- Install spark plug and camshaft cover seals as required. Insert intake camshaft through hole in camshaft cover and, using fingers, guide camshaft cover up over edge of cylinder head. (Scheme 3) Use care to prevent exposed section of camshaft cover seal from being damaged by edge of cylinder head casting. Work cover into position by allowing top edge of cover to follow left edge of intake manifold.
- Install camshaft cover screws and tighten to specification. See «TORQUE SPECIFICATIONS»(ref-1392-S09285118392000031300000) table. To complete installation, reverse removal procedure. Ensure correct spark plug wire routing. Install water pump pulley, using Pulley Installer (J-38823). Tighten all fasteners to specification. See «TORQUE SPECIFICATIONS»(ref-1392-S09285118392000031300000) table.
