Automatic Transmission Shift Lock Control Connector End Views
Automatic Transmission Shift Lock Actuator Connector End Connector Part Information 12064762 6-Way F Metri-Pack 150 Series (GY) Pin Wire Color Circuit No. Function A BK 2250 Ground B L-GN/BK 584 A/T Shift Lock Control Switch Supply Voltage C YE 1996 Ignition Lock Cylinder Control Actuator Signal D - - Not Used E D-GN/WH 1135 A/T Shift Lock Control Solenoid Supply Voltage F PK 1020 Ignition 0 Voltage
Park Neutral Position Switch (PNP) Connector End Connector Part Information 15416722 11-Way F GT Mixed with Latch (GY) Pin Wire Color Circuit No. Function 1 YE 1737 Neutral Safety Switch Park/Neutral Signal 2 - - Not Available 3 - - Not Used 4 YE 722 Transmission Range Switch Signal B 5 BK/WH 771 Transmission Range Switch Signal A 6 GY 773 Transmission Range Switch Signal C 7 BK 450 Ground 8 WH 776 Transmission Range Switch Signal P 9 L-GN 275 Park Neutral Position Park Signal 10 - - Not Used 11 PK 339 Ignition 1 Voltage 12 PK 639 Ignition 1 Voltage
