TORQUE
| Description | N.m | Ft. Lbs. | In. Lbs. |
|---|---|---|---|
| All Screws NOT Listed Below | 2 | 17 | |
| A/C Compressor to 2.7L Engine Front Bolts | 26 | 19 | |
| A/C Compressor to 2.7L Engine Rear Bolt | 50 | 37 | |
| A/C Compressor to 3.0L Engine Bolts | 26 | 19 | |
| A/C Compressor to 3.5L Engine Bolts | 26 | 19 | |
| A/C Compressor to 5.7L/6.1L Engine Bolts | 50 | 37 | |
| A/C Condenser to Radiator Bolts | 5 | 44 | |
| A/C Expansion Valve to Evaporator Tube Tapping Block Bolts | 11 | 97 | |
| Air Distribution Housing Halves Screws | 2.2 | 20 | |
| Air Distribution Housing to HVAC Housing Screws | 2.2 | 20 | |
| Air Inlet Housing to HVAC Housing Screws | 2.2 | 20 | |
| Blower Motor Screws | 2.2 | 20 | |
| Compressor Shaft Bolt | 19 | 168 | |
| Flange to HVAC Housing Screws | 2.2 | 20 | |
| Floor Console Duct to Floor Panel Screws | 2.2 | 20 | |
| Fresh Air Inlet Housing/Water Separator Filter Housing to Dash Panel Nuts | 7 | 62 | |
| Heater Core Retaining Bracket to Air Distribution Housing Screw | 2.2 | 20 | |
| HVAC Housing Halves Screws | 2.2 | 20 | |
| HVAC Housing to Engine Side of Dash Panel Nuts | 7 | 62 | |
| HVAC Housing to Passenger Side of Dash Panel Nuts | 3 | 26 | |
| Instrument Panel/demister Ducts to Instrument Panel Screw | 2.2 | 20 | |
| Liquid Line Front to Rear Section Nut | 22 | 16 | |
| PTC Heater Unit Screws | 2.2 | 20 | |
| Refrigerant Lines to A/C Expansion Valve Nut | 23 | 17 | |
| Refrigerant Line to A/C Compressor Nut | 23 | 17 | |
| Refrigerant Line to A/C Condenser Nut | 22 | 16 | |
| Refrigerant Line Bracket to Strut Tower Bolt | 11 | 97 | |
| Receiver/drier to A/C Condenser Bolt | 22 | 16 | |
| Receiver/drier Bracket to A/C Condenser Screw | 5 | 44 | |
| Suction Line Front to Rear Section Nut | 22 | 16 | |
| Strut Support to Strut Tower Bolts | 38 | 28 |
Scheme 119
Scheme 120
The blend door actuators (1) are reversible, 12 volt direct current (DC), servo motors. Models equipped with the MTC single zone heating-A/C system have a single blend-air door, which is controlled by a single blend door actuator. Models with the ATC dual zone heating-A/C system have two blend-air doors, which are controlled by two blend door actuators.
The blend door actuator for the single zone heating-A/C system is located on the driver side end of the HVAC air distribution housing, close to the dash panel.
For the dual zone heating-A/C system, the same blend door actuator used for the single zone system becomes the driver side blend door actuator, which is mechanically connected to only the driver side blend-air door. A second separate blend door actuator is also located on the passenger side of the HVAC air distribution housing which is mechanically connected to only the passenger side blend-air door.
The blend door actuators are interchangeable with each other, as well as with the actuators for the mode-air door and the recirculation-air door. Each actuator is contained within an identical black molded plastic housing with an integral wire connector receptacle (2). Each actuator also has an identical output shaft with splines (3) that connect it to its respective door linkage and three integral mounting tabs (4) that allow the actuator to be secured to the HVAC housing. The blend door actuators do not require mechanical indexing to the blend-air doors, as they are electronically calibrated by the A/C-heater control.
