TORQUE
| DESCRIPTION | N.m | Ft. | In. |
|---|---|---|---|
| Lbs. | Lbs. | ||
| Block Pipe Plugs (1/4 NPT) | 20 | 177 | |
| (3/8 NPT) | 27 | 240 | |
| Camshaft Sprocket-Bolt | 122 | 90 | |
| Camshaft Tensioner Plate-Bolts | 28 | 250 | |
| Coil to Cylinder Head Cover- Bolts | 7 | 62 | |
| Timing Chain Case Cover-Bolts | 28 | 250 | |
| Lifting Stud | 55 | 40 | |
| Connecting Rod Cap-Bolts | 21 plus 90° Turn | 15 plus 90° Turn | |
| Main Bearing Cap-Bolts M-12 | 27 plus 90° Turn | ||
| Crossbolts M-8 | 28 | ||
| Cylinder Head-Bolts M-12 Bolts | |||
| Step 1 | 34 | 25 | |
| Step 2 | 54 | 40 | |
| Step 3 | Turn 90° | Turn 90° | |
| M-8 Bolts | |||
| Step 1 | 20 | 15 | |
| Step 2 | 34 | 25 | |
| Cylinder Head Cover-Bolts | 8 | 70 | |
| Exhaust Manifold to Cylinder Head | 25 | 220 | |
| Flexplate to crankshaft-Bolts | 95 | 70 | |
| Flywheel to crankshaft-Bolts | 75 | 55 | |
| Front Insulator-Through bolt/nut | 95 | 70 | |
| Front Insulator to Block-Bolts | 95 | 70 | |
| Generator-Mounting Bolt | 55 | 40 | |
| Intake Manifold-Bolts | Refer to Procedure | ||
| Lifter Guide Holder | 12 | 106 | |
| Oil Pan Bolts | 12 | 105 | |
| Oil Dipstick Tube | 12 | 105 | |
| Oil Pan-Drain Plug | 27 | 20 | |
| Oil Pump-Attaching Bolts | 28 | 250 | |
| Oil Pump Pickup Tube - Bolt and Nut | 28 | 250 | |
| Rear Seal Retainer Attaching Bolts | 15 | 132 | |
| Rear Insulator to Bracket | 68 | 50 | |
| Rear Insulator to Crossmember | 41 | 30 | |
| Rear Insulator to Transmission | 68 | 50 | |
| Rear Insulator Bracket-Bolts | 68 | 50 | |
| Rocker Arm-Bolts | 22 | 195 | |
| Spark Plugs | |||
| Thermostat Housing-Bolts | 28 | 250 | |
| Throttle Body-Bolts | 12 | 105 | |
| Vibration Damper-Bolt | 176 | 129 | |
| Water Pump to Timing Chain | 28 | 250 | |
| Case Cover-Bolts | |||
TORQUE CHART 5.7L ENGINE
Scheme 371
Scheme 372
Scheme 373
Scheme 374
Scheme 375
Scheme 376
Scheme 377
Scheme 378
Scheme 379
Scheme 380
Scheme 381
Scheme 382
Scheme 383
Scheme 384
Scheme 385
Scheme 386
Scheme 387
Scheme 388
Scheme 389
Scheme 390
Scheme 391
Scheme 392
Housing removal is not necessary for element (filter) replacement.
- Loosen clamp and disconnect air duct at air cleaner cover.
- Pry over 4 spring clips (5) from housing cover (3) (spring clips retain cover to housing).
- Release housing cover (3) from locating tabs (4) on housing and remove cover (3).
- Remove air cleaner element (filter) from housing.
- Clean inside of housing before replacing element.
Scheme 393
- Loosen clamp and disconnect air duct at air cleaner cover.
- Lift entire housing (1) assembly from 4 locating pins (2).
