Engine- Special Tools BMW X5 E70

Mechanical 25 illustrations ~1851 words

11 0 000 Engine Lifter For Removing And Installing Engines

Minimum set: Mechanical tools

Engine: M10, M47T2, M47TU, M52, M52TU, M54, M56, M60, M62, M67, M70, M73, N52, N62, N62TU, N73, S14, S54, S62, W10, W11

SI number: 1 13 94 (888)

Order number: 11 0 000

Engine lifter for removing and installing engines

Consisting of

1 = 11 0 001 Lifting beam

2 = 11 0 002 Chain, long

3 = 11 0 003 Chain, short

4 = 11 0 009 Shackle (2 x)

Scheme 770

Scheme 770: 11 0 000 Engine Lifter For Removing And Installing Engines

11 0 020 Engine Hoist For Removing And Installing Engines

Minimum set: Mechanical tools

Engine: M20, M20B25, M20B27, M21, M30, M30B34, M30Tur, M47T2, M47TU, M50, M51, M52, M54, M57, M57D25, M57D30, M57T2, M57TU, N52, N62, N62TU, N73, S38, S50B30, S50B32, S50US, S85

SI number: 1 13 94 (888)

Order number: 11 0 020

Engine hoist for removing and installing engines

Consisting of

1 = 11 0 021 Lifting beam

2 = 11 0 022 Chain, medium

3 = 11 0 023 Chain, long

4 = 11 0 024 Chain, short

5 = 11 0 029 Shackle (2 x)

Scheme 771

Scheme 771: 11 0 020 Engine Hoist For Removing And Installing Engines

11 0 240 Coupling

In conjunction with: 11 0 222, 11 0 226, 11 0 227, 11 0 225

Note. For adapting test probes to pressure gauge 11 0 162

Engine: All models

Order number: 11 0 240

Coupling

Scheme 772

Scheme 772: 11 0 240 Coupling

11 0 320 Removal and Installation Bracket

Note. For removing and installing piston pin circlips.

Engine: N51, N52, N52K, N53, N54

Storage location: B51

SI number: 1 17 04 (130)

Order number: 11 0 320

Removal and installation bracket

11 1 310 Drift

Note. For driving needle bearing out of crankcase (M20) and pressing out propeller shaft centring mount

Series: E28, E30, E38, E39, E46, E52, E65, E66, E70, E81, E85, E87, E90, E91, E92, RR1

Order number: 11 1 310

Drift

Scheme 773

Scheme 773: 11 1 310 Drift

11 2 000 Puller

Minimum set: Mechanical tools

Note. For crankshaft sprocket

Engine: M10, M30, M50, M52, M60, M62, M70, M73, N62TU, N73, S14, S38, W10, W11

Storage location: B9, C42

Order number: 11 2 000

Puller

Consisting of

1 = 11 2 001 Bell housing

2 = 11 2 002 Plate

Note. Engine: M10, M30, S14, S38, N73

3 = 11 2 003 Spindle

Note. Engine: M10, M30, M70, M73, S14, S38, N73

4 = 11 2 004 Plate

Note. Engine: M50, M52, M60, M62

5 = 11 2 005 Spindle 165 mm

Note. Engine: M50, M52, M60, M62

6 = 11 2 006 Plate

Note. Engine: M70, M73, N73

7 = 11 2 007 Thrust piece

Note. Engine: N73

Scheme 774

Scheme 774: 11 2 000 Puller

Minimum set: Mechanical tools

In conjunction with: 00 5 500

Note. For driving the guide bearing into the crankshaft (S14, S38, M10, M20, M21, M30, M40, M42, M50, M51 M52) and driving the centring support into the propeller shaft

Series: E28, E30, E32, E34, E36, E38, E39, E46, E52, E65, E66, E70, E81, E85, E87, E90, E92, RR1

Storage location: A28

Order number: 11 2 030

Drift

Scheme 775

Scheme 775: Minimum set: Mechanical tools

11 3 460 Protractor

Minimum set: Mechanical tools

In conjunction with: 11 2 450

Note. For fitting on brace 11 2 450 when tightening central bolt using torsion angle tightening method

Engine: M60, M62, M73, N62, N62TU, N73

Storage location: C10

SI number: 1 08 92 (555)

Order number: 11 3 460

Protractor

Scheme 776

Scheme 776: 11 3 460 Protractor

In conjunction with: 11 3 390, 00 2 050

Note. M73 For removing and installing pedal travel sensor M60 Pretensioning timing chain E53 Mounting airbag control unit

Series: All models

Storage location: B6

SI number: 1 06 94(801)

Order number: 11 4 190

1/4" extension piece

Scheme 777

Scheme 777: Minimum set: Mechanical tools

Note. For removing and installing cylinder head.

Engine: N51, N52, N52K, N53, N54

Storage location: A51

SI number: 1 17 04 (130)

Order number: 11 4 420 Torx socket T50

11 4 430 Seal plugs (2 x)

Note. For sealing off oil holes in oil pump.

Engine: N51, N52, N52K, N53, N54

Storage location: A52

SI number: 1 17 04 (130)

Order number: 11 4 430 Seal plugs (2 x)

Note. For cleaning sealing surfaces on magnesium crankcase/cylinder head.

Engine: N43, N45T, N46T, N47, N51, N52, N52K, N53, N54

SI number: 1 17 04 (130)

Order number: 11 4 470 Cleaning kit

Consisting of: 1 = 11 4 471 Scraper 2 = 11 4 472 Grindstone

11 5 461 Installation Holder

Order number: 11 5 461

Installation holder

Scheme 778

Scheme 778: 11 5 461 Installation Holder

11 5 462 Installation Pliers

Order number: 11 5 462

Installation pliers

11 5 463 Installation Drift

Order number: 11 5 463

Installation drift

11 5 464 Removal Pliers

Order number: 11 5 464

Removal pliers

11 4 490 Removal And Installation Kit

Note. For removing and installing piston pin circlips

Engine: M57T2, N43, N45T, N46T, N51, N52, N53, N54, N62TU

SI number: 1 17 04 (130)

Order number: 11 4 490

Removal and installation kit

Consisting of

1 = 11 4 491 Mounting holder

2 = 11 4 492 Removal pliers

3 = 11 4 493 Mounting pliers

4 = 11 4 494 Drift

Scheme 779

Scheme 779: 11 4 490 Removal And Installation Kit

11 5 430 Piston Ring Pliers

Note. Diameter 93 mm N62TU B48 engine

Engine: N62TU

Storage location: A20, B20

Order number: 11 5 430

Piston ring pliers

Scheme 780

Scheme 780: 11 5 430 Piston Ring Pliers

11 5 450 Mounting Sleeve

Note. For installing piston (dia. 87 mm) with connecting rod. Engine: M67TU" N62TU B40"

Engine: M67TU, N62TU

SI number: 1 14 05 (198)

Order number: 11 5 450

Mounting sleeve

Scheme 781

Scheme 781: 11 5 450 Mounting Sleeve

Order number: 11 5 461

Installation holder

Order number: 11 5 462

Installation pliers

Order number: 11 5 463

Installation drift

11 5 464 Installation Pliers

Order number: 11 5 464

Installation pliers

11 7 030 Socket Wrench Socket WAF 22

Minimum set: Mechanical tools

In conjunction with: 11 9 150

Note. For loosening and tightening oxygen sensor

Engine: M40, M43, M43TU, M44, M52, M52TU, M54, M56, M62, N40, N42, N45, N46, N53, N54, N62, N62TU, N73, S54, S62, S85

Storage location: B15

SI number: 1 06 95 (963)

Order number: 11 7 030

Socket wrench socket WAF 22

Scheme 782

Scheme 782: 11 7 030 Socket Wrench Socket WAF 22

In conjunction with: 11 9 150

Note. For removing and installing cylinder head (outside dia. 13.5 mm).

Engine: N52K, N53, N54

Storage location: A20, B20

SI number: 1 20 06 (299)

Order number: 11 8 580

Wrench socket Torx T60

Scheme 783

Scheme 783: Minimum set: Mechanical tools

11 9 000 Cylinder Head Expander Tool

Minimum set: Mechanical tools

In conjunction with: Assembly stand 00 1 450

Engine: M10, M20, M20B25, M20B27, M21, M30, M30B34, M30Tur, M40, M41, M42, M43, M43TU, M44, M47, M47TU, M50, M51, M52, M52TU, M54, M56, M57, M57D25, M57D30, M57T2, M57TU, M60, M62, M62VAN, M67, M70, M73, M88, N12, N14, N40, N42, N45, N46, N51, N52, N53, N54, N62, N62TU, N73, S14, S38, S50B30, S50B32, S50US, S52US, S54, S62, S85, W10, W11, W17

Storage location: Single

SI number: 1 03 02 (833)

Order number: 11 9 000

Cylinder head expander tool

Consisting of

1 = 11 9 001 Fixture

2 = 11 9 002 Rod

3 = 11 9 003 Sliding block with M10 thread

4 = 11 9 004 Tab

5 = 11 9 005 Quick tensioner

6 = 11 9 006 Aluminium profile insert

7 = 11 9 007 Slide

8 = 11 9 008 Profile plastic part

9 = 11 9 009 Lever

10 = 11 9 011 Hook

11 = 11 9 012 Valve spring cage

Note. Engine M41, M51, S50

12 = 11 9 013 Valve spring cage

Note. Engine M43, M73

13 = 11 9 014 Valve spring cage

Note. Engine M44, M52, M54, M56, M62, S52, S54, S62

14 = 11 9 015 Valve spring cage

Note. Engine M47, M47TU, M57, M57TU, N40, N42, N62, N73

15 = 11 9 016 Valve spring cage

Note. Engine M21, M40

16 = 11 8 421 Valve spring cage

Note. Engine: W10, W11, W17

17 = 11 9 017 Valve spring cage

Note. Engine N52

Scheme 784

Scheme 784: 11 9 000 Cylinder Head Expander Tool

11 9 150 Special Wrench

Minimum set: Mechanical tools

In conjunction with: 11 7 030

Note. For releasing and tightening down oxygen sensors

Engine: M54, M56, N12, N14, N42, N45, N46, N53, N54, N62, N62TU, N73, S54, S85

Storage location: A42

SI number: 01 15 00 (609)

Order number: 11 9 150

Special wrench

Scheme 785

Scheme 785: 11 9 150 Special Wrench

11 9 190 Plug Mandrel

Minimum set: Mechanical tools

Note. For locking flywheel in TDC position

Engine: N40, N42, N62, N62TU, N73

Storage location: B43

SI number: 1 01 01(662)

Order number: 11 9 190

Plug mandrel

Scheme 786

Scheme 786: 11 9 190 Plug Mandrel

11 9 410 Puller

Minimum set: Mechanical tools

Note. For pulling radial seal out of engine block at front

Engine: N62, N62TU, N73

Storage location: A45

SI number: 1 14 01(766)

Order number: 11 9 410

Puller

Scheme 787

Scheme 787: 11 9 410 Puller

11 9 420 Installer

Minimum set: Mechanical tools

Note. For drawing in radial shaft seal in gearcase cover at bottom

Engine: N62, N62TU, N73

Storage location: C45

SI number: 1 14 01(766)

Order number: 11 9 420

Installer

Scheme 788

Scheme 788: 11 9 420 Installer

11 9 450 Counter Holder W/ Socket & Pointer

Minimum set: Mechanical tools

Note. For gripping crankshaft when releasing/tightening central bolt

Engine: N62, N62TU, N73

Storage location: A45, C42

SI number: 1 14 01 (766)

Order number: 11 9 450

Counter holder w/ socket & pointer

Consisting of

1 = 11 9 451 Lever

2 = 11 9 452 Disk

Note. Height 22.5 mm with hexagon screw

3 = 11 9 453 Pointer

4 = 11 9 454 Socket WAF 27

5 = 11 9 455 Disk

Note. Height 10 mm with hexagon screw

Scheme 789

Scheme 789: 11 9 450 Counter Holder W/ Socket & Pointer

11 9 460 Gauge

Minimum set: Mechanical tools

Note. For locating camshaft in TDC position

Engine: N62, N62TU, N73

Storage location: B45

SI number: 1 14 01 (766)

Order number: 11 9 460

Gauge

Consisting of

1 = 11 9 461 Gauge, inlet camshaft

2 = 11 9 462 Gauge, exhaust camshaft

3 = 11 9 463 Holder with screw

Scheme 790

Scheme 790: 11 9 460 Gauge

11 9 470 Support

Minimum set: Mechanical tools

Note. For installing/removing bearing bracket (Camcarrier)

Engine: N62, N62TU, N73

SI number: 1 14 01(766)

Order number: 11 9 470

Support

Consisting of

1 = 11 9 471 Base plate

2 = 11 9 472 Shaped section

3 = 11 9 473 Knurled nut

4 = 11 9 474 Retaining screws (2 x)

5 = 11 9 475 Guide bushes (2 x)

6 = 11 9 476 Shaped section

Note. Note: For securing inlet camshaft during installation in bearing bridge - Engine: N73

Scheme 791

Scheme 791: 11 9 470 Support

11 9 480 Lever

Minimum set: Mechanical tools

Note. For pretensioning / relieving tension on torsion spring

Engine: N62, N62TU, N73

Storage location: B46

SI number: 1 14 01(766)

Order number: 11 9 480

Lever

Scheme 792

Scheme 792: 11 9 480 Lever

11 9 490 Holding Sleeve

Minimum set: Mechanical tools

Note. For protecting camshaft against damage by torsion spring (1 set = 20 pcs.)

Engine: N62, N62TU, N73

Storage location: C45

SI number: 1 14 01(766)

Order number: 11 9 490

Holding sleeve

Scheme 793

Scheme 793: 11 9 490 Holding Sleeve

11 9 811 Holder

Order number: 11 9 811

Holder

Scheme 794

Scheme 794: 11 9 811 Holder

11 9 812 Screw

Order number: 11 9 812

Screw
