Lubricants, Fluids, Sealants and Adhesives
| Name | Specification | Fill Capacity |
|---|---|---|
| Motorcraft® Orange Antifreeze/Coolant Prediluted (U.S.) VC-3DIL-B (U.S.) | WSS-M97B44-D2 | Total volume 1.06 qt (1.0 L), Initial fill 0.74 qt (0.7 L) |
| Item | Part Number | Description |
|---|---|---|
| 1 | 8C351 | Coolant expansion tank-to-secondary on board diagnostic module C/transmission control module (SOBDMC/TMC) hose |
| 2 | 8C045 | Coolant expansion tank |
| 3 | 7B012 | Secondary on board diagnostic module C/transmission control module (SOBDMC/TCM) (Refer to AUTOMATIC TRANSAXLE - HF35 ) |
| 4 | 7A095 | Radiator/transmission fluid cooler assembly |
| 5 | 8B274 | Upper hose and clamp assembly |
| 6 | 18D474 | Coolant pump |
| 7 | 8B273 | Lower hose and clamp assembly |
Cooling System Draining, Filling and Bleeding
Special Tool(s)/General Equipment
Hose Clamp Remover/Installer
| Name | Specification |
|---|---|
| Motorcraft® Orange Antifreeze/Coolant Prediluted (U.S.) VC-3DIL-B (U.S.) | WSS-M97B44-D2 |
MATERIALS SPECIFICATIONS
Scheme 6
- WARNING: Before beginning any service procedure in this article, refer to Safety Warnings in «GENERAL INFORMATION»(ref-635189) . Failure to follow this instruction may result in serious personal injury. Refer to: «ENGINE COOLING SYSTEM HEALTH AND SAFETY PRECAUTIONS»(ref-635189-S05974742782014070200000) .
- Refer to: «JACKING AND LIFTING - OVERVIEW»(ref-635208-S40563097982014070200000) .
- NOTE: Be prepared to capture escaping fluid. Use the General Equipment: Hose Clamp Remover/Installer
Scheme 7
Scheme 8
- Use the General Equipment: Hose Clamp Remover/Installer
- NOTE: Remove the 2 bolts from the SOBDMC/ TCM coolant expansion tank and raise the front of the reservoir to about a 30 degree angle. This will speed the initial fill process and ensure adequate initial fill volume. Angle: 30°
- NOTE: Fill the coolant expansion tank until air bubbles stop entering the tank from the SOBDMC/ TCM . Material: Motorcraft® Orange Antifreeze/Coolant Prediluted (U.S.)/VC-3DIL-B (U.S.) (WSS-M97B44-D2)
- Torque: 71 lb.in (8 Nm)
