DTC P0107: MAP SENSOR VOLTAGE TOO LOW Dodge Ram Wagon B1500

Note. For connector terminal identification, see CONNECTOR IDENTIFICATION . For circuit identification and wiring diagram, see RAM VAN & RAM WAGON wiring diagram in WIRING DIAGRAMS article.

Note. DTC P0107: MAP SENSOR VOLTAGE TOO LOW is monitored when engine speed is more than 416 RPM but less than 3520 RPM, Throttle Position (TP) sensor voltage is less than 1.13 volt and battery voltage more than 10.4 volts. DTC may be stored in Powertrain Control Module (PCM) when PCM senses Manifold Absolute Pressure (MAP) sensor voltage is less than .1 volt for 2 seconds with engine running. Possible causes are: defective MAP sensor, defective PCM, defective connectors or defective wiring.

Scheme 26

1. Start engine and allow it to idle. Using scan tool, read MAP sensor voltage. If voltage is less than.2 volt, turn ignition off and go to step 3). If voltage is.2 volt or more, turn ignition off and go to next step.
2. Turn ignition on, with engine off. Using scan tool, read MAP sensor voltage. If voltage is less than 2.35 volts, go to next step. If voltage is 2.35 volts or more, go to step 8).
3. Turn ignition on, with engine off. Disconnect MAP sensor connector. (Scheme 26) Clean and/or repair connector as necessary. Using a voltmeter, check voltage on MAP sensor connector, 5-volt supply circuit (Orange wire). If voltage is more than 4.5 volts, go to next step. If voltage is 4.5 volts or less, repair open in 5-volt supply circuit. Perform TEST VER-5A.
4. Ensure MAP sensor connector is still disconnected. Ensure ignition is on, with engine off. Using scan tool, read MAP sensor voltage. If voltage is more than 4.5 volts, replace MAP sensor. Perform TEST VER-5A. If voltage is 4.5 volts or less, go to next step.
5. Turn ignition off. Ensure MAP sensor connector is still disconnected. Disconnect PCM connectors. PCM is located in engine compartment. See PCM LOCATION table under SYSTEM DIAGNOSTICS. Clean and/or repair connectors as necessary. Using an ohmmeter, check resistance between ground and MAP sensor connector, signal circuit (Dark Green/Red wire). If resistance is less than 5 ohms, repair short to ground in signal circuit. Perform TEST VER-5A. If resistance is 5 ohms or more, go to next step.
6. Ensure ignition is off. Ensure MAP sensor and PCM connectors are still disconnected. Using ohmmeter, check resistance between MAP sensor connector, signal circuit (Dark Green/Red wire) and sensor ground circuit (Black/Light Blue wire). If resistance is less than 5 ohms, repair signal circuit for short to sensor ground circuit. Perform TEST VER-5A. If resistance is 5 ohms or more, go to next step.
7. At this time, PCM is assumed to be defective. Replace PCM. Perform TEST VER-5A.
8. Turn ignition off. Visually inspect related connectors and wiring harness. Repair connectors and wiring harness as necessary. Perform TEST VER-5A. If connectors and wiring harness are okay, go to next step.
9. Turn ignition on, with engine off. Wiggle connectors and wiring harness from MAP sensor to PCM while monitoring MAP sensor voltage. (Scheme 26) PCM is located in engine compartment. See PCM LOCATION table under SYSTEM DIAGNOSTICS. If voltage changes while wiggling connectors and wiring harness, repair connectors and wiring harness that caused voltage to change. Perform TEST VER-5A. If voltage does not change, go to next step.
10. Ensure ignition is on, with engine off. Using scan tool, read and record FREEZE FRAME data. Ensure CAUSED BY DTC matches DTC on DTC screen. If DTC matches, road test vehicle under conditions in FREEZE FRAME data. Using scan tool, read DTCs. If DTC P0107: MAP SENSOR VOLTAGE TOO LOW returns, visually inspect related connectors and wiring harness for damage. Repair connectors and wiring harness as necessary. Perform TEST VER-5A. If DTC P0107: MAP SENSOR VOLTAGE TOO LOW does not return, see «INACTIVE DTC CONDITION»(ref-139160-S32382818132002042600000). Test is complete.
