Transfer Case - NV241 Genii: Specifications Dodge Pickup R2500

Transfer Case 13 illustrations

TORQUE SPECIFICATIONS

DESCRIPTIONN-mFt. Lbs.In. Lbs.
Plug, Detent16-2412-18
Plug, Drain/Fill40-4530-40
Bolt, Extension Housing16-2412-18
Bolt, Case Half20-2715-24
Screw, Oil Pump12-168-12
Nut, Range Lever27-3420-25
Sector Support27-4220-30
Nuts, Mounting30-4120-30
Position Sensor20-3416-25

TRANSFER CASE (NV241 GENII) TORQUE SPECIFICATIONS

Scheme 1

Scheme 1: TRANSFER CASE - NV241/NV243
Scheme 1: TRANSFER CASE - NV241/NV243

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9
Scheme 9

Scheme 10

Scheme 10
Scheme 10

Scheme 11

Scheme 11
Scheme 11

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13
Scheme 13
