Automatic Transmission - Automatic Transaxle/transmission - External Controls: Wiring Ford Expedition III

Automatic Trans 1 illustration

Transmission Vehicle Harness - C1548

Pin NumberCircuitCircuit Description
1CET34 (BN/GN)Tow/haul signal
2VDB05 (WH)HS CAN
3NOT USED
4NOT USED
5NOT USED
6VDB04 (WH/BU)HS CAN+
7CAT03 (GY/BN)Backup lamp relay feed
8NOT USED
9CBB54 (VT/OG)Ignition input
10CET40 (GN/OG)Park/Neutral
11NOT USED
12NOT USED
13GD113 (BK/YE)Ground
14SBB26 (YE/RD)Battery input
15RET24 (BN/BU)Backup lamp relay control
16GD113 (BK/YE)Ground

PIN DESCRIPTION

Scheme 37

Scheme 37: Selector Lever Connector - C2096
Scheme 37: Selector Lever Connector - C2096
Pin NumberCircuit Function
1BSIA power
2Park detect
3Illumination
4Ground
5Tow/haul switch power
6Tow/haul switch ground

PIN FUNCTION CHART
