Engine Mechanical - 3.6l (Lfx) - Special Tools and Equipment

Engine Mechanical - 3.6l (Lfx) - Special Tools and Equipment Cadillac ATS I

Mechanical 44 illustrations ~798 words

Illustration Tool Number/Description CH 25033-C J 25033-C Pulley Installer CH 25034-C J 25034-C Pulley Remover CH 45722 J 45722 Fuel Sender Lock Ring Wrench CH 48027 DW 100-010 EN 49495 J 21867 Digital Pressure Gauge South America Use Local Equivalent CH 48482 Fuel Sender Lock Ring Wrench DT 5590 J 5590 J 24254 Bearing and Seal Driver DT 23129 J 23129 KM 586 Universal Seal Remover DW 110-030 Engine Overhaul Stand EN 8037 J 8037 Ring Compressor South America Use Local Equivalent EN 8062 J 8062 7-0006798 Valve Spring Compressor - Head Off EN 8087 J 8087 Cylinder Bore Gauge South America Use Local Equivalent EN 21867-6 J 21867-6 83 93 852 Oil Pressure Adapter Fitting South America Use Local Equivalent EN 22738-B J 22738-B Valve Spring Tester South America Use Local Equivalent EN 24254-A J 24254-A J 24254 Oil Seal Installer EN 28410 J 28410 Gasket Remover South America Use Local Equivalent EN 28467-B DW 110-060 J 28467-B X-0206951 L-0906004 Universal Engine Support Fixture EN 28467-501 J 28467-501 Engine Support Fixture Adapters EN 29184 EN 47635 & J 41998-B EN 47635 J 29184 V-0506019 Oil Seal Installer EN 35667-A J 35667-A Cylinder Head Leakdown Tester South America Use Local Equivalent EN 36462-A J 36462-A X-0206951 L-0906004 Engine Support Adapter Leg EN 36857 J 36857 Engine Lift Bracket EN 38416-2 J 38416-2 6-9806636 Crankshaft Button EN 39313 J 39313 V-0506023 Spark Plug Port Adapter EN 41712 J 41712 Oil Pressure Switch Socket South America Use Local Equivalent EN 41816 J 41816 6-9806636 Crankshaft Balancer Remover EN 41998-B J 41998-B J 41998 Crankshaft Balancer Installer South America Use Local Equivalent EN 42096 Valve Guide Reamer EN 42183 J 42183 M-840911-A Driver Handle EN 42385-700 J 42385-700 High Feature Thread Repair Kit South America Use Local Equivalent EN 42385-2000 J 42385-2000 Thread Insert Kit South America Use Local Equivalent EN 43690-A J 43690-A Rod Bearing Clearance Checking Tool South America Use Local Equivalent EN 43965 J 43965 Thread Repair Extension Kit South America Use Local Equivalent EN 45000 J 45000 KM J 45000 87 91 360 Seal Remover South America Use Local Equivalent EN 45027 J 45027 Tensioner Tool South America Use Local Equivalent EN 45059 J 45059 KM 470-B Angle Meter South America Use Local Equivalent EN 45299 J 45299 Engine Preluber South America Use Local Equivalent EN 46101 J 46101 Spark Plug Tube Seal Guide EN 46103 J 46103 Camshaft Actuator Valve Seal Installer EN 46104 J 46104 V-0506022 Water Pump Pulley Holding Tool EN 46106 EN-50638 J 46106 KM 652 Flywheel Holding Tool EN 46109 J 46109 V-0506033 Guide Pins EN 46110 EN 46110-EU J 46110-EU On-Vehicle Valve Spring Compressor South America Use Local Equivalent EN 46112 Tensioner Retraction Pins South America Use Local Equivalent EN 46114 Engine Lift Brackets EN 46116 KM 840 (Remover)/EN 47986 (Installer) 83 94 157 V-0506032 Valve Stem Seal Remover/Installer EN 46117 Valve Stem Key Remover/Installer South America Use Local Equivalent EN 46119 V-0506034 Off-Vehicle Valve Spring Compressor Adapter EN 46121 V-0506030 Connecting Rod Guide Pin Set EN 46122 Camshaft Position Actuator Check-Ball Valve Remover/Installer South America Use Local Equivalent EN 46745 J 43654 Piston Pin Clip Remover/Installer South America Use Local Equivalent EN 47839 V-0506024 Crankshaft Rear Oil Seal Installation Tool EN 47971 J 42907 Oil Pressure Gauge Adapter EN 48243 Engine Assembly Remove/Install Pallet EN 48244 Engine Assembly Remove/Install Pallet Supporter EN 48313 Timing Chain Retention Tool EN 48383 Camshaft Retaining Tool EN 48589-A EN 48589 Crankshaft Rotation Socket EN 48896 HP Fuel Pump Installation Alignment Gauge EN 49102 J 41818 & EN 47985 V-0506025 Crankshaft Bearing Cap Remover EN 49245 EN-48266 and EN-49245-1 Injector Seal Installer Kit EN 49247 Injector Retaining Clip Installer EN 49248 Injector Rail Assembly Remover EN 49982 Timing Chain Retainer EN 50789 Oil Pressure Adapter Fitting GE 6125-1B J 6125-1B KM J 7004 M-680770 Slide Hammer Adapter GE 7872 J 7872 Magnetic Base Dial Indicator South America Use Local Equivalent GE 8001 J 8001 Dial Indicator Set South America Use Local Equivalent GE 28428-E J 28428-E High Intensity Black Light Kit South America Use Local Equivalent GE 48326 Sealant Dispenser GE 8358 J 8358 Carbon Removal Brush South America Use Local Equivalent J 38416-B Crankshaft Balancer Remover
