Power Windows - Non-Dtc-Based Diagnostics: Diagnosis Dodge Durango III

DIAGNOSTIC TEST

1. WINDOW MOTOR NOT CALIBRATED Run the window to the full up position and continue to hold the switch for an additional two seconds. Run the window to the full down position and continue to hold the switch for an additional two seconds. Again run the window to the full up position and continue to hold the switch for an additional two seconds. Lower the window all the way down then press and release the switch to the express up position. Did the window move to the full up position? No Go To 2 . Yes Test complete.
2. EXPRESS WINDOW SWITCH Turn the ignition off. Move the Express Switch from the idle position to the up position and then to the express up position. Is there two definite detent positions felt? Yes Replace the Door Module in accordance with Service Information. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) . No Replace the Express Window Switch assembly. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) .

Scheme 19

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Note. The graphics in this test show the Left Rear connectors, the Right side connectors are similar, refer to the appropriate Wiring Information for the connector pinouts.
