Engine and Gearbox Suspension - Repair (n52) BMW X5 E70

Mechanical 11 illustrations ~810 words

22 11 001 Replacing Right Engine Mount (N52K)

Necessary preliminary tasks

  1. Secure engine. Refer to «11 00 670 SECURING ENGINE IN INSTALLATION POSITION (N62)»(/bmw/x5/e70-2006-2010/remont/mechanical/#engine-repair-n62__11-00-670-securing-engine-in) in installation position
  2. Remove reinforcement plate. Refer to «31 10 010 REMOVING AND INSTALLING/REPLACING REINFORCEMENT PLATE»(/bmw/x5/e70-2006-2010/remont/axle-shafts/#front-axle-repair__31-10-010-removing-and-installingreplacing)
  3. Remove heat shields.
  4. Remove engine support arm. Refer to «22 11 100 Replacing Right Engine Support Arm (N52K)»(/bmw/x5/e70-2006-2010/remont/mechanical/#engine-and-gearbox-suspension-repair-n52__22-11-100-replacing-right-engine) .

Release screws (1) and remove engine mount (2).

Tightening torque 22 11 1AZ. Refer to 22 11 ENGINE SUSPENSION .

Scheme 757

Scheme 757
Scheme 757

Installation

Holes (1) in engine mount must point to middle of vehicle.

Scheme 758

Scheme 758
Scheme 758

22 11 011 Replacing Left Engine Mount (N52K)

Necessary preliminary tasks

  1. Secure engine. Refer to «11 00 670 SECURING ENGINE IN INSTALLATION POSITION (N62)»(/bmw/x5/e70-2006-2010/remont/mechanical/#engine-repair-n62__11-00-670-securing-engine-in) in installation position
  2. Remove reinforcement plate. Refer to «31 10 010 REMOVING AND INSTALLING/REPLACING REINFORCEMENT PLATE»(/bmw/x5/e70-2006-2010/remont/axle-shafts/#front-axle-repair__31-10-010-removing-and-installingreplacing)
  3. Remove engine support arm. Refer to «22 11 100 Replacing Right Engine Support Arm (N52K)»(/bmw/x5/e70-2006-2010/remont/mechanical/#engine-and-gearbox-suspension-repair-n52__22-11-100-replacing-right-engine) .

Release screws (1) and remove engine mount (2).

Tightening torque 22 11 1AZ. Refer to 22 11 ENGINE SUSPENSION .

Scheme 759

Scheme 759
Scheme 759

Installation

Holes (1) in engine mount must point to middle of vehicle.

22 11 100 Replacing Right Engine Support Arm (N52K)

Necessary preliminary tasks

  1. Secure engine. Refer to «11 00 670 SECURING ENGINE IN INSTALLATION POSITION (N62)»(/bmw/x5/e70-2006-2010/remont/mechanical/#engine-repair-n62__11-00-670-securing-engine-in) in installation position
  2. Remove reinforcement plate. Refer to «31 10 010 REMOVING AND INSTALLING/REPLACING REINFORCEMENT PLATE»(/bmw/x5/e70-2006-2010/remont/axle-shafts/#front-axle-repair__31-10-010-removing-and-installingreplacing)
  3. Remove heat shields

Release screws and engine support arm.

Tightening torque 22 11 3AZ. Refer to 22 11 ENGINE SUSPENSION .

Scheme 760

Scheme 760
Scheme 760

22 11 110 Replacing Left Engine Support Arm (N52K)

Necessary preliminary tasks

  1. Secure engine «11 00 670 SECURING ENGINE IN INSTALLATION POSITION (N62)»(/bmw/x5/e70-2006-2010/remont/mechanical/#engine-repair-n62__11-00-670-securing-engine-in) . Refer to in installation position
  2. Remove reinforcement plate. Refer to «31 10 010 REMOVING AND INSTALLING/REPLACING REINFORCEMENT PLATE»(/bmw/x5/e70-2006-2010/remont/axle-shafts/#front-axle-repair__31-10-010-removing-and-installingreplacing)
  3. Remove upper section of microfilter housing. Refer to «64 31 081 REMOVING AND INSTALLING/REPLACING MICROFILTER HOUSING»(/bmw/x5/e70-2006-2010/remont/automatic-hvac-system/#heating-and-air-conditioning-repair__64-31-081-removing-and-installingreplacing)
  4. Remove heat shields
  5. Remove manifold.
  6. Remove air ducts

Release screw (1).

Release bracket (2) with oil line.

Release screws and engine support arm.

Tightening torque 22 11 3AZ. Refer to 22 11 ENGINE SUSPENSION .

Scheme 761

Scheme 761
Scheme 761

22 32 001 Replacing Rubber Mount For Transmission Mounting

Special Tools Required

  1. 22 1 016 «22 1 010 SET OF TOOLS»(/bmw/x5/e70-2006-2010/remont/mechanical/#engine-and-gearbox-suspension-special-tools-n52-n62)
  2. 22 1 017 «22 1 010 SET OF TOOLS»(/bmw/x5/e70-2006-2010/remont/mechanical/#engine-and-gearbox-suspension-special-tools-n52-n62)
  3. 22 1 101 «22 1 100 FIXTURE»(/bmw/x5/e70-2006-2010/remont/mechanical/#engine-and-gearbox-suspension-special-tools-n52-n62)
  4. 22 1 102 «22 1 100 FIXTURE»(/bmw/x5/e70-2006-2010/remont/mechanical/#engine-and-gearbox-suspension-special-tools-n52-n62)
  5. 22 1 103 «22 1 100 FIXTURE»(/bmw/x5/e70-2006-2010/remont/mechanical/#engine-and-gearbox-suspension-special-tools-n52-n62)
  6. 33 4 465 «33 4 460 SET OF TOOLS»(/bmw/x5/e70-2006-2010/remont/axle-shafts/#rear-axle-special-tools)

Necessary preliminary tasks

  1. Remove cross-member. Refer to for transmission mounting «22 32 050 Replacing Cross-Member For Transmission Mounting»(/bmw/x5/e70-2006-2010/remont/mechanical/#engine-and-gearbox-suspension-repair-n52__22-32-050-replacing-cross-member-for)

Place special tool 22 1 016. Refer to 22 1 010 SET OF TOOLS on opening (1) and insert screw (2) until hand-tight against housing.

Pull out rubber mount with special tools 22 1 101/ 33 4 465. Refer to 22 1 010 SET OF TOOLS and nut (22 1 017) 22 1 010 SET OF TOOLS .

Scheme 762

Scheme 762
Scheme 762

Installation

Arrow on rubber mount must point to arrow on housing.

Coat housing bore and rubber mount with Circolight, refer to BMW Parts Service.

Scheme 763

Scheme 763
Scheme 763

Insert special tool 22 1 102 with pins into openings of rubber mount. Refer to 22 1 010 SET OF TOOLS

Scheme 764

Scheme 764
Scheme 764

Install rubber mount with special tools 22 1 102/22 1 103/33 4 465 and 22 1 017. Refer to 22 1 010 SET OF TOOLS .

Scheme 765

Scheme 765
Scheme 765

22 32 050 Replacing Cross-Member For Transmission Mounting

Special Tools Required

Supporting Transmission

Support with special tools 23 4 050, 23 0 132 and 00 2 030 00 2 030 UNIVERSAL HYDRO-LIFTER BASIC UNIT .

Secure transmission with tensioning strap (1).

Tasks are described in TRANSMISSION BRACKET .

Scheme 766

Scheme 766: 22 32 050 Replacing Cross-Member For Transmission Mounting
Scheme 766: 22 32 050 Replacing Cross-Member For Transmission Mounting

Release screws.

Tightening torque 22 32 4AZ 22 32 TRANSMISSION MOUNTS .

Release screw (1).

Tightening torque 22 32 5AZ 22 32 TRANSMISSION MOUNTS .

Remove cross-member.

Scheme 767

Scheme 767
Scheme 767
  1. 00 2 030 «00 2 030 UNIVERSAL HYDRO-LIFTER BASIC UNIT»(/bmw/x5/e70-2006-2010/remont/oem-general-information/#maintenance-and-general-information-special-tools__00-2-030-universal-hydro-lifter-basic)
  2. 23 0 132 «23 TRANSMISSION DESIGNATIONS»(/bmw/x5/e70-2006-2010/remont/automatic-trans/#automatic-transmission-repair__23-transmission-designations)
  3. 23 4 050 «23 .. UNIVERSAL TRANSMISSION BRACKET»(/bmw/x5/e70-2006-2010/remont/automatic-trans/#automatic-transmission-repair__23-universal-transmission-bracket)

Necessary preliminary tasks

  1. Remove underbody protection «51 47 491 REMOVING AND INSTALLING/REPLACING REAR UNDERBODY PROTECTION»(/bmw/x5/e70-2006-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-47-491-removing-and-installingreplacing)
  2. Remove heat shields
  3. Remove exhaust system «18 00 020 REMOVING AND INSTALLING COMPLETE EXHAUST SYSTEM (N62TU)»(/bmw/x5/e70-2006-2010/remont/exhaust/#exhaust-repair-n52__18-00-020-removing-and-installing) .
