Transfer Case - NV243: Specifications Dodge Pickup R2500

Transfer Case 13 illustrations

TORQUE SPECIFICATIONS

DESCRIPTIONN.mFt. Lbs.In. Lbs.
Plug, Detent16-2412-18
Plug, Drain/Fill40-4530-40
Bolt, Extension Housing16-2412-18
Bolt, Case Half20-2715-24
Screw, Oil Pump12-168-12
Nuts, Mounting30-4120-30
Bolts, Shift Motor and Mode Sensor Assembly16-2412-18

TRANSFER CASE (NV243) TORQUE SPECIFICATIONS

Scheme 220

Scheme 220: TRANSFER CASE - NV241/NV243
Scheme 220: TRANSFER CASE - NV241/NV243

Scheme 221

Scheme 221
Scheme 221

Scheme 222

Scheme 222
Scheme 222

Scheme 223

Scheme 223
Scheme 223

Scheme 224

Scheme 224
Scheme 224

Scheme 225

Scheme 225
Scheme 225

Scheme 226

Scheme 226
Scheme 226

Scheme 227

Scheme 227
Scheme 227

Scheme 228

Scheme 228
Scheme 228

Scheme 229

Scheme 229
Scheme 229

Scheme 230

Scheme 230
Scheme 230

Scheme 231

Scheme 231
Scheme 231

Scheme 232
