TORQUE SPECIFICATIONS
| Description | Nm |
|---|---|
| Selector lever cable bracket screws (5R55S) | 40 |
| Selector lever cable bracket screws (6R60) | 27 |
| Selector lever housing nuts | 9 |
| Selector lever knob set screw | 3 |
TORQUE SPECIFICATIONS
Scheme 32
| Item | Part Number | Description |
|---|---|---|
| 1 | 7G550 | Transmission control (TC) switch |
| 2 | 7213 | Transmission selector lever knob |
| 3 | 061A16 | Transmission selector lever bezel ring |
| 4 | 7D443 | Transmission selector lever housing bezel |
| 5 | 7C444 | Transmission selector lever housing slider |
| 6 | Transmission selector lever housing | |
| 7 | 7E096 | Brake shift interlock actuator |
| 8 | 7J437 | Brake shift interlock actuator module |
| 9 | 5A808 | Transmission selector lever harness |
| 10 | Transmission selector lever knob set screw |
The selector lever cable transfers the transmission operating mode from the selector lever to the transmission. The indicated position of the selector lever is transferred to the transmission through the selector lever linkage, then to the selector lever cable and bracket and down to the manual control lever on the transmission.
