3.5L Engine - Service Information: Specifications Dodge Charger V

Mechanical 29 illustrations ~151 words

TORQUE - 3.5L

DESCRIPTIONN.mFt. Lbs.In. Lbs.
Camshaft Sprocket Bolt - Right Side102 +1/4 Turn75 +1/4 Turn
Camshaft Sprocket Bolt - Left Side102 +1/4 Turn75 +1/4 Turn
Camshaft Thrust Plate - Bolts28250
Connecting Rod Cap - Bolts27 +1/4 Turn20 +1/4 Turn
Crankshaft Main Bearing Cap Inner Main Cap Bolts20 +1/4 Turn15 +1/4 Turn
Crankshaft Main Bearing Cap Outer Main Cap Bolts27 +1/4 Turn20 +1/4 Turn
Tie Bolts (Horizontal)28250
Crankshaft Damper - Bolt9570
Cylinder Head Bolts* -Step 16145
Cylinder Head Bolts* -Step 28865
Cylinder Head Bolts* -Step 38865
Cylinder Head Bolts* -Step 4+1/4 Turn+1/4 Turn
*Refer to procedure for tightening sequence. (Refer to ENGINE/CYLINDER HEAD - INSTALLATION) .
Cylinder Head Cover - Bolts12105
Exhaust Manifold to Cylinder Head - Bolts23200
Exhaust Manifold Heat Shield - Bolts12105
Flex plate to Crankshaft9570
Flex plate to Torque Converter7555
Intake Manifold - Lower28250
Intake Manifold - Upper12105
Oil Pan -M6 Bolts12105
Oil Pan -M8 Bolts28250
Oil Pan to Transmission Bell Housing5540
Flex Plate Inspection Cover1197
Oil Pan Drain Plug2720
Oil Cooler Connector Bolt6145
Oil Filter12102
Oil Pump to Block - Bolts28250
Oil Pump Cover - Bolts12105
Oil Pump Pick Up Tube - Bolt28250
Crankshaft Rear Seal Retainer12105
Engine Mount to Mounting Bracket7555
Engine Mount to Cradle - Nuts7555
Engine Mount Heat Shield1197
Engine Mount Through Studs12106
Rocker Shaft Pedestal Retaining - Bolts31275
Spark Plugs2820
Timing Belt Tensioner-Bolts28250
Timing Belt Tensioner Pulley Assembly - Bolt6145
Timing Belt Cover -M6 Bolts12105
Timing Belt Cover -M8 Bolts28250
Timing Belt Cover -M10 Bolts5440

Scheme 171

Scheme 171: 3.5L ENGINE

Scheme 172

Scheme 172

Scheme 173

Scheme 173

Scheme 174

Scheme 174

Scheme 175

Scheme 175

Scheme 176

Scheme 176

Scheme 177

Scheme 177

Scheme 178

Scheme 178

Scheme 179

Scheme 179

Scheme 180

Scheme 180

Scheme 181

Scheme 181

Scheme 182

Scheme 182

Scheme 183

Scheme 183

Scheme 184

Scheme 184

Scheme 185

Scheme 185

Scheme 186

Scheme 186

Scheme 187

Scheme 187

Scheme 188

Scheme 188

Scheme 189

Scheme 189

Scheme 190

Scheme 190

Scheme 191

Scheme 191

Scheme 192

Scheme 192

Scheme 193

Scheme 193

Scheme 194

Scheme 194

Scheme 195

Scheme 195

Scheme 196

Scheme 196

Scheme 197

Scheme 197

Scheme 198

Scheme 198: REMOVAL
1 - AIR INLET DUCT TO THROTTLE BODY
2 - AIR CLEANER HOUSING COVER
3 - LOCKING TABS
4 - CCV HOSE

Scheme 199

Scheme 199
  1. Disconnect the CCV hose (4) at the housing cover (2). (Scheme 198)
  2. Release the housing cover tabs (3). (Scheme 198)1 - AIR CLEANER COVER 2 - ELEMENT 3 - CCV HOSE
  3. Lift the cover (1) and pull toward the front of the vehicle to release the rear cover to housing alignment tabs. (Scheme 199)
  4. Remove the element (2).

OIL FILTER SPECIFICATION

All engines are equipped with a high quality full-flow, disposable type oil filter. When replacing oil filter, use a Mopar® filter or equivalent.
