3.6L Engine - Service Information: Specifications Dodge Challenger III рестайлинг

Mechanical 49 illustrations ~1619 words

SPECIFICATIONS

DESCRIPTIONSPECIFICATION
Type60° DOHC V-6 24-Valve
Compression Ratio10.2:1
Lead Cylinder#1 Right Bank
Firing Order1-2-3-4-5-6
MetricStandard
Displacement3.6 Liters220 Cubic Inches
Bore and Stroke96.0 x 83.0 mm3.779 in. x 3.268 in.

GENERAL SPECIFICATIONS

DescriptionSpecification
MetricStandard
Cylinder Bore Diameter - Grade 195.995 mm ± 0.005 mm3.7793 in. ± 0.0002 in.
Cylinder Bore Diameter - Grade 296.005 mm ± 0.005 mm3.7797 in. ± 0.0002 in.
Cylinder Bore Out-of-Round (Max.)0.009 mm0.00035 in.
Cylinder Bore Cylindricity0.014 mm0.0006 in.
Crankshaft Bore Taper* (Max.)0.006 mm0.0002 in.
*Measured over length of bulkhead

CYLINDER BLOCK

DescriptionSpecification
MetricStandard
MaterialCast Aluminum Alloy
Piston Diameter (Metal to Metal) - Grade 195.955 mm ± 0.005 mm3.7778 in. ± 0.0002 in.
Piston Diameter (Metal to Metal) - Grade 295.965 mm ± 0.005 mm3.7781 in. ± 0.0002 in.
Piston Diameter (Metal to Coating) - Grade 195.970 - 96.000 mm3.7783 - 3.7795 in.
Piston Diameter (Metal to Coating) - Grade 295.980 - 96.010 mm3.7787 - 3.7835 in.
Clearance at Size Location (Metal to Metal)0.030 - 0.050 mm0.0012 - 0.0020 in.
Clearance at Size Location (Metal to Coating)0.010 - 0.030 mm0.0004 - 0.0012 in.
Piston Weight354 - 364 grams12.487 - 12.840 oz.
Piston Pin Offset0.8 mm0.031 in.
Piston Ring Groove Diameter - No. 188.24 - 88.44 mm3.474 - 3.482 in.
Piston Ring Groove Diameter - No. 286.54 - 86.74 mm3.407 - 3.415 in.
Piston Ring Groove Diameter - No. 389.16 - 89.36 mm3.510 - 3.518 in.

PISTONS

DescriptionSpecification
MetricStandard
TypeFull Floating
Pin Diameter21.9985 ± 0.0015 mm0.86608 ± 0.00006 in.
Clearance in Piston0.002 - 0.011 mm0.0001 - 0.0004 in.
Clearance in Rod0.011 - 0.024 mm0.0004 - 0.0009 in.

PISTON PINS

DescriptionSpecification
MetricStandard
Ring Gap - Number 1 Ring (Top)0.25 - 0.40 mm0.010 - 0.016 in.
Ring Gap - Number 2 Ring (Center)0.30 - 0.45 mm0.012 - 0.018 in.
Ring Gap - Oil Control Ring (Steel Rails)0.15 - 0.66 mm0.006 - 0.026 in.

PISTON RINGS

DescriptionSpecification
MetricStandard
Number 1 Ring (Top)0.025 - 0.083 mm0.0010 - 0.0033 in.
Number 2 Ring (Center)0.030 - 0.078 mm0.0012 - 0.0031 in.
Oil Control Ring (Steel Rails)0.007 - 0.173 mm0.0003 - 0.0068 in.

PISTON RING SIDE CLEARANCE

DescriptionSpecification
MetricStandard
Number 1 Ring (Top)3.00 - 3.20 mm0.118 - 0.126 in.
Number 2 Ring (Center)3.59 - 3.85 mm0.141 - 0.152 in.
Oil Control Ring (Steel Rails)1.930 - 2.083 mm0.076 - 0.082 in.

PISTON RING WIDTH

DescriptionSpecification
MetricStandard
Bearing Clearance (With Crush)0.023 - 0.064 mm0.0009 - 0.0025 in.
Side Clearance0.070 - 0.370 mm0.0028 - 0.0146 in.
Side Clearance (Max.)0.370 mm0.0146 in.
Piston Pin Bore Diameter22.016 ± 0.005 mm0.8668 ± 0.0002 in.
Bearing Bore Out of Round (Max.)0.008 mm0.0003 in.
Total Weight (Less Bearing)546.7 ± 8 grams19.28 ± 0.28 oz.

CONNECTING RODS

DescriptionSpecification
MetricStandard
Diameter71.996 ± 0.009 mm2.8345 ± 0.0035 in.
Bearing Clearance0.024 - 0.050 mm0.0009 - 0.0020 in.
Bearing Clearance (Max.)0.050 mm0.0020 in.
Out of Round (Max.)0.005 mm0.0002 in.
Taper (Max.)0.005 mm0.0002 in.
End Play0.050 - 0.290 mm0.0020 - 0.0114 in.
End Play (Max.)0.290 mm0.0114 in.

CRANKSHAFT MAIN BEARING JOURNALS

DescriptionSpecification
MetricStandard
Diameter59.0 ± 0.009 mm2.3228 ± 0.0035 in.
Bearing Clearance0.023 - 0.064 mm0.0009 - 0.0025 in.
Out of Round (Max.)0.005 mm0.0002 in.
Taper (Max.)0.005 mm0.0002 in.

CONNECTING ROD JOURNALS

DescriptionSpecification
MetricStandard
Bore Diameter - No. 1 Cam Towers32.020 - 32.041 mm1.2606 - 1.2615 in.
Bore Diameter - No. 2, 3, 4 Cam Towers24.020 - 24.041 mm0.9457 - 0.9465 in.
Bearing Journal Diameter - No. 131.976 - 31.995 mm1.2589 - 1.2596 in.
Bearing Journal Diameter - No. 2, 3, 423.977 - 23.9960.9440 - 0.9447 in.
Bearing Clearance - No. 10.025 - 0.065 mm0.00010 - 0.0026 in.
Bearing Clearance - No. 2, 3, 40.024 - 0.064 mm0.0009 - 0.0025 in.
End Play0.075 - 0.251 mm0.003 - 0.010 in.

CAMSHAFT

DescriptionSpecification
Opens2° (ATDC)
Closes82° (ABDC) or 262° (ATDC)
Duration260°
Centerline128°
Note: Units are in crank degrees, using 0.1524 mm (0.006 in.) valve lift as the threshold.

VALVE TIMING-INTAKE VALVES

DescriptionSpecification
Opens59° (BBDC) or 239° (BTDC)
Closes12° (ATDC)
Duration251°
Valve Overlap10°
Note: Units are in crank degrees, using 0.1524 mm (0.006 in.) valve lift as the threshold.

VALVE TIMING-EXHAUST VALVES

DescriptionSpecification
MetricStandard
Gasket Thickness* (Compressed)0.48 - 0.60 mm0.019 - 0.024 in.
Flatness (Head Gasket Surface)0.09 mm0.0035 in.
Valve Seat Angle44.75° ± 0.25° from the valve guide axis
Valve Seat Runout (relative to the valve guide axis) - Intake and Exhaust0.050 mm0.002 in.
Intake Valve Seat Width1.0 - 1.2 mm0.04 - 0.05 in.
Exhaust Valve Seat Width1.41 - 1.61 mm0.055 - 0.063 in.
Guide Bore Diameter (Std.)6.00 - 6.02 mm0.236 - 0.237 in.
Valve Guide Height** - Intake and Exhaust16.05 - 16.55 mm0.632 - 0.652 in.
*Measured at the fire ring, not at the outer edge **Measured from cylinder head valve spring seat surface to top of guide

CYLINDER HEAD

DescriptionSpecification
MetricStandard
Face Angle45.25° ± 0.25°
Head Diameter - Intake39.0 ± 0.100 mm1.535 ± 0.004 in.
Head Diameter - Exhaust30.0 ± 0.100 mm1.181 ± 0.004 in.
Length-Intake (Overall)116.54 ± 0.23 mm4.588 ± 0.009 in.
Length-Exhaust (Overall)115.6 ± 0.23 mm4.551 ± 0.009 in.
Stem Diameter - Intake5.968 ± 0.009 mm0.2350 ± 0.0004 in.
Stem Diameter - Exhaust5.961± 0.009 mm0.2347 ± 0.0004 in.
Stem-to-Guide Clearance - Intake (New)0.023 - 0.061 mm0.0009 - 0.0024 in.
Stem-to-Guide Clearance - Exhaust (New)0.030 - 0.068 mm0.0012 - 0.0027 in.
Stem-to-Guide Clearance-Intake (Max., Rocking Method)0.29 mm0.011 in.
Stem-to-Guide Clearance - Exhaust (Max., Rocking Method)0.37 mm0.015 in.
Valve Lift-Intake (Zero Lash)10.3 mm0.406 in.
Valve Lift-Exhaust (Zero Lash)10.0 mm0.394 in.
Valve Stem Tip Height* - Intake52.4 - 53.5 mm2.063 - 2.106 in.
Valve Stem Tip Height* - Exhaust51.8 - 52.9 mm2.039 - 2.083 in.
*Valve tip to aluminum spring seat boss

VALVES

DescriptionSpecification
MetricStandard
Free Length - Intake AND Exhaust (Approx.)52.5 mm2.067 in.
Spring Force - Intake AND Exhaust (Valve Closed)295 ± 13 N @ 40.0 mm66 ± 3 lbs. @ 1.57 in.
Spring Force - Intake (Valve Open)688 ± 31 N @ 10.3 mm155 ± 7 lbs. @ 0.4055 in.
Spring Force - Exhaust (Valve Open)676 ± 30 N @ 10.0 mm152 ± 6 lbs. @ 0.3937 in.
Number of Coils - Intake AND Exhaust9.35
Wire Diameter - Intake AND Exhaust3.18 x 3.99 mm (ovate)0.125 x 0.157 in. (ovate)
Installed Height - Intake AND Exhaust (Spring seat top to bottom of retainer)40.0 mm1.575 in.

VALVE SPRING

DescriptionSpecification
MetricStandard
(NOTE: At Normal Operating Temperatures)
Pressure @ Curb Idle Speed*34.7 kPa Min.5 psi Min.
Pressure @ 600 - 1200 RPM34.7 (warm) - 958.0 (cold) kPa5 (warm) - 139 (cold) psi
Pressure @ 1201 - 3500 RPM206.8 (warm) - 958.0 (cold) kPa30 (warm) - 139 (cold) psi
Pressure @ 3501 - 6400 RPM427.0 (warm) - 958.0 (cold) kPa62 (warm) - 139 (cold) psi
*CAUTION: If oil pressure is zero at idle, DO NOT run engine at 3000 RPM.

OIL PRESSURE

TORQUE SPECIFICATIONS

DESCRIPTIONN.mFt. Lbs.In. Lbs.
Air Inlet Hose - Band Clamps435
A/C Compressor to Engine - M8 Bolts2518
Camshaft Chain Tensioner (Primary) - M6 T3012106
Camshaft Chain Guide (Primary) - M6 T3012106
Camshaft Chain Idler Sprocket - M8 T452518
Camshaft Chain LH Tensioner (Secondary) - M6 T3012106
Camshaft Chain LH Guide (Secondary) - M6 T3012106
Camshaft Chain RH Tensioner (Secondary) - M6 T3012106
Camshaft Chain RH Guide (Secondary) - M6 T3012106
Camshaft Position (CMP) Sensor to Cylinder Head - 6M T30980
Camshaft Bearing Cap - M6 T309.584
Connecting Rod Cap - M9 Bolts20 + 90° Turn15 + 90° Turn
Coolant Pump to Engine Timing Cover - M6 Bolts12106
Coolant Crossover Housing to Engine Timing Cover - M6 Bolts12106
Coolant Pump to Engine Timing Cover - M10 Bolt5540
Crankshaft Target Wheel to Counterweight - M6 T301089
Crankshaft Outer Main Bearing Cap and Windage Tray - M8 Bolts21 + 90° Turn16 + 90° Turn
Crankshaft Inner Main Bearing Cap - M11 Bolts20 + 90° Turn15 + 90° Turn
Crankshaft Side Main Bearing Cap (Tie Bolt) - M8 Bolts28250
Crankshaft Vibration Damper - M16 Bolt40 + 105° Turn30 + 105° Turn
Crankshaft Position (CKP) Sensor to Engine Block - M6 Bolt12106
Crankshaft Rear Oil Seal Retainer - M6 T3012106
Cylinder Head Oil Restrictor - M8 Plug15133
Cylinder Head to Engine Block - M12 Bolts in SequenceSee INSTALLATION Procedure.
Cylinder Head Cover - M6 Bolts12106
Catalytic Converter to Cylinder Head - M8 Bolts2317
Engine Coolant Temperature (ECT) Sensor1197
Engine Block Heater - M6 Bolt12106
Left/Right Engine Mount Bracket to Engine Block - M10 Bolts6145
Left/Right Engine Mount Isolator to Engine Mount Bracket - M10 Nuts6145
Left/Right Engine Mount Heatshield to Engine Mount Bracket - M6 Bolts12106
Left/Right Engine Mount Isolator to Frame - M10 Bolts6145
Flexplate to Crankshaft - M10 Bolts9570
Fuel Rail to Lower Intake Manifold - M6 Bolts762
Generator - M8 Bolts2518
Heater Core Supply Tube to Cylinder Head - M8 Bolt12106
Idler Pulley to Engine Timing Cover - Accessory Drive M8 Bolt2518
Ignition Capacitor to Cylinder Head - M6 Bolts1089
Ignition Coil to Cylinder Head Cover - M6 Bolts871
Intake Manifold (Upper) - M6 Bolts871
Intake Manifold (Lower) - M6 Bolts871
Knock Sensor to Engine Block - M8 T402216
Negative Battery Cable to Battery545
Engine Block Oil Gallery - M24 Plugs10 + 1250° Turn89 + 1250° Turn
Oil Control Valve - Cam Phaser M18150111
Upper Oil Pan to Engine Block - M8 Bolts2518
Transmission to Upper Oil Pan - M10 Bolts5541
Transmission to Starter - M10 Bolts5541
Torque Converter Dust Shield - M8 Bolt12106
Oil Cooler to Oil Filter Housing Screws435
Upper Oil Pan to Rear Seal Retainer - M6 Bolts12106
Oil Pan Drain - Plug M142720
Oil Pressure Sensor to Oil Filter Housing20177
Oil Temperature Sensor to Oil Filter Housing20177
Lower Oil Pan to Upper Oil Pan - M6 Bolts10.593
Piston Oil Cooler Jet to Engine Block - M5653
Oil Filter Housing/Oil Cooler to Engine Block - M6 Bolts12106
Oil Filter Housing Cap2518
Oil Pump to Block - M6 Bolts12106
Oil Level Indicator to Engine Block - M10 Bolt3526
Oil Level Indicator to Cylinder Head - M6 Bolt12106
Oil Pump Sprocket - M8 T452518
Oil Pump Pick Up Tube Bracket to Windage Tray - M6 Bolt12106
Oil Pump Pick Up Tube to Oil Pump - M6 Bolt12106
Oxygen Sensor to Exhaust Pipe - M185037
PCV Valve - M5 T25435
Power Steering Pump to Bracket - M8 Bolts2518
Power Steering Pump Bracket to Engine - M8 Bolts2518
Spark Plug to Cylinder Head - M1217.513
Starter Mounting - M10 Bolts5541
Tensioner to Engine Timing Cover - Accessory Drive M10 Bolt5541
Thermostat Housing to Coolant Crossover - M6 Bolts12106
Throttle Body - M6 Bolts762
Engine Timing Cover - M6 Bolts12106
Engine Timing Cover - M8 Bolt2518
Engine Timing Cover - M10 Bolts5541
Transmission to Engine Block - M10 Bolts5541
Transmission Fluid Indicator to Transmission - M6 Bolt12106
Torque Converter - M8 Bolts4231
Upper Intake Manifold Support Bracket to Cylinder Head - M8 Bolt20177
Upper Intake Manifold Support Bracket to Upper Intake Manifold - M6 Nuts1089
Variable Valve Timing Solenoid to Cylinder Head Cover - M5 T25435
Wire Harness Retainer Bracket to LH Cylinder Head - M6 T3012106
Rear Engine Mount Bracket to Transmission - M8 Bolts3324
Rear Engine Mount Isolator to Rear Engine Mount Bracket - M10 Bolts6145
Rear Engine Mount Crossmember to Frame - M10 Bolts5541
Rear Engine Mount Isolator to Crossmember - M10 Bolts6145
Left/Right Crossmember Brace to Crossmember - M8 Bolts5541
Left/Right Crossmember Brace to Frame - M8 Bolts5541

Scheme 1

Scheme 1: REMOVAL
Scheme 1: REMOVAL

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9
Scheme 9

Scheme 10

Scheme 10
Scheme 10

Scheme 11

Scheme 11
Scheme 11

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13
Scheme 13

Scheme 14

Scheme 14
Scheme 14

Scheme 15

Scheme 15
Scheme 15

Scheme 16

Scheme 16
Scheme 16

Scheme 17

Scheme 17
Scheme 17

Scheme 18

Scheme 18
Scheme 18

Scheme 19

Scheme 19
Scheme 19

Scheme 20

Scheme 20
Scheme 20

Scheme 21

Scheme 21
Scheme 21

Scheme 22

Scheme 22
Scheme 22

Scheme 23

Scheme 23
Scheme 23

Scheme 24

Scheme 24
Scheme 24

Scheme 25

Scheme 25
Scheme 25

Scheme 26

Scheme 26
Scheme 26

Scheme 27

Scheme 27
Scheme 27

Scheme 28

Scheme 28
Scheme 28

Scheme 29

Scheme 29
Scheme 29

Scheme 30

Scheme 30
Scheme 30

Scheme 31

Scheme 31
Scheme 31

Scheme 32

Scheme 32
Scheme 32

Scheme 33

Scheme 33
Scheme 33

Scheme 34

Scheme 34
Scheme 34

Scheme 35

Scheme 35
Scheme 35

Scheme 36

Scheme 36
Scheme 36

Scheme 37

Scheme 37
Scheme 37

Scheme 38

Scheme 38
Scheme 38

Scheme 39

Scheme 39
Scheme 39

Scheme 40

Scheme 40
Scheme 40

Scheme 41

Scheme 41
Scheme 41

Scheme 42

Scheme 42
Scheme 42

Scheme 43

Scheme 43
Scheme 43

Scheme 44

Scheme 44
Scheme 44

Scheme 45

Scheme 45
Scheme 45

Scheme 46

Scheme 46
Scheme 46

Scheme 47

Scheme 47
Scheme 47

Scheme 48

Scheme 48
Scheme 48

Scheme 49

Scheme 49
Scheme 49
  1. Remove the hood. Refer to «HOOD, REMOVAL»(ref-489285-S30284196642012072600000) .
  2. Remove the cowl panel cover (2). Refer to «COVER, COWL PANEL, REMOVAL»(ref-489285-S37125661702012072600000) .
  3. Remove the strut tower support (6).
  4. Perform the fuel pressure release procedure. Refer to «FUEL DELIVERY, GAS, STANDARD PROCEDURE»(ref-489307-S24512055572012072600000) .
  5. Disconnect and isolate the negative battery cable (1).
  6. Perform the Refrigerant System Recovery procedure. Refer to «PLUMBING, STANDARD PROCEDURE»(ref-489295-S09639003932012072600000) .
  7. Lift the engine cover retaining grommets off the ball studs and remove the engine cover (1).
  8. Disconnect the electrical connector (1) from the Inlet Air Temperature (IAT) sensor.
  9. Loosen the clamp (2) at the throttle body.
  10. Loosen the clamp (3) at the air cleaner housing.
  11. Lift the air inlet hose assembly retaining grommet off the ball stud (4).
  12. Remove the air inlet hose assembly (5).
  13. Disconnect the fresh air makeup hose (1) from the air cleaner housing.
  14. Remove the air cleaner housing retaining bolt (2).
  15. Remove the air cleaner housing (3).
  16. Raise and support the vehicle. Refer to «HOISTING, STANDARD PROCEDURE»(ref-489279-S05318852982012072600000) .
  17. Remove the belly pan retainers (1) and remove the belly pan.
  18. Drain the cooling system. Refer to «STANDARD PROCEDURE»(ref-489282-S15090009642012072600000) .
  19. Drain the engine oil. Refer to «Engine/Lubrication/OIL - Standard Procedure»(ref-489304-S28780796782012072600000) .
  20. Remove the starter motor. Refer to «STARTER, REMOVAL»(ref-489321-S10145474592012072600000) . NOTE: Left side shown in illustration, right side similar.
  21. Disconnect both left and right upstream oxygen sensor (2) electrical connectors (1). NOTE: Left side shown in illustration, right side similar.
  22. Remove the exhaust down pipe (1) to catalytic converter retaining nuts (2) from both left and right down pipes.
  23. Rotate the crankshaft in a clockwise direction until the torque converter bolts (1) are accessible through the starter mounting hole and remove the six torque converter bolts (1).
  24. Lower the vehicle.
  25. Remove the coolant bottle return hose (1).
  26. Remove the heater core purge hose (1) from the coolant bottle.
  27. Remove the coolant bottle retaining bolts (2).
  28. Remove the coolant bottle (3).
  29. Disconnect the vacuum line (3) at the EVAP purge solenoid (1).
  30. Disconnect the EVAP purge solenoid vacuum line (4) at the intake manifold and remove the vacuum line.
  31. Disconnect the PCV hose from the PCV valve (1) and the intake manifold (2) and remove hose.
  32. Disconnect the brake booster vacuum hose (3) and position aside.
  33. Disconnect the electrical connector at the Manifold Absolute Pressure (MAP) Sensor (4).
  34. Disconnect the electrical connector at the Electronic Throttle Control (ETC) (5).
  35. Disconnect the electrical connector at the Camshaft Position Sensor (CMP) (6) and position harness aside.
  36. Remove the fresh air makeup hose (2) from the rear of the intake manifold (1).
  37. Remove the upper intake manifold (2) and insulator. Refer to «MANIFOLD, INTAKE, REMOVAL»(ref-489304-S37202509642012072600000) .
  38. Disconnect the fuel supply hose (1) from the underbody fuel supply tube (2). Refer to «FITTING, QUICK CONNECT, STANDARD PROCEDURE»(ref-489307-S24042286862012072600000) .
  39. Remove the cooling fan module. Refer to «FAN, COOLING, REMOVAL»(ref-489282-S31342832962012072600000) . CAUTION: Do not let the tensioner arm snap back to the freearm position, sever damage may occur to the tensioner.
  40. Rotate the accessory drive belt tensioner (7) counterclockwise until it contacts the stop and remove the accessory drive belt (3), then slowly rotate the tensioner into the freearm position.
  41. Remove the generator (1). Refer to «GENERATOR, REMOVAL»(ref-489323-S33373725232012072600000) . NOTE: Mark the variable valve timing solenoid connectors (2) with a paint pen or equivalent so that they may be reinstalled in their original locations.
  42. Disconnect the electrical connectors (2) from the variable valve timing solenoids on the right cylinder head.
  43. Unfasten the starter harness to main harness retainer (3).
  44. Unfasten the two starter wire harness retainers (1) from the right cylinder head cover.
  45. Unfasten the main wire harness retainer (2) from the right cylinder head cover mounting stud.
  46. Unfasten the four main wire harness retainers (1) from the right cylinder head cover.
  47. Disconnect the oil pump solenoid electrical connector (2).
  48. Unfasten the four wire harness retainers (1).
  49. Remove the ground strap (3) from the right engine mount bracket. NOTE: Mark the variable valve timing solenoid connectors (2) with a paint pen or equivalent so that they may be reinstalled in their original locations.
  50. Disconnect the electrical connectors (2) from the left variable valve timing solenoids.
  51. Unfasten the two starter wire harness retainers (1) from the left cylinder head cover.
  52. Disconnect the A/C compressor electrical connector (1) and unfasten the wire harness retainer (2) from the A/C compressor discharge line.
  53. Unfasten the two starter wire harness retainers (1) from the upper intake manifold support brackets.
  54. Unfasten the main wire harness retainer (3) from the left cylinder head cover and two retainers (2) from the upper intake manifold support brackets.
  55. Disconnect the Engine Coolant Temperature (ECT) sensor connector (3).
  56. Disconnect the left Camshaft Position (CMP) sensor (5).
  57. Unfasten the main wire harness retainer (2) from the cylinder head cover and one main wire harness retainer (4) from the cylinder head cover mounting stud.
  58. Unfasten the main wire harness retainer (1) form the rear of the lower intake manifold.
  59. Remove the upper radiator hose (1) from the engine thermostat housing.
  60. Remove the lower heater core return hose (1) from the engine coolant pump housing.
  61. Remove the lower radiator hose (2) from the engine coolant pump housing.
  62. Remove the heater core return tube lower support bracket retaining nut (1).
  63. Disconnect the heater core return hose (1).
  64. Remove the heater core return tube upper support bracket retaining nut (2) and remove tube (1).
  65. Remove the A/C compressor (2). Refer to «COMPRESSOR, A/C, REMOVAL»(ref-489295-S39235681332012072600000) .
  66. Raise and support the vehicle. Refer to «HOISTING, STANDARD PROCEDURE»(ref-489279-S05318852982012072600000) .
  67. Remove the starter. Refer to «STARTER, REMOVAL»(ref-489321-S10145474592012072600000) .
  68. Unfasten the starter wire harness retainer (2) and the main wire harness retainer (1) from the engine block.
  69. Remove the bolt (1) and reposition the transmission cooling lines (2).
  70. Push back the heat shield (1) from the crankshaft position (CKP) sensor.
  71. Disconnect the main wire harness from the Crankshaft Position (CKP) sensor (3).
  72. Unfasten the main wire harness retainer (1) from the engine block and one main wire harness retainer (2) from the right engine mount bracket.
  73. Disconnect and reposition the power cord from the engine block heater (if equipped).
  74. Remove the two upper side transmission to engine retaining bolts (1).
  75. Disconnect the main harness from the engine injection/ignition harness (1) at the rear of the left cylinder head.
  76. Disconnect the main harness from the engine oil pressure/temperature harness (2) at the rear of the left cylinder head.
  77. Remove the side engine to transmission bolt (1). Remove the transmission dust shield retaining bolt (2) and remove the dust shield (3)
  78. Remove the two rubber plugs (1) covering the rear oil seal retainer flange bolts.
  79. Remove four transmission to the engine oil pan bolts (1).
  80. Lower the vehicle.
  81. Remove two bolts (3) and remove the heater core inlet tube (4).
  82. Remove the bolt (1) and remove the oil level indicator (2).
  83. Remove the left intake manifold support bracket retaining bolts (2) and remove the support brackets (1).
  84. Install the Driver Side Engine Lifting Bracket (special tool #10242-1, Brackets, Engine Lifting, Left Side) (1) on the left cylinder head with bolts (2) provided with the Engine Lifting Bracket and tighten bolts to 21 N.m (15 ft. lbs.).
  85. Install the Passenger Side Engine Lifting Bracket (special tool #10242-2, Brackets, Engine Lifting, Right Side) (1) on the right cylinder head with bolts (2) provided with the Engine Lifting Bracket and tighten bolts to 21 N.m (15 ft. lbs.).
  86. Reposition the starter wire harness and the main wire harness to the rear of the engine compartment.
  87. Position a load-leveling lifting sling (2), such as OTC® 4305 Engine Load Leveler or equivalent, between the engine lifting brackets (3) and an engine hoist (1).
  88. Support the transmission with a suitable jack.
  89. Unfasten the harness retainer (4) from the electric vacuum pump mounting bracket.
  90. Disconnect the electrical connector (1) from the electric vacuum pump (3).
  91. Remove the quick connect vacuum hose (2) from the electric vacuum pump (3).
  92. Remove the two upper transmission to engine retaining bolts (2) and remove the electric vacuum pump (3). NOTE: Left engine mount shown in illustration, right engine mount similar.
  93. Remove both left and right engine mount heat shield retaining nuts (3) and remove the heat shields (4).
  94. Remove both left and right engine mount lower retaining bolts (2). CAUTION: While slowly separating the engine from the vehicle, constant checks must be made to assure proper positioning and that no damage to other components or wiring harnesses occur during separation.
  95. Carefully remove the engine from the engine compartment.
  96. If required, remove the following components for installation on the replacement engine
  1. Left exhaust down pipe
  2. Right exhaust down pipe
  3. Left engine mount bracket
  4. Left engine mount
  5. Right engine mount bracket
  6. Right engine mount
  7. Accessory drive belt tensioner
  8. Upper intake manifold support bracket
  9. Block heater (if equipped)

OIL FILTER SPECIFICATION

All engines are equipped with a high quality full-flow, disposable type oil filter. When replacing oil filter, use a Mopar® filter or equivalent.

More articles — 3.6L Engine - Service Information
