TORQUE SPECIFICATIONS
| DESCRIPTION | N-m | Ft. Lbs. | In. Lbs. |
|---|---|---|---|
| Plug, Detent | 16-25 | 12-18 | |
| Plug, Drain/Fill | 20-34 | 15-25 | |
| Bolt, Extension Housing | 27-34 | 20-25 | |
| Bolt, Case Half | 27-34 | 20-25 | |
| Nut, Range Lever | 27-34 | 20-25 | |
| Sector Support | 27-34 | 20-25 | |
| Nuts, Mounting | 30-41 | 20-30 | |
| Position Sensor | 20-34 | 15-25 | |
| Nut, Companion Flange | 176-271 | 130-200 |
TRANSFER CASE (NV271) TORQUE SPECIFICATIONS
Scheme 106
Scheme 107
Scheme 108
Scheme 109
Scheme 110
Scheme 111
Scheme 112
Scheme 113
Scheme 114
Scheme 115
Scheme 116
Scheme 117
Scheme 118
Scheme 119
- Raise and support vehicle.
- Remove rear propeller shaft. (Refer to «PROPELLER SHAFT»(ref-189646) )
- Use a suitable chisel or pry tool to remove the rear extension housing dust boot (Scheme 119)
- Use a suitable chisel or pry tool to remove the rear extension housing seal.
Scheme 120
- Clean fluid residue from sealing surface and inspect for defects.
- Install the extension housing dust boot and seal assembly with Installer 9037 and Handle C-4171 (Scheme 120)
- Install propeller shaft. (Refer to «PROPELLER SHAFT»(ref-189646) )
- Verify proper transfer case fluid level.
- Lower vehicle.
