Automatic Highbeam Module (Ahbm) - Electrical Diagnostics: Diagnosis Dodge Durango III

DIAGNOSTIC CODE INDEX

DIAGNOSTIC CODE INDEX

DIAGNOSTIC TEST

1. TEST FOR INTERMITTENT CONDITION Turn the ignition on. Using the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Perform the Smart Beam Calibration in accordance with the Service Information. Refer to «SMART BEAM , STANDARD PROCEDURE»(ref-465935-S05185871492012042300000) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) .

1. CHECK FOR AN ACTIVE DTC Turn the ignition on. Using the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Perform the Smart Beam Calibration in accordance with the Service Information. Refer to «SMART BEAM , STANDARD PROCEDURE»(ref-465935-S05185871492012042300000) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) .

1. CHECK FOR AN ACTIVE DTC Turn the ignition on. Using the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Perform the Smart Beam Calibration in accordance with the Service Information. Refer to «SMART BEAM , STANDARD PROCEDURE»(ref-465935-S05185871492012042300000) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) .

1. CHECK FOR AN ACTIVE DTC Turn the ignition on. Using the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Perform the Smart Beam Calibration in accordance with the Service Information. Refer to «SMART BEAM , STANDARD PROCEDURE»(ref-465935-S05185871492012042300000) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) .

1. CHECK FOR AN ACTIVE DTC Turn the ignition on. Using the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Perform the Smart Beam Calibration in accordance with the Service Information. Refer to «SMART BEAM , STANDARD PROCEDURE»(ref-465935-S05185871492012042300000) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) .

Scheme 35

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

1. CHECK FOR ANY POWERTRAIN CONTROL MODULES DTCS NOTE: Make sure the Battery is in good condition. Using the Midtronics Battery Tester, test the Battery before continuing. NOTE: Inspect the vehicle for after market accessories that may exceed the Generator System output. NOTE: Make sure the generator drive belt is in good operating condition. NOTE: Inspect the fuses in the TIPM. If an open fuse is found, use the wire diagram/schematic as a guide, inspect the wiring and connectors for damage. Turn the ignition on. With the scan tool, read active PCM DTCs. Does the scan tool display any active PCM DTCs? Yes Refer to «DIAGNOSTIC CODE INDEX»(ref-466007) and perform the appropriate diagnostic procedure . No Check the above conditions that can cause a low voltage condition. Repair as necessary. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) .

1. CHECK FOR ANY POWERTRAIN CONTROL MODULES DTCS NOTE: Make sure the Battery is in good condition. Using the Midtronics Battery Tester, test the Battery before continuing. NOTE: Inspect the vehicle for after market accessories that may exceed the Generator System output. NOTE: Make sure the generator drive belt is in good operating condition. NOTE: Inspect the fuses in the TIPM. If an open fuse is found, use the wire diagram/schematic as a guide, inspect the wiring and connectors for damage. Turn the ignition on. With the scan tool, read active PCM DTCs. Does the scan tool display any active PCM DTCs? Yes Refer to «DIAGNOSTIC CODE INDEX»(ref-466007) and perform the appropriate diagnostic procedure . No Check the above conditions that can cause a high voltage condition. Repair as necessary. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) .

1. CHECK FOR AN ACTIVE DTC Turn the ignition on. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Replace and program the Auto High Beam Module (Rearview Mirror) in accordance with the Service Information. Refer to «MIRROR, REARVIEW , REMOVAL»(ref-465921-S19421942362012042300000) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) .

1. VERIFY DIAGNOSTIC TROUBLE CODE (DTC) IS ACTIVE NOTE: Make sure the IOD fuse is installed and battery voltage is between 10 and 16 volts before proceeding. Using the scan tool, read active DTCs. Is this DTC active? Yes Refer to «DIAGNOSIS AND TESTING»(ref-465991-S16226542852012042300000) . and perform the U0010-CAN Interior Bus diagnostic procedure. No Refer to «DIAGNOSIS AND TESTING»(ref-465945-S21111524872012042300000) . and perform the Stored Lost Communication DTCs diagnostic procedure.

1. VERIFY THE DTC IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. With the scan tool, read active DTCs. Is the DTC active at this time? Yes Perform the U0141-Lost Communication with IPM (FCM/TIPM) diagnostic procedure. Refer to «DIAGNOSIS AND TESTING»(ref-465991-S16226542852012042300000) . . No Perform the Stored Lost Communication DTCs diagnostic procedure. Refer to «DIAGNOSIS AND TESTING»(ref-465945-S21111524872012042300000) . .

1. VERIFY DTC IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. With the scan tool, read active DTCs. Is this DTC active? Yes Refer to «DIAGNOSIS AND TESTING»(ref-465991-S16226542852012042300000) . and perform the U0155-Lost Communication with Cluster/CCN diagnostic procedure. No Refer to «DIAGNOSIS AND TESTING»(ref-465945-S21111524872012042300000) . and perform the Stored Lost Communication DTCs diagnostic procedure.
