Engine Cooling System - 2.0L: Maintenance Ford C-MAX II

Cooling System (Mechanical) 2 illustrations

Lubricants, Fluids, Sealants and Adhesives

Name	Specification	Fill Capacity
Motorcraft® Orange Antifreeze/Coolant Concentrated (U.S.) VC-3-B (U.S.)	WSS-M97B44-D	FHEV: Total volume 8.2 qt (7.8 L), Initial fill 7.1 qt (6.7 L); PHEV: Total volume 8.7 qt (8.3 L), Initial fill 6.1 qt (5.7L)

Name	Specification	Fill Capacity
Motorcraft® Orange Antifreeze/Coolant Prediluted (U.S.) VC-3DIL-B (U.S.)	WSS-M97B44-D2	FHEV: Total volume 8.2 qt (7.8 L), Initial fill 7.1 qt (6.7 L); PHEV: Total volume 8.7 qt (8.3 L), Initial fill 6.1 qt (5.7L)

Lubricants, Fluids, Sealers and Adhesives

	Specifications
Motorcraft® Orange Antifreeze/Coolant Concentrated VC-3-B (US); CVC-3-B2 (Canada)	WSS-M97B44-D
Motorcraft® Orange Antifreeze/Coolant Prediluted VC-3DIL-B (US); CVC-3DIL-B (Canada)	WSS-M97B44- D2

Cooling System Draining, Filling and Bleeding

SPECIAL TOOL DESCRIPTIONS ROB75240 Coolant/Battery Refractometer (Fahrenheit) Cooling System Vacuum Tester and Refiller

Name	Specification
Motorcraft® Orange Antifreeze/Coolant Prediluted (U.S.) VC-3DIL-B (U.S.)	WSS-M97B44-D2
Motorcraft® Orange Antifreeze/Coolant Concentrated (U.S.) VC-3-B (U.S.)	WSS-M97B44-D

MATERIALS SPECIFICATIONS

Scheme 29

Scheme 29: Draining

Scheme 29: Draining

Scheme 30

Scheme 30

Scheme 30

WARNING: Before beginning any service procedure in this article, refer to Safety Warnings in «GENERAL INFORMATION»(ref-635189) . Failure to follow this instruction may result in serious personal injury. Refer to: «ENGINE COOLING SYSTEM HEALTH AND SAFETY PRECAUTIONS»(ref-635189-S05974742782014070200000) .
Refer to: «JACKING AND LIFTING - OVERVIEW»(ref-635208-S40563097982014070200000) .
NOTE: Use a drain hose to drain the coolant.
