Automatic Highbeam Module (Ahbm) - Electrical Diagnostics: Other Dodge Durango III

WHEN MONITORED

With the ignition on.

SET CONDITION

The DTC will be set if the target light source is not within the correctable limits of the mirror.

POSSIBLE CAUSES

With the ignition on.

The DTC will be set if the target light source is not within the correctable limits of the mirror.

With the ignition on.

The DTC will be set if the target light source is not within the correctable limits of the mirror.

With the ignition on.

The DTC will be set if the target light source is not within the correctable limits of the mirror.

B17F3-00-AUTO HIGH BEAM SYSTEM AIM

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition on.

The DTC will be set if the target light source is not within the correctable limits of the mirror.

With the ignition on.

The Auto High Beam Module detects the supply circuit voltage below 10.0 volts.

Scheme 36

1. CHECK FOR AN ACTIVE DTC Turn the ignition on. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) .
2. (F943) FUSED IGNITION SWITCH OUTPUT (RUN-START) CIRCUIT SHORTED TO GROUND Turn the ignition off. NOTE: The AHBM is part of the Rearview Mirror. Disconnect the AHBM (Rearview Mirror) harness connector. Measure the resistance between ground and the (F943) Fused Ignition Switch Output (Run-Start) circuit. Is the resistance below 10K Ohms? Yes Repair the short to ground in the (F943) Fused Ignition Run/Start circuit. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) . No Inspect the wiring and connectors for damage or shorted circuits. If OK, replace and program the AHBM (Rearview Mirror) in accordance with the Service Information. Refer to «MIRROR, REARVIEW , REMOVAL»(ref-465921-S19421942362012042300000) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) .

B210B-85-SYSTEM VOLTAGE HIGH

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition on.

The Auto High Beam Module detects the (F943) Fused Ignition Switch Output (Run-Start) circuit voltage is shorted high.

Scheme 37

1. CHECK FOR ACTIVE DTC Turn the ignition on. With the scan tool, read the active DTCs. Does the scan tool display this DTC as active? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) .
2. (F943) FUSED IGNITION SWITCH OUTPUT (RUN-START) CIRCUIT SHORTED TO VOLTAGE Turn the ignition off. Remove Fuse M15 from the TIPM. Disconnect the AHBM (Rearview Mirror) harness connector. Turn the ignition on. Measure the voltage of the (F943) Fused Ignition Switch Output (Run-Start) circuit. Is there any voltage present? Yes Repair the short to voltage in the (F943) Fused Ignition Switch Output (Run-Start) circuit. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) . No Inspect the wiring and connectors for damage or shorted circuits. If OK, replace the TIPM in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) .

B210D-84-BATTERY VOLTAGE LOW

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition on.

Battery voltage less than 9 volts for more than 15 seconds.

B210E-85-BATTERY VOLTAGE HIGH

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition on.

Battery voltage greater than 16 volts for more than 15 seconds.

B223A-00-AUTO HIGH BEAM ECU INTERNAL

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition on.

The Auto High Beam Module detects an internal fault.

Continuously when the ignition is on.

Battery voltage between 10 and 16 volts.

Ignition Off Draw (IOD) fuse installed.

The controller detects a short to ground on the CAN Interior Bus (125K) (+) circuit or a short to voltage on the CAN Interior Bus (125K) (-) circuit.

Continuously when the ignition is on.

Battery voltage between 10 and 16 volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the Integrated Power Module (TIPM) for approximately two to five seconds.

Continuously when the ignition is on.

Battery voltage between 10 and 16 volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the Instrument Cluster (CCN) for approximately two to five seconds.
