DESCRIPTION
| CAUTION | Within the power distribution system there are replaceable diodes that can be installed incorrectly. Ensure when replacing a diode that it is inserted in the correct orientation. |
The power distribution system for this vehicle consists of the following components
- Cigar Lighter Outlet
- Totally Integrated Power Module (TIPM) - located underhood
- Power Distribution Center (PDC) - located in trunk
- Power Outlets
Refer to appropriate Wiring Diagrams for complete circuit schematics.
The power distribution system also incorporates various types of circuit control and protection features, including
- Automatic resetting circuit breakers
- Blade-type fuses
- Cartridge fuses
- Relays
- Mini fuses
Scheme 1
The majority of electrical system fuses and relays are housed in the two Power Distribution Centers (PDC). One is located in the engine compartment, the Totally Integrated Power Module (TIPM). Refer to MODULE, TOTALLY INTEGRATED POWER (TIPM), DESCRIPTION . The PDC is located next to the battery in the rear of the vehicle. The PDC located next to the battery is replaced only as part of the body wiring harness.
For fuse description and layout. Refer to FUSE LOCATIONS AND TYPES, SPECIFICATIONS .
The majority of electrical system fuses and relays are housed in the Totally Integrated Power Module (TIPM) located in the engine compartment and the rear Power Distribution Center (PDC) next to the battery in the trunk of the vehicle. For the rear PDC. Refer to CENTER, POWER DISTRIBUTION (PDC), DESCRIPTION .
For fuse description and layout. Refer to FUSE LOCATIONS AND TYPES, SPECIFICATIONS .
Sedans are equipped with two 12-volt electrical outlets. Five-door models are equipped with three 12-volt electrical outlets. The outlets are located in the following locations
- Cargo area right quarter trim panel (Five-door models only).
- Inside the center console.
- Next to the ash receiver in the center stack.
The outlets in the console and quarter trim panel have power at all times, and include tethered covers. The outlet in the ash receiver tray is shipped with power available only when the ignition is in the ON position. This outlet can be changed to provide power at all times by moving a fuse in the fuse block.
Scheme 2
Scheme 3
- Disconnect and isolate the battery negative cable.
- Look inside and note position of the retaining bosses (2).
- Insert Remover, Power Outlet (special tool #10246, Remover, Power Outlet) (1) into the retaining bosses (2) of the power outlet.
- Pull out the base through the mounting ring by gently rocking the tool.
- Disconnect the harness (1) from the power outlet (2).
- Set the base aside and remove the base mount ring.
