Radio/Audio System Schematics (Base/Uplevel Radio - UQ3/UQ5)
For wiring diagram, see SYSTEM WIRING DIAGRAMS .
For wiring diagram, see SYSTEM WIRING DIAGRAMS .
Radio/Audio System Schematics (Luxury Radio - UQ7 w/Y91)
For wiring diagram, see SYSTEM WIRING DIAGRAMS .
Scheme 32
Scheme 33
Scheme 34
| Callout | Component Name |
|---|---|
| 1 | Auxiliary Power Outlet - Front Connector |
| 2 | S333 |
| 3 | S307 |
| 4 | S303 |
| 5 | Rear Seat Audio (RSA) Controller Connector |
| 6 | Auxiliary Power Outlet - Console Connector |
| 7 | Audio Amplifier Connector C2 |
| 8 | Audio Amplifier Connector C1 |
| 9 | Cigar Lighter |
| 10 | C306 |
| 11 | Speaker - Subwoofer Connector |
| 12 | Speaker - Subwoofer (UQ7) |
Scheme 35
| Callout | Component Name |
|---|---|
| 1 | Radio Connectors |
| 2 | Radio Antenna |
| 3 | Instrument Panel |
| 4 | HVAC Control Module |
| 5 | Radio |
| 6 | HVAC Control Module Connectors |
Scheme 36
| Callout | Component Name |
|---|---|
| 1 | Inner Body Panel-LH |
| 2 | Speaker Connector - Harness |
| 3 | Electrical Connector - Speaker |
| 4 | Speaker-LR |
Scheme 37
| Callout | Component Name |
|---|---|
| 1 | Door-RF |
| 2 | Speaker-RF Door |
| 3 | Speaker-RF Door Connector |
Scheme 38
| Callout | Component Name |
|---|---|
| 1 | Door-LF |
| 2 | Speaker-LF Door |
| 3 | Window Motor-Driver Connector |
| 4 | Speaker-LF Door Connector |
| 5 | Driver Door Module (DDM) Connectors |
| 6 | Outside Rearview Mirror-Left Connector |
Scheme 39
| Callout | Component Name |
|---|---|
| 1 | Left A-Pillar Trim Panel |
| 2 | Speaker-LF Tweeter |
| 3 | Speaker-LF Tweeter Connector |
Scheme 40
| Callout | Component Name |
|---|---|
| 1 | Door-LR |
| 2 | Window Motor-LR |
| 3 | Speaker-LR |
Scheme 41
| Callout | Component Name |
|---|---|
| 1 | Instrument Panel |
| 2 | C202 |
| 3 | SP250 |
Scheme 42
| Callout | Component Name |
|---|---|
| 1 | Center Console |
| 2 | Rear Seat Audio (RSA)/Rear HVAC Controller |
| 3 | Auxiliary Power Outlet-Console |
Scheme 43
| Callout | Component Name |
|---|---|
| 1 | Steering Wheel Audio Controls-Left |
| 2 | Inflatable Restraint Steering Wheel Module - C4 |
| 3 | Steering Wheel Audio Controls-Right |
| 4 | Steering Wheel Driver Information Center (DIC) Controls-Right |
| 5 | Inflatable Restraint Steering Wheel Module - C3 |
| 6 | Inflatable Restraint Steering Wheel Module - C2 |
| 7 | Steering Wheel Driver Information Center (DIC) Controls-Left |
| 8 | Steering Column |
| 9 | Steering Wheel |
Scheme 44
| Callout | Component Name |
|---|---|
| 1 | Lower I/P Bezel |
| 2 | Remote Playback Device-CD Player |
Scheme 45
| Callout | Component Name |
|---|---|
| 1 | Right Side of Instrument Panel |
| 2 | Digital Radio Receiver |
| 3 | Digital Radio Receiver Connector |
Scheme 46
| Callout | Component Name |
|---|---|
| 1 | Headliner |
| 2 | Rear Seat Entertainment (RSE) Assembly |
| 3 | Rear Seat Entertainment (RSE) Display |
| 4 | Intermediate Bracket |
| 5 | Fir Tree Retainer |
Scheme 47
| Callout | Component Name |
|---|---|
| 1 | Steering Wheel Audio Controls - Left |
| 2 | Passlock Sensor Connector |
| 3 | Ignition Key Alarm Switch |
| 4 | Ignition Lock Cylinder Control Actuator |
| 5 | Ignition Lock Cylinder Control Actuator Connector |
| 6 | Ignition Switch |
| 7 | Ignition Key Cylinder |
| 8 | Steering Wheel Audio Controls - Right |
| 9 | Horn Switch |
| 10 | Steering Wheel Driver Information (DIC) Controls - Right |
| 11 | C277 |
| 12 | Steering Wheel Driver Information Center (DIC) Controls - Left |
| 13 | Turn Signal/Multifunction Switch |
Entertainment Connector End Views
Audio Amplifier C1 (RPO Code UQ7 w/o Y91) Terminal Identification Connector Part Information 12110088 24-Way F Micro-Pack 100 Series (GRY) Pin Wire Color Circuit No. Function A1-A4 - - Not Used A5 BRN 199 Left Rear Speaker Output (+) A6 YEL 116 Left Rear Speaker Output (-) A7 DK BLU 46 Right Rear Speaker Output (+) A8 LT BLU 115 Right Rear Speaker Output (-) A9 TAN 201 Left Front Speaker Output (+) A10 GRY 118 Left Front Speaker Output (-) A11 LT GRN 200 Right Front Speaker Output (+) A12 DK GRN 117 Right Front Speaker Output (-) B1 GRY/BLK 2334 Radio Mute B2 PPL 493 Rear Seat Audio Enable Signal B3 BLK 1946 Right Rear Low Level Audio Signal (-) B4 DK BLU 546 Right Rear Low Level Audio Signal (+) B5 DK GRN/WHT 1547 Left Rear Low Level Audio Signal (-) B6 BRN 599 Left Rear Low Level Audio Signal (+) B7 ORN/BLK 1546 Right Front Low Level Audio Signal (-) B8 LT GRN 512 Right Front Low Level Audio Signal (+) B9 DK GRN 1947 Left Front Low Level Audio Signal (-) B10 TAN 511 Left Front Low Level Audio Signal (+) B11 PNK 314 Radio On Signal B12 BARE 2099 Drain Wire
Audio Amplifier C1 (RPO Code UQ7 w/Y91) Terminal Identification Connector Part Information 12110088 24-Way F Micro-Pack 100 Series (GRY) Pin Wire Color Circuit No. Function A1-A2 - - Not Used A3 YEL 116 Left Rear Speaker Output (+) A4 BRN 199 Left Rear Speaker Output (-) A5 TAN 201 Left Front Speaker Output (+) A6 GRY 118 Left Front Speaker Output (-) A7 LT BLU 115 Right Rear Speaker Output (+) A8 DK BLU 46 Right Rear Speaker Output (-) A9 LT GRN 200 Right Front Speaker Output (+) A10 DK GRN 117 Right Front Speaker Output (-) A11-A12 - - Not Used B1 DK GRN 1488 Noise Compensation Microphone Supply Voltage B2 LT GRN/BLK 1354 Drain Wire B3 ORN/BLK 1546 Right Front Low Level Audio Signal (-) B4 DK GRN 1947 Left Front Low Level Audio Signal (-) B5 TAN 511 Left Front Low Level Audio Signal (+) B6 LT GRN 512 Right Front Low Level Audio Signal (+) B7 BARE 2011 Drain Wire B8-B9 - - Not Used B10 DK BLU 2272 Amplifier Class 2 Serial Data B11-B12 - - Not Used
Audio Amplifier C2 (RPO Code UQ7 w/o Y91) Terminal Identification Connector Part Information 12110626 8-Way F Metri-pack 280 Series (GRY) Pin Wire Color Circuit No. Function A BLK/WHT 1851 Ground B DK BLU/WHT 346 Left Suborder Speaker Output (+) C DK GRN 1795 Right Subwoofer Speaker Output (+) D - - Not Used E BARE 2011 Drain Wire F LT BLU/BLK 315 Right Subwoofer Speaker Output (-) G LT GRN/BLK 1794 Left Subwoofer Speaker Output (-) H ORN 3740 Battery Positive Voltage
Audio Amplifier C2 (RPO Code UQ7 w/Y91) Terminal Identification Connector Part Information 12110626 8-Way F Metri-Pack 280 Series (GRY) Pin Wire Color Circuit No. Function A BLK/WHT 1851 Ground B DK GRN 1795 Right Subwoofer Speaker Output (+) C - - Not Used D LT GRN/BLK 1794 Left Subwoofer Speaker Output (-) E DK BLU/WHT 346 Left Subwoofer Speaker Output (+) F - - Not Used G LT BLU/BLK 315 Right Subwoofer Speaker Output (-) H ORN 3740 Battery Positive Voltage
Digital Radio Receiver (RPO Code w/ U2K/U2L) Terminal Identification Connector Part Information 15394150 16-Way F Micro 64 (BLK) Pin Wire Color Circuit No. Function 1 - - Not Used 2 BRN/WHT 367 Remote Playback Device Left Audio Signal 3 DK GRN/WHT 368 Remote Playback Device Right Audio Signal 4-6 - - Not Used 7 LT GRN 2271 ADG Class 2 Serial Data 8 - - Not Used 9 BLK/WHT 1851 Ground 10 BLK/WHT 372 Remote Playback Device Common Audio Signal 11-15 - - Not Used 16 ORN 340 Battery Positive Voltage
Noise Compensation Microphone (RPO Code UQ7 w/Y91) Terminal Identification Connector Part Information 12047663 2-Way M Metri-Pack 150 Series (BLK) Pin Wire Color Circuit No. Function A LT GRN/BLK 1354 Drain Wire B DK GRN 1488 Noise Reduction Microphone Supply Voltage
Radio C1 Terminal Identification Connector Part Information 12110088 24-Way F Micro-Pack 100 Series (GRN) Pin Wire Color Circuit No. Function A1 ORN 1044 Radio Class 2 Serial Data A2 - - Not Used A3 PPL 493 Rear Seat Audio Enable Signal (UQ7) A4-A7 - - Not Used A8 TAN 201 Left Front Speaker Output (+) (UQ3/UQ5) TAN 511 Left Front Low Level Audio Signal (+) (UQ7) A9 GRY 118 Left Front Speaker Output (-) (UQ3/UQ5) DK GRN 1947 Left Front Low Level Audio Signal (-) (UQ7) A10 LT BLU 115 Right Rear Speaker Output (-) (UQ3/UQ5) BLK 1946 Right Rear Low Level Audio Signal (-) (UQ7) A11 DK BLU 46 Right Rear Speaker Output (+) (UQ3/UQ5) DK BLU 546 Right Rear Low Level Audio Signal (+) (UQ7) A12 BLK/WHT 1851 Ground B1 ORN 340 Battery Positive Voltage B2 - - Not Used B3 PNK 314 Radio On Signal (UQ7 w/o Y91) B4-B5 - - Not Used B6 GRY/BLK 2334 Radio Mute (UQ7 w/o Y91) B7 - - Not Used B8 BRN 199 Left Rear Speaker Output (+) (UQ3/UQ5) BRN 599 Left Rear Low Level Audio Signal (+) (UQ7) B9 YEL 116 Left Rear Speaker Output (-) (UQ3/UQ5) DK GRN/WHT 1547 Left Rear Low Level Audio Signal (-) (UQ7) B10 DK GRN 200 Right Front Speaker Output (+) (UQ3/UQ5) ORN/BLK 1546 Right Front Low Level Audio Signal (-) (UQ7) B11 LT GRN 117 Right Front Speaker Output (-) (UQ3/UQ5) LT GRN 512 Right Front Low Level Audio Signal (+) (UQ7) B12 - - Not Used
Radio C2 Terminal Identification Connector Part Information 12064799 12-Way F Micro-Pack 100 Series (BLK) Pin Wire Color Circuit No. Function A-B - - Not Used C BARE 1573 Drain Wire (w/ U2K/U2L) D-G - - Not Used H DK GRN/WHT 368 Remote Playback Device Right Audio Signal (w/ U2K/U2L) J BRN/WHT 367 Remote Playback Device Left Audio Signal (w/ U2K/U2L) K BLK/WHT 372 Remote Playback Device Common Audio Signal (w/ U2K/U2L) L ORN/BLK 2061 Cellular Telephone Voice Low Reference M PNK/BLK 2062 Cellular Telephone Voice Signal
Rear Seat Audio (RSA) Controller Terminal Identification Connector Part Information 12110206 24-Way F Micro-Pack 100 Series (LT BLU) Pin Wire Color Circuit No. Function A1 LT BLU 2288 RSA Class 2 Serial Data A2 ORN 340 Battery Positive Voltage A3 - - Not Used A4 BLK/WHT 1851 Ground A5 BARE 2099 Drain Wire (Except Y91) A6 DK GRN/WHT 1547 Left Rear Low Level Audio Signal (-) A7 BLK 1946 Right Rear Low Level Audio Signal (-) A8 DK GRN/WHT 1547 Left Rear Low Level Audio Signal (-) (Except Y91) A9 BLK 1946 Right Rear Low Level Audio Signal (-) (Except Y91) A10-A12 - - Not Used B1-B4 - - Not Used B5 BARE 2099 Drain Wire (Except Y91) B6 BRN 599 Left Rear Low Level Audio Signal (+) B7 DK BLU 546 Right Rear Low Level Audio Signal (+) B8 BRN 599 Left Rear Low Level Audio Signal (+) (Except Y91) B9 DK BLU 546 Right Rear Low Level Audio Signal (+) (Except Y91) B10-B12 - - Not Used
Rear Seat Entertainment (RSE) Assembly Terminal Identification Connector Part Information 15341086 12-Way F Multi-Lock Series (BLK) Pin Wire Color Circuit No. Function 1 - - Not Used 2 LT GRN/BLK 1098 VCM Class 2 Serial Data 3-4 - - Not Used 5 DK GRN/WHT 368 Remote Playback Device Right Audio Signal 6 BRN/WHT 367 Remote Playback Device Left Audio Signal 7 BLK/WHT 1851 Ground 8 - - Not Used 9 ORN 3240 Battery Positive Voltage 10-11 - - Not Used 12 BLK/WHT 372 Remote Playback Device Common Audio Signal
Remote Playback Device - CD Player Terminal Identification Connector Part Information 12064980 9-Way F Micro-Pack 100 Series (BLK) Pin Wire Color Circuit No. Function 7 - - Not Used 8 BRN/WHT 230 Instrument Panel Lamps Dimming Control 9 - - Not Used 10 DK GRN/WHT 368 Remote Playback Device Right Audio Signal 11 BRN/WHT 367 Remote Playback Device Left Audio Signal 12 BLK/WHT 372 Remote Playback Device Common Audio Signal 13 BLK/WHT 1851 Ground 14 TAN 5072 Remote Playback Device Class 2 Serial Data 15 ORN 3240 Battery Positive Voltage
Speaker - LF Door (RPO Code UQ5) Terminal Identification Connector Part Information 12186847 2-Way F Metri-Pack 150 Series (NAT) Pin Wire Color Circuit No. Function A GRY 118 Left Front Speaker Output (-) B TAN 201 Left Front Speaker Output (+)
Speaker - LF Door (RPO Code UQ3/UQ7) Terminal Identification Connector Part Information 15433787 2-Way F Metri-Pack 150 Series (NAT) Pin Wire Color Circuit No. Function A GRY 118 Left Front Speaker Output (-) B TAN 201 Left Front Speaker Output (+)
Speaker - RF Door (RPO Code UQ5) Terminal Identification Connector Part Information 12186847 2-Way F Metri-Pack 150 Series (NAT) Pin Wire Color Circuit No. Function A DK GRN 117 Right Front Speaker Output (-) B LT GRN 200 Right Front Speaker Output (+)
Speaker - RF Door (RPO Code UQ3/UQ7) Terminal Identification Connector Part Information 15433787 2-Way F Metri-Pack 150 Series (NAT) Pin Wire Color Circuit No. Function A DK GRN 117 Right Front Speaker Output (-) B LT GRN 200 Right Front Speaker Output (+)
Speaker - LR - Except Crew Cab Terminal Identification Connector Part Information 12052832 2-Way F Metri-Pack 150 Series (BLK) Pin Wire Color Circuit No. Function A YEL 116 Left Rear Speaker Output (-) B BRN 199 Left Rear Speaker Output (+)
Speaker - LR Door - Crew Cab Terminal Identification Connector Part Information 12052832 2-Way F Metri-Pack 150 Series (BLK) Pin Wire Color Circuit No. Function A YEL 116 Left Rear Speaker Output (-) B BRN 199 Left Rear Speaker Output (+)
Speaker - RR - Except Crew Cab Terminal Identification Connector Part Information 12052832 2-Way F Metri-Pack 150 Series (BLK) Pin Wire Color Circuit No. Function A LT BLU 115 Right Rear Speaker Output (-) B DK BLU 46 Right Rear Speaker Output (+)
Speaker - RR Door - Crew Cab Terminal Identification Connector Part Information 12052832 2-Way F Metri-Pack 150 Series (BLK) Pin Wire Color Circuit No. Function A LT BLU 115 Right Rear Speaker Output (-) B DK BLU 46 Right Rear Speaker Output (+)
Speaker - LF Tweeter (RPO Code UQ3) Terminal Identification Connector Part Information 12052832 2-Way F Metri-Pack 150 Series (BLK) Pin Wire Color Circuit No. Function A GRY 118 Left Front Speaker Output (-) B TAN 201 Left Front Speaker Output (+)
Speaker - LF Tweeter (RPO Code UQ7) Terminal Identification Connector Part Information 12110131 2-Way F Metri-Pack 150 Series (NAT) Pin Wire Color Circuit No. Function A GRY 118 Left Front Speaker Output (-) GRY 118 Left Front Speaker Output (-) B TAN 201 Left Front Speaker Output (+) TAN 201 Left Front Speaker Output (+)
Speaker - RF Tweeter (RPO Code UQ3) Terminal Identification Connector Part Information 12052832 2-Way F Metri-Pack 150 Series (BLK) Pin Wire Color Circuit No. Function A DK GRN 117 Right Front Speaker Output (-) B LT GRN 200 Right Front Speaker Output (+)
Speaker - RF Tweeter (RPO Code UQ7) Terminal Identification Connector Part Information 12110131 2-Way F Metri-Pack 150 Series (NAT) Pin Wire Color Circuit No. Function A DK GRN 117 Right Front Speaker Output (-) DK GRN 117 Right Front Speaker Output (-) B LT GRN 200 Right Front Speaker Output (+) LT GRN 200 Right Front Speaker Output (+)
Speaker - Subwoofer (RPO Code UQ7) Terminal Identification Connector Part Information 12064760 4-Way F Metri-Pack 150 Series (BLK) Pin Wire Color Circuit No. Function A LT GRN/BLK 1794 Left Subwoofer Speaker Output (-) B DK BLU/WHT 346 Left Subwoofer Speaker Output (+) C DK GRN 1795 Right Subwoofer Speaker Output (+) D LT BLU/BLK 315 Right Subwoofer Speaker Output (-)
Splice Pack SP250 (RPO Code UQ7) Terminal Identification Connector Part Information 12176473 12-Way F Metri-Pack 280 Series Splice Saver(BLK) Pin Wire Color Circuit No. Function A BRN/WHT 367 Remote Playback Device Left Audio Signal B BRN/WHT 367 Remote Playback Device Left Audio Signal C BRN/WHT 367 Remote Playback Device Left Audio Signal D BLK/WHT 372 Remote Playback Device Common Audio Signal E BLK/WHT 372 Remote Playback Device Common Audio Signal F BLK/WHT 372 Remote Playback Device Common Audio Signal G DK GRN/WHT 368 Remote Playback Device Right Audio Signal H DK GRN/WHT 368 Remote Playback Device Right Audio Signal J DK GRN/WHT 368 Remote Playback Device Right Audio Signal K BARE 1573 Drain Wire L BARE 1573 Drain Wire M BARE 1573 Drain Wire
Steering Wheel Audio Controls - Left (RPO Code YE9) Terminal Identification Connector Part Information 50-57-9405 5-Way F (BLK) Pin Wire Color Circuit No. Function 1 LT GRN 1011 2283 Remote Radio Control Signal 2 BRN 230 Instrument Panel Lamps Dimming Control 3 BLK 2250 Ground 4 - - Not Used 5 LT GRN 1011 Remote Radio Control Signal
Steering Wheel Audio Controls - Right (RPO Code YE9) Terminal Identification Connector Part Information 50-57-9406 6-Way F (BLK) Pin Wire Color Circuit No. Function 1 WHT 2283 12-Volt Reference 2 LT GRN 1011 Remote Radio Control Signal 3 BRN 230 Instrument Panel Lamps Dimming Control 4 - - Not Used 5 BLK 2250 Ground 6 LT GRN 1101 Remote Radio Control Signal
Steering Wheel Driver Information Center (DIC) Controls - Left (RPO Code YE9) Terminal Identification Connector Part Information 50-57-9404 4-Way F (BLK) Pin Wire Color Circuit No. Function 1 BRN 230 Instrument Panel Lamps Dimming Control 2 YEL 1327 Fuel Signal 3 DK BLU 894 Trip Signal 4 BLK 2250 Ground
Steering Wheel Driver Information Center (DIC) Controls - Right (RPO Code YE9) Terminal Identification Connector Part Information 50-57-9405 5-Way F (BLK) Pin Wire Color Circuit No. Function 1 BRN 230 Instrument Panel Lamps Dimming Control 2 DK GRN 1358 Personalization Signal 3 ORN 1816 Select Signal 4 BLK 2250 Ground 5 - - Not Used
