Scheme 282

1. Apply a 2 to 3 mm wide bead of Mopar® Threebond Engine RTV Sealant to the upper oil pan as shown in illustration in the following locations: Oil pan to engine block flange (1) Two timing cover to engine block T-joints (2) Two rear seal retainer to engine block T-joints (3) CAUTION: Make sure that the rear face of the oil pan is flush to the transmission bell housing before tightening any of the oil pan mounting bolts. A gap between the oil pan and the transmission could crack the oil pan or transmission casting.
2. Install the oil pan to the engine block and flush to the transmission bell housing. Secure the oil pan to the engine block with nineteen M8 oil pan mounting bolts (1) finger tight.
3. Install the five oil pan to transmission bolts (1) and tighten to 55 N.m (41 ft. lbs.).
4. Tighten the nineteen previously installed M8 oil pan mounting bolts (3) to 25 N.m (18 ft. lbs.). NOTE: Illustration shows transmission removed for clarity.
5. Install the two M6 bolts (1) to the rear oil seal retainer flange and tighten to 12 N.m (9 ft. lbs.).
6. Install the torque converter bolt access cover (1).
7. Install the two rubber plugs (2) covering the rear oil seal retainer flange bolts.
8. Install the bolt (1) securing the coolant tube (2) to oil pan and tighten to 12 N.m (106 in. lbs.).
9. Install the lower oil pan. Refer to «PAN, OIL, INSTALLATION»(ref-574535-S11376826212013082700000) .
10. Install the front fore-aft crossmember (1). Refer to «CROSSMEMBER, FRONT FORE AND AFT, INSTALLATION»(ref-574538-S23116445172013082700000) and «CROSSMEMBER, FRONT SUSPENSION, INSTALLATION»(ref-574538-S06308787792013082700000) .
11. Install the crossunder pipe (2). Refer to «PIPE, EXHAUST CROSSUNDER, INSTALLATION»(ref-574575-S01990010872013082700000) .
12. Install the right halfshaft assembly, steering knuckle, wheel and tire. Refer to «INSTALLATION»(ref-574539-S35475249922013082700000) .
13. Install the belly pan (Refer to «UNDER BODY PROTECTION»(ref-574538-S25621752162013082700000) ).
14. Lower the vehicle.
15. Install the oil level indicator (1) with bolt (2) tightened 12 N.m (106 in. lbs.).
16. If removed, install the oil filter and fill the engine crankcase with the proper oil to the correct level. Refer to «STANDARD PROCEDURE»(ref-574535-S31460334432013082700000) .
17. Connect the negative battery cable and tighten nut to 5 N.m (45 in. lbs.).
18. Run the engine until it reaches normal operating temperature.

Scheme 283

Scheme 284

1. Disconnect and isolate the negative battery cable.
2. Remove the lower oil pan. Refer to «PAN, OIL, REMOVAL»(ref-574535-S41682488282013082700000) .
3. Remove the bolt (3) and the oil pick-up tube (1) from the oil pump.
4. Remove and discard the O-ring seal (1) from the oil pick-up tube.

INSTALLATION

1. Lightly lubricate the new O-ring seal (1) with engine oil and install on the oil pick-up tube.
2. Install the oil pick-up tube (1). Tighten the bolt (3) to 12 N.m (106 in. lbs.).
3. Install the lower oil pan. Refer to «PAN, OIL, INSTALLATION»(ref-574535-S11376826212013082700000) .
4. If removed, install the oil filter and fill the engine crankcase with the proper oil to the correct level. Refer to «STANDARD PROCEDURE»(ref-574535-S31460334432013082700000) .
5. Connect the negative battery cable and tighten nut to 5 N.m (45 in. lbs.).
6. Run the engine until it reaches normal operating temperature.

Scheme 285

The vane type engine oil pump is mounted to the underside of the cylinder block and is driven by the oil pump chain off the crankshaft at a 1:1 drive ratio. This pump location improves efficiency compared to an on-crankshaft location. The pump is driven with a silent chain which is tensioned using a spring loaded tensioner. The pump is not timed to the engine.

An internal mechanical ball and spring type relief valve prevents excess pressure in the engine by dumping oil into the sump and provides emergency protection at conditions such as a cold start with high engine speed.

The pump has a moving slide mechanism for variable displacement capability and an on-off solenoid for two-stage pressure regulation. The pump and the solenoid are not to be disassembled. Both are non-serviceable items and are to be replaced as a complete assembly.

Scheme 286

The engine oil pump features seven vanes and a moving element (1) that continuously adjusts to maintain a regulated oil pressure supply by varying the displacement of the pump. The pump has two regulated pressure stages of operation controlled by an on/off solenoid (2). Low pressure mode regulation (solenoid on) is approximately 200 kPa (29 psi) and high pressure mode regulation (solenoid off) is approximately 450 kPa (65 psi). The Powertrain Control Module (PCM) switches the pump between stages based on engine operating conditions, oil and coolant temperatures, speed and load. Under most typical conditions, the pump will run in low mode from idle up to around 3000 RPM, and switch from low to high mode between 3000 and 4000 RPM.

The maximum oil pressure in the engine is limited to 1000 kPa (145 psi) by the relief valve (3). Pressure in the main oil gallery of the engine can be monitored with diagnostic equipment through the oil pressure sensor mounted on the rear of the oil filter module. The minimum pressure for the engine is 41 kPa (6 psi) at any operating condition. Anything under this pressure could result in damage to critical moving parts.

Scheme 287

In high pressure mode regulation (solenoid off) main gallery oil pressure (2) is applied to the moving element (1). The main gallery oil pressure works against spring pressure (3) to move the element to a more concentric location about the pump driveshaft (4) thus reducing displacement and pump output.

Scheme 288

In low pressure mode regulation (solenoid on) the energized solenoid opens an additional chamber (1) to main gallery oil pressure increasing the force on the spring (2) to further reduce displacement and output pressure.

Scheme 289

Scheme 290

Scheme 291

Scheme 292

Scheme 293

Scheme 294

Scheme 295

Scheme 296

Scheme 297

1. Disconnect and isolate the negative battery cable.
2. Remove the upper oil pan. Refer to «PAN, OIL, REMOVAL»(ref-574535-S41682488282013082700000) .
3. Remove the oil pump pick-up (2). Refer to «PICK-UP, OIL PUMP, REMOVAL»(ref-574535-S09875536832013082700000) .
4. Disconnect the engine wire harness from the oil pump solenoid electrical connector (1).
5. Depress the connector retention lock tab (1) to disengage the oil pump solenoid electrical connector from the engine block.
6. Remove bolts (2) and the timing gear splash shield (1). NOTE: Graphic shows the engine timing cover removed for clarity.
7. Push the oil pump solenoid electrical connector into the engine block, rotate the connector slightly CW, push it past the primary chain tensioner mounting bolt (1) and into the engine.
8. Push back the oil pump chain tensioner (2) and insert a suitable retaining pin (1) such as a 3 mm Allen wrench. CAUTION: Always reinstall timing chains so that they maintain the same direction of rotation. Inverting a previously run chain on a previously run sprocket will result in excessive wear to both the chain and sprocket.
9. Mark the direction of rotation on the oil pump chain (3) and sprocket (4) using a paint pen or equivalent to aid in reassembly. NOTE: There are no timing marks on the oil pump gear or chain. Timing of the oil pump is not required.
10. Remove the oil pump sprocket T45 retaining bolt (2) and remove the oil pump sprocket (4).
11. Remove the retaining pin (3) and disengage the oil pump chain tensioner spring (1) from the dowel pin (2).
12. Remove the oil pump chain tensioner from the oil pump.
13. Remove the four oil pump bolts (1) and remove the oil pump (3).

Scheme 298

Note. The Oil pump is released as an assembly. The assembly includes both the pump and the solenoid. There are no serviceable sub-assembly components. In the event the oil pump or solenoid are not functioning or out of specification they must be replaced as an assembly.

1. Inspect the solenoid wires (1) for cuts or chaffing.
2. Inspect the condition of the connector O-ring seal (3).

1. Align the locator pins (2) to the engine block and install the oil pump (3) with four bolts (1). Tighten the bolts to 12 N.m (106 in. lbs.).
2. Install the oil pump chain tensioner on the oil pump.
3. Position the oil pump chain tensioner spring (1) above the dowel pin (2).
4. Push back the oil pump chain tensioner and insert a suitable retaining pin (3) such as a 3 mm Allen wrench. NOTE: There are no timing marks on the oil pump gear or chain. Timing of the oil pump is not required. CAUTION: Always reinstall timing chains so that they maintain the same direction of rotation. Inverting a previously run chain on a previously run sprocket will result in excessive wear to both the chain and sprocket.
5. Place the oil pump sprocket (4) into the oil pump chain (3). Align the oil pump sprocket with the oil pump shaft and install the sprocket. Install the T45 retaining bolt (2) and tighten to 25 N.m (18 ft. lbs.).
6. Remove the retaining pin (1). Verify that the oil pump chain is centered on the tensioner and crankshaft sprocket.
7. Rotate the crankshaft CW one complete revolution to verify proper oil pump chain installation. NOTE: Graphic shows the engine timing cover removed for clarity.
8. Position the oil pump solenoid electrical connector (2) into the engine block. Rotate the connector so that it can be pushed past the primary chain tensioner mounting bolt (1). Then rotate the connector slightly CCW and push it into the engine block until it locks in place.
9. Install the timing gear splash shield (1). Tighten bolts (2) to 5 N.m (35 in. lbs.).
10. Verify that the oil pump solenoid electrical connector retention lock tab (1) is engaged to the engine block.
11. Connect the engine wire harness to the oil pump solenoid electrical connector (1).
12. Install the oil pump pick-up (2). Refer to «PICK-UP, OIL PUMP, INSTALLATION»(ref-574535-S20342226752013082700000) .
13. Install the oil pan. Refer to «PAN, OIL, INSTALLATION»(ref-574535-S11376826212013082700000) .
14. If removed, install the oil filter and fill the engine crankcase with the proper oil to the correct level. Refer to «STANDARD PROCEDURE»(ref-574535-S31460334432013082700000) .
15. Connect the negative battery cable and tighten nut to 5 N.m (45 in. lbs.). CAUTION: A MIL or low oil pressure indicator that remains illuminated for more than 2 seconds may indicate low or no engine oil pressure. Stop the engine and investigate the cause of the indication.
16. Start and run the engine until it reaches normal operating temperature.
