Engine Cooling System - 2.0L: Removal & Installation Ford C-MAX II

Removal

Note. Removal steps in this procedure may contain installation details.

1. WARNING: Before beginning any service procedure in this article, refer to Safety Warnings in «GENERAL INFORMATION»(ref-635189) . Failure to follow this instruction may result in serious personal injury. Refer to: «ENGINE COOLING SYSTEM HEALTH AND SAFETY PRECAUTIONS»(ref-635189-S05974742782014070200000) .
2. Refer to: «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-635217-S18215536912014070200000) .
3. Refer to: «CATALYTIC CONVERTER - HYBRID ELECTRIC VEHICLE (HEV)»(ref-635253-S36882817412014070200000) .
4. NOTE: Note the position of the component before removal. NOTE: Make sure that the component is installed to the position noted before removal. Torque : 30 lb.ft (40 Nm)

Installation

1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 10

1. WARNING: Before beginning any service procedure in this article, refer to Safety Warnings in «GENERAL INFORMATION»(ref-635189) . Failure to follow this instruction may result in serious personal injury. Refer to: «ENGINE COOLING SYSTEM HEALTH AND SAFETY PRECAUTIONS»(ref-635189-S05974742782014070200000) .
2. Refer to: «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-635217-S18215536912014070200000) .
3. NOTE: Do not allow coolant or any fluid to spill into the coolant pump wiring connector or the coolant pump wiring harness connector. If fluid is spilled or found in the coolant pump wiring connector, install a new coolant pump. If fluid is found in the coolant pump wiring harness connector, thoroughly dry the coolant pump wiring harness connector. Only connect the coolant pump wiring harness connector to the coolant pump wiring connector when both are completely dry. NOTE: Be prepared to capture escaping fluid. Use the General Equipment: Hose Clamp Remover/Installer
4. NOTE: Be prepared to capture escaping fluid. Use the General Equipment: Hose Clamp Remover/Installer M8 Bolt Torque : 18 lb.ft (25 Nm) M6 Bolt Torque : Stage 1: 89 lb.in (10 Nm) Stage 2: 90°

Scheme 11

1. NOTE: Three 2-piece grommet (a rubber overmolded aluminum torque limiter and a black rubber ring) assemblies must be present on the electric coolant pump before assembling it to the bracket.
2. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 12

Scheme 13

Scheme 14

Scheme 15

Scheme 16

1. WARNING: Before beginning any service procedure in this article, refer to Safety Warnings in «GENERAL INFORMATION»(ref-635189) . Failure to follow this instruction may result in serious personal injury. Refer to: «ENGINE COOLING SYSTEM HEALTH AND SAFETY PRECAUTIONS»(ref-635189-S05974742782014070200000) .
2. Refer to: «JACKING AND LIFTING - OVERVIEW»(ref-635208-S40563097982014070200000) .
3. Use the General Equipment: Cable Ties
4. Torque : 44 lb.in (5 Nm)
5. Torque : 18 lb.ft (25 Nm)
6. Torque : 18 lb.ft (25 Nm)
7. Torque : 44 lb.in (5 Nm)

1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 17

Scheme 18

Scheme 19

Scheme 20

Scheme 21

Scheme 22

1. WARNING: Before beginning any service procedure in this article, refer to Safety Warnings in «GENERAL INFORMATION»(ref-635189) . Failure to follow this instruction may result in serious personal injury. Refer to: «ENGINE COOLING SYSTEM HEALTH AND SAFETY PRECAUTIONS»(ref-635189-S05974742782014070200000) .
2. Refer to: «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-635217-S18215536912014070200000) .
3. Refer to: «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-635216-S38165086382014070200000) .
4. Refer to: «AIR CONDITIONING (A/C) SYSTEM RECOVERY, EVACUATION AND CHARGING»(ref-635194-S13131673022014070200000) .
5. Refer to: «ACTIVE GRILLE SHUTTER»(ref-635237-S38052633542014070200000) .
6. Torque : 133 lb.in (15 Nm)
7. NOTE: Be prepared to capture escaping fluid Plug holes and lines to minimize fluid loss. Torque : 18 lb.ft (25 Nm)
8. Both sides. Torque : 18 lb.ft (25 Nm)
9. This procedure step requires the specified number of technicians. Torque : 18 lb.ft (25 Nm)

1. To install, reverse the removal procedure.
2. Check and top off the transmission fluid.

Note. Removal steps in this procedure may contain installation details.

1. To install, reverse the removal procedure.
2. Fill the cooling system through the degas bottle to the MAX line. Material : Motorcraft® Orange Antifreeze/Coolant Prediluted (U.S.)/VC-3DIL-B (U.S.) (WSS-M97B44-D2)
3. Perform the cooling system bleed procedure. Refer to: «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-635217-S18215536912014070200000) .

Note. Removal steps in this procedure may contain installation details.

Scheme 23

Scheme 24

Scheme 25

Scheme 26

1. WARNING: Before beginning any service procedure in this article, refer to Safety Warnings in «GENERAL INFORMATION»(ref-635189) . Failure to follow this instruction may result in serious personal injury. Refer to: «ENGINE COOLING SYSTEM HEALTH AND SAFETY PRECAUTIONS»(ref-635189-S05974742782014070200000) .
2. Refer to: «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-635217-S18215536912014070200000) .
3. Refer to: «COOLING FAN MOTOR AND SHROUD»(ref-635217-S32768020702014070200000) .
4. Refer to: «ACTIVE GRILLE SHUTTER»(ref-635237-S38052633542014070200000) .
5. Install the General Equipment: Remove the General Equipment
6. Relocate and support the component. Torque : 53 lb.in (6 Nm)
7. Use the General Equipment: Knife

1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

1. WARNING: Before beginning any service procedure in this article, refer to Safety Warnings in «GENERAL INFORMATION»(ref-635189) . Failure to follow this instruction may result in serious personal injury. Refer to: «ENGINE COOLING SYSTEM HEALTH AND SAFETY PRECAUTIONS»(ref-635189-S05974742782014070200000) .
2. Refer to: «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-635217-S18215536912014070200000) .
3. NOTE: Be prepared to contain escaping fluid. Torque : 89 lb.in (10 Nm)
4. Discard the specified component. Follow local disposal regulations.

1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 27

Scheme 28

1. WARNING: Before beginning any service procedure in this article, refer to Safety Warnings in «GENERAL INFORMATION»(ref-635189) . Failure to follow this instruction may result in serious personal injury. Refer to: «ENGINE COOLING SYSTEM HEALTH AND SAFETY PRECAUTIONS»(ref-635189-S05974742782014070200000) .
2. Refer to: «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-635217-S18215536912014070200000) .
3. NOTE: Be prepared to capture escaping fluid. Use the General Equipment: Hose Clamp Remover/Installer
4. Use the General Equipment: Hose Clamp Remover/Installer Torque : 89 lb.in (10 Nm)

1. To install, reverse the removal procedure.

All vehicles

1. To install, reverse the removal procedure.
