Power Windows - Non-Dtc-Based Diagnostics: Overview Dodge Durango III

THEORY OF OPERATION

By studying the schematic above, you will notice that the window driver circuits both go to ground when the switches are in the neutral position. In the driver switch, when a switch is moved to lower or raise a window, the switch leaves the ground contact, and supplies 12 volts to the Master Window Switch Rear Up or Down circuit. Likewise in the rear switch, when a switch is moved it leaves the ground contact and supplies 12 volts (through the window lockout switch output circuit) to the Rear Window Driver Up or Down circuit.

Scheme 5

Scheme 6

Scheme 7

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Scheme 14

Scheme 15

Scheme 16

Scheme 17

Scheme 18

1. TEST FOR DIAGNOSTIC TROUBLE CODES Turn the ignition on. With the scan tool, read the DTCs. Does the scan tool display any Power Window related DTCs? Yes Refer to «DIAGNOSIS AND TESTING»(ref-465966-S27579584362012042300000) and perform the appropriate diagnostic procedure. No Go To 2 .
2. CHECK FOR OPEN OR SHORTED TOGETHER CIRCUIT Turn the ignition off. Disconnect the Driver Window Switch C1 connector. Measure the resistance between the Master Window Switch Left Rear (Up) circuit and the Master Window Switch Left Rear (Down) circuit in the Driver Window Switch C1 connector. Select the appropriate reading. Below.05 of an Ohm Go To 11 . Between 0.6 and 15.5 Ohms Go To 3 . Above 15.6 Ohms Go To 5 .
3. CHECK FOR SHORTED CIRCUIT Measure the resistance between ground and the Master Window Switch Left Rear (Up) circuit. Measure the resistance between ground and the Master Window Switch Left Rear (Down) circuit. Is the resistance below 20k Ohms on either or both circuits? Yes Go To 14 . No Go To 4 .
4. DRIVER WINDOW SWITCH OR MOTOR Turn the ignition on. Connect a Jumper wire between the Fused B(+) circuit (cavity 8) and the Master Window Switch Left Rear (Down) circuit (Cavity 7) in the Driver Switch C1 connector. Connect a Jumper wire between the Master Window Switch Left Rear (Up) circuit (Cavity 5) in the Driver Switch C1 connector and momentarily touch it to the Ground (cavity 11). Reverse the wires if there is a short to ground. NOTE: For the Right Rear Motor, substitute cavities 12 and 14 for cavities 5 and 7. If the motor ran in one direction, reverse the jumper wires (5 to 8 and 7 to 11) to run the motor in the opposite direction. Did the window motor operate properly in both directions? Yes Replace the Driver Window Switch in accordance with the Service Information. Refer to «SWITCH, POWER WINDOW , REMOVAL»(ref-465953-S23881180922012042300000) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/dodge/durango/iii-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No Replace the Rear Window Motor (regulator) in accordance with the Service Information. Refer to «REGULATOR, WINDOW , REMOVAL»(ref-465921-S09650896722012042300000) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/dodge/durango/iii-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .
5. OPEN WINDOW (UP) CIRCUIT Disconnect the Left Rear Window Motor connector. Measure the resistance between the Master Window Switch Left Rear (Up) circuit in the Driver Window Switch C1 connector and the Left Rear Window Driver (Up) circuit (WK cavity 1-WD cavity 2) in the Left Rear Window Motor connector. Is the resistance below 3.0 Ohms? Yes Go To 8 . No Go To 6 .
6. OPEN MASTER WINDOW SWITCH LEFT REAR (UP) CIRCUIT Disconnect the Left Rear Window Switch connector. Measure the resistance of the Master Window Switch Left Rear (Up) circuit between the Driver Window Switch C1 connector and the Left Rear Window Switch connector. Is the resistance below 3.0 Ohms? Yes Go To 7 . No Repair the open in the Master Window Switch Left Rear (Up) circuit. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/dodge/durango/iii-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .
7. OPEN LEFT REAR WINDOW DRIVER (UP) CIRCUIT Measure the resistance of the Left Rear Window Driver (Up) circuit between the Left Rear Window Switch connector and the Left Rear Window Motor connector (WK cavity 1-WD cavity 2). Is the resistance below 3.0 Ohms? Yes Replace the Left Rear Window Switch. Refer to «SWITCH, POWER WINDOW , REMOVAL»(ref-465953-S23881180922012042300000) . NOTE: The rear switch removal is similar to the front switch procedure. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/dodge/durango/iii-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No Repair the open in the Left Rear Window Driver (Up) circuit. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/dodge/durango/iii-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .
8. OPEN WINDOW (DOWN) CIRCUIT Measure the resistance between the Master Window Switch Left Rear (Down) circuit in the Driver Window Switch C1 connector and the Left Rear Window Driver (Down) circuit (WK cavity 2-WD cavity 1) in the Left Rear Window Motor connector. Is the resistance below 3.0 Ohms? Yes Replace the Left Rear Window Motor in accordance with the Service Information. Refer to «REGULATOR, WINDOW , REMOVAL»(ref-465921-S09650896722012042300000) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/dodge/durango/iii-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No Go To 9 .
9. OPEN MASTER WINDOW SWITCH LEFT REAR (DOWN) CIRCUIT Disconnect the Left Rear Window Switch connector. Measure the resistance of the Master Window Switch Left Rear (Down) circuit between the Driver Window Switch C1 connector and the Left Rear Window Switch connector. Is the resistance below 3.0 Ohms? Yes Go To 10 . No Repair the open in the Master Window Switch Left Rear (Down) circuit. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/dodge/durango/iii-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .
10. OPEN LEFT REAR WINDOW DRIVER (DOWN) CIRCUIT Measure the resistance of the Left Rear Window Driver (Down) circuit between the Left Rear Window Switch connector and the Left Rear Window Motor connector (WK cavity 2-WD cavity 1). Is the resistance below 3.0 Ohms? Yes Replace the Left Rear Window Switch. Refer to «SWITCH, POWER WINDOW , REMOVAL»(ref-465953-S23881180922012042300000) . NOTE: The rear switch removal is similar to the front switch procedure. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/dodge/durango/iii-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No Repair the open in the Left Rear Window Driver (Down) circuit. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/dodge/durango/iii-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .
11. SHORTED REAR MOTOR NOTE: The graphics show the Left Rear Motor, the Right Rear uses Cavities 12 and 14. Disconnect the Rear Window Motor connector. Measure the resistance between the Master Window Switch Left Rear (Up) circuit and the Master Window Switch Left Rear (Down) circuit in the Driver Window Switch C1 connector. Is the resistance below 20k Ohms? Yes Go To 12 . No Replace the Rear Window Motor in accordance with the Service Information. Refer to «REGULATOR, WINDOW , REMOVAL»(ref-465921-S09650896722012042300000) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/dodge/durango/iii-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .
12. MASTER WINDOW SWITCH LEFT REAR (UP) CIRCUIT SHORTED TO THE MASTER WINDOW SWITCH LEFT REAR (DOWN) CIRCUIT Disconnect the Left Rear Window Switch connector. Measure the resistance between the Master Window Switch Left Rear (Up) circuit and the Master Window Switch Left Rear (Down) circuit in the Driver Window Switch C1 connector. Is the resistance below 20k Ohms? Yes Repair the short between the Master Window Switch Left Rear (Up) circuit and the Master Window Switch Left Rear (Down) circuit. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/dodge/durango/iii-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No Go To 13 .
13. REAR WINDOW DRIVER (UP) CIRCUIT SHORTED TO THE REAR WINDOW DRIVER (DOWN) CIRCUIT Measure the resistance between the Left Rear Window Driver (Up) circuit and the Left Rear Window Driver (Down) circuit in the Left Rear Window Motor connector. Is the resistance below 20k Ohms? Yes Repair the short between the Left Rear Window Driver (Up) circuit and the Left Rear Window Driver (Down) circuit. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/dodge/durango/iii-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No Replace the Left Rear Window Switch. Refer to «SWITCH, POWER WINDOW , REMOVAL»(ref-465953-S23881180922012042300000) . NOTE: The rear switch removal is similar to the front switch procedure. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/dodge/durango/iii-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .
14. CHECK FOR SHORTED MOTOR Disconnect the Left Rear Window Motor connector. Measure the resistance between ground and the Master Window Switch Left Rear (Up) circuit. Measure the resistance between ground and the Master Window Switch Left Rear (Down) circuit. Is the resistance below 20k Ohms on either or both circuits? Yes Go To 15 . No Replace the Rear Window Motor in accordance with the Service Information. Refer to «REGULATOR, WINDOW , REMOVAL»(ref-465921-S09650896722012042300000) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/dodge/durango/iii-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .
15. CHECK FOR SHORT TO GROUND Disconnect the Left Rear Window Switch connector. Measure the resistance between ground and the Master Window Switch Left Rear (Up) circuit. Measure the resistance between ground and the Master Window Switch Left Rear (Down) circuit. Is the resistance below 20k Ohms on either or both circuits? Yes Repair the short to ground in the Master Window Switch Left Rear (Up) or (Down) circuit. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/dodge/durango/iii-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No Repair the short to ground in the Left Rear Window Driver (Up) or (Down) circuit. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/dodge/durango/iii-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .
