2.7L DOHC Engine - Service Information: Specifications Dodge Charger V

Mechanical 35 illustrations ~164 words

TORQUE

DESCRIPTIONN.mFt. Lbs.In. Lbs.
A/C Compressor to Engine - Bolts2821
Camshaft Sprocket - Bolts28250
Camshaft Chain Tensioner (Secondary) - Bolts12105
Camshaft Bearing Cap - Bolts12105
Connecting Rod Cap - Bolts27 +1/4 Turn20 +1/4 Turn
Cooling System Bleed Screw12110
Crankshaft Main Bearing Cap - Tie Bolts28250
Crankshaft Main Bearing Cap - Outer Cap Bolts27 +1/4 Turn20 +1/4 Turn
Crankshaft Main Bearing Cap - Inner Cap Bolts20 +1/4 Turn15 +1/4 Turn
Crankshaft Damper - Bolt170125
Crankshaft Rear Seal Retainer - Bolts12105
Cylinder Head - Bolts(Refer to ENGINE/CYLINDER HEAD - INSTALLATION)
Cylinder Head Cover - Bolts12105
Exhaust Manifold - Bolts23200
Exhaust Manifold Heat Shield - Bolts12105
Engine Mount Bracket to Block - Bolts6145
Engine Mount Isolator - Nuts6145
Intake Manifold (Upper and Lower) - Bolts12105
Generator Bracket-Bolts4130
Oil Pan - m8 Bolts28250
Oil Pan - m6 Nuts12105
Oil Pan Drain - Plug2720
Oil Cooler - Stud6145
Oil Filter1612
Oil Pump to Block - Bolts28250
Oil Pump Cover - Bolts12105
Oil Pump Pick Up Tube - Bolt28250
PCV Valve760
Spark Plugs2015
Starter Mounting - Bolts4130
Structural Collar(Refer to ENGINE/ENGINE BLOCK/STRUCTURAL COVER - INSTALLATION)
Thermostat Housing/Water Inlet Connector - Bolts12105
Throttle Body - Bolts12105
Timing Chain Cover - M6 Bolts12105
Timing Chain Cover - M10 Bolts5440
Timing Chain Tensioner (Primary)12105
Timing Chain Guide Access Plug2015
Torque Converter7555
Water Pump - Bolts12105
Water Outlet Housing - Bolts12105

Scheme 1

Scheme 1: 2.7L ENGINE
Scheme 1: 2.7L ENGINE

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9
Scheme 9

Scheme 10

Scheme 10
Scheme 10

Scheme 11

Scheme 11
Scheme 11

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13
Scheme 13

Scheme 14

Scheme 14
Scheme 14

Scheme 15

Scheme 15
Scheme 15

Scheme 16

Scheme 16
Scheme 16

Scheme 17

Scheme 17
Scheme 17

Scheme 18

Scheme 18
Scheme 18

Scheme 19

Scheme 19
Scheme 19

Scheme 20

Scheme 20
Scheme 20

Scheme 21

Scheme 21
Scheme 21

Scheme 22

Scheme 22
Scheme 22

Scheme 23

Scheme 23
Scheme 23

Scheme 24

Scheme 24
Scheme 24

Scheme 25

Scheme 25
Scheme 25

Scheme 26

Scheme 26
Scheme 26

Scheme 27

Scheme 27
Scheme 27

Scheme 28

Scheme 28
Scheme 28

Scheme 29

Scheme 29
Scheme 29

Scheme 30

Scheme 30
Scheme 30

Scheme 31

Scheme 31
Scheme 31

Scheme 32

Scheme 32
Scheme 32

Scheme 33

Scheme 33
Scheme 33

Scheme 34

Scheme 34
Scheme 34

Scheme 35

Scheme 35: REMOVAL
Scheme 35: REMOVAL
1 - THROTTLE BODY
2 - MASS AIRFLOW SENSOR ELECTRICAL CONNECTOR
3 - CLEAN AIR DUCT
4 - AIR FILTER HOUSING ASSEMBLY
5 - BOLT
6 - VENT TUBE
  1. Disconnect negative battery cable.
  2. Disconnect mass airflow sensor electrical connector.
  3. Remove clean air duct between throttle body and air filter housing.
  4. Remove vent tube.
  5. Remove mounting bolt.
  6. Remove air filter housing.
  7. Raise vehicle.
  8. Partially remove front fascia to gain access to air filter resonator «(Refer to FRAME & BUMPERS/BUMPERS/FRONT FASCIA - REMOVAL)»(ref-255966-S26370488282007060500000) .
  9. Remove mounting bolt.
  10. Remove air cleaner resonator.

OIL FILTER SPECIFICATION

All engines are equipped with a high quality full-flow, disposable type oil filter. When replacing oil filter, use a Mopar® filter or equivalent.

More articles — 2.7L DOHC Engine - Service Information
