Charging - Service Information: Specifications Dodge Dart PF

TORQUE

GENERATOR TORQUE SPECIFICATIONS

Scheme 34

Scheme 35

Scheme 36

1. Disconnect and isolate the battery negative cable.
2. Remove the accessory drive belt. Refer to «BELT, SERPENTINE, REMOVAL»(ref-646235-S33730159442014072800000) .
3. Raise and support the vehicle.
4. Remove the belly pan (1) covering the bottom side of the engine compartment.
5. Remove the right side axle shaft (1).
6. Disconnect the field generator harness connector.
7. Remove the generator B+ cable retainer.
8. Remove the cable from the generator stud.
9. Remove the top generator mounting bolt (1). This bolt is located between the generator and the a/c compressor.
10. Remove the bottom two generator mounting bolts (2).
11. Carefully remove the generator (3).

Scheme 37

Scheme 38

1. Remove the engine cover.
2. Disconnect the negative battery cable.
3. Remove the accessory drive belt. Refer to «BELT, SERPENTINE, REMOVAL»(ref-646235-S33730159442014072800000) .
4. Disconnect the field generator harness connector (3).
5. Remove the B+ cable from the generator stud (2).
6. Remove the upper generator bolt (1).
7. Remove the lower generator bolts (4).
