Battery System - Service Information: Other Dodge Dart PF

Charging System 18 illustrations ~1908 words

GR8 ELECTRICAL SYSTEM TESTER

The Midtronics GR8 battery system tester is designed to help diagnose the cause of a defective battery. Refer to BATTERY, STANDARD PROCEDURE for directions on using the Midtronics GR8 battery tester.

STANDARD PROCEDURE - SHIPPING MODE

When a new vehicle is delivered, the Body Control Module (BCM) is set to shipping mode. The BCM has a mode that takes the place of pulling the IOD fuse called "Shipping Mode". Shipping mode deactivates several vehicle accessories to prevent normal ignition OFF draw from depleting the battery over time. Removing the vehicle from shipping mode activates all vehicle systems.

You can enable/disable the vehicle from "Shipping Mode" by using the scan tool, go to BCM >> Misc. function >> Exit Shipping Mode.

The battery Group Size number, the Cold Cranking Amperage (CCA) rating, and the Reserve Capacity (RC) rating or Ampere-Hours (AH) rating can be found on the original equipment battery label. Be certain that a replacement battery has the correct Group Size number, as well as CCA, and RC or AH ratings that equal or exceed the original equipment specification for the vehicle being serviced. Battery sizes and ratings are discussed in more detail below.

Note. Vehicles equipped with a diesel engine utilize a unique battery. The specifications for this battery may differ from the standards shown here. Refer to the battery manufacturer for detailed specifications.

  1. Group Size - The outside dimensions and terminal placement of the battery conform to standards established by the Battery Council International (BCI). Each battery is assigned a BCI Group Size number to help identify a correctly-sized replacement.
  2. Cold Cranking Amperage - The Cold Cranking Amperage (CCA) rating specifies how much current (in amperes) the battery can deliver for thirty seconds at -18° C (0° F). Terminal voltage must not fall below 7.2 volts during or after the thirty second discharge period. The CCA required is generally higher as engine displacement increases, depending also upon the starter current draw requirements.
  3. Reserve Capacity - The Reserve Capacity (RC) rating specifies the time (in minutes) it takes for battery terminal voltage to fall below 10.5 volts, at a discharge rate of 25 amperes. RC is determined with the battery fully-charged at 26.7° C (80° F). This rating estimates how long the battery might last after a charging system failure, under minimum electrical load.
  4. Ampere-Hours - The Ampere-Hours (AH) rating specifies the current (in amperes) that a battery can deliver steadily for twenty hours, with the voltage in the battery not falling below 10.5 volts. This rating is also sometimes identified as the twenty-hour discharge rating.
  5. Load Test Amperage - The Load Test Amperage rating specifies the current (in amperes) that a battery should be tested at with the battery load test equipment. This value should always be 50 percent of the CCA. For example: if the CCA for this battery is 700 amps, the Load Test Amperage is 50 percent of that or 350 amps.
BATTERY CLASSIFICATIONS AND RATINGS
BCI Group Size ClassificationCold Cranking AmperageReserve CapacityAmpere - HoursLoad Test Amperage
3470090 Minutes50350
86525100 Minutes60265

BATTERY CLASSIFICATIONS AND RATINGS

CLEANING

The following information details the recommended cleaning procedures for the battery and related components. In addition to the maintenance schedules found in this Service Information and the owner's manual, it is recommended that these procedures be performed any time the battery or related components must be removed for vehicle service.

Scheme 16

Scheme 16: CLEANING

Scheme 17

Scheme 17

Scheme 18

Scheme 18
  1. Clean the battery cable terminal clamps (2) of all corrosion. Remove any corrosion using a wire brush (1) or a post and terminal cleaning tool, and a sodium bicarbonate (baking soda) and warm water cleaning solution.
  2. Clean the battery tray and battery hold-down hardware of all corrosion. Remove any corrosion using a wire brush and a sodium bicarbonate (baking soda) and warm water cleaning solution. Paint any exposed bare metal.
  3. If the removed battery is to be reinstalled, clean the outside of the battery case (3) and the top cover with a sodium bicarbonate (baking soda) and warm water cleaning solution using a stiff bristle parts cleaning brush (1) to remove any acid film. Rinse the battery with clean water. Ensure that the cleaning solution does not enter the battery cells through the vent holes. If the battery is being replaced, for the factory-installed battery specifications. Refer to «SPECIFICATIONS»(ref-646227-S37074325252014072800000) . Confirm that the replacement battery is the correct size and has the correct ratings for the vehicle.
  4. Clean the battery thermal guard with a sodium bicarbonate (baking soda) and warm water cleaning solution using a stiff bristle parts cleaning brush to remove any acid film.
  5. Clean any corrosion from the battery terminal posts with a wire brush or a post and terminal cleaner, and a sodium bicarbonate (baking soda) and warm water cleaning solution.

MIDTRONICS GR8 BATTERY TESTER

The Midtronics GR8 battery tester is designed to help diagnose the cause of an inoperative battery. for instructions on the use of the Midtronics GR8 battery tester. Refer to BATTERY, STANDARD PROCEDURE .

CONVENTIONAL BATTERY CHARGING

CAUTIONVehicles equipped with a diesel engine utilize a unique spiral cell battery. This battery has a maximum charging voltage that must be used in order to restore the battery to its full potential, failure to use the spiral cell battery charging procedure could result in damage to the battery or personal injury. for the appropriate procedure.

Battery charging is the means by which the battery can be restored to its full voltage potential. A battery is fully-charged when

  1. Midtronics (special tool #GR8-1220KIT-CHRY, AGM Battery Tester/Charger Station) tester indicates battery is OK.
  2. Open-circuit voltage of the battery is 12.65 volts or above.
  3. Battery passes Load Test multiple times.
WARNINGIf the battery shows signs of freezing, leaking, loose posts, do not test, assist-boost, or charge. The battery may arc internally and explode. Personal injury and/or vehicle damage may result.
WARNINGEXPLOSIVE HYDROGEN GAS FORMS IN AND AROUND THE BATTERY. DO NOT SMOKE, USE FLAME, OR CREATE SPARKS NEAR THE BATTERY. PERSONAL INJURY AND/OR VEHICLE DAMAGE MAY RESULT.
WARNINGTHE BATTERY CONTAINS SULFURIC ACID, WHICH IS POISONOUS AND CAUSTIC. AVOID CONTACT WITH THE SKIN, EYES, OR CLOTHING. IN THE EVENT OF CONTACT, FLUSH WITH WATER AND CALL A PHYSICIAN IMMEDIATELY. KEEP OUT OF THE REACH OF CHILDREN.
WARNINGIf the battery is equipped with removable cell caps, be certain that each of the cell caps is in place and tight before the battery is returned to service. Personal injury and/or vehicle damage may result from loose or missing cell caps.
CAUTIONAlways disconnect and isolate the battery negative cable before charging a battery. Do not exceed sixteen volts while charging a battery. Damage to the vehicle electrical system components may result.
CAUTIONBattery electrolyte will bubble inside the battery case during normal battery charging. Electrolyte boiling or being discharged from the battery vents indicates a battery overcharging condition. Immediately reduce the charging rate or turn off the charger to evaluate the battery condition. Damage to the battery may result from overcharging.
CAUTIONThe battery should not be hot to the touch. If the battery feels hot to the touch, turn off the charger and let the battery cool before continuing the charging operation. Damage to the battery may result.

After the battery has been charged to an open-circuit voltage reading of 12.4 volts or greater, retest the battery with the Midtronics (special tool #GR8-1220KIT-CHRY, AGM Battery Tester/Charger Station) tester indicates battery is OK or perform a load test to determine the battery cranking capacity.

Refer to BATTERY, STANDARD PROCEDURE .

Clean and inspect the battery hold downs, tray, terminals, posts, and top before completing battery service. Refer to CLEANING for the proper battery system cleaning procedures. Refer to INSPECTION for the proper battery system inspection procedures.

CHARGING A COMPLETELY DISCHARGED CONVENTIONAL BATTERY

The following procedure should be used to recharge a completely discharged battery. Unless this procedure is properly followed, a good battery may be needlessly replaced.

  1. Measure the voltage at the battery posts with a voltmeter, accurate to 1/10 (0.10) volt. If the reading is below ten volts, the battery charging current will be low. It could take some time before the battery accepts a current greater than a few milliamperes. Such low current may not be detectable on the ammeters built into many battery chargers.
  2. Disconnect and isolate the battery negative cable. Connect the Midtronics (special tool #GR8-1220KIT-CHRY, AGM Battery Tester/Charger Station). NOTE: Some battery chargers are equipped with polarity-sensing circuitry. This circuitry protects the battery charger and the battery from being damaged if they are improperly connected. If the battery state-of-charge is too low for the polarity-sensing circuitry to detect, the battery charger will not operate. This makes it appear that the battery will not accept charging current. See the instructions provided by the manufacturer of the battery charger for details on how to bypass the polarity-sensing circuitry.
  3. Battery chargers vary in the amount of voltage and current they provide. The amount of time required for a battery to accept measurable charging current at various voltages is shown in the Charge Rate Table. If the charging current is still not measurable at the end of the charging time, the battery is faulty and must be replaced. If the charging current is measurable during the charging time, the battery may be good and the charging should be completed in the normal manner.
VoltageMinutes
16.0 volts maximumUp to 10 min.
14.0 to 15.9 voltsUp to 20 min.
13.9 volts or lessUp to 30 min.

CONVENTIONAL BATTERY CHARGE RATE TABLE

CHARGING TIME REQUIRED

The time required to charge a battery will vary, depending upon the following factors

  1. Battery Capacity - A completely discharged heavy-duty battery requires twice the charging time of a small capacity battery.
  2. Temperature - A longer time will be needed to charge a battery at -18° C (0° F) than at 27° C (80° F). When a fast battery charger is connected to a cold battery, the current accepted by the battery will be very low at first. As the battery warms, it will accept a higher charging current rate (amperage).
  3. Charger Capacity - A battery charger that supplies only five amperes will require a longer charging time. A battery charger that supplies twenty amperes or more will require a shorter charging time.
  4. State-Of-Charge - A completely discharged battery requires more charging time than a partially discharged battery. Electrolyte is nearly pure water in a completely discharged battery. At first, the charging current (amperage) will be low. As the battery charges, the specific gravity of the electrolyte will gradually rise.

The Conventional Battery Charging Time Table gives an indication of the time required to charge a typical battery at room temperature based upon the battery state-of-charge and the charger capacity.

Charging Amperage5 Amps10 Amps20 Amps
Open Circuit VoltageHours Charging @ 21° C (70° F)
12.25 to 12.496 hours3 hours1.5 hours
12.00 to 12.2410 hours5 hours2.5 hours
10.00 to 11.9914 hours7 hours3.5 hours
Below 10.0018 hours9 hours4.5 hours

CONVENTIONAL BATTERY CHARGING TIME TABLE

GR8 BATTERY TESTER / CHARGER

Always use the Midtronics GR8 Instruction Manual that was supplied with the tester as a reference. If the Instruction Manual is not available the following procedure can be used

WARNINGAlways wear appropriate eye protection and use extreme caution when working with batteries.

QUICK REFERENCE GUIDE

Inspect the battery for damages and check the electrolyte level. Always use the necessary safety precautions when working with batteries to prevent severe injury or death. Follow all manufacturers' instructions and BCI (Battery Council International) safety recommendations, which include the following precautions

MAIN MENU

The Main Menu is the starting point for all tools and utilities, which are depicted as icons. Some icons lead directly to the function they represent, while others are menu icons that lead to two or more options.

Scheme 19

Scheme 19: MAIN MENU

Automatically tests, charges, and provides battery decision using the information you select in a series of screens. Start here to generate warranty codes.

Scheme 20

Scheme 20

Tests the starting and charging systems.

Scheme 21

Scheme 21

Maintains battery voltage at 13.5 volts to provide uninterrupted reprogramming of ECUs and retain vehicle system settings.

Scheme 22

Scheme 22

Includes a utility to view and print a test counter, a data transfer utility, the software version and date, the GR8 serial number for the control module, and current wireless channel.

Scheme 23

Scheme 23

The Setup Menu lets you customize options in the GR8 to suit your needs.

Scheme 24

Scheme 24

Provides a list of topics and definitions. Also includes Midtronics Customer Service phone numbers.

Scheme 25

Scheme 25: CHARGE/TEST MENU

Automatically tests and charges battery, starting, and charging system. Generates a warranty code for Replace and Bad Cell decisions.

Scheme 26

Scheme 26

Pre Delivery Inspection (PDI): For testing delivered vehicles and lot maintenance. Uses the same inputs as a diagnostic charge.

Scheme 27

Scheme 27

Dual Battery Charge mode allows the charger to be used with dual battery systems.

Scheme 28

Scheme 28

Makes high output current available to boost charge an in-vehicle battery and assist in starting the engine.

Scheme 29

Scheme 29

Provides a timed charge that ranges from 5 to 120 minutes or a continuous charge that ends when you press the STOP key.

Scheme 30

Scheme 30

In this mode the charger can provide a trickle charge for long term, low amp battery charging.

Scheme 31

Scheme 31

Generates 15-digit warranty codes for physically defective batteries or customer good will.

Scheme 32

Scheme 32
  1. Control module: Backlit graphical display and keypad for data entry.
  2. ON/OFF switch: ON/OFF switch Turns power on and off to the GR8.
  3. STATUS light: Lights in conjunction with beeping alarm to indicate transitions and warnings.
  4. Data card slot: For future upgrades via a data card. The slot contains a plastic filler card for protection.

Scheme 33

Scheme 33: BATTERY DECISIONS
  1. Battery Decisions
  2. Select Rating
  3. Measured capacity
  4. Measured voltage
  5. Good Range NOTE: The warranty code screen will only be displayed for REPLACE BATTERY and BAD CELL-REPLACE decisions.
  6. Enter this number into wiTech
  7. Replace range
  8. Replaced AMP Hours
  9. Charging Time
