Scheme 92
Scheme 92: Transmission Identification Information
| Callout | Component Name |
|---|
| 1 | 4 = 2004 |
| 2 | Model |
| 3 | Hydra-Matic 4L60-E |
| 4 | Julian Date or Day of the Year |
| 5 | Shift Built, See Shift Build Chart |
| 6 | Serial Number |
| 7 | Case/Pan Frame Rail Location |
| 7 | Case/Pan Frame Rail Location |
| 8 | Optional Transmission ID Location, Tag Is Used as a Back-Up If Unable To Etch Case/Pan Area and To Bar Code Scan |
Scheme 93
| Callout | Component Name |
|---|
| 1 | 4 = 2004 |
| 2 | Model |
| 3 | Hydra-Matic 4L60-E |
| 4 | Plant of Manufacture, 4 is Ramos |
| 5 | Julian Date or Day of the Year |
| 6 | Shift Built, See Shift Build Chart |
| 7 | Transmission Serial Number |
| 8 | Optional Transmission ID Tag Location, Tag Is Used as a Back-Up If Unable To Etch Case/Pan Area and To Bar Code Scan |
| 9 | Case/Pan Frame Rail Area |
| 9 | Case/Pan Frame Rail Area |
Scheme 94
| Callout | Component Name |
|---|
| 1 | 4 = 2004 |
| 2 | Model |
| 3 | Hydra-Matic 4L60-E |
| 4 | Transmission Asm. as Shipped Number |
| 5 | 4 = Model Year |
| 6 | Julian Date or Day of the Year |
| 7 | Letter After Julian Date Identifies the Plant Shift Build, See Shift Build Chart |
| 8 | Bar Code |
| 9 | Serial Number |
| 10 | Broadcast Code |
| 11 | Transmission ID |
| 12 | Build Location Y = Toledo, OH, R = Romulus, MI, 4 = Ramos Arizpe, Mexico |
| Plant | Build Line | 1st Shift | 2nd Shift | 3rd Shift |
|---|
| Toledo, OH | ML1 | J | W | X |
| ML2 | A | C | Not Used |
| ML3 | B | H | Not Used |
| ML4 | S | L | V |
| ML5 | K | E | Z |
| Romulus, MI | 1 | A | | B |
| Ramos Arizpe, Mexico | 1 | A | | |
Plant And Shift Build Chart
