Power Distribution System: Overview Dodge Charger V

DESCRIPTION

The power distribution system for this vehicle consists of the following components

1. Cigar Lighter Outlet
2. Front Control Module (FCM) - located underhood
3. Integrated Power Module (IPM) - located underhood
4. Power Distribution Center (PDC) - located in trunk
5. Power Outlets

Refer to appropriate SYSTEM WIRING DIAGRAMS article for complete circuit schematics.

The power distribution system also incorporates various types of circuit control and protection features, including

1. Automatic resetting circuit breakers
2. Blade-type fuses
3. Cartridge fuses
4. Relays

OPERATION

The power distribution system for this vehicle is designed to provide safe, reliable, and centralized distribution points for the electrical current required to operate all of the many standard and optional factory-installed electrical and electronic powertrain, chassis, safety, security, comfort and convenience systems. At the same time, the power distribution system was designed to provide ready access to these electrical distribution points for the technician to use when conducting diagnosis and repair of inoperative circuits. The power distribution system can also prove useful for the sourcing of additional electrical circuits that may be required to provide the electrical current needed to operate many accessories that the vehicle owner may choose to have installed.

The majority of electrical system fuses and relays are housed in the two Power Distribution Centers (PDC). One is located in the engine compartment, combined with the Front Control Module (FCM) to form the Integrated Power Module (IPM). The other is next to the battery at the rear of the vehicle.

Scheme 1

Note. A battery reconnect procedure must be performed anytime the battery has been disconnected. (Refer to ELECTRICAL/BATTERY SYSTEM - STANDARD PROCEDURE) .

Scheme 2

Scheme 3

Scheme 4

1. Disconnect and isolate the battery negative cable (2).
2. Open the battery cable nut cover to expose nut.
3. Remove battery cable nut and battery cable from the Integrated Power Module (IPM).
4. Disengage the outboard retaining clip, and rotate the IPM to access wire harness connectors.
5. Disconnect wire harness connectors from IPM.
6. Disengage the two inboard retaining clips.
7. Remove IPM from vehicle.

Scheme 5

Note. A battery reconnect procedure must be performed anytime the battery has been disconnected. (Refer to ELECTRICAL/BATTERY SYSTEM - STANDARD PROCEDURE) .

Scheme 6

Scheme 7

1. Position Integrated Power Module (IPM) to vehicle. Engage the three retaining clips.
2. Disengage the outboard retaining clip and rotate the IPM to access wire harness connectors.
3. Connect electrical harness connectors to IPM.
4. Connect battery cable to IPM.
5. Install and tighten retaining nut.
6. Close the battery cable nut cover.
7. Connect battery negative cable (2).

Scheme 8

The majority of electrical system fuses and relays are housed in the two Power Distribution Centers (PDC). One is located in the engine compartment, combined with the Front Control Module (FCM) to form the Integrated Power Module (IPM). The other is next to the battery at the rear of the vehicle. The PDC located next to the battery is replaced only as part of the body wiring harness.

Sedans are equipped with two 12-volt electrical outlets. Wagons are equipped with three 12-volt electrical outlets. The outlets are located in the following locations

1. Cargo area right quarter trim panel (wagons only).
2. Inside the center console.
3. Next to the ash receiver in the center stack.

The outlets in the console and quarter trim panel have power at all times, and include tethered covers. The outlet in the ash receiver tray is shipped with power available only when the ignition is in the ON position. This outlet can be changed to provide power at all times by moving a fuse in the fuse block.
