Intermittent Condition, Pcm/ecm Reprogramming - Gas, Powertrain Verification Test & Pre-Diagnostic Troubleshooting Procedure: Other Dodge Durango III

Testing & Diagnostics 1 illustration ~1242 words

PCM/TCM FLASH REPROGRAMMING

This procedure is required when one or more of the following situations are true

  1. A Powertrain Control Module (PCM) has been replaced.
  2. Diagnostic Trouble Code (DTC) P1602 - PCM Not Programmed is set.
  3. An updated calibration or software release is available for either the PCM or TCM.

This procedure assumes that the wiTECH™ VCI Pod and StarMOBILE® devices are properly configured to the dealership network with either a wired or wireless connection. The wiTECH™ VCI Pod and StarMOBILE® must also be running the latest operating system and software release. For help on how to network the StarMOBILE®, reference the appropriate Quick Start Networking Guide available on 'DealerCONNECT > Service > StarSCAN® and StarMOBILE® Tools > Online Documentation' or at www.dcctools.com, under the Download Center. For help on how to network the wiTECH™ VCI Pod, use the "Help" tab at the top of the wiTECH™ Diagnostic Application.

TABLE OF CONTENTS

  1. Refer to «SECTION 1 - PCM/TCM FLASH PROCEDURE»(ref-466029-S02390506602012042300000)
  2. Refer to «REQUIRED TOOLS/EQUIPMENT»(ref-466029-S31607924642012042300000)
  3. Refer to «TECH TIPS AND INFORMATION»(ref-466029-S34360245432012042300000)
  4. Refer to «PARTS REQUIRED»(ref-466029-S15160662422012042300000)

SECTION 1 - PCM/TCM FLASH PROCEDURE

If using the wiTECH™ Diagnostic Application, go to Refer to REPAIR PROCEDURE - USING WITECH™ DIAGNOSTIC APPLICATION .

If using the StarMOBILE® Desktop Client, go to Refer to REPAIR PROCEDURE - USING STARMOBILE® DESKTOP CLIENT .

REPAIR PROCEDURE - USING STARMOBILE® DESKTOP CLIENT

Note. If this flash process is interrupted or aborted, the flash should be restarted.

  1. Open the hood of the vehicle and install a battery charger. Verify that the charging rate provides a continuous charge of 13.2 - 13.5 volts.
  2. Connect the StarMOBILE® to the vehicle data link connector located under the steering column and turn the ignition key to the "RUN" position.
  3. Power on the StarMOBILE®. Launch the StarMOBILE® Desktop Client and connect to the appropriate StarMOBILE® device.
  4. Retrieve the old ECU P/N. From the StarMOBILE® Home screen: Select "ECU View" Select "PCM" Select "More Options" Select "ECU Flash" Record the P/N at the top of the Flash PCM screen for later reference.
  5. Program the ECU. From the StarMOBILE® Home screen: Select "ECU View" Select "PCM" Select "More Options" Select "ECU Flash" Select "Browse for New File" and follow the on screen instructions. Highlight the appropriate calibration based on the P/N recorded in Step 4 e , or by using Year/Model/Engine and appropriate emissions selection for the vehicle being worked on. NOTE: If the tool is not connected to the vehicle, flash files can be searched for by selecting the "Flash Download" button from the Home screen. Select "Download to Scantool" Once the download is complete, select "Close" and then "Back" Highlight the listed calibration, select "Update Controller" and follow the on screen instructions. When the PCM update is complete, select "OK" Verify that the P/N at the top of the Flash PCM screen has updated to the new part number. NOTE: If the flash process is interrupted or aborted, the flash should be restarted.
  6. Continue to complete the process if the ECU has been replaced. Refer to «SECTION 2 - ADDITIONAL PCM/TCM REPLACEMENT PROCEDURES»(ref-466029-S23721719042012042300000) .
  7. Type the necessary information on the "Authorized Modification Label" (P/N 04275086AB) and attach near the VECI label (See for details). Refer to «SECTION 3 - AUTHORIZED MODIFICATION LABEL»(ref-466029-S02849327982012042300000) .

Check PCM Odometer

From the "Home" screen, select "ECU View".

  1. Select "PCM"
  2. Select "Misc. Functions"
  3. Select "Check PCM Odometer" and follow the on screen instructions.
  4. When complete, select "Finish".

Check PCM VIN

From the "Home" screen, select "ECU View"

  1. Select "PCM"
  2. Select "Misc. Functions"
  3. Select "Check PCM VIN" and follow the on screen instructions.
  4. When complete, select "Finish"

Initialize CVT

From the "Home" screen, select "ECU View"

  1. Select "TCM"
  2. Select "Misc. Functions"
  3. Select "Initialize CVT" and follow the on screen instructions.
  4. When complete, select "Finish"

Initialize EGS

From the "Home" screen, select "ECU View"

  1. Select "TCM"
  2. Select "Misc. Functions"
  3. Select "Initialize EGS" and follow the on screen instructions.
  4. When complete, select "Finish"

Learn ETC

From the "Home" screen, select "ECU View"

  1. Select "PCM"
  2. Select "Misc. Functions"
  3. Select "Learn ETC" and follow the on screen instructions.
  4. When complete, select "Finish"

Quicklearn

From the "Home" screen, select "ECU View"

  1. Select "PCM"
  2. Select "Misc. Functions"
  3. Select "Quicklearn" and follow the on screen instructions.
  4. When complete, select "Finish"

Update CVT TCM

From the "Home" screen

  1. Select "ECU View"
  2. Select "TCM"
  3. Select "More Options"
  4. Select "ECU Flash"
  5. Select "Browse for New File" and follow the on screen instructions.
  6. Highlight the appropriate calibration.
  7. Select "Download to Scantool"
  8. Once the download is complete, select "Close" and then "Back"
  9. Highlight the listed calibration, select "Update Controller" and follow the on screen instructions.
  10. When the TCM update is complete, select "OK"
  11. Verify that the part number at the top of the "Flash TCM" screen has updated to the latest level.

SECTION 3 - AUTHORIZED MODIFICATION LABEL

Note. The following step is required by law when reprogramming a PCM and/or TCM.

Type the necessary information on the "Authorized Modification Label" and attach near the VECI label.

Scheme 510

Scheme 510: SECTION 3 - AUTHORIZED MODIFICATION LABEL
Scheme 510: SECTION 3 - AUTHORIZED MODIFICATION LABEL
  1. Powertrain Control/Transmission Control Module Part Numbers (Insert P/Ns) Used
  2. Change Authority: TSB XX--XX
  3. Dealer Code: XXXXX
  4. Date: XX-XX-XX

REQUIRED TOOLS/EQUIPMENT

PART NUMBERStarMOBILE®PART NUMBERWiTECH™
NPNBattery ChargerNPNBattery Charger
CH9801StarMOBILE® Tool KitNPNWiiTECH™ Tool Kit
CH9804StarMOBILE® Vehicle CableNPNTechCONNECT PC or equivalent
NPNTechCONNECT PC or equivalent

TECH TIPS AND INFORMATION

  1. The wiTECH™ Diagnostic Application is the preferred method for flashing any Chrysler vehicle ECU. Training aids, including videos, are included under the "Help" tab in the wiTECH™ Diagnostic Application.
  2. To use the StarMOBILE® in Pass-Through Mode requires that the StarMOBILE® is connected to the dealership's network via a wired or wireless connection. For more information on how to use the StarMOBILE in Pass-Through Mode, see the StarMOBILE® training tutorials available on 'DealerCONNECT > Service > StarSCAN® and StarMOBILE® Tools > Training Aids' link or at www.dcctools.com, under the 'Training Aids' link.
  3. If the flash process is interrupted or aborted, the flash should be restarted.
  4. Due to the PCM/TCM programming procedure, a DTC may be set in other ECUs within the vehicle. Some DTCs may cause the MIL to illuminate. From the "Home" screen select "System View". Then select "All DTCs". Press "Clear All Stored DTCs" if there are any DTCs shown on the list.
  5. When replacing a GPEC PCM for a vehicle that is equipped with a CVT, it is extremely important that the PCM and TCM both have the latest software calibrations.
  6. Do not allow the battery charger to time out or the charging rate to climb above 13.5 volts during the flash process.
  7. The StarMOBILE® diagnostic tools fully support Internet connectivity and must be configured for the dealership network. For help on setting up the StarMOBILE® for the dealership network, refer to the StarMOBILE® Quick Start Networking Guide available on 'DealerCONNECT > Service > StarSCAN® and StarMOBILE® Tools > Online Documentation' or at www.dcctools.com, under the download center.
  8. The operating software in the wiTECH™ VCI Pod, wiTECH™ Diagnostic Application, and StarMOBILE® must be programmed with the latest software release. The software level is visible in the blue header at the top of the wiTECH™ Diagnostic Application and StarMOBILE® Desktop Client screens. For instructions on how to update the StarMOBILE®, refer to the StarMOBILE® Update guide available on 'DealerCONNECT > Service > StarSCAN® and StarMOBILE® Tools > Online Documentation' or at www.dcctools.com, under the Download Center. For instructions on how to update the wiTECH™ VCI Pod or wiTECH™ Diagnostic Application, use the "Help" tab at the top of the wiTECH™ Diagnostic Application.

PARTS REQUIRED

QtyPart NumberDESCRIPTION
104275086ABLabel, Authorized Modification

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .
