- Lubricate rotors with engine oil and install in pump cover with same orientation as when removed. Install pressure relief valve seat, spring and pilot in pump housing. Pack housing with petroleum jelly to ensure pump priming.
- Assemble housing and cover over locating dowel. Insert 3/8" (9.5 mm) drill bit into pump mounting hole, on side opposite dowel, to aid alignment of housing and cover. Install 2 screws and tighten to 106 INCH lbs. (12 N.m).
- Install oil pump drive spacer into oil pump from rear so drive flat engages pump rotor. Position pump over crankshaft. Loosely install screws. Hold pump in its furthest up position while tightening screws. Tighten screws to specification. See «TORQUE SPECIFICATIONS»(ref-1392-S09285118392000031300000) table. To complete installation, reverse removal procedure.
