Engine Controls - Diagnostic Subroutines - 6.0L Diesel: Overview Ford Econoline E150

Testing & Diagnostics 2 illustrations ~234 words

Scheme 48

Scheme 48: Hard Start/No Start Diagnostic Procedures
Scheme 48: Hard Start/No Start Diagnostic Procedures

Scheme 49

Scheme 49
Scheme 49

Note. A hard start/no start concern with the engine oil temperature (EOT) below 15°C (60°F) perform Step 11 first.

Glow Plug System Operation

  1. Glow Plug Control Module (GPCM) Operation Glow plug ON time is dependent on oil temperature and altitude. The GPCM will command the glow plugs on for 1 to 120 seconds. The GPCM does not operate if the oil temperature is above 55°C (131°F). Connect the scan tool. Access and retrieve the KOEO and continuous DTCs. If GPCM DTCs are present, GO to «PINPOINT TEST AF: GLOW PLUG SYSTEM»(ref-225542-S11057899972006031800000) . Verify B+ voltage is supplied to the GPCM. Access and monitor the GPCTM and EOT PIDS to verify sufficient glow plug "ON" time. Turn the key to the ON position and measure the glow plug voltage ("ON" time). NOTE: The Wait To Start indicator "ON" time (1 -10 seconds) is independent from glow plug "ON" time. On Time Specification Measurement 1 to 120 seconds B+
  2. Glow Plug Resistance Disconnect the glow plug bus bar connector. Measure the resistance between the glow plug bus bar connector, component side and battery ground. Disconnect the GPCM. Measure the resistance between the GPCM connector, harness side and the glow plug bus bar connector, harness side.
Glow Plug NumberGlow Plug to Ground (0.1 to 2 ohms)Glow Plug Connector to GPCM Connector (less than 5 ohms)
1
3
5
7
2
4
6
8

Diagnostic Trouble Code (DTC) Descriptions

4-DigitDescriptionPinpoint Test Step GO to Direction
KOEOKOERContinuous
P0046Turbo/Super Charger Boost Control Solenoid Circuit Range/PerformanceGO to PINPOINT TEST AK .
P0069MAP/BARO CorrelationGO to PINPOINT TEST AU .
P0096Intake Air Temperature Sensor 2 Circuit Range/PerformanceGO to G: Intake Air Temperature 2 (IAT2) Sensor STEP G2.
P0097Intake Air Temperature Sensor 2 Circuit Low InputGO to G: Intake Air Temperature 2 (IAT2) Sensor STEP G6.
P0098Intake Air Temperature Sensor 2 Circuit High InputGO to G: Intake Air Temperature 2 (IAT2) Sensor STEP G8.
P0101Mass or Volume Air Flow Circuit Range/PerformanceGO to J: Mass Air Flow (MAF) Sensor STEP J2.
P0103Mass or Volume Air Flow Circuit High InputGO to J: Mass Air Flow (MAF) Sensor STEP J8.
P0107Manifold Absolute Pressure/BARO Sensor Low InputGO to H: Barometric Pressure (BARO) Sensor STEP H2.
P0108Manifold Absolute Pressure/BARO Sensor High InputGO to H: Barometric Pressure (BARO) Sensor STEP H6.
P0112Intake Air Temperature Circuit Low InputGO to F: Intake Air Temperature (IAT) Sensor STEP F2.
P0113Intake Air Temperature Circuit High InputGO to F: Intake Air Temperature (IAT) Sensor STEP F4.
P0117Engine Coolant Temperature Circuit Low InputGO to K: Engine Coolant Temperature (ECT) Sensor STEP K2.
P0118Engine Coolant Temperature High InputGO to K: Engine Coolant Temperature (ECT) Sensor STEP K4.
P0148Fueling ErrorGO to PINPOINT TEST AT .
P0196Engine Oil Temperature Sensor Circuit Range/PerformanceGO to L: Engine Oil Temperature (EOT) Sensor STEP L2.
P0197Engine Oil Temperature Sensor Circuit Low InputGO to L: Engine Oil Temperature (EOT) Sensor STEP L7.
P0198Engine Oil Temperature Sensor Circuit High InputGO to L: Engine Oil Temperature (EOT) Sensor STEP L9.
P0219Engine Overspeed Condition(1)
P0230Fuel Pump Primary CircuitGO to M: Fuel Pump Monitor/Control STEP M2.
P0231Fuel Pump Secondary Circuit LowGO to M: Fuel Pump Monitor/Control STEP M6.
P0232Fuel Pump Secondary Circuit HighGO to M: Fuel Pump Monitor/Control STEP M10.
P0236Turbo/Super Charger Boost Sensor A Circuit Range/PerformanceGO to E: Manifold Absolute Pressure (MAP) Sensor, Analog STEP E2.
P0237Turbo/Super Charger Boost Sensor A Circuit LowGO to E: Manifold Absolute Pressure (MAP) Sensor, Analog STEP E6.
P0238Turbo/Super Charger Boost Sensor A Circuit HighGO to E: Manifold Absolute Pressure (MAP) Sensor, Analog STEP E10.
P0261Cylinder #1 Injector Circuit LowGO to P: Misfire/Injector Driver Circuit Operation STEP P1.
P0262Cylinder #1 Injector Circuit HighGO to P: Misfire/Injector Driver Circuit Operation STEP P1.
P0263Cylinder #1 Contribution/BalanceGO to P: Misfire/Injector Driver Circuit Operation STEP P1.
P0264Cylinder #2 Injector Circuit LowGO to P: Misfire/Injector Driver Circuit Operation STEP P1.
P0265Cylinder #2 Injector Circuit HighGO to P: Misfire/Injector Driver Circuit Operation STEP P1.
P0266Cylinder #2 Contribution/BalanceGO to P: Misfire/Injector Driver Circuit Operation STEP P1.
P0267Cylinder #3 Injector Circuit LowGO to P: Misfire/Injector Driver Circuit Operation STEP P1.
P0268Cylinder #3 Injector Circuit HighGO to P: Misfire/Injector Driver Circuit Operation STEP P1.
P0269Cylinder #3 Contribution/BalanceGO to P: Misfire/Injector Driver Circuit Operation STEP P1.
P0270Cylinder #4 Injector Circuit LowGO to P: Misfire/Injector Driver Circuit Operation STEP P1.
P0271Cylinder #4 Injector Circuit HighGO to P: Misfire/Injector Driver Circuit Operation STEP P1.
P0272Cylinder #4 Contribution/BalanceGO to P: Misfire/Injector Driver Circuit Operation STEP P1.
P0273Cylinder #5 Injector Circuit LowGO to P: Misfire/Injector Driver Circuit Operation STEP P1.
P0274Cylinder #5 Injector Circuit HighGO to P: Misfire/Injector Driver Circuit Operation STEP P1.
P0275Cylinder #5 Contribution/BalanceGO to P: Misfire/Injector Driver Circuit Operation STEP P1.
P0276Cylinder #6 Injector Circuit LowGO to P: Misfire/Injector Driver Circuit Operation STEP P1.
P0277Cylinder #6 Injector Circuit HighGO to P: Misfire/Injector Driver Circuit Operation STEP P1.
P0278Cylinder #6 Contribution/BalanceGO to P: Misfire/Injector Driver Circuit Operation STEP P1.
P0279Cylinder #7 Injector Circuit LowGO to P: Misfire/Injector Driver Circuit Operation STEP P1.
P0280Cylinder #7 Injector Circuit HighGO to P: Misfire/Injector Driver Circuit Operation STEP P1.
P0281Cylinder #7 Contribution/BalanceGO to P: Misfire/Injector Driver Circuit Operation STEP P1.
P0282Cylinder #8 Injector Circuit LowGO to P: Misfire/Injector Driver Circuit Operation STEP P1.
P0283Cylinder #8 Injector Circuit HighGO to P: Misfire/Injector Driver Circuit Operation STEP P1.
P0284Cylinder #8 Contribution/BalanceGO to P: Misfire/Injector Driver Circuit Operation STEP P1.
P0297Vehicle Overspeed Condition(1)
P0298Engine Oil Overtemperature ConditionGO to L: Engine Oil Temperature (EOT) Sensor STEP L19.
P0299Turbo/SuperCharger Under BoostGO to PINPOINT TEST KA .
P0300Random Misfire DetectedGO to PINPOINT TEST AR .
P0301Cylinder #1 Misfire DetectedGO to P: Misfire/Injector Driver Circuit Operation STEP P7.
P0302Cylinder #2 Misfire DetectedGO to P: Misfire/Injector Driver Circuit Operation STEP P7.
P0303Cylinder #3 Misfire DetectedGO to P: Misfire/Injector Driver Circuit Operation STEP P7.
P0304Cylinder #4 Misfire DetectedGO to P: Misfire/Injector Driver Circuit Operation STEP P7.
P0305Cylinder #5 Misfire DetectedGO to P: Misfire/Injector Driver Circuit Operation STEP P7.
P0306Cylinder #6 Misfire DetectedGO to P: Misfire/Injector Driver Circuit Operation STEP P7.
P0307Cylinder #7 Misfire DetectedGO to P: Misfire/Injector Driver Circuit Operation STEP P7.
P0308Cylinder #8 Misfire DetectedGO to P: Misfire/Injector Driver Circuit Operation STEP P7.
P0335Crankshaft Position Sensor A CircuitGO to PINPOINT TEST D .
P0336Crankshaft Position Sensor A Circuit Range/PerformanceGO to PINPOINT TEST D .
P0340Camshaft Position Sensor A Circuit (Bank 1 or single sensor)GO to PINPOINT TEST V
P0341Camshaft Position Sensor A Circuit Range/Performance (Bank 1 or single sensor)GO to PINPOINT TEST V
P0381Glow Plug/Heater Indicator Circuit(2)
P0401Exhaust Gas Recirculation Flow Insufficient DetectedGO to W: Exhaust Gas Recirculation (EGR) STEP W2.
P0402Exhaust Gas Recirculation Flow Excessive DetectedGO to W: Exhaust Gas Recirculation (EGR) STEP W2.
P0403Exhaust Gas Recirculation Control CircuitGO to W: Exhaust Gas Recirculation (EGR) STEP W4.
P0404Exhaust Gas Recirculation Control Circuit Range/PerformanceGO to W: Exhaust Gas Recirculation (EGR) STEP W9.
P0405Exhaust Gas Recirculation Sensor A Circuit LowGO to W: Exhaust Gas Recirculation (EGR) STEP W10.
P0406Exhaust Gas Recirculation Sensor A Circuit HighGO to W: Exhaust Gas Recirculation (EGR) STEP W14.
P0407Exhaust Gas Recirculation Sensor B Circuit LowGO to PINPOINT TEST AX .
P0408Exhaust Gas Recirculation Sensor B Circuit HighGO to PINPOINT TEST AX .
P0460Fuel Level Sensor Circuit(2)
P0461Fuel Level Sensor Circuit Range/Performance(2)
P0470Exhaust Pressure SensorGO to X: Exhaust Pressure (EP) Sensor STEP X2.
P0471Exhaust Pressure Sensor Range/PerformanceGO to X: Exhaust Pressure (EP) Sensor STEP X6.
P0472Exhaust Pressure Sensor Low InputGO to X: Exhaust Pressure (EP) Sensor STEP X10.
P0473Exhaust Pressure Sensor High InputGO to X: Exhaust Pressure (EP) Sensor STEP X15.
P0478Exhaust Pressure Control Valve High Input
P0480Fan 1 Control CircuitGO to PINPOINT TEST AH .
P0487EGR Throttle Position Control CircuitGO to PINPOINT TEST AX .
P0488EGR Throttle Position Range/PerformanceGO to PINPOINT TEST AX .
P0500Vehicle Speed Sensor A(3)
P0528Fan Speed Sensor Circuit No SignalGO to PINPOINT TEST AH .
P0560System VoltageGO to PINPOINT TEST A .
P0562System Voltage LowGO to PINPOINT TEST A .
P0563System Voltage HighGO to PINPOINT TEST A .
P0565Cruise Control ON SignalGO to PINPOINT TEST Y .
P0566Cruise Control OFF SignalGO to PINPOINT TEST Y .
P0567Cruise Control RESUME SignalGO to PINPOINT TEST Y .
P0568Cruise Control SET SignalGO to PINPOINT TEST Y .
P0569Cruise Control COAST SignalGO to PINPOINT TEST Y .
P0603Powertrain Control Module Keep Alive Memory (KAM) ErrorGO to PINPOINT TEST Z .
P0605Powertrain Control Module Read Only Memory (ROM) ErrorGO to PINPOINT TEST AA .
P0606ECM/PCM Processor(4)
P0611Fuel Injector Control Module PerformanceGO to PINPOINT TEST S .
P0620Generator 1 Control Circuit(5)
P0623Generator Lamp Control Circuit(5)
P0645A/C Clutch Relay Control CircuitGO to PINPOINT TEST AV .
P0649Cruise Control Lamp Control Circuit(2)
P0657Actuator Supply Voltage A Circuit Open(6)
P0670Glow Plug Module Control CircuitPINPOINT TEST AF
P0671Cylinder 1 Glow Plug CircuitPINPOINT TEST AF
P0672Cylinder 2 Glow Plug CircuitPINPOINT TEST AF
P0673Cylinder 3 Glow Plug CircuitPINPOINT TEST AF
P0674Cylinder 4 Glow Plug CircuitPINPOINT TEST AF
P0675Cylinder 5 Glow Plug CircuitPINPOINT TEST AF
P0676Cylinder 6 Glow Plug CircuitPINPOINT TEST AF
P0677Cylinder 7 Glow Plug CircuitPINPOINT TEST AF
P0678Cylinder 8 Glow Plug CircuitPINPOINT TEST AF
P0683Glow Plug Control Module to PCM Communication CircuitPINPOINT TEST AF
P0700Transmission Control System (MIL Request)(6)
P0703Brake Switch B Input CircuitGO to PINPOINT TEST AY .
P0704Clutch Switch Input CircuitGO to PINPOINT TEST C .
P1000OBD Systems Readiness Test Not CompleteGO to PINPOINT TEST AC .
P1001KOER Not Able To Complete, KOER Aborted(1)
P1102Mass Air Flow Sensor In Range But Lower Than ExpectedGO to PINPOINT TEST J .
P1139Water in Fuel Indicator Circuit(2)
P1148Generator 2 Control Circuit(5)
P1149Generator 2 Control Circuit High(5)
P1184Engine Oil Temperature Sensor Out Of Self Test RangeGO to L: Engine Oil Temperature (EOT) Sensor STEP L13.
P1260Theft Detected, Vehicle Immobilized(7)
P1284Aborted KOER -Injector Control Pressure Regulator(8)
P132BTurbocharger/Supercharger Boost Control A PerformanceGO to PINPOINT TEST KA .
P1334EGR Throttle Position Sensor Minimum Stop PerformanceGO to PINPOINT TEST AX .
P1335EGR Position Sensor Minimum Stop PerformanceGO to PINPOINT TEST W .
P1378FICM Supply Voltage Circuit LowGO to S: Fuel Injector Control Module (FICM) Low Voltage STEP S2.
P1379FICM Supply Voltage Circuit HighGO to S: Fuel Injector Control Module (FICM) Low Voltage STEP S7.
P1408Exhaust Gas Recirculation Flow Out Of Self-Test Range(9)
P1464A/C Demand Out Of Self-Test RangeGO to PINPOINT TEST AM .
P1501Vehicle Speed Sensor Out Of Self-Test Range(3)
P1502Invalid Test - Auxiliary Power Control Module FunctioningGO to PINPOINT TEST AE .
P1531Invalid Test - Accelerator Pedal MovementRepeat the self-test.
P1536Parking Brake Switch CircuitGO to PINPOINT TEST I .
P1635Tire/Axle Out Of Acceptable Range(10)
P1639Vehicle ID Block Corrupted, Not Programmed(10)
P1703Brake Switch Out Of Self -Test RangeGO to PINPOINT TEST AI .
P1705Transmission Range Circuit Not Indicating Park/Neutral During Self-TestGO to PINPOINT TEST AL .
P1725Insufficient Engine Speed Increase During Self -Test(11)
P1726Insufficient Engine Speed Decrease During Self-Test(11)
P2122Throttle/Pedal Position Sensor/Switch D Circuit Low InputGO to G: Accelerator Pedal Position (APP) Sensor STEP AG2.
P2123Throttle/Pedal Position Sensor/Switch D Circuit High InputGO to G: Accelerator Pedal Position (APP) Sensor STEP AG8.
P2127Throttle/Pedal Position Sensor/Switch E Circuit Low InputGO to G: Accelerator Pedal Position (APP) Sensor STEP AG2.
P2128Throttle/Pedal Position Sensor/Switch E Circuit High InputGO to G: Accelerator Pedal Position (APP) Sensor STEP AG8.
P2132Throttle/Pedal Position Sensor/Switch F Circuit Low InputGO to G: Accelerator Pedal Position (APP) Sensor STEP AG2.
P2133Throttle/Pedal Position Sensor/Switch F Circuit High InputGO to G: Accelerator Pedal Position (APP) Sensor STEP AG8.
P2138Throttle/Pedal Position Sensor/Switch D/E Voltage CorrelationGO to G: Accelerator Pedal Position (APP) Sensor STEP AG13.
P2139Throttle/Pedal Position Sensor/Switch D/F Voltage CorrelationGO to G: Accelerator Pedal Position (APP) Sensor STEP AG13.
P2140Throttle/Pedal Position Sensor/Switch E/F Voltage CorrelationGO to G: Accelerator Pedal Position (APP) Sensor STEP AG13.
P2199Intake Air Temperature 1/2 CorrelationGO to PINPOINT TEST AW .
P2262Turbo/Super Charger Boost Pressure Not Detected - MechanicalGO to PINPOINT TEST KA .
P2263Turbo/Super Charger System PerformanceGO to PINPOINT TEST KA .
P2269Water in Fuel ConditionGO to PINPOINT TEST O .
P2284Injector Control Pressure Sensor Circuit Range/PerformanceGO to PINPOINT TEST AO .
P2285Injector Control Pressure Sensor Circuit LowGO to Q: Injection Control Pressure (ICP) Sensor STEP Q2.
P2286Injector Control Pressure Sensor Circuit HighGO to Q: Injection Control Pressure (ICP) Sensor STEP Q6.
P2287Injector Control Pressure Sensor Circuit IntermittentGO to PINPOINT TEST Q .
P2288Injector Control Pressure Too HighGO to PINPOINT TEST AO .
P2289Injector Control Pressure Too High - Engine OffGO to PINPOINT TEST AP .
P2290Injector Control Pressure Too LowGO to O: Injector Control Pressure Too High STEP AO9.
P2291Injector Control Pressure Too Low - Engine CrankingGO to PINPOINT TEST AQ .
P2552FICMM Circuit - Throttle/Fuel Inhibit CircuitGO to PINPOINT TEST AT .
P2614Camshaft Position Output CircuitGO to PINPOINT TEST V
P2617Crankshaft Position Output CircuitGO to PINPOINT TEST D .
P2623Injector Control Pressure Regulator CircuitGO to PINPOINT TEST R .
U0101Lost Communication with TCMReplace PCM.
U0105Lost Communication with FICMGO to PINPOINT TEST AS .
U0155Lost Communication with Instrument Cluster(12)
U0306Software Incompatibility with Fuel Injector Control Module(12)
B1213Less than two keys programmed to the system(7)
B1342ECU damaged (EEPROM in PCM not working, replace PCM)(7)
B1600PATS Ignition Key Transponder Signal Is Not Received(7)
B1601PATS Received Incorrect Key-Code From Ignition Key Transponder(7)
B1602PATS Received Invalid Format Of Key-Code From Ignition Key Transponder(7)
B1681PATS Transceiver Module Signal Is Not Received(7)
B2103Antenna Not Connected(7)
B2431Transponder Programming Failed(7)
P1610Interactive Reprogramming Code - Replace PCM moduleReflash the module.
P1611Interactive Reprogramming Code - Diagnose FurtherReflash the module.
P1615Interactive Reprogramming Code - Flash Erase ErrorReflash the module.
P1616Interactive Reprogramming Code - Flash Erase Error, Low VoltageReflash the module.
P1617Interactive Reprogramming Code - Block Programming ErrorReflash the module.
P1618Interactive Reprogramming Code - Block Programming Error, Low VoltageReflash the module.
Malfunction Indicator(13)
(1) Rerun self-test, refer to Symptom Quick Test for further diagnostic information. (2) Refer to the appropriate INSTRUMENT CLUSTER article for diagnostic procedures. (3) For F-Super Duty/Excursion, vehicle speed information is provided by the anti-lock brake system. Refer to ANTI-LOCK CONTROL - 4-WHEEL - EXCURSION & F250-F550 SUPER DUTY PICKUP . For E-Series, Refer to the appropriate AUTOMATIC TRANSAXLE/TRANSMISSION article. (4) Clear the DTCs. Repeat the self-test. If the DTC is retrieved again, install a new PCM. (5) Refer to the appropriate GENERATORS & REGULATORS article for diagnostic procedures. (6) Refer to the appropriate AUTOMATIC TRANSAXLE/TRANSMISSION article for diagnostic procedures. (7) Refer to the appropriate ANTI-THEFT article for diagnostic procedures. (8) Carry out the KOEO self-test. Diagnose all other DTCs first. Clear the DTCs. Repeat the KOER self test. If DTC P1284 is retrieved again, refer to the PERFORMANCE DIAGNOSTIC PROCEDURES to diagnose the high pressure oil system. (9) Refer to PERFORMANCE DIAGNOSTIC PROCEDURES for further diagnostics. (10) Refer to FLASH ELECTRICALLY ERASABLE PROGRAMMABLE READ ONLY MEMORY - FLASH EEPROM (11) If the Glow Plug Monitor Self-Test aborts and this DTC is present, repeat the Glow Plug Monitor Self-Test. (12) Refer to the appropriate MODULE COMMUNICATIONS NETWORK for diagnostic procedures. (13) Malfunction indicator lamp concerns, Refer to SYMPTOM CHARTS - 6.0L DIESEL
(1)Rerun self-test, refer to Symptom Quick Test for further diagnostic information.
(2)Refer to the appropriate INSTRUMENT CLUSTER article for diagnostic procedures.
(3)For F-Super Duty/Excursion, vehicle speed information is provided by the anti-lock brake system. Refer to ANTI-LOCK CONTROL - 4-WHEEL - EXCURSION & F250-F550 SUPER DUTY PICKUP . For E-Series, Refer to the appropriate AUTOMATIC TRANSAXLE/TRANSMISSION article.
(4)Clear the DTCs. Repeat the self-test. If the DTC is retrieved again, install a new PCM.
(5)Refer to the appropriate GENERATORS & REGULATORS article for diagnostic procedures.
(6)Refer to the appropriate AUTOMATIC TRANSAXLE/TRANSMISSION article for diagnostic procedures.
(7)Refer to the appropriate ANTI-THEFT article for diagnostic procedures.
(8)Carry out the KOEO self-test. Diagnose all other DTCs first. Clear the DTCs. Repeat the KOER self test. If DTC P1284 is retrieved again, refer to the PERFORMANCE DIAGNOSTIC PROCEDURES to diagnose the high pressure oil system.
(9)Refer to PERFORMANCE DIAGNOSTIC PROCEDURES for further diagnostics.
(10)Refer to FLASH ELECTRICALLY ERASABLE PROGRAMMABLE READ ONLY MEMORY - FLASH EEPROM
(11)If the Glow Plug Monitor Self-Test aborts and this DTC is present, repeat the Glow Plug Monitor Self-Test.
(12)Refer to the appropriate MODULE COMMUNICATIONS NETWORK for diagnostic procedures.
(13)Malfunction indicator lamp concerns, Refer to SYMPTOM CHARTS - 6.0L DIESEL

DIAGNOSTIC TROUBLE CODE (DTC) DESCRIPTIONS

More articles — Engine Controls - Diagnostic Subroutines - 6.0L Diesel
