Power Distribution: Other Dodge Challenger III рестайлинг

Body Electrical 7 illustrations ~328 words

STANDARD PROCEDURE - PROGRAMMING

  1. Install a battery charger.
  2. Verify that the charging rate provides approximately 13.5 volts. NOTE: Do not allow the charger to time out during the reconfiguration process. Set the battery charger timer (if so equipped) to continuous charge.
  3. Connect the CH9410 StarSCAN ethernet cable to the StarSCAN and the dealer's network drop.
  4. Connect the CH9404 StarSCAN vehicle cable to the StarSCAN and the vehicle.
  5. Place the Ignition in the "RUN" position, then Power "ON" the StarSCAN.
  6. Select "ECU View".
  7. Select "TIPMCGW" or "FCMCGW".
  8. Select "MISC".
  9. Select "Restore Vehicle Configuration".
  10. Follow prompts on StarSCAN to complete the reconfigure procedure.
  11. Once complete, Wait one minute and turn the ignition key to the "OFF" position.
  12. Remove the StarSCAN unit, cable and charger from the vehicle.
  13. Verify proper operation.

Scheme 4

Scheme 4: REMOVAL
Scheme 4: REMOVAL

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7
Scheme 7
  1. Disconnect and isolate the battery negative cable (2).
  2. Open the positive battery cable nut cover to expose nut.
  3. Remove the battery cable nut and the battery cable from the Totally Integrated Power Module (TIPM).
  4. Disengage the outboard retaining clip, and rotate the TIPM to access wire harness connectors.
  5. Disconnect the wire harness connectors from TIPM.
  6. Disengage the two inboard retaining clips.
  7. Remove the TIPM from vehicle.

Scheme 8

Scheme 8: INSTALLATION
Scheme 8: INSTALLATION
CAUTIONThe original Cab Compartment Node (CCN) and Powertrain Control Module (PCM) must be installed and functioning properly prior to powering up the new Totally Integrated Power Module (TIPM). The TIPM receives vehicle configuration data from the CCN and Vehicle Identification Number information from the PCM. If configuration information becomes lost or corrupted, the data can be obtained from DealerCONNECT

Scheme 9

Scheme 9
Scheme 9

Scheme 10

Scheme 10
Scheme 10
  1. Position Totally Integrated Power Module (TIPM) to vehicle. Engage the three retaining clips.
  2. Disengage the outboard retaining clip and rotate the TIPM to access wire harness connectors.
  3. Connect electrical harness connectors to TIPM.
  4. Connect battery cable to TIPM. Tighten the nut to 20 - 28 N.m (15 - 21 ft. lbs.).
  5. Close the battery cable nut cover.
  6. Connect negative battery cable (2).
  7. Insert the ignition key and turn it to the RUNposition and wait twenty seconds. The TIPM will collect the necessary vehicle configuration and VIN data from the CCN and PCM at this time. After twenty seconds turn the ignition key to the OFFposition and then back to the ONposition and verify proper vehicle systems operation.
