Transaxle/transmission Cooling: Maintenance Ford Explorer IV

Automatic Trans 4 illustrations ~102 words

Transmission Fluid Cooler Backflushing and Cleaning

  1. For the 5R55S transmission, refer to «AUTOMATIC TRANSAXLE/TRANSMISSION - 5R55S»(ref-270891) .
  2. For the 6R60 transmission, refer to «AUTOMATIC TRANSAXLE/TRANSMISSION - 6R60»(ref-270910) .

Auxiliary Transmission Fluid Cooler

ItemSpecification
MERCON® SP Automatic Transmission Fluid XT-6-QSP (US); CXT-6-LSP12 (Canada)MERCON® SP
MERCON® V Automatic Transmission Fluid XT-5-QM (or XT-5-QMC) (US); CXT-5-LM12 (Canada)MERCON® V

Material

Scheme 63

Scheme 63
Scheme 63
ItemPart NumberDescription
1Transmission fluid cooler hose constant tension clamps
2Transmission fluid cooler bolts
3Transmission fluid cooler

Transmission Fluid Cooler Tubes - 5R55S

Special Tools Illustration Tool Name Tool Number Disconnect Tool, Transmission Cooler Line 307-569

ItemSpecification
MERCON® V Automatic Transmission Fluid XT-5-QM (or XT-5-QMC) (US); CXT-5-LM12 (Canada)MERCON® V

Material

Scheme 64

Scheme 64
Scheme 64
ItemPart NumberDescription
1Transmission fluid cooler tube nuts
27J081Transmission fluid cooler tube secondary latches
37R081Transmission fluid cooler tubes
4Transmission fluid cooler tube bracket nut

Transmission Fluid Cooler Tubes - 6R60

Special Tools Illustration Tool Name Tool Number Disconnect Tool, Transmission Cooler Line 307-569

ItemSpecification
MERCON® SP Automatic Transmission Fluid XT-6-QSP (US); CXT-6-LSP12 (Canada)MERCON® SP
Threadlock and Sealer TA-25WSK-M2G351-A5

Material

Scheme 65

Scheme 65
Scheme 65
ItemPart NumberDescription
17J081Transmission fluid cooler tube secondary latches
27R081Transmission fluid cooler tubes
3Transmission fluid cooler tube bracket nut
4Transmission fluid cooler tube bracket bolt
57J227Transmission fluid cooler tube O-rings (4 required)

Transmission Fluid Cooler Hoses

Special Tools Illustration Tool Name Tool Number Disconnect Tool, Transmission Cooler Line 307-569

ItemSpecification
MERCON® SP Automatic Transmission Fluid XT-6-QSP (US); CXT-6-LSP12 (Canada)MERCON® SP
MERCON® V Automatic Transmission Fluid XT-5-QM (or XT-5-QMC) (US); CXT-5-LM12 (Canada)MERCON® V

Material

Scheme 66

Scheme 66
Scheme 66
ItemPart NumberDescription
1Transmission fluid cooler constant tension hose clamps
27B028Transmission fluid cooler hoses
37J081Transmission fluid cooler hose secondary latches
47B028Transmission fluid cooler hoses
5Transmission fluid cooler hose retainer
