the feedback input detects 0-volts.

DTC FAULT TRIGGER CONDITIONS

PINPOINT TEST T: P2682:00, P2683:00, P26A3:00, P26A3:12, P26A3:14

  1. T1 RETRIEVE AND RECORD ALL DTCS Connect the diagnostic tool. Using the scan tool, retrieve all Diagnostic Trouble Codes (DTCs). Is DTC P2682:00, P2683:00, P26A3:00, P26A3:12 and/or P26A3:14 set? Yes : For DTC P2682:00 and/or P26A3:00, GO to T2 For DTC P2683:00 and/or P26A3:00, GO to T5 For DTC P26A3:12, GO to T6 No : GO to «SYMPTOM CHART»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control__symptom-chart) .
  2. T2 CHECK THE ENGINE COOLANT BYPASS VALVE A POWER CIRCUIT FOR AN OPEN Disconnect Engine Coolant Bypass Valve C1809 . Ignition ON. Measure the voltage between. Positive Lead Measurement/Action Negative Lead C1809-A Ground Is voltage greater than 10.5 volts? Yes : GO to T3 No : REPAIR the circuit.
  3. T3 CHECK THE ENGINE COOLANT BYPASS VALVE A GROUND CIRCUIT FOR AN OPEN Measure the voltage between. Positive Lead Measurement/Action Negative Lead C1809-A C1809-C Is voltage greater than 10.5 volts? Yes : GO to T4 No : REPAIR the circuit.
  4. T4 CHECK THE ENGINE COOLANT BYPASS VALVE A PULSE WIDTH MODULATION (PWM) CIRCUIT FOR A SHORT TO GROUND Ignition OFF. Disconnect Powertrain Control Module (PCM) C175B . Measure the resistance between. Positive Lead Measurement/Action Negative Lead C175B-22 Ground Is the resistance greater than 10, 000 ohms? Yes : INSTALL a new PCM . REFER to: «POWERTRAIN CONTROL MODULE (PCM)»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control) . No : REPAIR the circuit.
  5. T5 CHECK THE ENGINE COOLANT BYPASS VALVE A PULSE WIDTH MODULATION (PWM) CIRCUIT FOR A SHORT TO POWER Disconnect Powertrain Control Module (PCM) C175B . Disconnect Engine Coolant Bypass Valve C1809 . Ignition ON. Measure the voltage between. Positive Lead Measurement/Action Negative Lead C175B-22 Ground Is any voltage present? Yes : REPAIR the circuit. No : INSTALL a new PCM . REFER to: «POWERTRAIN CONTROL MODULE (PCM)»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control) .
  6. T6 CHECK THE ENGINE COOLANT BYPASS VALVE A FEEDBACK CIRCUIT FOR A SHORT TO POWER Disconnect Powertrain Control Module (PCM) C175B . Disconnect Engine Coolant Bypass Valve C1809 . Ignition ON. Measure the voltage between. Positive Lead Measurement/Action Negative Lead C175B-56 Ground Is any voltage present? Yes : REPAIR the circuit. No : INSTALL a new PCM . REFER to: «POWERTRAIN CONTROL MODULE (PCM)»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control) .

C113A:12

Diagnostics in this service information assume a certain skill level and knowledge of Ford-specific diagnostic practices.

REFER to: DIAGNOSTIC METHODS .

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

The PCM receives a wake-up signal from the BECM. The PCM sets a DTC if voltage on this input is above a calibrated threshold.

  1. Connectors damaged or pushed-out terminals, corrosion, loose wires and missing or damaged seals
  2. BECM
  3. PCM
DTCDescriptionFault Trigger Conditions
C113A:12Wakeup ControlThe vehicle is not in park and the PCM detects a voltage input greater than 3.55 volts.

DTC FAULT TRIGGER CONDITIONS

PINPOINT TEST U: C113A:12

  1. U1 RETRIEVE AND RECORD ALL DTCS Using the scan tool, retrieve all Diagnostic Trouble Codes (DTCs). Is DTC C113A:12 set? Yes : GO to U2 No : GO to «SYMPTOM CHART»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control__symptom-chart)
  2. U2 CHECK THE POWERTRAIN CONTROL MODULE (PCM) WAKE UP CIRCUIT FOR A SHORT TO POWER Connect the diagnostic tool. Disconnect Powertrain Control Module (PCM) C175A . Disconnect Battery Energy Control Module (BECM) C4805E . Ignition ON. Measure the voltage between. Positive Lead Measurement/Action Negative Lead C175A-67 Ground Is the voltage greater than 3.55 volts? Yes : REPAIR the circuit. If a short to power is not found, REPLACE the high voltage lower and upper battery. REFER to: «HIGH VOLTAGE LOWER BATTERY»(/ford/focus-st/iii-2012-2015/remont/body-electrical/#high-voltage-battery-mounting-cables-electric__high-voltage-lower-battery) and REFER to: «HIGH VOLTAGE UPPER BATTERY»(/ford/focus-st/iii-2012-2015/remont/body-electrical/#high-voltage-battery-mounting-cables-electric__high-voltage-upper-battery) . No : INSTALL a new PCM . REFER to: «POWERTRAIN CONTROL MODULE (PCM)»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control) .

B10E8:00, B139F:12, B139F:14

Diagnostics in this service information assume a certain skill level and knowledge of Ford-specific diagnostic practices.

REFER to: DIAGNOSTIC METHODS .

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

The PCM controls the low side of the PCM contactor relay. When the PCM contactor relay is energized, battery voltage is applied to the various components including the PCM contactor sense input. The PCM sets a DTC if voltage on these inputs are above or below a calibrated threshold.

  1. Connectors damaged or pushed-out terminals, corrosion, loose wires and missing or damaged seals
  2. Battery and charging system
  3. BJB fuse 23 (5A)
  4. BJB fuse 34 (15A)
  5. BJB fuse 12 (40A)
  6. BJB
  7. PCM
DTCDescriptionFault Trigger Conditions
B10E8:00Secondary Battery Relay "A"The contactor relay was commanded on or off and the PCM detect a voltage mismatch at the contactor disable input.
B139F:12Main Battery Relay Short To BatteryThe contactor relay was commanded off, but the PCM detected greater than 4.9 volts on the contactor sense input.
B139F:14Main Battery Relay Short To Ground or OpenThe contactor relay was commanded on, but the PCM detected 0-volts on the contactor sense input.

DTC FAULT TRIGGER CONDITIONS

PINPOINT TEST V: B10E8:00, B139F:12, B139F:14

  1. V1 RETRIEVE AND RECORD ALL DTCS Using the scan tool, retrieve all Diagnostic Trouble Codes (DTCs). Is DTC B139F:12, B139F:14, B10E8:00 and/or P0AA0:01 set? Yes : For DTC B139F:12, GO to V2 For DTC B139F:14, GO to V3 For DTC B10E8:00, GO to V5 No : GO to «SYMPTOM CHARTS»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control__symptom-chart) .
  2. V2 CHECK THE CONTACTOR RELAY SENSE CIRCUIT FOR A SHORT TO POWER Disconnect Contactor Relay. Disconnect Powertrain Control Module (PCM) C175A . Ignition ON. Measure the voltage between. Positive Lead Measurement/Action Negative Lead C175A-32 Ground Is voltage greater than 4.9 volts? Yes : REPAIR the circuit. No : INSTALL a new contactor relay. CLEAR the DTC , if the DTC returns, INSTALL a new PCM .
  3. V3 CHECK THE CONTACTOR RELAY SENSE CIRCUIT FOR AN OPEN Disconnect Contactor Relay. Disconnect Powertrain Control Module (PCM) C175A . Measure the resistance between. Positive Lead Measurement/Action Negative Lead C175A-32 Relay Pin 4 Is the resistance less than 5.0 ohms? Yes : GO to V4 No : REPAIR the circuit.
  4. V4 CHECK THE CONTACTOR RELAY SENSE CIRCUIT FOR A SHORT TO GROUND Measure the resistance between. Positive Lead Measurement/Action Negative Lead C175A-32 Ground Is the resistance greater than 10, 000 ohms? Yes : INSTALL a new PCM . REFER to: «POWERTRAIN CONTROL MODULE (PCM)»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control) . No : REPAIR the circuit.
  5. V5 CHECK THE CONTACTOR RELAY POWER CIRCUIT FOR AN OPEN Disconnect Contactor Relay. Measure the voltage between. Positive Lead Measurement/Action Negative Lead Relay Pin 1 Ground Is the voltage greater than 10.5 volts? Yes : GO to V6 No : REPAIR the circuit.
  6. V6 CHECK THE CONTACTOR RELAY DISABLE CIRCUIT FOR AN OPEN Disconnect Powertrain Control Module (PCM) C175A . Measure the resistance between. Positive Lead Measurement/Action Negative Lead C175A-35 Relay Pin 2 Is the resistance less than 5.0 ohms? Yes : GO to V7 No : REPAIR the circuit.
  7. V7 CHECK THE CONTACTOR RELAY DISABLE CIRCUIT FOR A SHORT TO GROUND Measure the resistance between. Positive Lead Measurement/Action Negative Lead C175A-35 Ground Is the resistance greater than 10, 000 ohms? Yes : GO to V8 No : REPAIR the circuit.
  8. V8 CHECK THE CONTACTOR RELAY DISABLE CIRCUIT FOR A SHORT TO POWER Ignition ON. Measure the voltage between. Positive Lead Measurement/Action Negative Lead C175A-36 Ground Is any voltage present? Yes : REPAIR the circuit. No : INSTALL a new contactor relay. If the DTC returns, INSTALL a new PCM . REFER to: «POWERTRAIN CONTROL MODULE (PCM)»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control) .

P0CE9:00, P0CEA:00, P0CEA:12, P0CEA:14

Diagnostics in this service information assume a certain skill level and knowledge of Ford-specific diagnostic practices.

REFER to: DIAGNOSTIC METHODS .

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

The cabin heater coolant pump is a 12-volt pump which can operate at variable speeds. The PCM provides a PWM signal to the pump and monitors this signal by monitoring a diagnostic circuit input. The cabin heater coolant pump provides coolant to the battery pack to keep the battery warm by providing warm coolant and to keep the battery cool as it begins to generate heat.

  1. Connectors damaged or pushed-out terminals, corrosion, loose wires and missing or damaged seals
  2. Cabin heater coolant pump
  3. BJB fuse 36 (20A)
  4. PCM

Note. If electric motor coolant pump and battery pack coolant pump Diagnostic Trouble Codes (DTCs) are set, inspect the BJB fuse 36 (20A) for an open.

DTCDescriptionFault Trigger Conditions
P0CE9:00Hybrid/EV Electronics Coolant Pump Control Circuit/OpenThe PCM detects a short to power, ground or an open on the PWM output.
P0CEA:00Hybrid/EV Electronics Coolant Pump Control PerformanceThe PCM detects a short to power, ground or an open on the PWM output.
P0CEA:12Hybrid/EV Electronics Coolant Pump Control Performance Short to BatteryThe PCM detects a 100% duty cycle on the diagnostic input.
P0CEA:14Hybrid/EV Electronics Coolant Pump Control Performance Short to Ground or OpenThe PCM detects a 0% duty cycle on the diagnostic input.

DTC FAULT TRIGGER CONDITIONS

PINPOINT TEST W: P0CE9:00, P0CEA:00, P0CEA:12, P0CEA:14

  1. W1 RETRIEVE AND RECORD ALL DTCS Connect the diagnostic tool. Using the scan tool, retrieve all Diagnostic Trouble Codes (DTCs). Is DTC P0CE9:00, P0CEA:00, P0CEA:12 and/or P0CEA:14 set? Yes : For Diagnostic Trouble Codes (DTCs) P0CE9:00 and P0CEA:00, GO to W2 For DTC P0CEA:12, GO to W7 For DTC P0CEA:14, GO to W8 No : GO to «SYMPTOM CHART»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control__symptom-chart) .
  2. W2 CHECK THE CABIN HEATER COOLANT PUMP POWER CIRCUIT Ignition OFF. Disconnect Cabin Heater Coolant Pump C1813 . Ignition ON. Measure the voltage between. Positive Lead Measurement/Action Negative Lead C1813-1 Ground C1813-5 Ground Is voltage greater than 10.5 volts? Yes : GO to W3 No : REPAIR the circuit.
  3. W3 CHECK THE CABIN HEATER COOLANT PUMP GROUND CIRCUIT Measure the voltage between. Positive Lead Measurement/Action Negative Lead C1813-1 C1813-4 Is voltage greater than 10.5 volts? Yes : GO to W4 No : REPAIR the circuit.
  4. W4 CHECK THE CABIN HEATER COOLANT PUMP PULSE WIDTH MODULATION (PWM) CIRCUIT FOR AN OPEN Ignition OFF. Disconnect Powertrain Control Module (PCM) C175B . Measure the resistance between. Positive Lead Measurement/Action Negative Lead C175B-11 C1813-3 Is the resistance less than 5.0 ohms? Yes : GO to W5 No : REPAIR the circuit.
  5. W5 CHECK THE CABIN HEATER COOLANT PUMP PULSE WIDTH MODULATION (PWM) CIRCUIT FOR A SHORT TO GROUND Measure the resistance between. Positive Lead Measurement/Action Negative Lead C175B-11 Ground Is the resistance greater than 10, 000 ohms? Yes : GO to W6 No : REPAIR the circuit.
  6. W6 CHECK THE CABIN HEATER COOLANT PUMP PULSE WIDTH MODULATION (PWM) CIRCUIT FOR A SHORT TO POWER Ignition ON. Measure the voltage between. Positive Lead Measurement/Action Negative Lead C175B-11 Ground Is the voltage greater than 0.1 volt? Yes : REPAIR the circuit. No : INSTALL a new cabin heater coolant pump. REFER to: «CABIN HEATER COOLANT PUMP»(/ford/focus-st/iii-2012-2015/remont/cooling-system-mechanical/#electric-powertrain-cooling__cabin-heater-coolant-pump) .
  7. W7 CHECK THE CABIN HEATER COOLANT PUMP DIAGNOSTIC CIRCUIT FOR A SHORT TO POWER Ignition OFF. Disconnect Powertrain Control Module (PCM) C175B . Disconnect Cabin Heater Coolant Pump C1813 . Ignition ON. Measure the voltage between. Positive Lead Measurement/Action Negative Lead C175B-53 Ground Is the voltage greater than 0.1 volt? Yes : REPAIR the circuit. No : INSTALL a new PCM . REFER to: «POWERTRAIN CONTROL MODULE (PCM)»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control) .
  8. W8 CHECK THE CABIN HEATER COOLANT PUMP DIAGNOSTIC CIRCUIT FOR AN OPEN Ignition OFF. Disconnect Powertrain Control Module (PCM) C175B . Disconnect Cabin Heater Coolant Pump C1813 . Measure the resistance between. Positive Lead Measurement/Action Negative Lead C175B-53 C1813-2 Is the resistance less than 5.0 ohms? Yes : GO to W9 No : REPAIR the circuit.
  9. W9 CHECK THE CABIN HEATER COOLANT PUMP DIAGNOSTIC CIRCUIT FOR A SHORT TO GROUND Measure the resistance between. Positive Lead Measurement/Action Negative Lead C175B-53 Ground Is the resistance greater than 10, 000? Yes : INSTALL a new PCM . REFER to: «POWERTRAIN CONTROL MODULE (PCM)»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control) . No : REPAIR the circuit.

P1543:11, P1543:15, P1543:25, P1543:92

Diagnostics in this service information assume a certain skill level and knowledge of Ford-specific diagnostic practices.

REFER to: DIAGNOSTIC METHODS .

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

The PCM sends a 12-volts to the PTC engine coolant heater. The PCM monitors the heater enable and heater PWM input voltage. The PCM sets a DTC if voltage on these inputs are above or below a calibrated threshold.

  1. Connectors damaged or pushed-out terminals, corrosion, loose wires and missing or damaged seals
  2. Engine coolant heater
  3. PCM
DTCDescriptionFault Trigger Conditions
P1543:11Engine Coolant Heater "A" Control Circuit Short To GroundThe PCM detects 0-volts on the PTC cabin coolant heater enable input.
P1543:15Engine Coolant Heater "A" Control Circuit Short To Battery or OpenThe PCM detects high voltage on the PTC cabin coolant heater enable input.
P1543:25Engine Coolant Heater "A" Control Circuit Signal Shape/Waveform FailureThe PCM detects a voltage mismatch on the PTC cabin coolant heater PWM input.
P1543:92Engine Coolant Heater "A" Control Circuit Performance or Incorrect OperationThe PCM detects a PTC cabin coolant heater malfunction. This DTC sets only if Diagnostic Trouble Codes (DTCs) P1543:11, P1543:15 and P1543:25 are not set.

DTC FAULT TRIGGER CONDITIONS

PINPOINT TEST X: P1543:11, P1543:15, P1543:25, P1543:92

  1. X1 RETRIEVE AND RECORD ALL DTCS Connect the diagnostic tool. Using the scan tool, retrieve all Diagnostic Trouble Codes (DTCs). Is DTC P1543:11, P1543:15, P1543:25, and/or P1543:92 set? Yes : For DTC P1543:11, GO to X2 For DTC P1543:15, GO to X3 For DTC P1543:25, GO to X5 For DTC P1543:92, GO to X8 No : GO to «SYMPTOM CHART»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control__symptom-chart) .
  2. X2 CHECK THE ENGINE COOLANT HEATER HIGH SIDE DRIVER ENABLE CIRCUIT FOR A SHORT TO GROUND Disconnect Powertrain Control Module (PCM) C175A . Disconnect Engine Coolant Heater C1815 . Measure the resistance between. Positive Lead Measurement/Action Negative Lead C175A-16 Ground Is the resistance greater than 10, 000 ohms? Yes : INSTALL a new PCM . REFER to: «POWERTRAIN CONTROL MODULE (PCM)»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control) . No : REPAIR the circuit.
  3. X3 CHECK THE ENGINE COOLANT HEATER HIGH SIDE DRIVER ENABLE CIRCUIT FOR AN OPEN Disconnect Powertrain Control Module (PCM) C175A . Disconnect Engine Coolant Heater C1815 . Measure the resistance between. Positive Lead Measurement/Action Negative Lead C175A-16 C1815-C Is the resistance less than 5.0 ohms? Yes : GO to X4 No : REPAIR the circuit.
  4. X4 CHECK THE ENGINE COOLANT HEATER HIGH SIDE DRIVER ENABLE CIRCUIT FOR A SHORT TO POWER Ignition ON. Measure the voltage between. Positive Lead Measurement/Action Negative Lead C175A-16 Ground Is any voltage present? Yes : REPAIR the circuit. No : INSTALL a new PCM . REFER to: «POWERTRAIN CONTROL MODULE (PCM)»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control) .
  5. X5 CHECK THE ENGINE COOLANT HEATER PULSE WIDTH MODULATION (PWM) CIRCUIT FOR AN OPEN Disconnect Powertrain Control Module (PCM) C175A . Disconnect Engine Coolant Heater C1815 . Measure the resistance between. Positive Lead Measurement/Action Negative Lead C175B-14 C1815-B Is the resistance less than 5.0 ohms? Yes : GO to X6 No : REPAIR the circuit.
  6. X6 CHECK THE ENGINE COOLANT HEATER PULSE WIDTH MODULATION (PWM) CIRCUIT FOR A SHORT TO GROUND Measure the resistance between. Positive Lead Measurement/Action Negative Lead C175B-14 Ground Is the resistance greater than 10, 000 ohms? Yes : GO to X7 No : REPAIR the circuit.
  7. X7 CHECK THE ENGINE COOLANT HEATER PULSE WIDTH MODULATION (PWM) CIRCUIT FOR A SHORT TO POWER Ignition ON. Measure the voltage between. Positive Lead Measurement/Action Negative Lead C175B-14 Ground Is any voltage present? Yes : REPAIR the circuit. No : INSTALL a new PCM . REFER to: «POWERTRAIN CONTROL MODULE (PCM)»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control) .
  8. X8 CHECK THE HIGH VOLTAGE TCM (40A) HIGH-VOLTAGE LOW-CURRENT FUSE WARNING: To prevent the risk of high-voltage shock, always follow precisely all warnings and service instructions, including instructions to depower the system. The high-voltage hybrid system utilizes approximately 300 volts DC, provided through high-voltage cables to its components and modules. The high-voltage cables and wiring are identified by orange harness tape or orange wire covering. All high-voltage components are marked with high-voltage warning labels with a high-voltage symbol. Failure to follow these instructions may result in serious personal injury or death. Ignition OFF. Depower the high voltage battery. REFER to: «HIGH VOLTAGE BATTERY DISCONNECT AND CONNECT»(/ford/focus-st/iii-2012-2015/remont/body-electrical/#high-voltage-battery-mounting-cables-electric) . Disconnect High Voltage TCM C1822F . Disconnect High Voltage TCM C1822B . Measure: Positive Lead Measurement/Action Negative Lead C1822B-2 (Component side) C1822F-A (Component side) Is the resistance less than 3 ohms? Yes : INSTALL a new engine coolant heater. REFER to: «CABIN COOLANT HEATER»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric) . No : Install a new High Voltage TCM (40A) high-voltage low-current fuse. Operate the in-cabin heater for 5 minutes and recheck the PCM for DTCs. If DTC is reset in memory, INSTALL a new PTC heater. REFER to: «CABIN COOLANT HEATER»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric) . Verify that the High Voltage TCM (40A) high-voltage low-current fuse is still OK.

B1D22:11, B1D22:15

Diagnostics in this service information assume a certain skill level and knowledge of Ford-specific diagnostic practices.

REFER to: DIAGNOSTIC METHODS .

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

The PTC cabin coolant heater temperature sensor is a temperature-sensitive device called a thermistor. The resistance value of the PTC cabin coolant heater temperature sensor will vary with temperature change. The PCM provides a signal voltage to the PTC cabin coolant heater temperature sensor. The PCM monitors the voltage across the PTC cabin coolant heater temperature sensor to determine the temperature of the cabin coolant. The PCM sets a DTC if voltage on this input is above or below a calibrated threshold.

  1. Connectors damaged or pushed-out terminals, corrosion, loose wires and missing or damaged seals
  2. PTC cabin coolant temperature sensor
  3. PCM
DTCDescriptionFault Trigger Conditions
B1D22:11Coolant Temperature Sensor Circuit Short To GroundThe PCM detects 0-volts on the PTC cabin coolant signal input.
B1D22:15Coolant Temperature Sensor Circuit Short To Battery or OpenThe PCM detects greater than 4.9 volts on the PTC cabin coolant signal input.

DTC FAULT TRIGGER CONDITIONS

PINPOINT TEST Y: B1D22:11, B1D22:15

  1. Y1 READ AND RECORD ALL DTCS Using the scan tool, retrieve all Diagnostic Trouble Codes (DTCs). Is DTC B1D22:11 and/or B1D22:15 set? Yes : GO to Y2 No : GO to «SYMPTOM CHART»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control__symptom-chart) .
  2. Y2 CHECK THE POSITIVE TEMPERATURE COEFFICIENT (PTC) CABIN COOLANT HEATER TEMPERATURE SENSOR SIGNAL CIRCUIT FOR A SHORT TO GROUND Ignition OFF. Disconnect Cabin Coolant Heater Temperature C1818 . Ignition ON. Locate the cabin coolant heater temperature sensor PID and observe the scan tool. Does the PID display 5.1 volts? Yes : GO to Y3 No : REPAIR the circuit.
  3. Y3 CHECK THE POSITIVE TEMPERATURE COEFFICIENT (PTC) CABIN COOLANT HEATER TEMPERATURE SENSOR SIGNAL CIRCUIT FOR AN OPEN Connect a fuse jumper wire between. Positive Lead Measurement/Action Negative Lead C1818-1 C1818-2 Does the cabin coolant heater temperature sensor PID display 0.0 volts? Yes : GO to Y5 No : GO to Y4
  4. Y4 CHECK THE POSITIVE TEMPERATURE COEFFICIENT (PTC) CABIN COOLANT HEATER TEMPERATURE SENSOR SIGNAL VOLTAGE Measure the voltage between. Positive Lead Measurement/Action Negative Lead C1818-1 Ground Is the voltage between 4.8 and 5.1 volts? Yes : GO to Y5 No : INSPECT and REPAIR the circuit. If an open circuit is not found, INSTALL a new PCM . REFER to: «POWERTRAIN CONTROL MODULE (PCM)»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control) .
  5. Y5 CHECK THE POSITIVE TEMPERATURE COEFFICIENT (PTC) CABIN COOLANT HEATER TEMPERATURE SENSOR RESISTANCE Measure the component side resistance between. Positive Lead Measurement/Action Negative Lead C1818-1 C1818-2 TEMPERATURE °F (°C) Ohms -39.9-4.0°F (-40-20°C) 1, 076K-269K -2.2-30.2°F (-19-1°C) 309K-91K 32.0-68.0°F (-20°C) 104K-35K 69.8-103.9°F (21-40°C) 40K-15K 105.7-157.9°F (41-70°C) 17K-4.9K 159.7-193.9°F (71-90°C) 5.6K-2.5K 195.7-229.8°F (91-110°C) 3.0K-1.4K 231.6-265.8°F (111-130°C) 1.7K-0.8K 267.6-301.8°F (131-150°C) 0.97K-0.56K Does the temperature to resistance specification match? Yes : INSTALL a new PCM . REFER to: «POWERTRAIN CONTROL MODULE (PCM)»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control) . No : INSTALL a new PTC cabin coolant heater temperature sensor. REFER to REFER to: «ELECTRIC MOTOR COOLANT TEMPERATURE SENSOR»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control) .

U0101:00

Diagnostics in this service information assume a certain skill level and knowledge of Ford-specific diagnostic practices.

REFER to: DIAGNOSTIC METHODS .

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

The PCM continuously monitors the CAN for messages from the TCM . This DTC sets when the PCM does not receive the TCM message within the defined amount of time.

  1. Connectors damaged or pushed-out terminals, corrosion, loose wires and missing or damaged seals
  2. Communication error
  3. Low battery condition
  4. Battery recently replaced
  5. BJB fuse 30 (5A)
  6. TCM
  7. PCM
DTCDescriptionFault Trigger Conditions
U0101:00Lost Communication With Transmission Control Module (TCM)After the PCM , TCM wake up the PCM did not detect a response from the TCM .

DTC FAULT TRIGGER CONDITIONS

PINPOINT TEST Z: U0101:00

  1. Z1 RETRIEVE AND RECORD ALL DTCS Connect the diagnostic tool. Using the scan tool, retrieve all Diagnostic Trouble Codes (DTCs). Does the TCM respond to the scan tool? Yes : GO to Z2 No : REFER to: «NO COMMUNICATION BETWEEN THE INTEGRATED DIAGNOSTIC SYSTEM (IDS) AND THE VEHICLE»(/ford/focus-st/iii-2012-2015/remont/communication-devices/#module-communications-network-electric) .
  2. Z2 CHECK FOR NETWORK COMMUNICATION DTCS Using the scan tool, retrieve network Diagnostic Trouble Codes (DTCs). Are any network Diagnostic Trouble Codes (DTCs) set? Yes : REFER to: «COMMUNICATIONS NETWORK»(/ford/focus-st/iii-2012-2015/remont/communication-devices/#module-communications-network-electric) . No : GO to Z3
  3. Z3 CHECK FOR BATTERY VOLTAGE DTCS Using the scan tool, retrieve battery voltage Diagnostic Trouble Codes (DTCs). Are any TCM high or low voltage Diagnostic Trouble Codes (DTCs) set? Yes : REFER to: «TRANSMISSION CONTROL MODULE (TCM)»(/ford/focus-st/iii-2012-2015/remont/automatic-trans/#automatic-transaxle-electric) . No : REFER to: «COMMUNICATIONS NETWORK»(/ford/focus-st/iii-2012-2015/remont/communication-devices/#module-communications-network-electric) .

U0111:00

Diagnostics in this service information assume a certain skill level and knowledge of Ford-specific diagnostic practices.

REFER to: DIAGNOSTIC METHODS .

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

The PCM continuously monitors the CAN for messages from the BECM. This DTC sets when the PCM does not receive the BECM message within the defined amount of time.

  1. Connectors damaged or pushed-out terminals, corrosion, loose wires and missing or damaged seals
  2. Communication error
  3. Low battery condition
  4. Battery recently replaced
  5. RJB fuse 11 (5A)
  6. BECM
  7. PCM
DTCDescriptionFault Trigger Conditions
U0111:00Lost Communication With Battery Energy Control Module AAfter the PCM , Battery Energy Control Module (BECM) wake up the PCM did not detect a response from the Battery Energy Control Module (BECM).

DTC FAULT TRIGGER CONDITIONS

PINPOINT TEST AA: U0111:00

  1. AA1 RETRIEVE AND RECORD ALL DTCS Connect the diagnostic tool. Using the scan tool, retrieve all Diagnostic Trouble Codes (DTCs). Does the BECM respond to the scan tool? Yes : GO to AA2 No : REFER to: «NO COMMUNICATION BETWEEN THE INTEGRATED DIAGNOSTIC SYSTEM (IDS) AND THE VEHICLE»(/ford/focus-st/iii-2012-2015/remont/communication-devices/#module-communications-network-electric) .
  2. AA2 CHECK FOR NETWORK COMMUNICATION DTCS Using the scan tool, retrieve network Diagnostic Trouble Codes (DTCs). Are any network Diagnostic Trouble Codes (DTCs) set? Yes : REFER to: «COMMUNICATIONS NETWORK»(/ford/focus-st/iii-2012-2015/remont/communication-devices/#module-communications-network-electric) . No : GO to AA3
  3. AA3 CHECK FOR BATTERY VOLTAGE DTCS Using the scan tool, retrieve battery voltage Diagnostic Trouble Codes (DTCs). Are any BECM high or low voltage Diagnostic Trouble Codes (DTCs) set? Yes : REFER to: «HIGH VOLTAGE BATTERY, MOUNTING AND CABLES»(/ford/focus-st/iii-2012-2015/remont/body-electrical/#high-voltage-battery-mounting-cables-electric) . No : REFER to: «COMMUNICATIONS NETWORK»(/ford/focus-st/iii-2012-2015/remont/communication-devices/#module-communications-network-electric) .

U0129:00

Diagnostics in this service information assume a certain skill level and knowledge of Ford-specific diagnostic practices.

REFER to: DIAGNOSTIC METHODS .

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

The PCM continuously monitors the CAN for messages from the ABS. This DTC sets when the PCM does not receive the ABS message within the defined amount of time.

  1. Connectors damaged or pushed-out terminals, corrosion, loose wires and missing or damaged seals
  2. Communication error
  3. Low battery condition
  4. Battery recently replaced
  5. BJB fuse 7 (40A)
  6. BJB fuse 8 (30A)
  7. ABS module
  8. PCM
DTCDescriptionFault Trigger Conditions
U0129:00Lost Communication With The Brake System Control ModuleAfter the PCM , ABS wake up the PCM did not detect a response from the ABS.

DTC FAULT TRIGGER CONDITIONS

PINPOINT TEST AB: U0129:00

  1. AB1 RETRIEVE AND RECORD ALL DTCS Connect the diagnostic tool. Using the scan tool, retrieve all Diagnostic Trouble Codes (DTCs). Does the ABS respond to the scan tool? Yes : GO to AB2 No : REFER to: «NO COMMUNICATION BETWEEN THE INTEGRATED DIAGNOSTIC SYSTEM (IDS) AND THE VEHICLE»(/ford/focus-st/iii-2012-2015/remont/communication-devices/#module-communications-network-electric) .
  2. AB2 CHECK FOR NETWORK COMMUNICATION DTCS Using the scan tool, retrieve network Diagnostic Trouble Codes (DTCs). Are any network Diagnostic Trouble Codes (DTCs) set? Yes : REFER to: «COMMUNICATIONS NETWORK»(/ford/focus-st/iii-2012-2015/remont/communication-devices/#module-communications-network-electric) . No : GO to AB3
  3. AB3 CHECK FOR BATTERY VOLTAGE DTCS Using the scan tool, retrieve battery voltage Diagnostic Trouble Codes (DTCs). Are any ABS module high or low voltage Diagnostic Trouble Codes (DTCs) set? Yes : REFER to: «ANTI-LOCK BRAKE SYSTEM (ABS) AND STABILITY CONTROL»(/ford/focus-st/iii-2012-2015/remont/anti-locktraction-control/#anti-lock-brake-system-stability-control-system-electric) . No : REFER to: «COMMUNICATIONS NETWORK»(/ford/focus-st/iii-2012-2015/remont/communication-devices/#module-communications-network-electric)

U0140:00

Diagnostics in this service information assume a certain skill level and knowledge of Ford-specific diagnostic practices.

REFER to: DIAGNOSTIC METHODS .

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

The PCM continuously monitors the CAN for messages from the BCM . This DTC sets when the PCM does not receive the BCM message within the defined amount of time.

  1. Connectors damaged or pushed-out terminals, corrosion, loose wires and missing or damaged seals
  2. Communication error
  3. Low battery condition
  4. Battery recently replaced
  5. BJB fuse 41 (20A)
  6. High current BJB mega fuse 4 (50A)
  7. High current BJB mega fuse 9 (50A)
  8. ABS module
  9. PCM
DTCDescriptionFault Trigger Conditions
U0140:00Lost Communication With The Body Control Module (BCM)After the PCM , BCM wake up the PCM did not detect a response from the BCM .

DTC FAULT TRIGGER CONDITIONS

PINPOINT TEST AC: U0140:00

  1. AC1 RETRIEVE AND RECORD ALL DTCS Connect the diagnostic tool. Using the scan tool, retrieve all Diagnostic Trouble Codes (DTCs). Does the BCM respond to the scan tool? Yes : GO to AC2 No : REFER to: «NO COMMUNICATION BETWEEN THE INTEGRATED DIAGNOSTIC SYSTEM (IDS) AND THE VEHICLE»(/ford/focus-st/iii-2012-2015/remont/communication-devices/#module-communications-network-electric) .
  2. AC2 CHECK FOR NETWORK COMMUNICATION DTCS Using the scan tool, retrieve network Diagnostic Trouble Codes (DTCs). Are any network Diagnostic Trouble Codes (DTCs) set? Yes : REFER to: «COMMUNICATIONS NETWORK»(/ford/focus-st/iii-2012-2015/remont/communication-devices/#module-communications-network-electric) . No : GO to AC3
  3. AC3 CHECK FOR BATTERY VOLTAGE DTCS Using the scan tool, retrieve battery voltage Diagnostic Trouble Codes (DTCs). Are any BCM high or low voltage Diagnostic Trouble Codes (DTCs) set? Yes : REFER to: «BODY CONTROL MODULE (BCM)»(/ford/focus-st/iii-2012-2015/remont/communication-devices/#multifunction-electronic-modules-electric) . No : REFER to: «COMMUNICATIONS NETWORK»(/ford/focus-st/iii-2012-2015/remont/communication-devices/#module-communications-network-electric) .

U0151:00

Diagnostics in this service information assume a certain skill level and knowledge of Ford-specific diagnostic practices.

REFER to: DIAGNOSTIC METHODS .

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

The PCM continuously monitors the CAN for messages from the RCM . This DTC sets when the PCM does not receive the RCM message within the defined amount of time.

  1. Connectors damaged or pushed-out terminals, corrosion, loose wires and missing or damaged seals
  2. Communication error
  3. Low battery condition
  4. Battery recently replaced
  5. BJB fuse 86 (10A)
  6. RCM
  7. PCM
DTCDescriptionFault Trigger Conditions
U0151:00Lost Communication With The Restraints Control Module (RCM)After the PCM , RCM wake up the PCM did not detect a response from the RCM .

DTC FAULT TRIGGER CONDITIONS

PINPOINT TEST AD: U0151:00

  1. AD1 RETRIEVE AND RECORD ALL DTCS Connect the diagnostic tool. Using the scan tool, retrieve all Diagnostic Trouble Codes (DTCs). Does the RCM respond to the scan tool? Yes : GO to AD2 No : REFER to: «NO COMMUNICATION BETWEEN THE INTEGRATED DIAGNOSTIC SYSTEM (IDS) AND THE VEHICLE»(/ford/focus-st/iii-2012-2015/remont/communication-devices/#module-communications-network-electric) .
  2. AD2 CHECK FOR NETWORK COMMUNICATION DTCS Using the scan tool, retrieve network Diagnostic Trouble Codes (DTCs). Are any network Diagnostic Trouble Codes (DTCs) set? Yes : REFER to: «COMMUNICATIONS NETWORK»(/ford/focus-st/iii-2012-2015/remont/communication-devices/#module-communications-network-electric) . No : GO to AD3
  3. AD3 CHECK FOR BATTERY VOLTAGE DTCS Using the scan tool, retrieve battery voltage Diagnostic Trouble Codes (DTCs). Are any RCM high or low voltage Diagnostic Trouble Codes (DTCs) set? Yes : REFER to: «AIRBAG SUPPLEMENTAL RESTRAINT SYSTEM (SRS) - VEHICLES BUILT FROM: 11-JUNE-2012»(/ford/focus-st/iii-2012-2015/remont/airbag/#supplemental-restraint-system-electric) . No : REFER to: «COMMUNICATIONS NETWORK»(/ford/focus-st/iii-2012-2015/remont/communication-devices/#module-communications-network-electric) .

U0155:00

Diagnostics in this service information assume a certain skill level and knowledge of Ford-specific diagnostic practices.

REFER to: DIAGNOSTIC METHODS .

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

The PCM continuously monitors the CAN for messages from the IPC module. This DTC sets when the PCM does not receive the IPC module message within the defined amount of time.

  1. Connectors damaged or pushed-out terminals, corrosion, loose wires and missing or damaged seals
  2. Communication error
  3. Low battery condition
  4. Battery recently replaced
  5. BCM fuse 69 (5A)
  6. IPC module
  7. PCM
DTCDescriptionFault Trigger Conditions
U0155:00Lost Communication With The Instrument Panel Cluster (IPC) ModuleAfter the PCM , IPC module wake up the PCM did not detect a response from the IPC module.

DTC FAULT TRIGGER CONDITIONS

PINPOINT TEST AE: U0155:00

  1. AE1 RETRIEVE AND RECORD ALL DTCS Connect the diagnostic tool. Using the scan tool, retrieve all Diagnostic Trouble Codes (DTCs). Does the IPC module respond to the scan tool? Yes : GO to AE2 No : REFER to: «NO COMMUNICATION BETWEEN THE INTEGRATED DIAGNOSTIC SYSTEM (IDS) AND THE VEHICLE»(/ford/focus-st/iii-2012-2015/remont/communication-devices/#module-communications-network-electric) .
  2. AE2 CHECK FOR NETWORK COMMUNICATION DTCS Using the scan tool, retrieve network Diagnostic Trouble Codes (DTCs). Are any network Diagnostic Trouble Codes (DTCs) set? Yes : REFER to: «COMMUNICATIONS NETWORK»(/ford/focus-st/iii-2012-2015/remont/communication-devices/#module-communications-network-electric) . No : GO to AE3
  3. AE3 CHECK FOR BATTERY VOLTAGE DTCS Using the scan tool, retrieve battery voltage Diagnostic Trouble Codes (DTCs). Are any IPC module high or low voltage Diagnostic Trouble Codes (DTCs) set? Yes : REFER to: «INSTRUMENT PANEL CLUSTER (IPC) AND PANEL ILLUMINATION»(/ford/focus-st/iii-2012-2015/remont/gauges-instrument-panels/#instrument-panel-cluster-panel-illumination-electric) . No : REFER to: «COMMUNICATIONS NETWORK»(/ford/focus-st/iii-2012-2015/remont/communication-devices/#module-communications-network-electric) .

U0164:00

Diagnostics in this service information assume a certain skill level and knowledge of Ford-specific diagnostic practices.

REFER to: DIAGNOSTIC METHODS .

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

The PCM continuously monitors the CAN for messages from the HVAC module. This DTC sets when the PCM does not receive the HVAC module message within the defined amount of time.

  1. Connectors damaged or pushed-out terminals, corrosion, loose wires and missing or damaged seals
  2. Communication error
  3. Low battery condition
  4. Battery recently replaced
  5. BCM fuse 71 (10A)
  6. HVAC module
  7. PCM
DTCDescriptionFault Trigger Conditions
U0164:00Lost Communication With The HVAC ModuleAfter the PCM , HVAC module wake up the PCM did not detect a response from the HVAC module.

DTC FAULT TRIGGER CONDITIONS

PINPOINT TEST AF: U0164:00

  1. AF1 RETRIEVE AND RECORD ALL DTCS Connect the diagnostic tool. Using the scan tool, retrieve all Diagnostic Trouble Codes (DTCs). Does the HVAC module respond to the scan tool? Yes : GO to AF2 No : REFER to: «NO COMMUNICATION BETWEEN THE INTEGRATED DIAGNOSTIC SYSTEM (IDS) AND THE VEHICLE»(/ford/focus-st/iii-2012-2015/remont/communication-devices/#module-communications-network-electric) .
  2. AF2 CHECK FOR NETWORK COMMUNICATION DTCS Using the scan tool, retrieve network Diagnostic Trouble Codes (DTCs). Are any network Diagnostic Trouble Codes (DTCs) set? Yes : REFER to: «COMMUNICATIONS NETWORK»(/ford/focus-st/iii-2012-2015/remont/communication-devices/#module-communications-network-electric) No : GO to AF3
  3. AF3 CHECK FOR BATTERY VOLTAGE DTCS Using the scan tool, retrieve battery voltage Diagnostic Trouble Codes (DTCs). Are any HVAC module high or low voltage Diagnostic Trouble Codes (DTCs) set? Yes : REFER to: «CLIMATE CONTROL SYSTEM»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric) . No : REFER to: «COMMUNICATIONS NETWORK»(/ford/focus-st/iii-2012-2015/remont/communication-devices/#module-communications-network-electric) .

U016A:00

Diagnostics in this service information assume a certain skill level and knowledge of Ford-specific diagnostic practices.

REFER to: DIAGNOSTIC METHODS .

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

The PCM continuously monitors the CAN for messages from the GPS module. This DTC sets when the PCM does not receive the GPS module message within the defined amount of time.

  1. Connectors damaged or pushed-out terminals, corrosion, loose wires and missing or damaged seals
  2. Communication error
  3. Low battery condition
  4. Battery recently replaced
  5. BCM fuse 67 (7.5A)
  6. GPS module
  7. PCM
DTCDescriptionFault Trigger Conditions
U016A:00Lost Communication With The Global Positioning System (GPS) ModuleAfter the PCM , GPS module wake up the PCM did not detect a response from the GPS module.

DTC FAULT TRIGGER CONDITIONS

PINPOINT TEST AG: U016A:00

  1. AG1 RETRIEVE AND RECORD ALL DTCS Connect the diagnostic tool. Using the scan tool, retrieve all Diagnostic Trouble Codes (DTCs). Does the GPS module respond to the scan tool? Yes : GO to AG2 No : REFER to: «NO COMMUNICATION BETWEEN THE INTEGRATED DIAGNOSTIC SYSTEM (IDS) AND THE VEHICLE»(/ford/focus-st/iii-2012-2015/remont/communication-devices/#module-communications-network-electric) .
  2. AG2 CHECK FOR NETWORK COMMUNICATION DTCS Using the scan tool, retrieve network Diagnostic Trouble Codes (DTCs). Are any network Diagnostic Trouble Codes (DTCs) set? Yes : REFER to: «COMMUNICATIONS NETWORK»(/ford/focus-st/iii-2012-2015/remont/communication-devices/#module-communications-network-electric) . No : GO to AG3
  3. AG3 CHECK FOR BATTERY VOLTAGE DTCS Using the scan tool, retrieve battery voltage Diagnostic Trouble Codes (DTCs). Are any GPS module high or low voltage Diagnostic Trouble Codes (DTCs) set? Yes : REFER to: «INFORMATION AND ENTERTAINMENT SYSTEM»(/ford/focus-st/iii-2012-2015/remont/entertainment-systems/#information-entertainment-systems-with-o-touchscreen-electric) . No : REFER to: «COMMUNICATIONS NETWORK»(/ford/focus-st/iii-2012-2015/remont/communication-devices/#module-communications-network-electric) .

U016B:00

Diagnostics in this service information assume a certain skill level and knowledge of Ford-specific diagnostic practices.

REFER to: DIAGNOSTIC METHODS .

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

The PCM continuously monitors the CAN for messages from the ACCM . This DTC sets when the PCM does not receive the electronic ACCM message within the defined amount of time.

  1. Connectors damaged or pushed-out terminals, corrosion, loose wires and missing or damaged seals
  2. Communication error
  3. Low battery condition
  4. Battery recently replaced
  5. BJB fuse 33 (10A)
  6. ACCM
  7. PCM
DTCDescriptionFault Trigger Conditions
U016B:00Lost Communication With The Electric A/C Compressor Control ModuleAfter the PCM , ACCM wake up the PCM did not detect a response from the electronic ACCM .

DTC FAULT TRIGGER CONDITIONS

PINPOINT TEST AH: U016B:00

  1. AH1 RETRIEVE AND RECORD ALL DTCS Connect the diagnostic tool. Using the scan tool, retrieve all Diagnostic Trouble Codes (DTCs). Does the ACCM respond to the scan tool? Yes : GO to AH2 No : REFER to: «NO COMMUNICATION BETWEEN THE INTEGRATED DIAGNOSTIC SYSTEM (IDS) AND THE VEHICLE»(/ford/focus-st/iii-2012-2015/remont/communication-devices/#module-communications-network-electric) .
  2. AH2 CHECK FOR NETWORK COMMUNICATION DTCS Using the scan tool, retrieve network Diagnostic Trouble Codes (DTCs). Are any network Diagnostic Trouble Codes (DTCs) set? Yes : REFER to: «COMMUNICATIONS NETWORK»(/ford/focus-st/iii-2012-2015/remont/communication-devices/#module-communications-network-electric) . No : GO to AH3
  3. AH3 CHECK FOR BATTERY VOLTAGE DTCS Using the scan tool, retrieve battery voltage Diagnostic Trouble Codes (DTCs). Are any ACCM high or low voltage Diagnostic Trouble Codes (DTCs) set? Yes : REFER to: «CLIMATE CONTROL SYSTEM»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric) . No : REFER to: «COMMUNICATIONS NETWORK»(/ford/focus-st/iii-2012-2015/remont/communication-devices/#module-communications-network-electric) .

U0198:00

Diagnostics in this service information assume a certain skill level and knowledge of Ford-specific diagnostic practices.

REFER to: DIAGNOSTIC METHODS .

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

The PCM continuously monitors the CAN for messages from the TCU . This DTC sets when the PCM does not receive the TCU message within the defined amount of time.

  1. Connectors damaged or pushed-out terminals, corrosion, loose wires and missing or damaged seals
  2. Communication error
  3. Low battery condition
  4. Battery recently replaced
  5. RJB fuse 1 (5A)
  6. TCU
  7. PCM
DTCDescriptionFault Trigger Conditions
U0198:00Lost Communication With The Telematic Control Unit Module (TCU)After the PCM , TCU wake up the PCM did not detect a response from the TCU .

DTC FAULT TRIGGER CONDITIONS

PINPOINT TEST AI: U0198:00

  1. AI1 RETRIEVE AND RECORD ALL DTCS Connect the diagnostic tool. Using the scan tool, retrieve all Diagnostic Trouble Codes (DTCs). Does the TCU respond to the scan tool? Yes : GO to AI2 No : REFER to: «NO COMMUNICATION BETWEEN THE INTEGRATED DIAGNOSTIC SYSTEM (IDS) AND THE VEHICLE»(/ford/focus-st/iii-2012-2015/remont/communication-devices/#module-communications-network-electric) .
  2. AI2 CHECK FOR NETWORK COMMUNICATION DTCS Using the scan tool, retrieve network Diagnostic Trouble Codes (DTCs). Are any network Diagnostic Trouble Codes (DTCs) set? Yes : REFER to: «COMMUNICATIONS NETWORK»(/ford/focus-st/iii-2012-2015/remont/communication-devices/#module-communications-network-electric) . No : GO to AI3
  3. AI3 CHECK FOR BATTERY VOLTAGE DTCS Using the scan tool, retrieve battery voltage Diagnostic Trouble Codes (DTCs). Are any TCU high or low voltage Diagnostic Trouble Codes (DTCs) set? Yes : REFER to: «INFORMATION AND ENTERTAINMENT SYSTEM»(/ford/focus-st/iii-2012-2015/remont/entertainment-systems/#information-entertainment-systems-with-o-touchscreen-electric) . No : REFER to: «COMMUNICATIONS NETWORK»(/ford/focus-st/iii-2012-2015/remont/communication-devices/#module-communications-network-electric) .

U019B:00

Diagnostics in this service information assume a certain skill level and knowledge of Ford-specific diagnostic practices.

REFER to: DIAGNOSTIC METHODS .

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

The PCM continuously monitors the CAN for messages from the Secondary OBD Module A. This DTC sets when the PCM does not receive the Secondary OBD Module A message within the defined amount of time.

  1. Connectors damaged or pushed-out terminals, corrosion, loose wires and missing or damaged seals
  2. Communication error
  3. Low battery condition
  4. Battery recently replaced
  5. BJB fuse 13 (40A)
  6. Secondary OBD Module A
  7. PCM
DTCDescriptionFault Trigger Conditions
U019B:00Lost Communication With The Battery Charger Control ModuleAfter the PCM , Secondary OBD Module A wake up the PCM did not detect a response from the Secondary OBD Module A.

DTC FAULT TRIGGER CONDITIONS

PINPOINT TEST AJ: U019B:00

  1. AJ1 RETRIEVE AND RECORD ALL DTCS Connect the diagnostic tool. Using the scan tool, retrieve all Diagnostic Trouble Codes (DTCs). Does the Secondary OBD Module A respond to the scan tool? Yes : GO to AJ2 No : REFER to: «NO COMMUNICATION BETWEEN THE INTEGRATED DIAGNOSTIC SYSTEM (IDS) AND THE VEHICLE»(/ford/focus-st/iii-2012-2015/remont/communication-devices/#module-communications-network-electric) .
  2. AJ2 CHECK FOR NETWORK COMMUNICATION DTCS Using the scan tool, retrieve network Diagnostic Trouble Codes (DTCs). Are any network Diagnostic Trouble Codes (DTCs) set? Yes : REFER to: «COMMUNICATIONS NETWORK»(/ford/focus-st/iii-2012-2015/remont/communication-devices/#module-communications-network-electric) . No : GO to AJ3
  3. AJ3 CHECK FOR BATTERY VOLTAGE DTCS Using the scan tool, retrieve battery voltage Diagnostic Trouble Codes (DTCs). Are any Secondary OBD Module A high or low voltage Diagnostic Trouble Codes (DTCs) set? Yes : REFER to: «HIGH VOLTAGE BATTERY CHARGING SYSTEM»(/ford/focus-st/iii-2012-2015/remont/body-electrical/#high-voltage-battery-charging-system-electric) . No : REFER to: «COMMUNICATIONS NETWORK»(/ford/focus-st/iii-2012-2015/remont/communication-devices/#module-communications-network-electric) .

U0298:00

Diagnostics in this service information assume a certain skill level and knowledge of Ford-specific diagnostic practices.

REFER to: DIAGNOSTIC METHODS .

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

The PCM continuously monitors the CAN for messages from the DC to DC Converter Control Module (DC/DC). This DTC sets when the PCM does not receive the DC to DC Converter Control Module (DC/DC) message within the defined amount of time.

  1. Connectors damaged or pushed-out terminals, corrosion, loose wires and missing or damaged seals
  2. Communication error
  3. Low battery condition
  4. Battery recently replaced
  5. High Current BJB mega fuse 2 (150A)
  6. DC to DC Converter Control Module (DC/DC)
  7. PCM
DTCDescriptionFault Trigger Conditions
U0298:00Lost Communication With The DC to DC Converter Control Module "A"After the PCM , DC to DC Converter Control Module (DC/DC) wake up the PCM did not detect a response from the DC to DC Converter Control Module (DC/DC).

DTC FAULT TRIGGER CONDITIONS

PINPOINT TEST AK: U0298:00

  1. AK1 RETRIEVE AND RECORD ALL DTCS Connect the diagnostic tool. Using the scan tool, retrieve all Diagnostic Trouble Codes (DTCs). Does the DC to DC Converter Control Module (DC/DC) respond to the scan tool? Yes : GO to AK2 No : REFER to: «NO COMMUNICATION BETWEEN THE INTEGRATED DIAGNOSTIC SYSTEM (IDS) AND THE VEHICLE»(/ford/focus-st/iii-2012-2015/remont/communication-devices/#module-communications-network-electric) .
  2. AK2 CHECK FOR NETWORK COMMUNICATION DTCS Using the scan tool, retrieve network Diagnostic Trouble Codes (DTCs). Are any network Diagnostic Trouble Codes (DTCs) set? Yes : REFER to: «COMMUNICATIONS NETWORK»(/ford/focus-st/iii-2012-2015/remont/communication-devices/#module-communications-network-electric) . No : GO to AK3
  3. AK3 CHECK FOR BATTERY VOLTAGE DTCS Using the scan tool, retrieve battery voltage Diagnostic Trouble Codes (DTCs). Are any DC to DC Converter Control Module (DC/DC) high or low voltage Diagnostic Trouble Codes (DTCs) set? Yes : REFER to: «DIRECT CURRENT/DIRECT CURRENT (DC/DC) CONVERTER CONTROL MODULE»(/ford/focus-st/iii-2012-2015/remont/body-electrical/#voltage-converterinverter-electric) . No : REFER to: «COMMUNICATIONS NETWORK»(/ford/focus-st/iii-2012-2015/remont/communication-devices/#module-communications-network-electric) .

P2611:00, P2611:09, P2613:00

Diagnostics in this service information assume a certain skill level and knowledge of Ford-specific diagnostic practices.

REFER to: DIAGNOSTIC METHODS .

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

The PCM provides a ground input which energizes the cabin air conditioning isolator solenoid valve which diverts refrigerant to the cabin coolant heater. The PCM sets a DTC if voltage on this input is above or below a calibrated threshold.

  1. Connectors damaged or pushed-out terminals, corrosion, loose wires and missing or damaged seals
  2. BJB fuse 32 (10A)
  3. Cabin air conditioning isolator solenoid valve
  4. BJB
  5. PCM
DTCDescriptionFault Trigger Conditions
P2611:00Air Conditioning Refrigerant Distribution Valve Control Circuit/OpenThe PCM detected voltage out of range on the cabin air conditioning isolator solenoid valve input.
P2611:09Air Conditioning Refrigerant Distribution Valve Control Circuit/OpenThe PCM detected voltage out of range on the cabin air conditioning isolator solenoid valve input.
P2613:00Air Conditioning Refrigerant Distribution Valve Control Circuit HighThe PCM detected voltage out of range on the cabin air conditioning isolator solenoid valve input.

DTC FAULT TRIGGER CONDITIONS

PINPOINT TEST AL: P2611:00, P2611:09, P2613:00

  1. AL1 RETRIEVE AND RECORD ALL DTCS Using the scan tool, retrieve all Diagnostic Trouble Codes (DTCs). Are Diagnostic Trouble Codes (DTCs) P2611:00, P2611:09 and/or P2613:00 set? Yes : GO to AL2 No : GO to «SYMPTOM CHART»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control__symptom-chart)
  2. AL2 CHECK THE CABIN AIR CONDITIONING ISOLATOR SOLENOID VALVE CIRCUIT FOR AN OPEN Disconnect Powertrain Control Module (PCM) C175A . Disconnect Air Conditioning Isolator Solenoid C1035C . Measure the resistance between. Positive Lead Measurement/Action Negative Lead C175A-11 C1035C-2 Is the resistance less than 5.0 ohms? Yes : GO to AL3 No : REPAIR the circuit.
  3. AL3 CHECK THE CABIN AIR CONDITIONING ISOLATOR SOLENOID VALVE CIRCUIT FOR A SHORT TO GROUND Measure the resistance between. Positive Lead Measurement/Action Negative Lead C175A-11 Ground Is the resistance greater than 10, 000 ohms? Yes : GO to AL4 No : REPAIR the circuit.
  4. AL4 CHECK THE CABIN AIR CONDITIONING ISOLATOR SOLENOID VALVE CIRCUIT FOR A SHORT TO POWER Ignition ON. Measure the voltage between. Positive Lead Measurement/Action Negative Lead C175A-42 Ground Is any voltage present? Yes : REPAIR the circuit. No : INSTALL a new PCM . REFER to: «POWERTRAIN CONTROL MODULE (PCM)»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control) .

P26AD:00, P26AE:00, P26B0:00, P26B0:12, P26B0:14

Diagnostics in this service information assume a certain skill level and knowledge of Ford-specific diagnostic practices.

REFER to: DIAGNOSTIC METHODS .

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

The engine coolant bypass valve is a 12-volt operated valve which regulates coolant to the elecric motor. The PCM provides a PWM signal to the pump and monitors this signal by monitoring a diagnostic circuit input. The PCM sets a DTC if voltage on these inputs are above or below a calibrated threshold.

  1. Connectors damaged or pushed-out terminals, corrosion, loose wires and missing or damaged seals
  2. BJB fuse 32 (10A)
  3. Engine coolant bypass valve
  4. PCM
DTCDescriptionFault Trigger Conditions
P26AD:00Engine Coolant Bypass Valve "B" Control Circuit LowThe PCM commanded PWM output greater than 11% but the feedback input detects 0-volts.
P26AE:00Engine Coolant Bypass Valve "B" Control Circuit HighThe PCM commanded PWM output less than 70% but the feedback input detects 12-volts.
P26B0:00Engine Coolant Bypass Valve "B" Range/PerformanceThe PCM PWM output is greater than 11% but the feedback input detects at or near 100%.
P26B0:12Engine Coolant Bypass Valve "B" Range/Performance Short To BatteryThe PCM commanded PWM greater than 11% but the feedback input detects 12-volts.
P26B0:14Engine Coolant Bypass Valve "B" Range/Performance Short To Ground or OpenThe PCM commanded PWM output less than 70% but the feedback input detects 0-volts.

DTC FAULT TRIGGER CONDITIONS

PINPOINT TEST AM: P26AD:00, P26AE:00, P26B0:00, P26B0:12, P26B0:14

  1. AM1 RETRIEVE AND RECORD ALL DTCS Connect the diagnostic tool. Using the scan tool, retrieve all Diagnostic Trouble Codes (DTCs). Is DTC P26AD:00, P26AE:00, P26B0:00, P26B0:12 and/or P26B0:14 set? Yes : For DTC P26AD:00 and/or P26B0:00, GO to AM2 For DTC P26AE:00 and/or P26B0:00, GO to AM5 For DTC P26B0:12, GO to AM6 For DTC P26B0:14, GO to AM7 No : GO to «SYMPTOM CHART»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control__symptom-chart) .
  2. AM2 CHECK THE ENGINE COOLANT BYPASS VALVE B POWER CIRCUITS FOR AN OPEN Disconnect Engine Coolant Bypass Valve B C1810 . Ignition ON. Measure the voltage between. Positive Lead Measurement/Action Negative Lead C1810-A Ground Is voltage greater than 10.5 volts? Yes : GO to AM3 No : REPAIR the circuit.
  3. AM3 CHECK THE ENGINE COOLANT BYPASS VALVE B GROUND CIRCUITS FOR AN OPEN Measure the voltage between. Positive Lead Measurement/Action Negative Lead C1810-A C1810-C Is voltage greater than 10.5 volts? Yes : GO to AM4 No : REPAIR the circuit.
  4. AM4 CHECK THE ENGINE COOLANT BYPASS VALVE B PULSE WIDTH MODULATION (PWM) CIRCUIT FOR A SHORT TO GROUND Ignition OFF. Disconnect Powertrain Control Module (PCM) C175B . Measure the resistance between. Positive Lead Measurement/Action Negative Lead C175B-23 Ground Is the resistance greater than 10, 000 ohms? Yes : INSTALL a new PCM . REFER to: «POWERTRAIN CONTROL MODULE (PCM)»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control) . No : REPAIR the circuit.
  5. AM5 CHECK THE ENGINE COOLANT BYPASS VALVE B PULSE WIDTH MODULATION (PWM) CIRCUIT FOR A SHORT TO POWER Disconnect Powertrain Control Module (PCM) C175B . Disconnect Engine Coolant Bypass Valve B C1810 . Ignition ON. Measure the voltage between. Positive Lead Measurement/Action Negative Lead C175B-23 Ground Is any voltage present? Yes : REPAIR the circuit. No : INSTALL a new PCM . REFER to: «POWERTRAIN CONTROL MODULE (PCM)»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control) .
  6. AM6 CHECK THE ENGINE COOLANT BYPASS VALVE B FEEDBACK CIRCUIT FOR A SHORT TO POWER Disconnect Powertrain Control Module (PCM) C175A . Disconnect Engine Coolant Bypass Valve B C1810 . Ignition ON. Measure the voltage between. Positive Lead Measurement/Action Negative Lead C175A-64 Ground Is any voltage present? Yes : REPAIR the circuit. No : INSTALL a new PCM . REFER to: «POWERTRAIN CONTROL MODULE (PCM)»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control) .
  7. AM7 CHECK THE ENGINE COOLANT BYPASS VALVE B FEEDBACK CIRCUIT FOR AN OPEN Disconnect Powertrain Control Module (PCM) C175A . Disconnect Engine Coolant Bypass Valve B C1810 . Measure the resistance between. Positive Lead Measurement/Action Negative Lead C175A-64 C1810-F Is the resistance less than 5.0 ohms? Yes : GO to AM8 No : REPAIR the circuit.
  8. AM8 CHECK THE ENGINE COOLANT BYPASS VALVE B FEEDBACK CIRCUIT FOR A SHORT TO GROUND Measure the resistance between. Positive Lead Measurement/Action Negative Lead C175A-64 Ground Is the resistance greater than 10, 000 ohms? Yes : INSTALL a new PCM . REFER to: «POWERTRAIN CONTROL MODULE (PCM)»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control) . No : REPAIR the circuit.

B1D17:11

Diagnostics in this service information assume a certain skill level and knowledge of Ford-specific diagnostic practices.

REFER to: DIAGNOSTIC METHODS .

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

The PCM sends a signal to the vehicle audio signal pedestrian module when the PCM receives a CAN signal from the Parking Aid Module (PAM) indicating an object is behind the vehicle. The PCM sets a DTC if voltage on this input is above or below a calibrated threshold.

  1. Connectors damaged or pushed-out terminals, corrosion, loose wires and missing or damaged seals
  2. BJB fuse 27 (15A)
  3. Vehicle audio signal module
  4. PCM
DTCDescriptionFault Trigger Conditions
B1D17:11Battery Backed Sounder Circuit Short To GroundThe PCM detects 0-volts on the vehicle audio signal pedestrian input.

DTC FAULT TRIGGER CONDITIONS

PINPOINT TEST AN: B1D17:11

  1. AN1 RETRIEVE AND RECORD ALL DTCS Using the scan tool, retrieve all Diagnostic Trouble Codes (DTCs). Is DTC B1D17:11 set? Yes : GO to AN2 No : GO to «SYMPTOM CHART»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control__symptom-chart) .
  2. AN2 CHECK THE VEHICLE AUDIO SIGNAL CIRCUIT FOR AN OPEN Disconnect Powertrain Control Module (PCM) C175A . Disconnect Parking Aid Module (PAM) C1820 . Measure the resistance between. Positive Lead Measurement/Action Negative Lead C175A-42 C1820-2 Is the resistance less than 5.0 ohms? Yes : GO to AN3 No : REPAIR the circuit.
  3. AN3 CHECK THE VEHICLE AUDIO SIGNAL CIRCUIT FOR A SHORT TO GROUND Measure the resistance between. Positive Lead Measurement/Action Negative Lead C175A-42 Ground Is the resistance greater than 10, 000 ohms? Yes : GO to AN4 No : REPAIR the circuit.
  4. AN4 CHECK THE VEHICLE AUDIO SIGNAL CIRCUIT FOR A SHORT TO POWER Ignition ON. Measure the voltage between. Positive Lead Measurement/Action Negative Lead C175A-42 Ground Is any voltage present? Yes : REPAIR the circuit. No : INSTALL a new PCM . REFER to: «POWERTRAIN CONTROL MODULE (PCM)»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control) . Diagnostics in this service information assume a certain skill level and knowledge of Ford-specific diagnostic practices. REFER to: «DIAGNOSTIC METHODS»(/ford/focus-st/iii-2012-2015/remont/oem-general-information/#general-information-electric) . Refer to «SYSTEM WIRING DIAGRAMS»(ref-541405) for schematic and connector information.

The PCM receives a wake up voltage signal from the BCM . The PCM provides a ground to energize the PCM power relay. Battery and ignition voltage is then applied to the PCM . The PCM provides 12 volt and 5 volt reference voltage to various solenoids and components.

  1. Connectors damaged or pushed-out terminals, corrosion, loose wires and missing or damaged seals
  2. BJB fuse 33 (10A)
  3. BJB fuse 38 (15A)
  4. BJB fuse 26 (10A)
  5. BJB fuse 12 (40A)
  6. BJB fuse 23 (5A)
  7. PCM power relay

PINPOINT TEST AO: UNABLE TO ACTIVATE SELF-TEST/NETWORK COMMUNICATION ERROR

  1. AO1 CHECK FOR VOLTAGE REFERENCE AT THE ACCELERATOR PEDAL POSITION (APP) SENSOR Disconnect Accelerator Pedal Position (APP) C2040 . Ignition ON. Measure the voltage between. Positive Lead Measurement/Action Negative Lead C2040-1 C2040-3 Is the voltage between 4.5 and 5.5 volts? Yes : REFER to: «COMMUNICATIONS NETWORK»(/ford/focus-st/iii-2012-2015/remont/communication-devices/#module-communications-network-electric) . No : GO to AO2
  2. AO2 CHECK THE IGNITION RELAY VOLTAGE POWER CIRCUIT FOR POWER Ignition OFF. Disconnect Powertrain Control Module (PCM) C175A . Ignition ON. Measure the voltage between. Positive Lead Measurement/Action Negative Lead C175A-56 Ground Is the voltage greater than 10.5 volts? Yes : GO to AO3 No : REPAIR the circuit.
  3. AO3 CHECK THE POWERTRAIN CONTROL MODULE (PCM) RELAY VOLTAGE POWER CIRCUIT FOR POWER Ignition OFF. Disconnect Powertrain Control Module (PCM) C175B . Connect a 5 amp fused jumper wire between. Positive Lead Measurement/Action Negative Lead C175A-62 Ground Ignition ON. Measure the voltage between. Positive Lead Measurement/Action Negative Lead C175B-6 Ground Is the voltage greater than 10.5 volts? Yes : GO to AO4 No : REPAIR the circuit.
  4. AO4 CHECK THE POWERTRAIN CONTROL MODULE (PCM) HOT AT ALL TIMES VOLTAGE BATTERY CIRCUITS FOR POWER Measure the voltage between. Positive Lead Measurement/Action Negative Lead C175B-88 Ground C175B-89 Ground Is the voltage greater than 10.5 volts? Yes : GO to AO5 No : REPAIR the circuit.
  5. AO5 CHECK THE POWERTRAIN CONTROL MODULE (PCM) GROUND CIRCUITS FOR AN OPEN Ignition OFF. Measure the resistance between. Positive Lead Measurement/Action Negative Lead C175A-100 Ground C175A-101 Ground Is the resistance less than 5.0 ohms? Yes : GO to AO6 No : REPAIR the circuit.
  6. AO6 CHECK FOR CORRECT POWERTRAIN CONTROL MODULE (PCM) OPERATION Connect Powertrain Control Module (PCM) C175A . Connect Powertrain Control Module (PCM) C175B . Perform the PCM self-test. Is the concern still present? Yes : INSTALL a new PCM . REFER to: «POWERTRAIN CONTROL MODULE (PCM)»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control) . No : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector.

P061B:00, P0161B:01, P061B:02

Diagnostics in this service information assume a certain skill level and knowledge of Ford-specific diagnostic practices.

REFER to: DIAGNOSTIC METHODS .

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

The PCM and TCM share torque calculations between each module. If a short to ground, short to power or an open circuit is detected on this circuit, then the DTC sets.

  1. Connectors damaged or pushed-out terminals, corrosion, loose wires and missing or damaged seals
  2. TCM
  3. PCM

PINPOINT TEST AP: P061B:00, P0161B:01, P061B:02

  1. AP1 RETRIEVE AND RECORD ALL DTCS Using the scan tool, retrieve all Diagnostic Trouble Codes (DTCs). Is DTC P061B:00, P0161B:01, and/or P061B:02 set? Yes : GO to AP2 No : If TCM DTC P1A0A:00 or any sub-set of P1A0A is set, REFER to: «TRANSMISSION CONTROL MODULE (TCM)»(/ford/focus-st/iii-2012-2015/remont/automatic-trans/#automatic-transaxle-electric) .
  2. AP2 CHECK THE INVERTER ENABLE CIRCUIT FOR AN OPEN Disconnect Transmission Control Module (TCM) C1822A . Disconnect Powertrain Control Module (PCM) C175A . Measure the resistance between. Positive Lead Measurement/Action Negative Lead C175B-58 C1822A-3 Is the resistance less than 5.0 ohms? Yes : GO to AP3 No : REPAIR the circuit.
  3. AP3 CHECK THE INVERTER ENABLE CIRCUIT FOR A SHORT TO GROUND Measure the resistance between. Positive Lead Measurement/Action Negative Lead C175B-58 Ground Is the resistance greater than 10, 000 ohms? Yes : GO to AP4 No : REPAIR the circuit.
  4. AP4 CHECK THE INVERTER ENABLE CIRCUIT FOR A SHORT TO POWER Ignition ON. Measure the voltage between. Positive Lead Measurement/Action Negative Lead C175B-58 Ground Is any voltage present? Yes : REPAIR the circuit. No : INSTALL a new PCM . REFER to REFER to: «POWERTRAIN CONTROL MODULE (PCM)»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control) .

Removal

Pinpoint Test A

A3 LH
  1. Refer to: «FENDER SPLASH SHIELD»(ref-566961-S40227465932013071700000) .

Installation

Pinpoint Test A

A1 All vehicles
  1. All vehicles

Note. Removal steps in this procedure may contain installation details.

  1. WARNING: Before beginning any service procedure, REFER to Safety Warnings in «GENERAL INFORMATION -- FOCUS ELECTRIC»(/ford/focus-st/iii-2012-2015/remont/oem-general-information/#general-information-electric) . Failure to follow this instruction may result in serious personal injury.
  2. Torque: 8 Nm
  1. To install, reverse the removal procedure.

Note. Electric motor coolant temperature sensor shown in illustration, high voltage battery and heater coolant temperature sensors similar.

Scheme 155

Scheme 155: Removal
Scheme 155: Removal

Scheme 156

Scheme 156
Scheme 156

Scheme 157

Scheme 157
Scheme 157
  1. WARNING: Before beginning any service procedure, REFER to Safety Warnings in «GENERAL INFORMATION -- FOCUS ELECTRIC»(/ford/focus-st/iii-2012-2015/remont/oem-general-information/#general-information-electric) . Failure to follow this instruction may result in serious personal injury.

Scheme 158

Scheme 158: Installation
Scheme 158: Installation
  1. To install, reverse the removal procedure.

See also:
• DIAGNOSTIC METHODS
• DIRECT CURRENT/DIRECT CURRENT (DC/DC) CONVERTER CONTROL MODULE
• CRUISE CONTROL
• BATTERY
• HIGH VOLTAGE BATTERY, MOUNTING AND CABLES
• CLIMATE CONTROL SYSTEM
• ANTI-LOCK BRAKE SYSTEM (ABS) AND STABILITY CONTROL
• MODULE CONFIGURATION - SYSTEM OPERATION AND COMPONENT DESCRIPTION
• NO COMMUNICATION BETWEEN THE INTEGRATED DIAGNOSTIC SYSTEM (IDS) AND THE VEHICLE
• HIGH VOLTAGE BATTERY COOLANT DIVERTER VALVE
• TRANSMISSION RANGE (TR) SENSOR
• SELECTOR LEVER CABLE ADJUSTMENT
• ELECTRIC MOTOR
• COOLING FAN MOTOR AND SHROUD
• HIGH VOLTAGE BATTERY COOLANT PUMP
• HIGH VOLTAGE BATTERY CHARGING SYSTEM
• ELECTRIC MOTOR COOLANT PUMP
• TIRE PRESSURE MONITORING SYSTEM (TPMS)
• HIGH VOLTAGE LOWER BATTERY
• HIGH VOLTAGE UPPER BATTERY
• CABIN HEATER COOLANT PUMP
• BODY CONTROL MODULE (BCM)
• AIRBAG SUPPLEMENTAL RESTRAINT SYSTEM (SRS) - VEHICLES BUILT FROM: 11-JUNE-2012
• INSTRUMENT PANEL CLUSTER (IPC) AND PANEL ILLUMINATION
• INFORMATION AND ENTERTAINMENT SYSTEM
• FENDER SPLASH SHIELD
• PINPOINT TEST A
• PINPOINT TEST J
• PINPOINT TEST K
• PINPOINT TEST B
• PINPOINT TEST C
• POWERTRAIN CONTROL MODULE (PCM)
• PINPOINT TEST AP
• PINPOINT TEST E
• PINPOINT TEST S
• PINPOINT TEST F
• PINPOINT TEST H
• PINPOINT TEST L
• PINPOINT TEST M
• PINPOINT TEST O
• PINPOINT TEST D
• PINPOINT TEST W
• PINPOINT TEST N
• PINPOINT TEST P
• PINPOINT TEST X
• PINPOINT TEST Z
• PINPOINT TEST Q
• PINPOINT TEST R
• PINPOINT TEST I
• PINPOINT TEST AL
• PINPOINT TEST T
• PINPOINT TEST AM
• PINPOINT TEST U
• PINPOINT TEST V
• PINPOINT TEST AN
• PINPOINT TEST Y
• PINPOINT TEST AA
• PINPOINT TEST AB
• PINPOINT TEST AC
• PINPOINT TEST AD
• PINPOINT TEST AE
• PINPOINT TEST AF
• PINPOINT TEST AG
• PINPOINT TEST AH
• PINPOINT TEST AI
• PINPOINT TEST AJ
• PINPOINT TEST AK
• DTC Chart Powertrain Control Module (PCM)
• PINPOINT TEST AO
• SYMPTOM CHART

More articles — Engine Performance
