Automatic Transmission Cooler - Transaxle/transmission Cooling: Specifications Ford Expedition III

Automatic Trans 2 illustrations ~123 words

MATERIAL SPECIFICATION

ItemSpecificationFill Capacity
Motorcraft® MERCON® LV Automatic Transmission Fluid XT-10-QLVMERCON® LV

MATERIAL SPECIFICATION

TORQUE SPECIFICATION

DescriptionNm
Engine mount nuts175
Sway bar bracket nuts55
Transmission fluid cooler tube bracket bolt at transmission48
Transmission fluid cooler tube bracket bolt25
Transmission fluid cooler tube bracket nut40

TORQUE SPECIFICATION

The transmission fluid cooling system consists of

  1. transmission fluid cooler inlet and outlet tubes.
  2. an in-tank transmission fluid cooler inlet tube.
  3. a non-repairable in-tank transmission fluid cooler.
  4. an auxiliary transmission fluid cooler inlet tube (HD).
  5. an auxiliary transmission fluid cooler (HD).
  6. an auxiliary transmission fluid cooler outlet tube (HD).

The transmission fluid flows from the transmission to the in-tank transmission fluid cooler, to the auxiliary transmission fluid cooler and returns to the transmission.

For Transmission Fluid Cooler Backflushing and Cleaning, refer to AUTOMATIC TRANSAXLE/TRANSMISSION - 6R80 .

Scheme 65

Scheme 65: 6R80 HD with Towing Package
Scheme 65: 6R80 HD with Towing Package
ItemPart NumberDescription
18005Radiator
27R081Transmission fluid cooler inlet and outlet tubes
37Z465Transmission fluid cooler tube secondary latches
47B028ATransmission fluid cooler inlet hose
57C410Auxiliary transmission fluid cooler inlet hose
67A095Auxiliary transmission fluid cooler
77B028BAuxiliary transmission fluid cooler outlet hose
87C107Transmission fluid cooler hose clamps
97000Transmission

PART NUMBER REFERENCE

Scheme 66

Scheme 66: 6R80 Base Package
Scheme 66: 6R80 Base Package
ItemPart NumberDescription
18005Radiator
27R081Transmission fluid cooler inlet and outlet tubes
37Z465Transmission fluid cooler tube secondary latches
47B028ATransmission fluid cooler inlet hose
57C410Transmission fluid cooler outlet hose
67C107Transmission fluid cooler hose clamps
77000Transmission

PART NUMBER REFERENCE
