Engine Controls - Pinpoint Tests - 6.0L Diesel: Overview Ford Econoline E150

Scheme 81

Scheme 82

DTC Description

1. P0704 = Clutch Switch Input Circuit Malfunction

DTC Descriptions

1. P0335 = Crankshaft Position Sensor Circuit A
2. P0336 = Crankshaft Position Sensor Circuit A Range/Performance
3. P2617 = Crankshaft Position Out Fault

1. P0236 = Turbo Boost Sensor A Circuit Performance
2. P0237 = Turbo Boost Sensor A Circuit Low Input
3. P0238 = Turbo Boost Sensor A Circuit High Input

MAP VOLTAGE

Note. +/- 0.3 volt from expected voltage reading is allowed.

1. P0113 = IAT Sensor Circuit High Input
2. P0112 = IAT Sensor Circuit Low Input

1. P0096 = IAT2 Sensor 2 Circuit Range/Performance
2. P0097 = IAT2 Sensor 2 Circuit Low Input
3. P0098 = IAT2 Sensor 2 Circuit High Input

1. P1536 = Parking Brake Switch Circuit

1. P0101 = Mass or Volume Air Flow Circuit Range/Performance
2. P0103 = Mass or Volume Air Flow Circuit High Input
3. P1102 = Mass Air Flow Sensor In Range But Lower Than Expected

1. P0117 = ECT Sensor Circuit Low Input
2. P0118 = ECT Sensor Circuit High Input

1. P0299 = Turbo/SuperCharger Underboost
2. P0478 = Exhaust Pressure Control Valve High Input
3. P132B = Turbocharger/Supercharger Boost Control A Performance (Build data on or before 9/28/03)
4. P2262 = Turbo/Super Charger Boost Pressure Not Detected
5. P2263 = Turbo/Super Charger System Boost Performance

1. Circuit Faults: P0196 = EOT Sensor Circuit Range/Performance P0197 = EOT Sensor Circuit Low Input P0198 = EOT Sensor Circuit High Input P1184 = EOT Sensor Out Of Self-Test Range P0298 = Engine Oil Over Temperature Condition

EOT SENSOR - OHMS, VOLTAGE & TEMPERATURE SPECIFICATIONS

1. P0230 = Fuel Pump Primary Circuit
2. P0231 = Fuel Pump Secondary Circuit Low
3. P0232 = Fuel Pump Secondary Circuit High

Note. Visually inspect the harness connectors for corrosion, damage, proper mating and correct pin tension.

Note. When the PCM is disconnected additional DTCs will be set. Clear all DTCs after restoring the vehicle.

1. P2269 = Water In Fuel Condition

1. P2285 = Injector Control Pressure Sensor Circuit Low
2. P2286 = Injector Control Pressure Sensor Circuit High
3. P2287 = Injector Control Pressure Sensor Circuit Intermittent

1. P2623 = Injector Control Pressure Regulator Circuit

1. P0611 = FICM Performance
2. P1378 = FICM Circuit Low Voltage
3. P1379 = FICM Circuit High Voltage

1. P0340 = CMP Sensor Circuit Malfunction
2. P0341 = CMP Sensor Circuit Performance
3. P2614 = Camshaft Position Out

1. P0401 = EGR Flow Insufficient Detected
2. P0402 = EGR Flow Excessive Detected
3. P0403 = EGR Control Circuits
4. P0404 = EGR Control Circuit Range/Performance
5. P0405 = EGR Sensor A Circuit Low
6. P0406 = EGR Sensor A Circuit High
7. P1335 = EGR Position Sensor Minimum Stop Performance

1. P0565 = Speed Control ON Signal
2. P0566 = Speed Control OFF Signal
3. P0567 = Speed Control RESUME Signal
4. P0568 = Speed Control SET Signal
5. P0569 = Speed Control COAST Signal

1. P0603 = Powertrain Control Module Keep Alive Memory (KAM) Error

Description

The powertrain control module (PCM) reset occurs when the PCM momentarily "reboots" or is turned off and on while the engine is operating. If the condition occurs a single time, the engine will momentarily stumble and the PCM will go through a normal key on cycle, including turning the glow plug lamp and glow plugs on and will also attempt to validate the accelerator pedal position. If the pedal is not at the idle position when this fault occurs, pedal authority will not be allowed by the PCM until the accelerator pedal is released and the engine returns to idle.

Note. Visually inspect the harness connectors for corrosion, damage, proper mating and correct pin tension.

Note. When the PCM is disconnected additional DTCs will be set. Clear all DTCs after restoring the vehicle.

1. P1502 = APCM On During Self-Test

The glow plug system is composed of a solid state glow plug control module (GPCM) and the glow plugs. The GPCM provides direct battery voltage to the glow plugs. The GPCM monitors the individual glow plug operation. Faults detected by the GPCM are transmitted to the PCM using a serial communication signal on a diagnostic line.

The powertrain control module (PCM) enables and controls the GPCM. Glow plug ON time is a function of oil temperature, barometric pressure and battery voltage. The ON time normally varies between 1 to 120 seconds and is limited by the GPCM to 180 seconds regardless of PCM commands.

Note. Wait-to-Start indicator ON time is independent from GPCM ON time.

1. P0670 = Glow Plug Module Control Circuit
2. P0671-P0678 = Cylinder 1 - 8 Glow Plug Circuit
3. P0683 = Glow Plug Control Module to PCM Communication Circuit

1. P2122 = APP Sensor D Low Input
2. P2123 = APP Sensor D High Input
3. P2127 = APP Sensor E Low Input
4. P2128 = APP Sensor E High Input
5. P2132 = APP Sensor F Low Input
6. P2133 = APP Sensor F High Input
7. P2138 = APP Sensor D/E Voltage Correlation
8. P2139 = APP Sensor D/F Voltage Correlation
9. P2140 = APP Sensor E/F Voltage Correlation

1. P0480 = Fan 1 Control Circuit
2. P0528 = Fan Speed Sensor Circuit No Signal

1. P1703 = Brake Switch Out Of Self-Test Range

1. P0046 = Turbo/Supercharger Boost Solenoid Circuit Range/Performance Fault

Note. Functions may not be available if the operator has deprogrammed them.

The APCM system provides an operator interface to the drive-by-wire powertrain control system to affect charge protection, engine RPM and manual throttle control between 1,300 and 2,500 rpm.

The following entry conditions/input signals are required to enable the APCM

Scheme 83

Scheme 84

Scheme 85

1. parking brake set
2. the automatic transmission in PARK or manual transmission in NEUTRAL with the clutch pedal released
3. brake pedal position (BPP)
4. accelerator pedal
5. hi-mount stoplamp (APCM operation with hazard lamps)

The following error codes are displayed from the APCM only

1. CErr indicates that one or both BUS circuits are open or shorted.
2. CrSd indicates a fault on BUS circuits or internal APCM fault.
3. EErr and AErr both indicate an internal APCM fault.

Follow the direction given below to aid in diagnosing the APCM fault condition

1. If APCM does not work at all, Go to AN1 .
2. If APCM does not work with hazard flashers, Go to AN7 .
3. If APCM error code CErr or CrSd are displayed, Go to AN5 .
4. If APCM error code EErr or AErr are displayed, install a new APCM.

1. P2284 = Injector Control Pressure Sensor Circuit Range/Performance
2. P2288 = Injector Control Pressure Too High

1. P2289 = Injection Control Pressure Too High - KOEO

1. P2291 = Injection Control Pressure Too Low - Engine Cranking

1. P0300 = Random Misfire Detected

1. U0105 = Loss of Communication With The FICM

1. P0148 = Fuel Error/Engine Speed Higher Than Expected.
2. P2552 = FICMM Circuit-Throttle/Fuel Inhibit Circuit.

1. P0069 = BARO/MAP Correlation

1. P0645 = A/C Clutch Relay Control Circuit

1. P2199 = Intake Air Temperature 1/2 Correlation

1. P0407 = Exhaust Gas Recirculation Sensor B Circuit Low
2. P0408 = Exhaust Gas Recirculation Sensor B Circuit High
3. P0487 = EGR Throttle Position Control Circuit
4. P0488 = EGR Throttle Position Control Range/Performance
5. P1334 = EGR Throttle Position Sensor Minimum Stop Performance

1. P0703 = Brake Switch B Input Circuit
